Work Flow
DETAILED FLOW
- OBTAIN INFORMATION ABOUT SYMPTOM Interview the customer to obtain as much information as possible about the conditions and environment under which the malfunction occurred. GO TO 2
- CHECK SYMPTOM Check the symptom based on the information obtained from the customer. Check to see if any other malfunctions are present. GO TO 3
- CHECK CONSULT-III SELF-DIAGNOSIS RESULTS Connect CONSULT-III and perform "SELF-DIAGNOSIS". Refer to " «CONSULT-III FUNCTION (METER/M&A)»(ref-388063-S39497450112011022800000) ". Are self-diagnosis results normal? YES >> GO TO 4 NO >> Repair or replace the malfunctioning parts, GO TO 5
- NARROW DOWN MALFUNCTIONING PARTS THROUGH SYMPTOM DIAGNOSIS Perform symptom diagnosis and repair or replace the identified malfunctioning parts. GO TO 5
- FINAL CHECK Check that the warning buzzer in the combination meter operates normally. Does it operate normally? YES >> Inspection End. NO >> GO TO 1
Scheme 74
Scheme 75
- The buzzer (1) for warning chime system is installed in the combination meter.
- The buzzer sounds when the combination meter receives a buzzer output signal from each unit.
BCM
BCM receives signals from various units and transmits a buzzer output signal to the combination meter with CAN communication line if it judges that the warning buzzer should be activated.
BCM warning function list
| Warning functions | Signal name |
|---|---|
| Light reminder warning chime | Lighting switch position signal Door switch signal |
| Seat belt warning chime | Seat belt buckle switch signal |
BCM WARNING FUNCTION LIST
Scheme 76
| Unit | Description |
|---|---|
| Combination meter | Judges whether the parking brake is released using the vehicle speed signal and the parking brake switch signal, and sounds the buzzer if necessary. Receives the seat belt buckle switch signal from the seat belt buckle switch and transmits it to BCM with CAN communication line. Receives a buzzer output signal from BCM with CAN communication line. |
| BCM | Transmits signals provided by various units to the combination meter with CAN communication line. |
| ABS actuator and electric unit (control unit) | Transmits the vehicle speed signal to combination meter with CAN communication line. |
| Seat belt buckle switch LH | Transmits a seat belt buckle switch signal to the combination meter. |
| Combination switch (lighting and turn signal switch) | Transmits the lighting switch position signal to BCM. |
| Front door switch LH | Transmits the door switch signal to BCM. |
| Parking brake switch | Transmits parking brake signal to combination meter. |
WARNING CHIME SYSTEM COMPONENT DESCRIPTION
Scheme 77
WARNING CANCEL CONDITIONS
Warning is canceled if any of the following conditions is fulfilled.
- Lighting switch OFF
- Ignition switch ON
- Front door switch LH is OFF
Scheme 78
Cancels the warning if any of the following conditions is fulfilled.
- Ignition switch OFF
- Seat buckle switch LH is OFF (driver seat belt fastened)
- 90 seconds have passed since the start of the warning
Scheme 79
Warning is canceled if any of the following conditions is fulfilled.
- Vehicle speed is approximately 3 km/h (1.9 MPH) or less
- Parking brake switch OFF
Scheme 80
CONSULT-III Function (METER/M&A)
CONSULT-III can display each diagnostic item using the diagnostic test modes shown in following table.
| METER/M&A diagnosis mode | Description |
|---|---|
| SELF DIAGNOSTIC RESULT | Displays combination meter self-diagnosis results. |
| DATA MONITOR | Displays combination meter input/output data in real time. |
| CAN DIAG SUPPORT MNTR | The result of transmit/receive diagnosis of CAN communication can be read. |
METER DIAGNOSIS MODE DESCRIPTION
SELF-DIAG RESULTS
Display Item List
Refer to " DTC INDEX ".
DATA MONITOR
Display Item List
| X: Applicable | |||
|---|---|---|---|
| Display item [Unit] | MAIN SIGNALS | SELECTION FROM MENU | Description |
| SPEED METER [km/h] or [mph] | X | X | Displays the value of vehicle speed signal. |
| SPEED OUTPUT [km/h] or [mph] | X | X | Displays the value of vehicle speed signal, which is transmitted to each unit with CAN communication. |
| ODO OUTPUT | X | Displays the value, which is calculated by vehicle speed signal. | |
| TACHOMETER [RPM] | X | X | Displays the value of engine speed signal, which is input from ECM. |
| FUEL METER [lit.] | X | X | Displays the value, which processes a resistance signal from fuel gauge. |
| W TEMP METER [°C] or [°F] | X | X | Displays the value of engine coolant temperature signal, which is input from ECM. |
| ABS W/L [ON/OFF] | X | Displays [ON/OFF] condition of ABS warning lamp. | |
| VDC/TCS IND [ON/OFF] | X | Displays [ON/OFF] condition of VDC/TCS OFF indicator lamp. | |
| SLIP IND [ON/OFF] | X | Displays [ON/OFF] condition of SLIP indicator lamp. | |
| BRAKE W/L [ON/OFF] | X | Displays [ON/OFF] condition of brake warning lamp.* | |
| DOOR W/L [ON/OFF] | X | Displays [ON/OFF] condition of door warning lamp. | |
| TRUNK/GLAS-H [ON/OFF] | X | Displays [ON/OFF] condition of trunk warning lamp. | |
| HI-BEAM IND [ON/OFF] | X | Displays [ON/OFF] condition of high beam indicator. | |
| TURN IND [ON/OFF] | X | Displays [ON/OFF] condition of turn indicator. | |
| LIGHT IND [ON/OFF] | X | Displays [ON/OFF] condition of light indicator. | |
| OIL W/L [ON/OFF] | X | Displays [ON/OFF] condition of oil pressure warning lamp. | |
| MIL [ON/OFF] | X | Displays [ON/OFF] condition of malfunction indicator lamp. | |
| CRUISE IND [ON/OFF] | X | Displays [ON/OFF] condition of CRUISE indicator. | |
| CVT IND [ON/OFF] | X | Displays [ON/OFF] condition of CVT warning lamp. | |
| FUEL W/L [ON/OFF] | X | Displays [ON/OFF] condition of low-fuel warning lamp. | |
| WASHER W/L [ON/OFF] | X | Displays [ON/OFF] condition of low washer fluid warning lamp. | |
| AIR PRES W/L [ON/OFF] | X | Displays [ON/OFF] condition of tire pressure warning lamp. | |
| KEY G/Y W/L [ON/OFF] | X | Displays [ON/OFF] condition of key warning lamp. | |
| LCD | X | Displays the value of Intelligent Key system message indication. | |
| SHIFT IND [P, R, N, D, L] | X | Displays [P, R, N, D, L] range position of CVT. | |
| M RANGE SW [ON/OFF] | X | Displays [ON/OFF] condition of manual mode range switch. | |
| NM RANGE SW [ON/OFF] | X | Displays [ON/OFF] condition of except for manual mode range switch. | |
| ST SFT UP SW [ON/OFF] | X | Displays [ON/OFF] condition of steering shift-up switch. | |
| ST SFT DWN SW [ON/OFF] | X | Displays [ON/OFF] condition of steering shift-down switch. | |
| AT SFT UP SW [ON/OFF] | X | Displays [ON/OFF] condition of CVT shift-up switch. | |
| AT SFT DWN SW [ON/OFF] | X | Displays [ON/OFF] condition of CVT shift-down switch. | |
| PKB SW [ON/OFF] | X | Displays [ON/OFF] condition of parking brake switch. | |
| BUCKLE SW [ON/OFF] | X | Displays [ON/OFF] condition of seat belt buckle switch LH. | |
| BRAKE OIL SW [ON/OFF] | X | Displays [ON/OFF] condition of brake fluid level switch. | |
| MODE A SW [ON/OFF] | X | Displays [ON/OFF] condition of mode switch A. | |
| MODE B SW [ON/OFF] | X | Displays [ON/OFF] condition of mode switch B. | |
| DISTANCE [km] or [mile] | X | Displays the value, which is calculated by vehicle speed signal, fuel gauge and fuel consumption from ECM. | |
| OUTSIDE TEMP [°C] | X | Displays the ambient air temperature, which is input from ambient sensor. | |
| FUEL LOW SIG [ON/FF] | X | Displays [ON/OFF] condition of low-fuel warning signal. | |
| BUZZER [ON/OFF] | X | X | Displays [ON/OFF] condition of buzzer. |
| NOTE: Some items are not available due to vehicle specification. *: The monitor will indicate "OFF" even though the brake warning lamp is on if either of the following conditions exist. The parking brake is engaged The brake fluid level is low | |||
| NOTE |
|---|
| Some items are not available due to vehicle specification. *: The monitor will indicate "OFF" even though the brake warning lamp is on if either of the following conditions exist. The parking brake is engaged The brake fluid level is low |
DATA MONITOR DISPLAY ITEM LIST
| Monitor Item [Unit] | Description |
|---|---|
| PUSH-SW [On/Off] | Indicates condition of push button ignition switch |
| UNLK SEN-DR [On/Off] | Indicates condition of door unlock sensor |
| VEH SPEED 1 [km/h] | Indicates vehicle speed signal received from ABS on CAN communication line |
| KEY SW-SLOT [On/Off] | Indicates condition of key slot |
| TAIL LAMP SW [On/Off] | Indicates condition of combination switch |
| FR FOG SW [On/Off] | Indicates condition of front fog lamp switch |
| DOOR SW-DR [On/Off] | Indicates condition of front door switch LH |
DATA MONITOR DISPLAY ITEM LIST
Component Function Check
- CHECK OPERATION OF METER BUZZER Select "BUZZER" of "BCM" on CONSULT-III. Perform "LIGHT WARN ALM" of "ACTIVE TEST". Does meter buzzer activate? YES >> Inspection End. NO >> Replace combination meter. Refer to " «REMOVAL AND INSTALLATION»(ref-388063-S27023497762011022800000) ".
- CHECK COMBINATION METER INPUT SIGNAL Select "DATA MONITOR" for "METER/M&A" and check the "BUCKLE SW" monitor value. BUCKLE SW When seat belt is fastened : OFF When seat belt is unfastened : ON Is the inspection result normal? YES >> Inspection End. NO >> Refer to " «DIAGNOSIS PROCEDURE»(ref-388088-S23057090052011022800000) ".
PHYSICAL VALUES
ECU DIAGNOSIS INFORMATION REFERENCE Terminal Wire color Item Condition Reference value (V) (Approx.) Ignition switch Operation or condition 1 W/L Battery power supply - - Battery voltage 2 O Ignition switch ON or START ON - Battery voltage 3 B Ground (Power) - - 0 4 B Ground (Illumination) 5 B Illumination output - - Refer to " SYSTEM DESCRIPTION ". 10 O/L Mode switch ground ON - 0 11 L/R Mode switch A ON Switch pressed 0 Switch released 5 12 B/R Mode switch B ON Switch pressed 0 Switch released 5 15 BR/W Air bag warning lamp input ON Air bag warning lamp ON 3 Air bag warning lamp OFF 0 18 O/B Ambient sensor signal ON - 0 - 5 (Based on ambient temperature) 19 P Ambient sensor power ON - 5 20 B/Y Ambient sensor ground ON - 0 21 L CAN-H - - - 22 P CAN-L - - - 23 B Ground (Circuit) - - 0 24 B/W Fuel level sensor ground ON - 0 25 BR Generator ON Generator voltage low 0 Generator voltage normal Battery voltage 26 G/R Parking brake switch ON Parking brake depressed 0 Parking brake released Battery voltage 27 V Brake fluid level switch ON Brake fluid level low 0 Brake fluid level normal Battery voltage 28 L/O Security indicator input OFF Security indicator ON 0 Security indicator OFF Battery voltage 29 R Washer fluid level switch ON Washer fluid level low 0 Washer fluid level normal Battery voltage 30 L/B Vehicle speed signal output (2-pulse) ON Speedometer operated [When vehicle speed is approx. 20 km/h (12 MPH)] 240 Hz 31 V/W Vehicle speed signal output (8-pulse) ON Speedometer operated [When vehicle speed is approx. 40 km/h (25 MPH)] NOTE: Maximum voltage may be 12V due to specifications (connected units). 34 G/B Fuel level sensor signal - - Refer to " FUEL GAUGE : SYSTEM DESCRIPTION ". 35 W/B Seat belt buckle switch LH ON Unfastened (ON) 0 Fastened (OFF) Battery voltage 36 L/W Seat belt buckle switch RH ON Unfastened (ON) 0 Fastened (OFF) Battery voltage 37 G Not M range ON Manual mode switch OFF 0 Manual mode switch ON Battery voltage 38 BR CVT shift down ON Manual mode switch ON Shift down operation 0 Other than above Battery voltage 39 W CVT shift up ON Manual mode switch ON Shift up operation 0 Other than above Battery voltage 40 LG/R M range ON Manual mode switch OFF Battery voltage Manual mode switch ON 0 49 G Paddle shift signal (shift down) ON Shift down operation 0 Switch released Battery voltage 50 O Paddle shift signal (shift up) ON Shift up operation 0 Switch released Battery voltage
Scheme 81
Fail Safe
The combination meter performs a fail-safe operation for the functions listed below when communication is lost.
| Function | Specifications | |
|---|---|---|
| Speedometer | Zero indication. | |
| Tachometer | ||
| Fuel gauge | ||
| Engine coolant temperature gauge | ||
| Illumination control | Meter illumination | Change to nighttime mode when communication is lost. |
| Segment LCD | Odometer | Freeze current indication. |
| CVT position | Display turns off. | |
| Buzzer | Buzzer turns off. | |
| Warning lamp/indicator lamp | ABS warning lamp | Lamp turns on when communication is lost. |
| Brake warning lamp | ||
| TCS/VDC OFF indicator lamp | ||
| SLIP indicator lamp | ||
| Malfunction indicator lamp | ||
| CVT warning lamp | Lamp turns off when communication is lost. | |
| Oil pressure warning lamp | ||
| Master warning lamp | ||
| Air bag warning lamp | ||
| High beam indicator | ||
| Turn signal indicator lamp | ||
| CRUISE indicator lamp | ||
| Intelligent Key system warning lamp | ||
| Driver and passenger seat belt warning lamp | Lamp turns off when disconnected. | |
| Charge warning lamp | ||
| Security indicator lamp | ||
| Low tire pressure warning lamp | Lamp will flash every second for 1 minute and then stay on continuously thereafter. | |
FAIL SAFE REFERENCE CHART
BCM (BODY CONTROL MODULE) INFORMATION REFERENCE Terminal No. (Wire color) Description Condition Value (Approx.) (+) (-) Signal name Input/Output 1 (W/B) Ground Battery power supply Input Ignition switch OFF Battery voltage 2 (R/Y) Ground Battery power supply output Output Ignition switch OFF Battery voltage 3 (L/W) Ground Ignition power supply output Output Ignition switch ON Battery voltage 4 (P/W) Ground Interior room lamp power supply Output After passing the interior room lamp battery saver operation time 0V Any other time after passing the interior room lamp battery saver operation time Battery voltage 5 (G) Ground Front door RH UNLOCK Output Front door RH UNLOCK (actuator is activated) Battery voltage Other than UNLOCK (actuator is not activated) 0V 7 (R/W) Ground Step lamp Output Step lamp ON 0V OFF Battery voltage 8 (V) Ground All doors LOCK Output All doors LOCK (actuator is activated) Battery voltage Other than LOCK (actuator is not activated) 0V 9 (L) Ground Front door LH UNLOCK Output Front door LH UNLOCK (actuator is activated) Battery voltage Other than UNLOCK (actuator is not activated) 0V 10 (G) Ground Rear door RH and rear door LH UNLOCK Output Rear door RH and rear door LH UNLOCK (actuator is activated) Battery voltage Other than UNLOCK (actuator is not activated) 0V 11 (Y/R) Ground Battery power supply Input Ignition switch OFF Battery voltage 13 (B) Ground Ground - Ignition switch ON 0V 14 (GR/W) Ground Engine switch (push switch) illumination ground Input Tail lamp OFF 0V ON NOTE: When the illumination brightening/dimming level is in the neutral position 15 (Y/L) Ground ACC indicator lamp Output Ignition switch OFF Battery voltage ACC or ON 0V 17 (G/B) Ground Turn signal (RH) Output Ignition switch ON Turn signal switch OFF 0V Turn signal switch RH 6.5 V 18 (G/Y) Ground Turn signal (LH) Output Ignition switch ON Turn signal switch OFF 0V Turn signal switch LH 6.5 V 19 (Y) Ground Room lamp timer control Output Interior room lamp OFF Battery voltage ON 0V 21 (P/B) Ground Optical sensor signal Input Ignition switch ON When outside of the vehicle is bright Close to 5V When outside of the vehicle is dark Close to 0V 24 (R/W) Ground Stop lamp switch 1 Input - Battery voltage 26 (O/L) Ground Stop lamp switch 2 Input Stop lamp switch OFF (brake pedal is released) 0V ON (brake pedal is depressed) Battery voltage 27 (O) Ground Front door lock assembly LH (unlock sensor) Input Front door LH LOCK status 11.8V UNLOCK status 0V 29 (Y) Ground Key slot switch Input When Intelligent Key is inserted into key slot Battery voltage When Intelligent Key is not inserted into key slot 0V 31 (G) Ground Rear window defogger feedback signal Input Rear window defogger switch OFF 0V ON Battery voltage 32 (R/B) Ground Front door RH switch Input Front door RH switch OFF (when front door RH closes) 11.8 V ON (when front door RH opens) 0V 37 (O) Ground Trunk lid opener cancel switch Input Trunk lid opener cancel switch CANCEL 1.1V ON 0V 38 (GR/W) Ground Rear window defogger ON signal Input Rear window defogger switch OFF 5V ON 0V 40 (Y/G) Ground Power window serial link Input/Output Ignition switch ON 10.2V Ignition switch OFF or ACC 0V 41 (W) Ground Engine switch (push switch) illumination Output Engine switch (push switch) illumination ON 5.5V OFF 0V 42 (R) Ground LOCK indicator lamp Output LOCK indicator lamp ON 0V OFF Battery voltage 45 (P) Ground Receiver & sensor ground Input Ignition switch ON 0V 46 (V/W) Ground Receiver & sensor power supply output Output Ignition switch OFF 0V ACC or ON 5.0V 47 (1) (G/O) Ground Tire pressure receiver signal Input/Output Ignition switch ON Standby state When receiving the signal from the transmitter 48 (R/G) Ground Selector lever transmission range switch signal Input Selector lever P or N position 12.0V Except P and N positions 0V 49 (L/O) Ground Security indicator signal Output Security indicator ON 0V Blinking 11.3V OFF Battery voltage 50 (LG/B) Ground Combination switch INPUT 5 Output Combination switch (Wiper intermittent dial 4) All switch OFF 0V Lighting switch 1ST 10.7V Lighting switch high-beam Lighting switch 2ND Turn signal switch RH 51 (L/W) Ground Combination switch INPUT 1 Output Combination switch All switch OFF (Wiper intermittent dial 4) 0V Front wiper switch HI (Wiper intermittent dial 4) 10.7V Any of the conditions below with all switch OFF Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 3 Wiper intermittent dial 6 Wiper intermittent dial 7 52 (G/B) Ground Combination switch INPUT 2 Output Combination switch All switch OFF (Wiper intermittent dial 4) 0V Front washer switch ON (Wiper intermittent dial 4) 10.7V Any of the conditions below with all switch OFF Wiper intermittent dial 1 Wiper intermittent dial 5 Wiper intermittent dial 6 53 (LG/R) Ground Combination switch INPUT 3 Output Combination switch (Wiper intermittent dial 4) All switch OFF 0V Front wiper switch INT 10.7V Front wiper switch LO Lighting switch AUTO 54 (G/Y) Ground Combination switch INPUT 4 Output Combination switch (Wiper intermittent dial 4) All switch OFF 0V Front fog lamp switch ON 10.7V Lighting switch 2ND Lighting switch flash-to-pass Turn signal switch LH 57 (1) (W) Ground Tire pressure warning check switch Input - 5V 58 (SB) Ground Front door LH switch Input Front door LH switch OFF (front door LH CLOSE) 11.8V ON (front door LH OPEN) 0V 59 (G/R) Ground Rear window defogger relay Output Rear window defogger Active Battery voltage Not activated 0V 60 (B/R) Ground Front console antenna 2 (-) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 61 (W/R) Ground Center console antenna 2 (+) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 62 (V) Ground Front outside handle RH antenna (-) Output When the front door RH request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 63 (P) Ground Front outside handle RH antenna (+) Output When the front door RH request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 64 (V) Ground Front outside handle LH antenna (-) Output When the front door LH request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 65 (P) Ground Front outside handle LH antenna (+) Output When the front door LH request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 68 (G/O) Ground NATS antenna amp (built in key slot) Input/Output During waiting Ignition switch is pressed while inserting the Intelligent Key into the key slot. Just after pressing ignition switch. Pointer of tester should move. 69 (O) Ground NATS antenna amp (built in key slot) Input/Output During waiting Ignition switch is pressed while inserting the Intelligent Key into the key slot. Just after pressing ignition switch. Pointer of tester should move. 70 (R/B) Ground Ignition relay-2 control Output Ignition switch OFF or ACC 0V ON Battery voltage 71 (L/O) Ground Remote keyless entry receiver signal Input/Output During waiting When operating either button on Intelligent Key 75 (R/Y) Ground Combination switch OUTPUT 5 Input Combination switch All switch OFF (Wiper intermittent dial 4) 1.4V Front fog lamp switch ON (Wiper intermittent dial 4) 1.3V Any of the conditions below with all switch OFF Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 6 Wiper intermittent dial 7 1.3V 76 (R/G) Ground Combination switch OUTPUT 3 Input Combination switch All switch OFF (Wiper intermittent dial 4) 1.4V Lighting switch high-beam (Wiper intermittent dial 4) 1.3V Lighting switch 2ND (Wiper intermittent dial 4) 1.3V Any of the conditions below with all switch OFF Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 3 1.3V 78 (P) Ground CAN-L Input/Output - - 79 (L) Ground CAN-H Input/Output - - 80 (R/L) Ground Key slot illumination Output Key slot illumination OFF 0V Blinking 6.5V ON Battery voltage 81 (LG) Ground ON indicator lamp Output Ignition switch OFF or ACC 0V ON Battery voltage 83 (L) Ground ACC relay control Output Ignition switch OFF 0V ACC or ON Battery voltage 84 (Y/R) Ground CVT shift selector Output - Battery voltage 87 (G/B) Ground Selector lever P position switch Input Selector lever P position 0V Any position other than P Battery voltage 88 (R) Ground Front door RH request switch Input Front door RH request switch ON (pressed) 0V OFF (not pressed) 1.0V 89 (R) Ground Front door LH request switch Input Front door LH request switch ON (pressed) 0V OFF (not pressed) 1.0V 90 (Y) Ground Blower fan motor relay control Output Ignition switch OFF or ACC 0V ON Battery voltage 91 (L/R) Ground Remote keyless entry receiver power supply Output Ignition switch OFF Battery voltage 95 (R/W) Ground Combination switch OUTPUT 1 Input Combination switch (Wiper intermittent dial 4) All switch OFF 1.4V Turn signal switch LH 1.3V Turn signal switch RH 1.3V Front wiper switch LO 1.3V Front washer switch ON 1.3V 96 (P/B) Ground Combination switch OUTPUT 4 Input Combination switch All switch OFF (Wiper intermittent dial 4) 1.4V Lighting switch AUTO (Wiper intermittent dial 4) 1.3V Lighting switch 1ST (Wiper intermittent dial 4) 1.3V Any of the conditions below with all switch OFF Wiper intermittent dial 1 Wiper intermittent dial 5 Wiper intermittent dial 6 1.3V 97 (R/B) Ground Combination switch OUTPUT 2 Input Combination switch (Wiper intermittent dial 4) All switch OFF 1.4V Lighting switch flash-to-pass 1.3V Lighting switch 2ND 1.3V Front wiper switch INT 1.3V Front wiper switch HI 1.3V 98 (G/O) Ground Hazard switch Input Hazard switch Pressed 0 V Not pressed 1.1V 103 (V) Ground Trunk lid opening. Output Trunk lid Open (trunk lid opener actuator is activated) Battery voltage Close (trunk lid opener actuator is not activated) 0V 110 (V/W) Ground Trunk room lamp Output Trunk room lamp ON 0V OFF Battery voltage 114 (B) Ground Trunk room antenna 1 (-) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 115 (W) Ground Trunk room antenna 1 (+) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 118 (L/O) Ground Rear bumper antenna (-) Output When the trunk lid request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 119 (BR/W) Ground Rear bumper antenna (+) Output When the trunk lid request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 127 (BR/W) Ground Ignition relay (IPDM E/R) control Output Ignition switch OFF or ACC Battery voltage ON 0V 130 (W) Ground Trunk room lamp switch Input Trunk room lamp switch OFF (trunk is closed) 11.8V ON (trunk is open) 0V 132 (R) Ground Starter motor relay control Output Ignition switch ON When selector lever is in P or N position and the brake is depressed Battery voltage When selector lever is in P or N position and the brake is not depressed 0V 140 (BR) Ground Engine switch (push switch) Input Engine switch (push switch) Pressed 0V Not pressed Battery voltage 141 (BR) Ground Trunk request switch Input Trunk request switch ON (pressed) 0V OFF (not pressed) 1.0V 144 (GR) Ground Request switch buzzer Output Request switch buzzer Sounding 0V Not sounding Battery voltage 147 (L/R) Ground Trunk lid opener switch Input Trunk lid opener switch Pressed 0V Not pressed Battery voltage 148 (R/W) Ground Rear door RH switch Input Rear door RH switch OFF (when rear door RH closes) 11.8V ON (when rear door RH opens) 0V 149 (R/B) Ground Rear door LH switch Input Rear door LH switch OFF (when rear door LH closes) 11.8V ON (when rear door LH opens) 0V (1) With low tire pressure monitoring system
Scheme 82
Scheme 83
Scheme 84
Scheme 85
Scheme 86
Scheme 87
Scheme 88
Scheme 89
Scheme 90
Scheme 91
Scheme 92
Scheme 93
Scheme 94
Scheme 95
Scheme 96
Scheme 97
Scheme 98
Scheme 99
Scheme 100
Scheme 101
Scheme 102
Scheme 103
Scheme 104
Scheme 105
| Display contents of CONSULT | Fail-safe | Cancellation |
|---|---|---|
| B2190: NATS ANTENNA AMP | Inhibit engine cranking | Erase DTC |
| B2191: DIFFERENCE OF KEY | Inhibit engine cranking | Erase DTC |
| B2192: ID DISCORD BCM-ECM | Inhibit engine cranking | Erase DTC |
| B2193: CHAIN OF BCM-ECM | Inhibit engine cranking | Erase DTC |
| B2195: ANTI-SCANNING | Inhibit engine cranking | Erase DTC |
| B2560: STARTER CONT RELAY | Inhibit engine cranking | 500 ms after the following CAN signal communication status has become consistent Starter control relay signal Starter relay status signal |
| B2562: LOW VOLTAGE | Inhibit engine cranking | 100 ms after the power supply voltage increases to more than 8.8 V |
| B2608: STARTER RELAY | Inhibit engine cranking | 500 ms after the following signal communication status becomes consistent Starter motor relay control signal Starter relay status signal (CAN) |
| B260A: IGNITION RELAY | Inhibit engine cranking | 500 ms after the following conditions are fulfilled IGN relay (IPDM E/R) control signal: OFF (Battery voltage) Ignition ON signal (CAN to IPDM E/R): OFF (Request signal) Ignition ON signal (CAN from IPDM E/R): OFF (Condition signal) |
| B260F: ENG STATE SIG LOST | Maintains the power supply position attained at the time of DTC detection | When any of the following conditions is fulfilled Power position changes to ACC Receives engine status signal (CAN) |
| B2617: STARTER RELAY CIRC | Inhibit engine cranking | 1 second after the starter motor relay control inside BCM becomes normal |
| B2618: BCM | Inhibit engine cranking | 1 second after the ignition relay (IPDM E/R) control inside BCM becomes normal |
| B26E1: ENG STATE NO RECIV | Inhibit engine cranking | When any of the following conditions are fulfilled Power position changes to ACC Receives engine status signal (CAN) |
FAIL SAFE REFERENCE CHART
