Interior Lighting System: Overhaul Nissan Maxima A35

Interior/illumination Lights 2 illustrations ~104 words

FRONT ROOM/MAP LAMP ASSEMBLY

Removal

Scheme 47

Scheme 47: FRONT ROOM/MAP LAMP ASSEMBLY

Scheme 47: FRONT ROOM/MAP LAMP ASSEMBLY

Release the metal clips and drop front edge of front room/map lamp assembly (1) away from headlining. Slide front room/map lamp assembly forward in vehicle to clear pawls at rear. <==: Vehicle front o:Pawl []:Metal clip
Disconnect the connectors, then remove the front room/map lamp assembly.

Installation

Installation is in the reverse order of removal.

Bulb or Lens Replacement

Scheme 48

Scheme 48

Scheme 48

Using a suitable tool (3), remove the front room/map lamp LH and/or RH lenses (2) as necessary.
Pull bulb (1) straight out to remove. Front room/map lamp bulb : 12V - 8W
