Engine Lubrication System: Other Nissan Maxima A35

Lubrication System 18 illustrations ~1320 words

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted. Information necessary to service the system safely is included in the " SRS AIRBAG and SEAT BELTS " articles.

WARNINGTo avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SRS AIRBAG . Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNINGWhen working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service.

Scheme 9

Scheme 9: REMOVAL OF LIQUID GASKET SEALING
Scheme 9: REMOVAL OF LIQUID GASKET SEALING
  1. After removing nuts and bolts, separate the mating surface using Tool and remove old liquid gasket sealing. Tool number : KV10111100 (J-37228) CAUTION: Be careful not to damage the mating surfaces.
  2. Tap (1) Tool to insert it, and then slide it (2) by tapping on the side as shown in the figure.
  3. In areas where Tool is difficult to use, use plastic hammer to lightly tap the parts, to remove it. CAUTION: If for some unavoidable reason tool such as screwdriver is used, be careful not to damage the mating surfaces.

Scheme 10

Scheme 10: LIQUID GASKET APPLICATION PROCEDURE
Scheme 10: LIQUID GASKET APPLICATION PROCEDURE

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12
  1. Remove old liquid gasket adhering to the liquid gasket application surface and the mating surface, Using scraper. Remove liquid gasket completely from the groove of the liquid gasket application surface, bolts, and bolt holes.
  2. Thoroughly clean the mating surfaces and remove adhering moisture, grease and foreign materials.
  3. Attach liquid gasket tube to Tool. Tool number : WS39930000 (-) Use Genuine RTV Silicone Sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-388039-S31807235822011022800000) ".
  4. Apply liquid gasket without breaks to the specified location with the specified dimensions. If there is a groove for the liquid gasket application, apply liquid gasket to the groove. As for the bolt holes, normally apply liquid gasket inside the holes. Occasionally, it should be applied outside the holes. Make sure to read the text of service information. Within five minutes of liquid gasket application, install the mating component. If liquid gasket protrudes, wipe it off immediately. Do not retighten nuts or bolts after the installation. After 30 minutes or more have passed from the installation, fill engine oil and engine coolant. CAUTION: If there are specific instructions in this article, observe them.

Special Service Tool

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

SPECIAL SERVICE TOOLS DESCRIPTION CHART Tool number (Kent-Moore No.) Tool name Description ST25051001 (J-25695-1) Oil pressure gauge Measuring oil pressure Maximum measuring range: 2,452 kPa (25 kg-cm 2 , 356 psi) ST25052000 (J-25695-2) Hose Adapting oil pressure gauge to upper oil pan KV10115801 (J-38956) Oil filter wrench Removing and installing oil filter KV10111100 (J-37228) Seal cutter Removing steel oil pan and rear timing chain case WS39930000 (-) Tube presser Pressing the tube of liquid gasket

Scheme 13

Scheme 13: Special Service Tool
Scheme 13: Special Service Tool

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Commercial Service Tool

COMMERCIAL SERVICE TOOLS DESCRIPTION CHART Tool name Description Deep socket Removing and installing oil pressure switch Deep socket 26 mm, 3/8 drive Power tools Loosening nuts and bolts

Scheme 18

Scheme 18: Commercial Service Tool
Scheme 18: Commercial Service Tool

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20: Lubrication Circuit
Scheme 20: Lubrication Circuit

Scheme 21

Scheme 21: Schematic
Scheme 21: Schematic

OIL LEVEL

Note. Before starting the engine, check the oil level. If the engine is already started, stop it and allow 10 minutes before checking. Check that the oil level is within the range as indicated on the dipstick. If it is out of range, add oil as necessary until the dipstick indicates the correct level.

ENGINE OIL APPEARANCE

  1. Check engine oil for white milky appearance or excessive contamination.
  2. If engine oil becomes milky, it is highly probable that it is contaminated with engine coolant. Repair or replace damaged parts.

OIL LEAKAGE

Check for oil leakage around the following areas

  1. Oil pan
  2. Oil pan drain plug
  3. Oil pressure switch
  4. Oil filter
  5. Oil cooler
  6. IVT cover
  7. Front cover
  8. Mating surface between cylinder block and cylinder head
  9. Mating surface between cylinder head and rocker cover
  10. Crank oil seal (front and rear)

OIL PRESSURE CHECK

WARNINGBe careful not to burn yourself, as engine oil may be hot. Put the CVT shift selector in the Park "P" position.

Scheme 22

Scheme 22
Scheme 22
  1. Check the oil level. Refer to «OIL LEVEL»(ref-388050-S12552195292011022800000) .
  2. Remove engine under cover. Refer to " «EXPLODED VIEW»(ref-388049-S07537635232011022800000) ".
  3. Disconnect oil pressure switch harness connector at the oil pressure switch. Remove oil pressure switch using suitable tool and install Tools. CAUTION: Do not drop or shock oil pressure switch. Tool numbers : ST25051001 (J-25695-1) : ST25052000 (J-25695-2)
  4. Start the engine and warm it up to normal operating temperature.
  5. Check oil pressure with engine running under no-load, using Tool. If difference is extreme, check oil passage and oil pump for oil leaks.
  6. After the inspections, install the oil pressure switch using suitable tool as follows: Remove the old sealant adhering to oil pressure switch and engine. Apply thread sealant and tighten the oil pressure switch to specification. Use Genuine High Performance Thread Sealant, or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-388039-S31807235822011022800000) ". Oil pressure switch : " «EXPLODED VIEW»(ref-388044-S04031738122011022800000) " After warming up engine, make sure there are no engine oil leaks.
  7. Install engine under cover. Refer to " «EXPLODED VIEW»(ref-388049-S07537635232011022800000) ".

Changing Engine Oil

WARNINGBe careful not to burn yourself, as the engine oil may be hot. Prolonged and repeated contact with used engine oil may cause skin cancer; try to avoid direct skin contact with used oil. If skin contact is made, wash thoroughly with soap or hand cleaner as soon as possible.
  1. Position the vehicle so it is level on the hoist.
  2. Warm up the engine and check for oil leaks from the engine.
  3. Stop engine and wait for 10 minutes.
  4. Remove the oil pan drain plug and oil filler cap.
  5. Drain the engine oil.
  6. Install the oil pan drain plug with a new washer and refill the engine with new engine oil. Oil specification and viscosity : Refer to " «FOR NORTH AMERICA : ENGINE OIL RECOMMENDATION»(ref-388045-S38134069192011022800000) " or " «FOR MEXICO : ENGINE OIL RECOMMENDATION»(ref-388045-S11054915982011022800000) ". Oil pan drain plug : 34.3 N.m (3.5 kg-m, 25 ft-lb) CAUTION: Be sure to clean the oil pan drain plug and install with a new washer. The refill capacity depends on the oil temperature and drain time. Use the specifications for reference only. Always use the dipstick to determine when the proper amount of oil is in the engine.
  7. Warm up the engine and check around the oil pan drain plug and oil filter for oil leaks.
  8. Stop engine and wait for 10 minutes.
  9. Check the engine oil level using the dipstick. CAUTION: Do not overfill the engine oil.

Scheme 23

Scheme 23: REMOVAL
Scheme 23: REMOVAL

Scheme 24

Scheme 24
Scheme 24
  1. Drain engine oil. Refer to " «CHANGING ENGINE OIL»(ref-388050-S21659641782011022800000) ".
  2. Remove front fender protector side cover. Refer to " «EXPLODED VIEW»(ref-388049-S07537635232011022800000) ".
  3. Remove the oil filter using Tool (A) as shown in the figure. Tool number : KV10115801 (J-38956) WARNING: Be careful not to get burned; the engine oil may be hot. CAUTION: When removing, prepare a shop cloth to absorb any oil leakage or spillage. Do not allow engine oil to adhere to the drive belts. Completely wipe off any oil that adheres to the engine and the vehicle. The oil filter is provided with a relief valve. Use a genuine NISSAN oil filter or equivalent

Scheme 25

Scheme 25: INSTALLATION
Scheme 25: INSTALLATION

Scheme 26

Scheme 26
Scheme 26
  1. Remove foreign materials adhering to the oil filter installation surface.
  2. Apply clean engine oil to the oil seal contact surface of the new oil filter.
  3. Screw the oil filter manually until it touches the installation surface, then tighten it by turning another 2/3 turn, or tighten to specification using Tool. Oil filter : 18.0 N.m (1.8 kg-m, 13 ft-lb) Tool number : KV10115801 (J-38956)
  4. Refill the engine with new engine oil. Refer to " «CHANGING ENGINE OIL»(ref-388050-S21659641782011022800000) ".
  5. Check the oil level and add engine oil as necessary. Refer to " «INSPECTION»(ref-388050-S42239623232011022800000) ".
  6. After warming up the engine, check for engine oil leaks.
  7. Install front fender protector side cover. Refer to " «EXPLODED VIEW»(ref-388049-S07537635232011022800000) ".

Oil Pressure

Unit: kPa (kg/cm 2 , psi)
Engine speedApproximate discharge oil pressure
Idle speedMore than 98 (1.0, 14)
2,000 RPM294 (3.0, 43)

OIL PRESSURE SPECIFICATION CHART

Regulator Valve

Unit: mm (in)
Regulator valve to oil pump cover clearance0.040 - 0.097 (0.0016 - 0.0038)

REGULATOR VALVE SPECIFICATION CHART

Oil Pump

Unit: mm (in)
Body to outer rotor radial clearance0.114 - 0.260 (0.0045 - 0.0102)
Inner rotor to outer rotor tip clearanceBelow 0.180 (0.0071)
Body to inner rotor axial clearance0.030 - 0.070 (0.0012 - 0.0028)
Body to outer rotor axial clearance0.050 - 0.110 (0.0020 - 0.0043)
Inner rotor to brazed portion of housing clearance0.045 - 0.091 (0.0018 - 0.0036)

OIL PUMP SPECIFICATION CHART
