Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted. Information necessary to service the system safely is included in the Safety Restraint and Seat Belt Service Information.
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SRS AIRBAG . Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Article. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
| WARNING | When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service. |
Service Notice or Precautions
- When installing rubber bushings, the final tightening must be carried out under unladen conditions with tires on ground. Oil might shorten the life of rubber bushings. Be sure to wipe off any spilled oil. Unladen conditions mean that fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and mats are in designated positions.
- After servicing suspension parts, be sure to check wheel alignment.
- Self-lock nuts are not reusable. Always use new ones when installing. Since new self-lock nuts are pre-oiled, tighten as they are.
Special Service Tool
The actual shapes of the Kent-Moore tools may differ from those of special service tools illustrated here.
SPECIAL TOOL DESCRIPTION CHART Tool number (Kent-Moore No.) Tool name Description HT7252000 (J-25730-B) Ball joint remover Removing tie-rod outer and lower ball joint - (J-44372) Spring gauge Measuring steering wheel turning force, rack sliding force and ball joint swinging force - (J-49286) Drift and Pull gauge Measuring drift and pull KV991040S1 (-) CCK gauge attachment KV99104020 Adapter A KV99104030 Adapter B KV99104040 Adapter C KV99104050 Adapter D KV99104060 Plate KV99104070 Guide bolt KV99104080 Spring KV99104090 Center plate Measuring wheel alignment ST35652000 (-) Strut attachment Disassembling and assembling strut
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Commercial Service Tool
SPECIAL TOOL DESCRIPTION CHART Tool name Description Power tool Loosening bolts and nuts Attachment wheel alignment screw M24 x 1.5 pitch 35 mm (1.38 in) dia. 65 mm (2.56 in) dia. 56 mm (2.20 in) dia. 12 mm (0.47 in) dia. Measuring wheel alignment Spring compressor Removing and installing coil spring Engine slinger Removing and installing suspension member with VQ35DE and CVT
Scheme 19
Scheme 20
LOWER BALL JOINT END PLAY
- Set front wheels in a straight-ahead position. Do not depress brake pedal.
- Place an iron bar or similar tool between upper link and steering knuckle.
- Measure axial end play by prying it up and down. Refer to " «BALL JOINT»(ref-388058-S03339863492011022800000) ". CAUTION: Be careful not to damage ball joint boot. Do not damage the installation position by applying excessive force.
SHOCK ABSORBER
Check for oil leakage, damage and replace if malfunction is detected.
Ball Joint
| Measurement on spring balance (cotter pinhole position) | 7.94 - 53.97 N (0.81 - 5.50 kg, 1.79 - 12.2 lb) |
|---|---|
| Axial endplay | 0.1 mm (0.004 in) or less |
BALL JOINT AXIAL END PLAY
Wheelarch Height (Unladen*1)
WHEELARCH HEIGHT SPECIFICATIONS Unit: mm (in) Market United States Canada Mexico Tire size P245/45R18 (1) P245/45R18 (2) P245/40R19 (1) P245/45R18 (1) P245/45R18 (2) P245/40R19 (1) P245/45R18 (1) P245/40R19 (1) Front (Hf) 719 (28.31) 719 (28.31) 723 (28.46) 720 (28.35) 719 (28.31) 723 (28.46) 729 (28.70) 732 (28.82) Rear (Hr) 728 (28.66) 727 (28.62) 730 (28.74) 728 (28.66) 727 (28.62) 730 (28.74) 747 (29.41) 750 (29.53) (1) Without top load sunroof (2) With top load sunroof
*1: Fuel, engine coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
