Roof: Removal & Installation Nissan Maxima A35

Sun Roof/t-Top/convertible Top 25 illustrations ~3157 words

Removal and Installation

CAUTIONAfter installing either sunroof unit assembly or glass lid assembly, check gap/height adjustments and operation to make sure there is no malfunction. Always work with a helper. Handle glass lid assembly with care to prevent damage. When taking sunroof unit out, use shop cloths to protect the seats and trim from damage.

Removal

Scheme 44

Scheme 44: SUNROOF UNIT ASSEMBLY
Scheme 44: SUNROOF UNIT ASSEMBLY

Scheme 45

Scheme 45
Scheme 45
  1. Close glass lid assembly.
  2. Remove headlining. Refer to " «REMOVAL AND INSTALLATION»(ref-388080-S05439423022011022800000) ".
  3. Disconnect drain hoses.
  4. Remove screws (A), then pull sunroof switch bracket (1) away from sunroof unit assembly (2). <= Vehicle front
  5. Disconnect sunroof motor harness connector.
  6. Remove bolts on the front end and side rails of the sunroof unit assembly.
  7. Remove front sunroof side bracket bolts.
  8. Remove rear sunroof side bracket bolts and remove sunroof unit assembly from roof panel.
  9. Remove sunroof unit assembly through the passenger compartment while being careful not to damage the seats and trim.

Installation

  1. Loosely tighten the rear sunroof side bracket bolts to the sunroof unit assembly side rails.
  2. Bring sunroof unit into passenger compartment and loosely tighten rear sunroof side bracket bolts to roof panel while supporting front.
  3. Align the sunroof unit assembly front end rail and side rails with the locator pins, then loosely tighten the bolts.
  4. Install remaining sunroof side brackets and loosely tighten bolts.
  5. Tighten the sunroof unit assembly front end and side rail bolts diagonally to the specified torque.
  6. Tighten the front sunroof side bracket bolts at the vehicle side first, then at the side rail end.
  7. Tighten the rear sunroof side bracket bolts at the vehicle side first, then at the side rail end.
  8. Connect sunroof motor harness connector.
  9. Install sunroof switch bracket.
  10. Connect drain hoses.
  11. Install headlining. Refer to " «REMOVAL AND INSTALLATION»(ref-388080-S05439423022011022800000) ".

REMOVAL

CAUTIONAlways work with a helper. Handle glass lid with care to prevent damage.

Note. For easier and more accurate installation, always mark each point before removal.

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48
  1. Open sunshade assembly.
  2. Tilt glass lid up, then slide rearward to expose all the glass lid bolts.
  3. Release the slide clip, then remove inner blind (1) RH/LH from the glass lid (2). <= : Front
  4. Remove the glass lid rear bolts (A), two on both the left and right sides. <= : Front
  5. Remove the glass lid front bolts (B), two on both the left and right sides. <= : Front
  6. Remove the glass lid from the vehicle.

INSTALLATION

CAUTIONAfter installing the glass lid, perform the water leak test.

Installation is in the reverse order of removal.

Note. After installing, perform glass lid adjustment procedure. Refer to " INSPECTION AND ADJUSTMENT ". After adjustment, always check for proper sunroof operation. If necessary, perform initialization procedure to synchronize entire system. Refer to " ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT ".

CAUTIONBefore removing sunroof motor, check that glass lid is fully closed. After removing sunroof motor, do not attempt to rotate sunroof motor assembly as a single unit.

Scheme 49

Scheme 49
Scheme 49
  1. Close glass lid.
  2. Remove the headlining. Refer to " «REMOVAL AND INSTALLATION»(ref-388080-S05439423022011022800000) ".
  3. Disconnect sunroof motor assembly harness connector (A).
  4. Remove sunroof motor assembly screws (B), then remove sunroof motor assembly (1) from sunroof unit assembly frame.
CAUTIONBefore installing the sunroof motor assembly, be sure to the place the link and wire assembly in the symmetrical and fully closed position.
  1. Move the sunroof motor assembly laterally so that the gear is completely engaged into the wire on the sunroof unit assembly frame, and mounting surface becomes parallel.
  2. Install and tighten sunroof motor assembly screws.
  3. Connect the sunroof motor assembly harness connector.
  4. Install the headlining. Refer to " «REMOVAL AND INSTALLATION»(ref-388080-S05439423022011022800000) ".
  5. Perform initilization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-388090-S12036064102011022800000) ".
CAUTIONBefore removing sunshade motor, check that glass lid is fully closed. After removing sunshade motor, do not attempt to rotate sunshade motor assembly as a single unit.

Scheme 50

Scheme 50
Scheme 50
  1. Close glass lid.
  2. Remove the headlining. Refer to " «REMOVAL AND INSTALLATION»(ref-388080-S05439423022011022800000) ".
  3. Disconnect sunshade motor assembly harness connector (A).
  4. Remove sunroof motor assembly screws (B), then remove sunroof motor assembly (1) from sunroof unit assembly frame.
CAUTIONBefore installing the sunshade motor assembly, be sure to the place the link and wire assembly in the symmetrical and fully closed position.
  1. Move the sunshade motor assembly laterally so that the gear is completely engaged into the wire on the sunroof unit assembly frame, and mounting surface becomes parallel.
  2. Install and tighten sunshade motor assembly screws.
  3. Connect the sunshade motor assembly harness connector.
  4. Install the headlining. Refer to " «REMOVAL AND INSTALLATION»(ref-388080-S05439423022011022800000) ".
  5. Perform initilization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-388090-S12036064102011022800000) ".
  1. Remove the sunshade assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S35952177502011022800000) ".
  2. Remove the wind deflector. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S25686674152011022800000) ".
  3. Remove the glass lid assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S00394106142011022800000) ".
  4. Remove the sunroof motor. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S12742265972011022800000) ".
  5. Remove the sunshade motor. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S25770329422011022800000) ".
  6. Remove the track assembly. Remove the 5 screws and 4 harness clips (LH). Remove the 5 screws (RH).
  7. Slide the guide link out of the channels.

Installation is in the reverse order of removal.

WARNINGDisconnect the negative and positive battery terminals, then wait at least three minutes.
CAUTIONAlways work with a helper. When taking sunroof unit assembly out, use cloths to protect the seats and trim from damage. Do not reuse the front or rear sunroof glass which has been removed once.

Scheme 51

Scheme 51
Scheme 51
  1. Remove the headlining. Refer to " «REMOVAL AND INSTALLATION»(ref-388080-S05439423022011022800000) ".
  2. Remove the glass lid. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S00394106142011022800000) ".
  3. Remove the wind deflector. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S25686674152011022800000) ".
  4. Apply protective tape over the weather stripping seal.
  5. Remove the sunshade carrier assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S35952177502011022800000) ".
  6. Apply protective tape to the body surrounding the entire sunroof frame.
  7. Remove the front sunroof glass. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S40273833822011022800000) ".
  8. Remove the roof side finishers. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S26382775252011022800000) ".
  9. Remove the rear window glass. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S25700698102011022800000) ".
  10. Remove the satellite antenna. Refer to " «REMOVAL AND INSTALLATION»(ref-388076-S38001056042011022800000) " (Bose W/Monochrome Display) " «REMOVAL AND INSTALLATION»(ref-388076-S01341869512011022800000) " (Bose W/Color Display W/O NAVI) or " «REMOVAL AND INSTALLATION»(ref-388076-S21958305902011022800000) " (Bose W/Color Display W/NAVI).
  11. Remove the rear sunroof glass. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S00919924732011022800000) ".
  12. Disconnect the sunroof motor assembly and sunshade motor assembly harness connectors.
  13. Remove the front nuts (A), the rear nuts (B), and the rear bolts (C) from the dual panel sunroof.
  14. Cut adhesive. Pass piano wire though the adhesive with a wire pierce. Tie piano wire on both ends to assist in wire grip. Pull piano wire with sawing motion to cut through adhesive, working around entire circumference.
  15. Using a helper, carefully lift each side and remove sunroof frame from vehicle.
WARNINGKeep heat and open flames away as primers and adhesive are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Never let them contact the skin or eyes. Use in an open, well ventilated location. Never breathe the vapors. They may be harmful if inhaled. Move immediately to an area with fresh air if affected by vapor inhalation.
CAUTIONAfter installing the sunroof unit assembly and glass lid, perform the leak test and check that there is no air or water intrusion.

Note. Use a genuine Nissan Urethane Adhesive Kit (if available) or an equivalent and follow the instructions furnished with it. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (approximately 24 hours). Curing time varies with temperature and humidity.

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55
  1. Using a knife or spatula, trim the adhesive (sealant) remaining on body down to approximately 2 mm thick (a) so that the contour becomes smooth. CAUTION: If bonded area on body is scratched, be sure to repair it with a 2 component urethane. Do not use lacquer.
  2. When installing new sunroof unit assembly frame, mount the roof frame dry (no adhesive) first onto the vehicle and paint mating marks on body and sunroof frame, then remove sunroof frame again.
  3. Thoroughly clean bonding area on sunroof frame and body with isopropyl alcohol or equivalent.
  4. Apply primer to the body and the sunroof frame (lower) surfaces.
  5. Apply adhesive along the entire circumference of the sunroof unit assembly frame contact area of body within the time specified in the instructions for the adhesive. Open adhesive by cutting off the nozzle tip and set it in a sealant gun. Form a continuous bead of adhesive resembling the measurements in applied thickness (A), and in applied width (B) on the body panel. Adhesive applied thickness (A) : 13 ± 1 mm (0.51 in ± 0.039 in) Adhesive applied width (B) : 8 ± 1 mm (0.31 ± 0.039 in)
  6. Using a helper, position the sunroof unit assembly frame over the body, visually aligning the paint mating marks. Then, lower the studs at each corner through the body panel holes, carefully installing the sunroof unit assembly to the body.
  7. Press down lightly by hand only on the frame to expand the adhesive contact completely so that it resembles a compressed thickness (A), and a compressed width (B) between the sunroof unit assembly frame and the body. Adhesive compressed thickness (A) : 5 +2/-1 mm (0.20 +0.079/-0.039 in) Adhesive compressed width (B) : Front edge 15 mm (0.59 in) : Side edge 21 mm (0.83 in) : Rear edge 15 mm (0.59 in)
  8. Install and tighten the sunroof unit assembly nuts and bolts in the order shown in the figure within five minutes. Sunroof unit assembly nuts and bolts : 17 N.m (1.7 kg-m, 13 ft-lb) <= : Front
  9. Install the sunshade carrier assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S35952177502011022800000) ".
  10. Using a suitable tool, remove any adhesive overflow, or work into pocket voids so as to make the surface edge smooth.
  11. Install the rear sunroof glass. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S00919924732011022800000) ".
  12. Install the rear window glass. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S25700698102011022800000) ".
  13. Install the roof side finishers. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S26382775252011022800000) ".
  14. Install the front sunroof glass. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S40273833822011022800000) ".
  15. Connect the sunroof motor assembly and sunshade motor assembly harness connectors.
  16. Install the wind deflector. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S25686674152011022800000) ".
  17. Install the glass lid. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S00394106142011022800000) ". NOTE: After installation, carry out fitting adjustment. Refer to " «INSPECTION AND ADJUSTMENT»(ref-388090-S00517532522011022800000) ".
  18. Install the satellite antenna. Refer to " «REMOVAL AND INSTALLATION»(ref-388076-S38001056042011022800000) " (Bose W/Monochrome Display) " «REMOVAL AND INSTALLATION»(ref-388076-S01341869512011022800000) " (Bose W/Color Display W/O NAVI), or " «REMOVAL AND INSTALLATION»(ref-388076-S21958305902011022800000) " (Bose W/Color Display W/NAVI).
  19. Install the headlining. Refer to " «REMOVAL AND INSTALLATION»(ref-388080-S05439423022011022800000) ".
  20. Check for water leaks. NOTE: Perform the water leakage check more than 2 hours after sunroof unit assembly installation. After glass lid fitting adjustment, carry out water leakage check by spreading water over entire roof surface.
  21. Remove the protective tape from the vehicle.
  1. Open the glass lid.
  2. Apply protective tape around the roof side finisher to protect the surface from damage.
  3. Cut adhesive. Pass piano wire through the adhesive with a wire pierce. Tie piano wire on both ends to assist in wire grip. Pull piano wire with sawing motion to cut through adhesive, working along the length of the panel.
  4. Remove the roof side finisher.
WARNINGKeep heat and open flames away as primers and adhesive are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Never let them contact the skin or eyes. Use in an open, well ventilated location. Never breathe the vapors. They may be harmful if inhaled. Move immediately to an area with fresh air if affected by vapor inhalation.

Note. Use a genuine Nissan Urethane Adhesive Kit (if available) or an equivalent and follow the instructions furnished with it. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (approximately 24 hours). Curing time varies with temperature and humidity.

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57
  1. Using a knife or spatula, trim the adhesive (sealant) remaining on body down to approximately 2 mm thick (a) so that the contour becomes smooth. CAUTION: If bonded area on body is scratched, be sure to repair it with a 2 component urethane. Do not use lacquer.
  2. When installing new roof side finisher, position the roof side finisher dry (no adhesive) first onto the vehicle and paint mating marks on the body and roof side finisher, then remove it again.
  3. Thoroughly clean bonding area on the roof side finisher and the body with isopropyl alcohol or equivalent.
  4. Apply primer to the body and the roof side trim (lower) surfaces.
  5. Apply adhesive to the contact areas of the body within the time specified in the instructions for the adhesive. Open adhesive by cutting off the nozzle tip and set it in a sealant gun. Form a continuous bead of adhesive resembling the measurements in applied thickness (A), and in applied width (B) on the body panel. Adhesive applied thickness (A) : 13 ± 1 mm (0.51 ± 0.039 in) Adhesive applied width (B) : 8 ± 1 mm (0.31 ± 0.039 in)
  6. Position the roof side finisher, align the paint marks, then lower it into position.
  7. Press down lightly by hand to evenly expand the adhesive contact with the roof side finisher.
  8. Using a suitable tool, remove any adhesive overflow.
  9. Remove the protective tape.
  1. Remove the wind deflector. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S25686674152011022800000) ".
  2. Tape down the glass lid weatherstrip along the from sunroof glass with protective tape.
  3. Apply protective tape around the front sunroof glass to protect the surface from damage.
  4. Cut adhesive. Pass piano wire through the adhesive with a wire pierce. Tie piano wire on both ends at assist in wire grip. Pull piano wire with a sawing motion to cut through the adhesive.
  5. Remove the front sunroof glass.
WARNINGKeep heat and open flames away as primers and adhesive are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Never let them contact the skin or eyes. Use in an open, well ventilated location. Never breathe the vapors. They may be harmful if inhaled. Move immediately to an area with fresh air if affected by vapor inhalation.

Note. Use a genuine Nissan Urethane Adhesive Kit (if available) or an equivalent and follow the instructions furnished with it. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (approximately 24 hours). Curing time varies with temperature and humidity.

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59
  1. Using a knife or spatula, trim the adhesive (sealant) remaining on body down to approximately 2 mm thick (a) so that the contour becomes smooth. CAUTION: If bonded area on body is scratched, be sure to repair it with a 2 component urethane. Do not use lacquer.
  2. When installing new front sunroof glass, position the front sunroof glass (no adhesive) first onto the vehicle and paint mating marks on the body and the front sunroof glass, then remove it again.
  3. Thoroughly clean bonding area on the front sunroof glass and the body with isopropyl alcohol or equivalent.
  4. Apply primer to the body and the front sunroof glass (lower) surfaces.
  5. Apply adhesive to the contact areas of the body within the time specified in the instructions for the adhesive. Open adhesive by cutting off the nozzle tip and set it in a sealant gun. Form a continuous bead of adhesive resembling the measurements in applied thickness (A), and in applied width (B) on the body panel. Adhesive applied thickness (A) : 13 ± 1 mm (0.51 ± 0.039 in) Adhesive applied width (B) : 8 ± 1 mm (0.31 ± 0.039 in)
  6. Position the front sunroof glass, align the paint marks and lower it into position.
  7. Press down lightly by hand to evenly expand the adhesive contact with the front sunroof glass.
  8. Using a suitable tool, remove any adhesive overflow.
  9. Remove the protective tape.
  1. Apply protective tape around all of the glass panels to be removed.
  2. Remove the satellite radio antenna. Refer to " «REMOVAL AND INSTALLATION»(ref-388076-S38001056042011022800000) " (Bose W/Monochrome Display), " «REMOVAL AND INSTALLATION»(ref-388076-S01341869512011022800000) " (Bose W/Color Display W/O Navi), or " «REMOVAL AND INSTALLATION»(ref-388076-S21958305902011022800000) " (Bose W/Color Display W/Navi).
  3. Remove the rear window glass. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S25700698102011022800000) ".
  4. Remove the glass lid. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S00394106142011022800000) ".
  5. Remove the roof side finishers. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S26382775252011022800000) ".
  6. Cut adhesive. Pass piano wire through the adhesive with a wire pierce. Tie piano wire on both ends at assist in wire grip. Pull piano wire with a sawing motion to cut through the adhesive.
  7. Remove the rear sunroof glass.
WARNINGKeep heat and open flames away as primers and adhesive are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Never let them contact the skin or eyes. Use in an open, well ventilated location. Never breathe the vapors. They may be harmful if inhaled. Move immediately to an area with fresh air if affected by vapor inhalation.

Note. Use a genuine Nissan Urethane Adhesive Kit (if available) or an equivalent and follow the instructions furnished with it. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (approximately 24 hours). Curing time varies with temperature and humidity.

Scheme 60

Scheme 60
Scheme 60

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62
  1. Using a knife or spatula, trim the adhesive (sealant) remaining on body down to approximately 2 mm thick (a) so that the contour becomes smooth. CAUTION: If bonded area on body is scratched, be sure to repair it with a 2 component urethane. Do not use lacquer.
  2. When installing new rear sunroof glass, position the rear sunroof glass (no adhesive) first onto the vehicle and paint mating marks on the body and the rear sunroof glass, then remove it again.
  3. Thoroughly clean bonding area on the rear glass panel and the body with isopropyl alcohol or equivalent.
  4. Apply primer to the sunroof frame anywhere the surface has been scratched and the rear sunroof glass (lower) surfaces.
  5. Apply adhesive along the entire circumference of the rear sunroof glass frame contact area of the body within the time specified in the instructions for the adhesive. Also apply adhesive around the satellite antenna hole outward from the hole along the sunroof frame to cover the existing adhesive. Open adhesive by cutting off the nozzle tip and set it in a sealant gun. Form a continuous bead of adhesive resembling the measurements in applied thickness (A), and in applied width (B) on the sunroof frame. Adhesive applied thickness (A) : 13 ± 1 mm (0.51 ± 0.039 in) Adhesive applied width (B) : 8 ± 1 mm (0.31 ± 0.039 in)
  6. Position the rear sunroof glass, align the paint marks and lower it into position.
  7. Press down lightly by hand to evenly expand the adhesive contact with the rear sunroof glass. Press down by hand to expand the adhesive contact completely so that it resembles a compressed thickness (A), and a compressed width (B). Adhesive compressed thickness (A) : 5 +2, -1 mm (0.20 +0.079 - 0.039 in) Adhesive compressed width (B) : Front edge 15 mm (0.59 in) : Side edge 21 mm (0.83 in) : Rear edge 15 mm (0.59 in)
  8. Install the rear window glass. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S25700698102011022800000) ".
  9. Install the roof side finishers. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S26382775252011022800000) ".
  10. Install the glass lid. Refer to " «REMOVAL AND INSTALLATION»(ref-388090-S00394106142011022800000) ". NOTE: After installation, carry out fitting adjustment. Refer to " «INSPECTION AND ADJUSTMENT»(ref-388090-S00517532522011022800000) ".
  11. Install the satellite radio antenna. Refer to " «REMOVAL AND INSTALLATION»(ref-388076-S38001056042011022800000) " (Bose W/Monochrome Display), " «REMOVAL AND INSTALLATION»(ref-388076-S01341869512011022800000) " (Bose W/Color Display W/O Navi) or " «REMOVAL AND INSTALLATION»(ref-388076-S21958305902011022800000) " (Bose W/Color Display W/Navi).
  12. Check for water leaks. NOTE: Perform the water leakage check more than 2 hours after sunroof unit assembly installation. After glass lid fitting adjustment, carry out water leakage check by spreading water over entire roof surface.
  13. Remove the protective tape from the vehicle.

Scheme 63

Scheme 63: REMOVAL
Scheme 63: REMOVAL

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65
  1. Open the glass lid.
  2. Remove the side screw (A) to release the wind deflector side arms (1). <= : Front
  3. Disconnect and release the inner blind (1) slide clip from wind deflector. <= : Front
  4. Remove the front screws (A), then remove wind deflector from sunroof unit assembly. <= : Front

Installation is in the reverse order of removal.

Scheme 66

Scheme 66: Exploded View
Scheme 66: Exploded View

Scheme 67

Scheme 67: REMOVAL
Scheme 67: REMOVAL
  1. Open glass lid and sunshades.
  2. Remove the headlining. Refer to " «REMOVAL AND INSTALLATION»(ref-388080-S05439423022011022800000) ".
  3. Release front sunshade rail (1) from sunshade drive post (2). <= : Front
  4. Repeat sunshade drive post release for the rear sunshade.
  5. Remove side curtain air bag module bolts (two on each RH/LH sides) for access.
  6. Release harness clips from sunshade carrier assembly.
  7. Remove the center bracket nuts and bolts, then remove the center brackets (RH/LH).
  8. Remove the sunshade carrier assembly bolts, then lower sunshade assembly and remove from vehicle. Release the end key slot from the sunshades.
CAUTIONBe careful not to release the spring when installing the sunshade.
  1. Wind the shade around the core post.
  2. Insert the round end of the shade (front - black curved rail) into the sunshade carrier assembly.
  3. Using a suitable tool, wind the double-D tang end 20 turns counter clockwise (when viewed from the end).
  4. Insert the double-d tang end into the slot and lock it into the carrier.
  5. Position the sunshade carrier assembly and install the bolts.
  6. Position the center brackets (RH/LH) and install the bolts and nuts.
  7. Install the side curtain air bag module bolts.
  8. Install the headliner. Refer to " «REMOVAL AND INSTALLATION»(ref-388080-S05439423022011022800000) ".

The sunroof switch (1) is an integrated part of the front room/map lamp (2), and therefore serviced as an assembly. For front room/map lamp removal and installation procedures, refer to " REMOVAL AND INSTALLATION ".

Scheme 68

Scheme 68: Removal and Installation
Scheme 68: Removal and Installation

More articles — Roof
