WITH COLOR DISPLAY : Discharge Air Flow
AUTOMATIC AIR CONDITIONER SYSTEM WITH COLOR DISPLAY - DISCHARGE AIR FLOW REFERENCE CHART Mode door position Air outlet/distribution Vent Foot Defroster 100% - - 57% 43% - 27% 50% 23% 27% 41% 32% 22% - 78%
Scheme 357
Scheme 358
WITH MONOCHROME DISPLAY : Discharge Air Flow
AUTOMATIC AIR CONDITIONER SYSTEM WITH MONOCHROME DISPLAY - DISCHARGE AIR FLOW REFERENCE CHART Mode door position Air outlet/distribution Vent Foot Defroster 100% - - 57% 43% - 27% 50% 23% 27% 41% 32% 22% - 78%
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS AIRBAG -- MAXIMA " and SEAT BELTS -- MAXIMA " articles.
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SRS AIRBAG . Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
| WARNING | When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service. |
Precaution for Procedure without Cowl Top Cover
When performing the procedure after removing cowl top cover, cover the lower end of windshield with urethane, etc.
Scheme 359
Precaution for Work
- When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
- When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
- Protect the removed parts with a shop cloth and prevent them from being dropped.
- Replace a deformed or damaged clip.
- If a part is specified as a non-reusable part, always replace it with new one.
- Be sure to tighten bolts and nuts securely to the specified torque.
- After installation is complete, be sure to check that each part works properly.
- Follow the steps below to clean components. Water soluble dirt: Dip a soft cloth into lukewarm water, and wring the water out of the cloth to wipe the dirty area. Then rub with a soft and dry cloth. Oily dirt: Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%), and wipe the dirty area. Then dip a cloth into fresh water, and wring the water out of the cloth to wipe the detergent off. Then rub with a soft and dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol, or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
Precautions For Xenon Headlamp Service
| WARNING | Comply with the following warnings to prevent any serious accident. Disconnect the battery cable (negative terminal) or the power supply fuse before installing, removing, or touching the xenon headlamp (bulb included). The xenon headlamp contains high-voltage generated parts. Never work with wet hands. Check the xenon headlamp ON-OFF status after assembling it to the vehicle. Never turn the xenon headlamp ON in other conditions. Connect the power supply to the vehicle-side connector. (Turning it ON outside the lamp case may cause fire or visual impairments.) Never touch the bulb glass immediately after turning it OFF. It is extremely hot. |
| CAUTION | Comply with the following cautions to prevent any error and malfunction. Install the xenon bulb securely. (Insufficient bulb socket installation may melt the bulb, the connector, the housing, etc. by high-voltage leakage or corona discharge.) Never perform HID circuit inspection with a tester. Never touch the xenon bulb glass with hands. Never put oil and grease on it. Dispose of the used xenon bulb after packing it in thick vinyl without breaking it. Never wipe out dirt and contamination with organic solvent (thinner, gasoline, etc.). |
Special Service Tool
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
SPECIAL SERVICE TOOL Tool number (Kent-Moore No.) Tool name Description - (J-46534) Trim tool set For removing trim
Scheme 360
Commercial Service Tool
COMMERCIAL SERVICE TOOL Tool number Tool name Description Power tool Removing bolts and nuts
Scheme 361
- Disengage the filter cover tab (1) by pushing up and pull out to remove the filter cover.
- Remove the in-cabin microfilter from the blower unit.
RH SIDE VENTILATOR GRILLE
| CAUTION | This procedure should only be used when replacing the RH side ventilator grille with a new one, as the side ventilator grille will be damaged during removal and cannot be reused. |
Scheme 362
- Remove the RH instrument side mask. Refer to " «REMOVAL AND INSTALLATION - INSTRUMENT PANEL»(ref-388073-S08312497292011022800000) ".
- Remove the glove box assembly. Refer to " «REMOVAL AND INSTALLATION - INSTRUMENT PANEL»(ref-388073-S08312497292011022800000) ".
- Depress the LH and RH bottom clips (A) and the LH upper clip (B) with suitable tools. CAUTION: Use care when inserting the suitable tool so as not to damage the instrument panel.
- Grip the front of the side ventilator grille with a suitable tool to pull from the front and use your hand to push from behind to remove the side ventilator grille from the instrument panel. Discard the side ventilator grille. CAUTION: The RH upper clip (C) will bend when the side ventilator grille is removed. Use care when removing the side ventilator grille so as not to damage the instrument panel. The side ventilator grille cannot be reused.
LH SIDE VENTILATOR GRILLE
| CAUTION | This procedure should only be used when replacing the LH side ventilator grille, as the side ventilator grille will be damaged during removal and cannot be reused. |
Scheme 363
- Remove the LH instrument side mask. Refer to " «REMOVAL AND INSTALLATION - INSTRUMENT PANEL»(ref-388073-S08312497292011022800000) ".
- Remove the instrument panel lower cover LH. Refer to " «REMOVAL AND INSTALLATION - INSTRUMENT PANEL»(ref-388073-S08312497292011022800000) ".
- Depress the LH and RH bottom clips (A) and the RH upper clip (B) with suitable tools. CAUTION: Use care when inserting the suitable tool so as not to damage the instrument panel.
- Grip the front of the side ventilator grille with a suitable tool to pull from the front and use your hand to push from behind to remove the side ventilator grille from the instrument panel. Discard the side ventilator grille. CAUTION: The LH upper clip (C) will bend when the side ventilator grille is removed. Use care when removing the side ventilator grille so as not to damage the instrument panel. The side ventilator grille cannot be reused.
