DESCRIPTION
With ignition switch in OFF or ACC position, driver door open, and lighting switch in 1ST or 2ND position, the light warning chime will sound.
- BCM detects ignition switch in OFF or ACC position, front door switch LH ON, and lighting switch in 1ST or 2ND position and then transmits buzzer output signal (light reminder warning chime) to combination meter with CAN communication line.
- When combination meter receives buzzer output signal (light reminder warning chime), it sounds the buzzer.
WARNING OPERATION CONDITIONS
If all of the following conditions are fulfilled
- Lighting switch is at 1st or 2nd position
- Ignition switch is at OFF or ACC
- Front door switch LH is ON
LIGHT REMINDER WARNING CHIME : Component Description
| Unit | Description |
|---|---|
| Combination meter | Receives a buzzer output signal from BCM via CAN communication line and sounds the buzzer. |
| BCM | Judges the light warning conditions from the signals provided by various switches and transmits a buzzer output signal to the combination meter via CAN communication line if necessary. |
| Combination switch (lighting and turn signal switch) | Transmits the lighting switch position signal to BCM. |
| Front door switch LH | Transmits the door switch signal to BCM. |
LIGHT REMINDER WARNING CHIME COMPONENT DESCRIPTION
Scheme 56
With ignition switch turned ON and driver seat belt unfastened, seat belt warning chime will sound for approximately 6 seconds.
- BCM receives seat belt buckle switch signal from combination meter with CAN communication line.
- BCM detects ignition switch turned ON and seat belt buckle switch LH ON and then transmits buzzer output signal (seat belt warning chime) to combination meter with CAN communication line.
- When combination meter receives buzzer output signal (seat belt warning chime), it sounds the buzzer.
If all of the following conditions are fulfilled
- Ignition switch OFF-->ON
- Seat buckle switch LH is ON (driver seat belt not fastened)
SEAT BELT WARNING CHIME : Component Description
| Unit | Description |
|---|---|
| Combination meter | Receives the seat belt buckle switch signal from the seat belt buckle switch and transmits it to BCM via CAN communication line. Receives a buzzer output signal from BCM via CAN communication line and sounds the buzzer. |
| BCM | Judges the seat belt warning condition from the seat belt buckle switch signal received from the combination meter and transmits a buzzer output signal to the combination meter via CAN communication line if necessary. |
| Seat belt buckle switch LH | Transmits seat belt buckle switch signal to combination meter. |
SEAT BELT WARNING CHIME COMPONENT DESCRIPTION
Scheme 57
- The combination meter receives the vehicle speed signal from the ABS actuator and electric unit (control unit) via CAN communication line.
- The combination meter judges whether the parking brake is released using the parking brake switch signal from the parking brake switch, and sounds the warning buzzer if necessary.
If all of the following conditions are fulfilled
- Vehicle speed is approximately 7 km/h (4.3 MPH) or higher
- Parking brake switch ON
PARKING BRAKE RELEASE WARNING CHIME : Component Description
| Unit | Description |
|---|---|
| Combination meter | Judges whether the parking brake is released using the parking brake switch signal from the parking brake switch, and sounds the buzzer if necessary. Receives a vehicle speed signal from ABS actuator and electric unit (control unit) via CAN communication line. |
| ABS actuator and electric unit (control unit) | Transmits the vehicle speed signal to combination meter via CAN communication line. |
| Parking brake switch | Transmits parking brake switch signal to the combination meter. |
PARKING BRAKE RELEASE WARNING CHIME COMPONENT DESCRIPTION
- The buzzer for warning chime system is installed in the combination meter.
- The combination meter sounds the alarm buzzer based on the signals transmitted from various units.
Transmits a seat belt buckle switch signal to the combination meter.
- The parking brake warning buzzer sounds continuously during vehicle travel though the parking brake is released
- The parking brake warning buzzer does not sound at all even though driving the vehicle with the parking brake applied.
Light reminder warning does not sound even though headlamp is illuminated.
- Seat belt warning does not sound even though driver seat belt is not fastened.
- Seat belt warning sounds even though driver seat belt is fastened.
