Wiper & Washer: Adjustments Nissan Maxima A35

ADJUSTMENT

To adjust the wiper arm stop location, the wiper arm must be removed and installed. Follow the FRONT WIPER ARM removal and installation procedure.

Scheme 5: REMOVAL

Turn wiper switch ON to operate wiper motor and then turn wiper switch OFF (auto stop).
Remove wiper arms. Refer to " «FRONT WIPER ARMS : REMOVAL AND INSTALLATION»(ref-388051-S00872989922011022800000) ".
Remove hood ledge covers.
Remove the cowl top grille. Refer to " «EXPLODED VIEW»(ref-388049-S02200598192011022800000) ".
Disconnect washer hose from the lower cowl top extension brace.
Remove the lower cowl top extension brace. Refer to " «REMOVAL AND INSTALLATION»(ref-388049-S31424973292011022800000) ".
Detach the wiper drive harness clip from the wiper drive assembly frame.
Remove the front wiper drive assembly bolts (A), disconnect the wiper drive motor connector (B) and remove the front wiper drive assembly (1).
