DETAILED FLOW
- INTERVIEW FOR MALFUNCTION Find out what the customer's concerns are. GO TO 2
- SYMPTOM CHECK Verify the symptom from the customer's information. GO TO 3
- BASIC INSPECTION Check the operation of each part. Check that any concerns occur other than those mentioned in the customer interview. GO TO 4
- SELF-DIAGNOSIS WITH CONSULT-III Perform the self-diagnosis with CONSULT-III. Check that any DTC is detected. Is any DTC detected? YES >> GO TO 5 NO >> GO TO 6
- TROUBLE DIAGNOSIS BY DTC Perform the trouble diagnosis for the detected DTC. Specify the malfunctioning part. GO TO 9
- FAIL-SAFE ACTIVATION CHECK Determine if the customer's concern is related to fail-safe activation. Does the fail-safe activate? YES >> GO TO 7 NO >> GO TO 8
- SYSTEM DIAGNOSIS Perform the system diagnosis for the system in which the fail-safe activates. Specify the malfunctioning part. GO TO 9
- SYMPTOM DIAGNOSIS Perform the symptom diagnosis. Specify the malfunctioning part. GO TO 9
- MALFUNCTION PART REPAIR Repair or replace the malfunctioning part. GO TO 10
- REPAIR CHECK (SELF-DIAGNOSIS WITH CONSULT-III) Perform the self-diagnosis with CONSULT-III. Verify that no DTCs are detected. Erase all DTCs detected prior to the repair. Verify that DTC is not detected again. Is any DTC detected? YES >> GO TO 5 NO >> GO TO 11
- REPAIR CHECK (OPERATION CHECK) Check the operation of each part. Does it operate normally? YES >> Inspection End NO >> GO TO 3
Scheme 50
INTERIOR LAMP BATTERY SAVER CONTROL
If an interior lamp is left ON and does not turn OFF even when the doors are closed, the BCM turns off power to the interior lamps automatically to save the battery 15 minutes after the ignition switch is turned OFF.
The BCM controls the interior lamps listed below
- Front step lamp LH and RH
- Rear step lamp LH and RH
- Front room/map lamp assembly
- Foot lamp LH and RH
- Personal lamp rear LH and RH
- Vanity mirror lamp LH and RH
- Trunk room lamp After the battery saver system turns the lamps OFF, the lamps will illuminate again when
- a signal is received from an Intelligent Key, main power window and door lock/unlock switch or power window and door lock/unlock switch RH, or when the front door LH lock assembly (key cylinder switch) is locked or unlocked
- a door is opened or closed
- the Intelligent Key is removed from or inserted into the key slot. The interior lamp battery saver control time period can be changed with the function setting of CONSULT-III.
Scheme 51
BATTERY SAVER CONTROL
When the lighting switch (combination switch) is in the 1ST or 2ND position and the ignition switch is turned from ON or ACC to OFF, the battery saver control feature is activated. Under this condition, the illumination lamps remain illuminated for 15 minutes unless the lighting switch position is changed. If the lighting switch position is changed, then the illumination lamps are turned off after a 30 second delay. When the lighting switch is turned from OFF to 1ST or 2ND position (or if auto light system is activated) after illumination lamps have been turned off by the battery saver control, the illumination lamps illuminate again.
DATA MONITOR
| Monitor Item [Unit] | Description |
|---|---|
| REQ SW-DR [On/Off] | Indicates condition of door request switch LH |
| REQ SW-AS [On/Off] | Indicates condition of door request switch RH |
| PUSH-SW [On/Off] | Indicates condition of push button ignition switch |
| ACC RLY-F/B [ON/OFF] | Indicates condition of accessory relay |
| UNLK SEN-DR [On/Off] | Indicates condition of door unlock sensor |
| KEY SW-SLOT [On/Off] | Indicates condition of key slot |
| DOOR SW-DR [On/Off] | Indicates condition of front door switch LH |
| DOOR SW-AS [On/Off] | Indicates condition of front door switch RH |
| DOOR SW-RR [On/Off] | Indicates condition of rear door switch RH |
| DOOR SW-RL [On/Off] | Indicates condition of rear door switch LH |
| DOOR SW-BK [On/Off] | Indicates condition of trunk switch |
| CDL LOCK SW [On/Off] | Indicates condition of lock signal from door lock and unlock switch |
| CDL UNLOCK SW [On/Off] | Indicates condition of unlock signal from door lock and unlock switch |
| KEY CYL LK-SW [On/Off] | Indicates condition of lock signal from door key cylinder switch |
| KEY CYL UN-SW [On/Off] | Indicates condition of unlock signal from door key cylinder switch |
| TRNK/HAT MNTR [ON/OFF] | Indicates condition of trunk room lamp switch |
| RKE-LOCK [On/Off] | Indicates condition of lock signal from Intelligent Key |
| RKE-UNLOCK [On/Off] | Indicates condition of unlock signal from Intelligent Key |
DATA MONITOR CHART
WORK SUPPORT
| Support Item | Setting | Description | |
|---|---|---|---|
| SET I/L D-UNLCK INTCON | On (1) | Interior room lamp timer function ON | |
| Off | Interior room lamp timer function OFF | ||
| ROOM LAMP TIMER SET | MODE 4 | 30 sec. | Sets the interior room lamp ON time. (Timer operating time) |
| MODE 3 (1) | 15 sec. | ||
| MODE 2 | 7.5 sec. | ||
| ROOM LAMP ON TIME SET | MODE 5 | 0 sec. | Sets the interior room lamp gradual brightening time. |
| MODE 4 | 3 sec. | ||
| MODE 3 | 2 sec. | ||
| MODE 2 (1) | 1 sec. | ||
| MODE 1 | 0.5 sec. | ||
| ROOM LAMP OFF TIME SET | MODE 5 | 0 sec. | Sets the interior room lamp gradual dimming time. |
| MODE 4 (1) | 3 sec. | ||
| MODE 3 | 2 sec. | ||
| MODE 2 | 1 sec. | ||
| MODE 1 | 0.5 sec. | ||
| R LAMP TIMER LOGIC SET | MODE 2 | Interior room lamp timer activates with all doors. | |
| MODE 1 (1) | Interior room lamp timer activates with the driver door only. | ||
| (1) Initial setting | |||
| (1) | Initial setting |
WORK SUPPORT CHART
| Monitor Item [Unit] | Description |
|---|---|
| REQ SW-DR [On/Off] | Indicates condition of door request switch LH |
| REQ SW-AS [On/Off] | Indicates condition of door request switch RH |
| PUSH SW [On/Off] | Indicates condition push button ignition switch |
| ACC RLY-F/B [On/Off] | Indicates condition of accessory relay |
| UNLK SEN-DR [On/Off] | Indicates condition of door unlock sensor |
| KEY SW-SLOT [On/Off] | Indicates condition of key slot |
| DOOR SW-DR [On/Off] | Indicates condition of front door switch LH |
| DOOR SW-AS [On/Off] | Indicates condition of front door switch RH |
| DOOR SW-RR [On/Off] | Indicates condition of rear door switch RH |
| DOOR SW-RL [On/Off] | Indicates condition of rear door switch LH |
| CDL LOCK SW [On/Off] | Indicates condition of lock signal from door lock and unlock switch |
| CDL UNLOCK SW [On/Off] | Indicates condition of unlock signal from door lock and unlock switch |
| KEY CYL LK-SW [On/Off] | Indicates condition of lock signal from door key cylinder switch |
| KEY CYL UN-SW [On/Off] | Indicates condition of unlock signal from door key cylinder switch |
| TRNK/HAT MNTR [On/Off] | Indicates condition of trunk room lamp switch |
| RKE-LOCK [On/Off] | Indicates condition of lock signal from Intelligent Key |
| RKE-UNLOCK [On/Off] | Indicates condition of unlock signal from Intelligent Key |
DATA MONITOR CHART
| Support Item | Setting | Description | |
|---|---|---|---|
| ROOM LAMP BAT SAV SET | ON (1) | Interior room lamp battery saver function ON | |
| OFF | Interior room lamp battery saver function OFF | ||
| ROOM LAMP TIMER SET | MODE 2 | 60 min. | Sets interior room lamp battery saver timer operating time |
| MODE 1 (1) | 15 min. | ||
| BATTERY SAVER SET | ON (1) | Exterior lamp battery saver function ON | |
| OFF | Exterior lamp battery saver function OFF | ||
| (1) Initial setting | |||
| (1) | Initial setting |
WORK SUPPORT CHART
| Monitor Item [Unit] | Main | Description |
|---|---|---|
| REQ SW-DR [On/Off] | X | Indicates condition of door request switch LH |
| REQ SW-AS [On/Off] | X | Indicates condition of door request switch RH |
| REQ SW-BD/TR [On/Off] | X | Indicates condition of trunk opener request switch |
| PUSH SW [On/Off] | Indicates condition of push button ignition switch | |
| IGN RLY2-F/B [On/Off] | Indicates condition of ignition relay 2 | |
| ACC RLY-F/B [On/Off] | Indicates condition of accessory relay | |
| BRAKE SW 1 [On/Off] | X | Indicates condition of brake switch |
| BRAKE SW 2 [On/Off] | Indicates condition of brake switch | |
| DETE/CANCL SW [On/Off] | X | Indicates condition of P position |
| SFT PN/N SW [On/Off] | X | Indicates condition of P or N position |
| UNLK SEN-DR [On/Off] | X | Indicates condition of door unlock sensor |
| PUSH SW-IPDM [On/Off] | Indicates condition of push button ignition switch received from IPDM E/R on CAN communication line | |
| IGN RLY1-F/B [On/Off] | Indicates condition of ignition relay 1 received from IPDM E/R on CAN communication line | |
| DETE SW-IPDM [On/Off] | Indicates condition of detent switch received from TCM on CAN communication line | |
| SFT PN-IPDM [On/Off] | Indicates condition of P or N position from TCM on CAN communication line | |
| SFT P-MET [On/Off] | Indicates condition of P position from TCM on CAN communication line | |
| SFT N-MET [On/Off] | Indicates condition of N position from IPDM E/R on CAN communication line | |
| ENGINE STATE [Stop/Start/Crank/Run] | X | Indicates condition of engine state from ECM on CAN communication line |
| VEH SPEED 1 [mph/km/h] | X | Indicates condition of vehicle speed signal received from ABS on CAN communication line |
| VEH SPEED 2 [mph/km/h] | X | Indicates condition of vehicle speed signal received from combination meter on CAN communication line |
| DOOR STAT-DR [LOCK/READY/UNLK] | X | Indicates condition of driver side door status. |
| DOOR STAT-AS [LOCK/READY/UNLK] | X | Indicates condition of passenger side door status. |
| ID OK FLAG [Set/Reset] | Indicates condition of Intelligent Key ID. | |
| PRMT ENG STRT [Set/Reset] | Indicates condition of engine start possibility. | |
| PRMT RKE STRT [Set/Reset] | Indicates condition of engine start possibility from Intelligent Key. | |
| KEY SW-SLOT [On/Off] | Indicates condition of key slot. | |
| TRNK/HAT MNTR [On/Off] | Indicates condition of trunk lid. | |
| RKE-LOCK [On/Off] | Indicates condition of lock signal from Intelligent Key. | |
| RKE-UNLOCK [On/Off] | Indicates condition of unlock signal from Intelligent Key. | |
| RKE-TR/BD [On/Off] | Indicates condition of trunk open signal from Intelligent Key. | |
| RKE-PANIC [On/Off] | Indicates condition of panic signal from Intelligent Key. | |
| RKE-P/W OPEN [On/Off] | Indicates condition of power window down signal from Intelligent Key. | |
| RKE-MODE CHG [On/Off] | Indicates condition of mode change signal from Intelligent Key. | |
| RKE OPE COUN1 [0-19] | X | When remote keyless entry receiver receives the signal transmitted while operating on Intelligent Key, the numerical value start changing. |
| RKE OPE COUN2 [0-19] | X | When remote keyless entry receiver receives the signal transmitted while operating on Intelligent Key, the numerical value start changing. |
| REVERSE SW [On/Off] | Indicates condition of reverse switch status. |
DATA MONITOR CHART
| Support Item | Setting | Description | |
|---|---|---|---|
| CONFIRM KEY FOB ID | MEMORY 1 | Intelligent Key ID code can be checked. | |
| MEMORY 2 | |||
| MEMORY 3 | |||
| MEMORY 4 | |||
| NON REGIST | |||
| AUTO LOCK SET | MODE 4 | 2 min | Auto door lock time can be set in this mode. |
| MODE 3 | 30 sec | ||
| MODE 2 | 5 min | ||
| MODE 1 (1) | 1 min | ||
| LOCK/UNLOCK BY I-KEY | On (1) | Door lock/unlock function by request switch ON. | |
| Off | Door lock/unlock function by request switch OFF. | ||
| ENGINE START BY I-KEY | On (1) | Engine start function from Intelligent Key ON. | |
| Off | Engine start function from Intelligent Key OFF. | ||
| TRUNK/GLASS HATCH OPEN | On (1) | Buzzer reminder function by trunk opener request switch ON. | |
| Off | Buzzer reminder function by trunk opener request switch OFF. | ||
| PANIC ALARM SET | MODE 3 | 1.5 sec | Panic alarm button set time on Intelligent Key can be set in this mode. |
| MODE 2 | OFF | ||
| MODE 1 (1) | 0.5 sec | ||
| PW DOWN SET | MODE 3 | 5 sec | Unlock button press time on Intelligent Key to lower front window can be set in this mode. |
| MODE 2 | OFF | ||
| MODE 1 (1) | 3 sec | ||
| TRUNK OPEN DELAY | MODE 3 | 1.5 sec | Trunk button pressing time on Intelligent Key button can be selected from the following with this mode. |
| MODE 2 | OFF | ||
| MODE 1 (1) | 0.5 sec | ||
| LO-BATT OF KEY FOB WARN | On (1) | Intelligent Key low battery warning mode ON. | |
| Off | Intelligent Key low battery warning mode OFF. | ||
| ANTI KEY LOCK IN FUNCTI | On (1) | Key reminder function mode ON. | |
| Off | Key reminder function mode OFF. | ||
| HAZARD ANSWER BACK | Lock/Unlock (1) | Hazard warning lamp activation when doors are locked or unlocked with Intelligent Key. | |
| Unlock Only | Hazard warning lamp activation when doors are unlocked with Intelligent Key. | ||
| Lock Only | Hazard warning lamp activation when doors are locked with Intelligent Key. | ||
| Off | No hazard warning lamp activation when doors are locked or unlocked with Intelligent Key. | ||
| ANS BACK I-KEY LOCK | Horn Chirp | Horn chirp reminder when doors are unlocked with Intelligent Key | |
| Buzzer (1) | Buzzer or horn chirp reminder when doors are unlocked with Intelligent Key | ||
| Off | No buzzer or horn chirp reminder when doors are unlocked with Intelligent Key | ||
| ANS BACK I-KEY UNLOCK | Off | No buzzer or horn chirp reminder when doors are unlocked with Intelligent Key | |
| On (1) | Buzzer or horn chirp reminder when doors are unlocked with Intelligent Key | ||
| SHORT CRANKING OUTPUT | Start | 70 msec | Starter motor operation duration times. |
| 100 msec | |||
| 200 msec | |||
| End | |||
| INSIDE ANT DIAGNOSIS | Start | This function allows inside key antenna self-diagnosis. | |
| HORN WITH KEYLESS LOCK | Off | No horn reminder activation when doors are locked with Intelligent Key. | |
| On (1) | Horn reminder activation when doors are locked with Intelligent Key. | ||
| (1) Initial Setting | |||
| (1) | Initial Setting |
WORK SUPPORT CHART
BCM : Special Repair Requirement
- REQUIRED WORK WHEN REPLACING BCM Initialize control unit. Refer to " «CONFIGURATION (BCM) : SPECIAL REPAIR REQUIREMENT»(ref-388072-S30068493832011022800000) ". Work End.
Component Function Check
- CHECK BATTERY SAVER OUTPUT/POWER SUPPLY FUNCTION CONSULT-III Turn ignition switch ON. Turn each interior room lamp ON. Front room/map lamp assembly Personal lamps rear Foot lamps Front step lamps Rear step lamps Trunk room lamp Vanity mirror lamps Select "BATTERY SAVER" of BCM (BATTERY SAVER) active test item. While operating the test item, check that each interior room lamp turns ON/OFF. OFF : Interior room lamp OFF ON : Interior room lamp ON Is the inspection result normal? YES >> Battery saver output/power supply circuit is normal. NO >> Refer to " «DIAGNOSIS PROCEDURE»(ref-388082-S40020338782011022800000) ".
| CAUTION | Before performing the diagnosis, check that the following is normal. Battery saver output/power supply Front room/map lamp assembly bulbs Personal lamp rear bulbs Foot lamp bulbs |
- CHECK INTERIOR ROOM LAMP CONTROL FUNCTION CONSULT-III Switch the front room/map lamp assembly to DOOR. Turn ignition switch ON. Select "INT LAMP" of BCM (INT LAMP) active test item. While operating the test item, check that each interior room lamp turns ON/OFF (gradual brightening/dimming). ON : Interior room lamp gradual brightening OFF : Interior room lamp gradual dimming Is the inspection result normal? YES >> Interior room lamp control circuit is normal. NO >> Refer to " «DIAGNOSIS PROCEDURE»(ref-388082-S00088899742011022800000) ".
| CAUTION | Before performing the diagnosis, check that the following is normal. Battery saver output/power supply Step lamp bulbs |
- CHECK STEP LAMP OPERATION CONSULT-III Turn ignition switch ON. Select "STEP LAMP TEST" of BCM (INT LAMP) active test item. While operating the test item, check that step lamps turn ON/OFF. ON : Step lamp ON OFF : Step lamp OFF Is the inspection result normal? YES >> Step lamp control circuit is normal. NO >> Refer to " «DIAGNOSIS PROCEDURE»(ref-388082-S37162995902011022800000) ".
| CAUTION | Before performing the diagnosis, check that the following is normal. Battery saver output/power supply Trunk room lamp bulb |
- CHECK TRUNK ROOM LAMP OPERATION CONSULT-III Turn ignition switch ON. Select "LUGGAGE LAMP TEST" of BCM (INT LAMP) active test item. While operating the test item, check that trunk room lamp turns ON/OFF. ON : Trunk room lamp ON OFF : Trunk room lamp OFF Is the inspection result normal? YES >> Trunk room lamp control circuit is normal. NO >> Refer to " «DIAGNOSIS PROCEDURE»(ref-388082-S17396940292011022800000) ".
- CHECK PUSH-BUTTON IGNITION SWITCH ILLUMINATION OPERATION CONSULT-III Turn the ignition switch ON. Select "ENGINE SW ILLUMI" of BCM (INTELLIGENT KEY) active test item. While operating the test item, check that the push-button ignition switch illumination turns ON/OFF ON : Push-button ignition switch illumination ON OFF : Push-button ignition switch illumination OFF Is the inspection result normal? YES >> Push-button ignition switch illumination circuit is normal. NO >> Refer to " «DIAGNOSIS PROCEDURE»(ref-388082-S05059823712011022800000) ".
Physical Values
ECU DIAGNOSIS INFORMATION CHART Terminal No. (Wire color) Description Condition Value (Approx.) (+) (-) Signal name Input/Output 1 (W/B) Ground Battery power supply Input Ignition switch OFF Battery voltage 2 (R/Y) Ground Battery power supply output Output Ignition switch OFF Battery voltage 3 (L/W) Ground Ignition power supply output Output Ignition switch ON Battery voltage 4 (P/W) Ground Interior room lamp power supply Output After passing the interior room lamp battery saver operation time v Any other time after passing the interior room lamp battery saver operation time Battery voltage 5 (G) Ground Front door RH UNLOCK Output Front door RH UNLOCK (actuator is activated) Battery voltage Other than UNLOCK (actuator is not activated) v 7 (R/W) Ground Step lamp Output Step lamp ON v OFF Battery voltage 8 (V) Ground All doors LOCK Output All doors LOCK (actuator is activated) Battery voltage Other than LOCK (actuator is not activated) v 9 (L) Ground Front door LH UNLOCK Output Front door LH UNLOCK (actuator is activated) Battery voltage Other than UNLOCK (actuator is not activated) v 10 (G) Ground Rear door RH and rear door LH UNLOCK Output Rear door RH and rear door LH UNLOCK (actuator is activated) Battery voltage Other than UNLOCK (actuator is not activated) v 11 (Y/R) Ground Battery power supply Input Ignition switch OFF Battery voltage 13 (B) Ground Ground - Ignition switch ON v 14 (OR/W) Ground Engine switch (push switch) illumination ground Input Tail lamp OFF v ON NOTE: When the illumination brightening/dimming level is in the neutral position 15 (Y/L) Ground ACC indicator lamp Output Ignition switch OFF Battery voltage ACC or ON v 17 (G/B) Ground Turn signal (RH) Output Ignition switch ON Turn signal switch OFF v Turn signal switch RH 18 (G/Y) Ground Turn signal (LH) Output Ignition switch ON Turn signal switch OFF v Turn signal switch LH 19 (Y) Ground Room lamp timer control Output Interior room lamp OFF Battery voltage ON v 21 (P/B) Ground Optical sensor signal Input Ignition switch ON When outside of the vehicle is bright Close to 5V When outside of the vehicle is dark Close to v 24 (R/W) Ground Stop lamp switch 1 Input - Battery voltage 26 (O/L) Ground Stop lamp switch 2 Input Stop lamp switch OFF (brake pedal is released) v ON (brake pedal is depressed) Battery voltage 27 (O) Ground Front door lock assembly LH (unlock sensor) Input Front door LH LOCK status UNLOCK status v 29 (Y) Ground Key slot switch Input When Intelligent Key is inserted into key slot Battery voltage When Intelligent Key is not inserted into key slot v 31 (G) Ground Rear window defogger feedback signal Input Rear window defogger switch OFF v ON Battery voltage 32 (R/B) Ground Front door RH switch Input Front door RH switch OFF (when front door RH closes) ON (when front door RH opens) v 37 (O) Ground Trunk lid opener cancel switch Input Trunk lid opener cancel switch CANCEL ON v 38 (OR/W) Ground Rear window defogger ON signal Input Rear window defogger switch OFF 5V ON v 40 (Y/G) Ground Power window serial link Input/Output Ignition switch ON Ignition switch OFF or ACC v 41 (W) Ground Engine switch (push switch) illumination Output Engine switch (push switch) illumination ON 5.5V OFF v 42 (R) Ground LOCK indicator lamp Output LOCK indicator lamp ON v OFF Battery voltage 45 (P) Ground Receiver & sensor ground Input Ignition switch ON v 46 (V/W) Ground Receiver & sensor power supply output Output Ignition switch OFF v ACC or ON 5.0V 47 (1) (G/O) Ground Tire pressure receiver signal Input/Output Ignition switch ON Standby state When receiving the signal from the transmitter 48 (R/G) Ground Selector lever transmission range switch signal Input Selector lever P or N position 12.0V Except P and N positions v 49 (L/O) Ground Security indicator signal Output Security indicator ON v Blinking OFF Battery voltage 50 (LG/B) Ground Combination switch INPUT 5 Output Combination switch (Wiper intermittent dial 4) All switch OFF v Lighting switch 1ST Lighting switch high-beam Lighting switch 2ND Turn signal switch RH 51 (L/W) Ground Combination switch INPUT 1 Output Combination switch All switch OFF (Wiper intermittent dial 4) v Front wiper switch HI (Wiper intermittent dial 4) Any of the conditions below with all switch OFF Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 3 Wiper intermittent dial 6 Wiper intermittent dial 7 52 (G/B) Ground Combination switch INPUT 2 Output Combination switch All switch OFF (Wiper intermittent dial 4) v Front washer switch ON (Wiper intermittent dial 4) Any of the conditions below with all switch OFF Wiper intermittent dial 1 Wiper intermittent dial 5 Wiper intermittent dial 6 53 (LG/R) Ground Combination switch INPUT 3 Output Combination switch (Wiper intermittent dial 4) All switch OFF v Front wiper switch INT Front wiper switch LO Lighting switch AUTO 54 (G/Y) Ground Combination switch INPUT 4 Output Combination switch (Wiper intermittent dial 4) All switch OFF v Front fog lamp switch ON Lighting switch 2ND Lighting switch flash-to-pass Turn signal switch LH 571 (W) Ground Tire pressure warning check switch Input - 5V 58 (SB) Ground Front door LH switch Input Front door LH switch OFF (front door LH CLOSE) ON (front door LH OPEN) v 59 (G/R) Ground Rear window defogger relay Output Rear window defogger Active Battery voltage Not activated v 60 (B/R) Ground Front console antenna 2 (-) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 61 (W/R) Ground Center console antenna 2 (+) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 62 (V) Ground Front outside handle RH antenna (-) Output When the front door RH request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 63 (P) Ground Front outside handle RH antenna (+) Output When the front door RH request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 64 (V) Ground Front outside handle LH antenna (-) Output When the front door LH request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 65 (P) Ground Front outside handle LH antenna (+) Output When the front door LH request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 68 (G/O) Ground NATS antenna amp (built in key slot) Input/Output During waiting Ignition switch is pressed while inserting the Intelligent Key into the key slot. Just after pressing ignition switch. Pointer of tester should move. 69 (O) Ground NATS antenna amp (built in key slot) Input/Output During waiting Ignition switch is pressed while inserting the Intelligent Key into the key slot. Just after pressing ignition switch. Pointer of tester should move. 70 (R/B) Ground Ignition relay-2 control Output Ignition switch OFF or ACC v ON Battery voltage 71 (L/O) Ground Remote keyless entry receiver signal Input/Output During waiting When operating either button on Intelligent Key 75 (R/Y) Ground Combination switch OUTPUT 5 Input Combination switch All switch OFF (Wiper intermittent dial 4) Front fog lamp switch ON (Wiper intermittent dial 4) Any of the conditions below with all switch OFF Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 6 Wiper intermittent dial 7 76 (R/G) Ground Combination switch OUTPUT 3 Input Combination switch All switch OFF (Wiper intermittent dial 4) Lighting switch high-beam (Wiper intermittent dial 4) Lighting switch 2ND (Wiper intermittent dial 4) Any of the conditions below with all switch OFF Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 3 78 (P) Ground CAN-L Input/Output - - 79 (L) Ground CAN-H Input/Output - - 80 (R/L) Ground Key slot illumination Output Key slot illumination OFF v Blinking ON Battery voltage 81 (LG) Ground ON indicator lamp Output Ignition switch OFF or ACC v ON Battery voltage 83 (L) Ground ACC relay control Output Ignition switch OFF v ACC or ON Battery voltage 84 (Y/R) Ground CVT shift selector Output - Battery voltage 87 (G/B) Ground Selector lever P position switch Input Selector lever P position v Any position other than P Battery voltage 88 (R) Ground Front door RH request switch Input Front door RH request switch ON (pressed) v OFF (not pressed) 89 (R) Ground Front door LH request switch Input Front door LH request switch ON (pressed) v OFF (not pressed) 90 (Y) Ground Blower fan motor relay control Output Ignition switch OFF or ACC v ON Battery voltage 91 (L/R) Ground Remote keyless entry receiver power supply Output Ignition switch OFF Battery voltage 95 (R/W) Ground Combination switch OUTPUT 1 Input Combination switch (Wiper intermittent dial 4) All switch OFF Turn signal switch LH Turn signal switch RH Front wiper switch LO Front washer switch ON 96 (P/B) Ground Combination switch OUTPUT 4 Input Combination switch All switch OFF (Wiper intermittent dial 4) Lighting switch AUTO (Wiper intermittent dial 4) Lighting switch 1ST (Wiper intermittent dial 4) Any of the conditions below with all switch OFF Wiper intermittent dial 1 Wiper intermittent dial 5 Wiper intermittent dial 6 97 (R/B) Ground Combination switch OUTPUT 2 Input Combination switch (Wiper intermittent dial 4) All switch OFF Lighting switch flash-to-pass Lighting switch 2ND Front wiper switch INT Front wiper switch HI 98 (G/O) Ground Hazard switch Input Hazard switch Pressed 0 V Not pressed 103 (V) Ground Trunk lid opening. Output Trunk lid Open (trunk lid opener actuator is activated) Battery voltage Close (trunk lid opener actuator is not activated) v 110 (V/W) Ground Trunk room lamp Output Trunk room lamp ON v OFF Battery voltage 114 (B) Ground Trunk room antenna 1 (-) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 115 (W) Ground Trunk room antenna 1 (+) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 118 (L/O) Ground Rear bumper antenna (-) Output When the trunk lid request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 119 (BR/W) Ground Rear bumper antenna (+) Output When the trunk lid request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 127 (BR/W) Ground Ignition relay (IPDM E/R) control Output Ignition switch OFF or ACC Battery voltage ON v 130 (W) Ground Trunk room lamp switch Input Trunk room lamp switch OFF (trunk is closed) ON (trunk is open) v 132 (R) Ground Starter motor relay control Output Ignition switch ON When selector lever is in P or N position and the brake is depressed Battery voltage When selector lever is in P or N position and the brake is not depressed v 140 (BR) Ground Engine switch (push switch) Input Engine switch (push switch) Pressed v Not pressed Battery voltage 141 (BR) Ground Trunk request switch Input Trunk request switch ON (pressed) v OFF (not pressed) 144 (OR) Ground Request switch buzzer Output Request switch buzzer Sounding v Not sounding Battery voltage 147 (L/R) Ground Trunk lid opener switch Input Trunk lid opener switch Pressed v Not pressed Battery voltage 148 (R/W) Ground Rear door RH switch Input Rear door RH switch OFF (when rear door RH closes) ON (when rear door RH opens) v 149 (R/B) Ground Rear door LH switch Input Rear door LH switch OFF (when rear door LH closes) ON (when rear door LH opens) v (1) With low tire pressure monitoring system
Scheme 52
Scheme 53
Scheme 54
Scheme 55
Scheme 56
Scheme 57
Scheme 58
Scheme 59
Scheme 60
Scheme 61
Scheme 62
Scheme 63
Scheme 64
Scheme 65
Scheme 66
Scheme 67
Scheme 68
Scheme 69
Scheme 70
Scheme 71
Scheme 72
Scheme 73
Scheme 74
Scheme 75
Fail Safe
| Display contents of CONSULT | Fail-safe | Cancellation |
|---|---|---|
| B2190: NATS ANTENNA AMP | Inhibit engine cranking | Erase DTC |
| B2191: DIFFERENCE OF KEY | Inhibit engine cranking | Erase DTC |
| B2192: ID DISCORD BCM-ECM | Inhibit engine cranking | Erase DTC |
| B2193: CHAIN OF BCM-ECM | Inhibit engine cranking | Erase DTC |
| B2195: ANTI-SCANNING | Inhibit engine cranking | Erase DTC |
| B2560: STARTER CONT RELAY | Inhibit engine cranking | 500 ms after the following CAN signal communication status has become consistent Starter control relay signal Starter relay status signal |
| B2562: LO VOLTAGE | Inhibit engine cranking | 100 ms after the power supply voltage increases to more than 8.8 V |
| B2608: STARTER RELAY | Inhibit engine cranking | 500 ms after the following signal communication status becomes consistent Starter motor relay control signal Starter relay status signal (CAN) |
| B260A: IGNITION RELAY | Inhibit engine cranking | 500 ms after the following conditions are fulfilled IGN relay (IPDM E/R) control signal: OFF (Battery voltage) Ignition ON signal (CAN to IPDM E/R): OFF (Request signal) Ignition ON signal (CAN from IPDM E/R): OFF (Condition signal) |
| B260F: ENG STATE SIG LOST | Maintains the power supply position attained at the time of DTC detection | When any of the following conditions is fulfilled Power position changes to ACC Receives engine status signal (CAN) |
| B2617: STARTER RELAY CIRC | Inhibit engine cranking | 1 second after the starter motor relay control inside BCM becomes normal |
| B2618: BCM | Inhibit engine cranking | 1 second after the ignition relay (IPDM E/R) control inside BCM becomes normal |
| B26E1: ENG STATE NO RECIV | Inhibit engine cranking | When any of the following conditions are fulfilled Power position changes to ACC Receives engine status signal (CAN) |
FAIL SAFE CHART
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or un-belted. Information necessary to service the system safely is included in the " SRS AIRBAG and SEAT BELTS " articles.
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SRS AIRBAG . Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
| WARNING | When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service. |
Precaution for Work
- When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
- When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
- Protect the removed parts with a shop cloth and prevent them from being dropped.
- Replace a deformed or damaged clip.
- If a part is specified as a non-reusable part, always replace it with new one.
- Be sure to tighten bolts and nuts securely to the specified torque.
- After installation is complete, be sure to check that each part works properly.
- Follow the steps below to clean components. Water soluble dirt: Dip a soft cloth into lukewarm water, and wring the water out of the cloth to wipe the dirty area. Then rub with a soft and dry cloth. Oily dirt: Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%), and wipe the dirty area. Then dip a cloth into fresh water, and wring the water out of the cloth to wipe the detergent off. Then rub with a soft and dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol, or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
Special Service Tool
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
SPECIAL SERVICE TOOL DESCRIPTION CHART Tool number (Kent-Moore No.) Tool name Description - (J-46534) Trim tool set For removing trim
Scheme 76
VANITY MIRROR LAMP
Removal
The vanity mirror lamp is replaced as part of the sunvisor assembly. Refer to " REMOVAL AND INSTALLATION ".
Installation
Installation is in the reverse order of removal.
Bulb or Lens Replacement
Scheme 77
- Using a suitable tool (1), remove the vanity mirror lamp LH and/or RH lenses (2) as necessary.
- Pull bulb (3) straight out to remove. Vanity mirror lamp bulb : 12V - 1.4W
GLOVE BOX LAMP
Removal
Scheme 78
- Remove the glove box assembly (1). Refer to " «REMOVAL AND INSTALLATION»(ref-388073-S31195668912011022800000) ".
- Rotate glove box lamp socket (3) counterclockwise to remove.
Installation
Installation is in the reverse order of removal.
Bulb Replacement
- Remove the glove box lamp. Refer to «REMOVAL AND INSTALLATION»(ref-388082-S32775265642011022800000) .
- Pull bulb (2) straight out to remove. Glove box lamp bulb : 12V - 3.4W
STEP LAMP
Removal
Scheme 79
- Insert a suitable tool between door finisher (2) and step lamp lens/socket (1) to release the pawls.
- Disconnect the step lamp connector, then remove step lamp.
Installation
Installation is in the reverse order of removal.
Bulb Replacement
- Remove the step lamp lens/socket.
- Pull the bulb straight out to remove. Step lamp bulb : 12V - 3.8W
FOOT LAMP
Removal
Scheme 80
- Using a suitable tool, release the pawls and remove the foot lamp from the instrument lower panel LH side, if servicing the left hand side foot lamp.
- Grasp foot lamp socket, then rotate counterclockwise to release from the foot lamp (LH) or from substrate - RH (1) as necessary. NOTE: Illustration shown below is of the RH side of the vehicle. LH side is similar.
Installation
Installation is in the reverse order of removal.
Bulb Replacement
- Remove the foot lamp. Refer to «FOOT LAMP REMOVAL AND INSTALLATION»(ref-388082-S34373387832011022800000)
- Pull bulb (2) straight out to remove. Foot lamp bulb : 12V - 3.4W
PERSONAL LAMP
Removal
The personal lamp is replaced as part of the headlining assembly. Refer to " REMOVAL AND INSTALLATION ".
Installation
Installation is in the reverse order of removal.
Bulb or Lens Replacement
Scheme 81
- Using a suitable tool, release the pawls and remove personal lamp lens (3) from the personal lamp (1). <==: Vehicle front
- Pull bulb (2) straight out to remove. Personal lamp bulb : 12V - 8W
TRUNK ROOM LAMP
Removal
Scheme 82
- Release the tab (A), then swing open the lens. <==: Vehicle front
- Remove the bulb (3).
- Release the tab (B), then pull trunk room lamp (2) away from body opening.
- Disconnect the connector (1) and remove trunk room lamp.
Installation
Installation is in the reverse order of removal.
Bulb Replacement
- Release the tab (A), then swing open the lens.
- Pull bulb (3) straight out to remove. Trunk room lamp bulb : 12V - 3.4W
