Driver Information System: Removal & Installation Nissan Murano Z50

Communication Devices 7 illustrations ~125 words

INSTALLATION

Installation is the reverse order of removal.

Scheme 51

Scheme 51: Disassembly and Assembly of Combination Meter
Scheme 51: Disassembly and Assembly of Combination Meter

Scheme 52

Scheme 52: DISASSEMBLY
Scheme 52: DISASSEMBLY

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55
  1. Remove screws (2). Disconnect odo/trip meter and illumination control switch and hazard switch connectors and remove meter lid.
  2. Remove screws (3) and remove odo/trip meter and illumination control switch.
  3. Remove screws (2) and remove switch cover.
  4. Remove screws (2) and remove rear cover.
  5. Disengaged the tabs (2) to separate bracket.
  6. Remove bulbs.

REMOVAL

  1. Remove the audio unit. Refer to «REMOVAL AND INSTALLATION OF AUDIO UNIT»(ref-234029-S13733428152006052700000) .
  2. Remove the fixing screws, then remove the unified meter and A/C amp.

Scheme 56

Scheme 56
Scheme 56

Installation is basically the reverse order of removal.

Removal and Installation of Compass

Refer to REMOVAL AND INSTALLATION .

Scheme 57

Scheme 57: Schematic
Scheme 57: Schematic
