ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
| CAUTION | To adjust neutral position of steering angle sensor, make sure to use CONSULT-III (Adjustment cannot be done without CONSULT-III) |
- ALIGN THE VEHICLE STATUS Stop vehicle with front wheels in straight-ahead position. GO TO 2.
- PERFORM THE NEUTRAL POSITION ADJUSTMENT FOR THE STEERING ANGLE SENSOR On the CONSULT-III screen, touch "WORK SUPPORT", then "ST ANGLE SENSOR ADJUSTMENT". Touch "START". CAUTION: Do not touch steering wheel while adjusting steering angle sensor. After approximately 10 seconds, touch "END". NOTE: After approximately 60 seconds, the adjustment ends automatically. Turn ignition switch OFF, then turn it ON again. CAUTION: Be sure to perform above operation. GO TO 3.
- CHECK DATA MONITOR Run vehicle with front wheels in straight-ahead position, then stop. Select "DATA MONITOR". Then make sure "STR ANGLE SIG" is within 0±2.5°. Is the steering angle within the specified range? YES >> GO TO 4. NO >> Perform the neutral position adjustment for the steering angle sensor again, GO TO 1 .
- ERASE THE SELF-DIAGNOSIS MEMORY Erase the self-diagnosis memories of the ABS actuator and electric unit (control unit) and ECM. ABS actuator and electric unit (control unit): Refer to " «CONSULT-III FUNCTION (ABS)»(ref-388064-S11617694902011022800000) ". ECM: Refer to " «CONSULT-III FUNCTION»(ref-388048-S19706257472011022800000) ". Are the memories erased? YES >> Inspection End. NO >> Check the items indicated by the self-diagnosis.
Scheme 5
Scheme 6
Scheme 6: Hydraulic Circuit Diagram
