APPLICATION ITEM
CONSULT-III performs the following functions via CAN communication with BCM.
| Direct Diagnostic Mode | Description |
|---|---|
| ECU Identification | The BCM part number is displayed. |
| Self Diagnostic Result | Displays the diagnosis results judged by BCM. |
| Data Monitor | The BCM input/output signals are displayed. |
| Active Test | The signals used to activate each device are forcibly supplied from BCM. |
| Work support | Changes the setting for each system function. |
| Configuration | Enables to read and save the vehicle specification. Enables to write the vehicle specification when replacing BCM. |
| CAN Diag Support Mntr | Monitors the reception status of CAN communication viewed from BCM. |
APPLICATION ITEM REFERENCE CHART
SYSTEM APPLICATION
BCM can perform the following functions.
Scheme 31
CONSULT-III performs the following functions via CAN communication with IPDM E/R.
| Direct Diagnostic Mode | Description |
|---|---|
| ECU Identification | The IPDM E/R part number is displayed. |
| Self Diagnostic Result | The IPDM E/R self diagnostic results are displayed. |
| Data Monitor | The IPDM E/R input/output data is displayed in real time. |
| Active Test | The IPDM E/R activates outputs to test components. |
| CAN Diag Support Mntr | The result of transmit/receive diagnosis of CAN communication is displayed. |
APPLICATION ITEM REFERENCE CHART
