Front Wheel Alignment (Unladen *1)
Front Wheel Alignment - Service Data & Specification Tire size 225/55R17 245/45R18 Camber degree minute (decimal degree) Minimum -1°00' (-1.00°) Nominal -0°15' (-0.25°) Maximum 0°30' (0.50°) Left and right difference 45' (0.75°) or less Caster degree minute (decimal degree) Minimum 2°05' (2.08°) Nominal 2°50' (2.83°) Maximum 3°35' (3.58°) Left and right difference 45' (0.75°) or less Kingpin inclination degree minute (decimal degree) Minimum 13°50' (13.83°) Nominal 14°35' (14.58°) Maximum 15°20' (15.33°) Total toe-in Distance (A - B) mm (in) Minimum -0.5 (-0.020) Nominal 0.5 (0.020) Maximum 1.5 (0.059) Angle (left plus right) degree minute (decimal degree) Minimum --- Nominal 2' (0.03°) Maximum - Wheel turning angle full turn (2) Inside degree minute (decimal degree) Minimum 32°00' (32.0°) 31°00' (31.0°) Nominal 35°30' (35.5°) 34°30' (34.5°) Maximum 36°30' (36.5°) 35°30' (35.5°) Outside degree minute (decimal degree) Nominal 29°30' (29.0°) 28°30' (28.5°) (1) Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions. (2) On power steering models, wheel turning force (at circumference of steering wheel) of 98 to 147 N (10 to 15 kg, 22 to 33 lb) with engine idle
