Lan System: Wiring Nissan Maxima A34

Wiring Diagram - CAN

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

1. When there are no indications of "METER A/C AMP", "BCM" or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "METER A/C AMP", "BCM", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "METER A/C AMP", "BCM", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", put marks onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items which are not in check sheet table are not related to diagnostic procedure on service manual. Therefore, it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
5. Mark the "NG" or "UNKWN" item of the check sheet table from the result of CAN DIAG SUPPORT MONITOR check sheet. NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
6. According to the Check Sheet Results, start inspection.

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

1. When there are no indications of "METER A/C AMP", "BCM", "AUTO DRIVE POS." or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", put marks onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items which are not in check sheet table are not related to diagnostic procedure on service manual. Therefore, it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
5. Mark the "NG" or "UNKWN" item of the check sheet table from the result of CAN DIAG SUPPORT MONITOR check sheet. NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
6. According to the Check Sheet Results, start inspection.

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

1. When there are no indications of "METER A/C AMP", "BCM", "AUTO DRIVE POS." or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", put marks onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items which are not in check sheet table are not related to diagnostic procedure on service manual. Therefore, it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
5. Check CAN communication line of the navigation system.
6. Mark the "NG" or "UNKWN" item of the check sheet table from the result of CAN DIAG SUPPORT MONITOR check sheet. NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
7. According to the Check Sheet Results, start inspection.

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

1. When there are no indications of "METER A/C AMP", "BCM" or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "METER A/C AMP", "BCM", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "METER A/C AMP", "BCM", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", put marks onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items which are not in check sheet table are not related to diagnostic procedure on service manual. Therefore, it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
5. Mark the "NG" or "UNKWN" item of the check sheet table from the result of CAN DIAG SUPPORT MONITOR check sheet. NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
6. According to the Check Sheet Results, start inspection.

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

1. When there are no indications of "METER A/C AMP", "BCM", "AUTO DRIVE POS." or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", put marks onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items which are not in check sheet table are not related to diagnostic procedure on service manual. Therefore, it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
5. Mark the "NG" or "UNKWN" item of the check sheet table from the result of CAN DIAG SUPPORT MONITOR check sheet. NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
6. According to the Check Sheet Results, start inspection.

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

1. When there are no indications of "METER A/C AMP", "BCM", "AUTO DRIVE POS." or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", put marks onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items which are not in check sheet table are not related to diagnostic procedure on service manual. Therefore, it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
5. Check CAN communication line of the navigation system.
6. Mark the "NG" or "UNKWN" item of the check sheet table from the result of CAN DIAG SUPPORT MONITOR check sheet. NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
7. According to the Check Sheet Results, start inspection.

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

1. When there are no indications of "TRANSMISSION", "METER A/C AMP", "BCM" or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "TRANSMISSION", "METER A/C AMP", "BCM", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "TRANSMISSION", "METER A/C AMP", "BCM", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", put marks onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items which are not in check sheet table are not related to diagnostic procedure on service manual. Therefore, it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
5. Mark the "NG" or "UNKWN" item of the check sheet table from the result of CAN DIAG SUPPORT MONITOR check sheet. NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
6. According to the Check Sheet Results, start inspection.

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

1. When there are no indications of "TRANSMISSION", "METER A/C AMP", "BCM", "AUTO DRIVE POS." or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "TRANSMISSION", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "TRANSMISSION", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", put marks onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items which are not in check sheet table are not related to diagnostic procedure on service manual. Therefore, it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
5. Mark the "NG" or "UNKWN" item of the check sheet table from the result of CAN DIAG SUPPORT MONITOR check sheet. NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
6. According to the Check Sheet Results, start inspection.

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

1. When there are no indications of "TRANSMISSION", "METER A/C AMP", "BCM" or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "TRANSMISSION", "METER A/C AMP", "BCM", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "TRANSMISSION", "METER A/C AMP", "BCM", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", put marks onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items which are not in check sheet table are not related to diagnostic procedure on service manual. Therefore, it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
5. Check CAN communication line of the navigation system.
6. Mark the "NG" or "UNKWN" item of the check sheet table from the result of CAN DIAG SUPPORT MONITOR check sheet. NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
7. According to the Check Sheet Results, start inspection.

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

1. When there are no indications of "TRANSMISSION", "METER A/C AMP", "BCM", "AUTO DRIVE POS." or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "TRANSMISSION", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "TRANSMISSION", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", put marks onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items which are not in check sheet table are not related to diagnostic procedure on service manual. Therefore, it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
5. Check CAN communication line of the navigation system.
6. Mark the "NG" or "UNKWN" item of the check sheet table from the result of CAN DIAG SUPPORT MONITOR check sheet. NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
7. According to the Check Sheet Results, start inspection.

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

1. When there are no indications of "TRANSMISSION", "METER A/C AMP", "BCM" or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "TRANSMISSION", "METER A/C AMP", "BCM", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "TRANSMISSION", "METER A/C AMP", "BCM", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", put marks onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items which are not in check sheet table are not related to diagnostic procedure on service manual. Therefore, it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
5. Mark the "NG" or "UNKWN" item of the check sheet table from the result of CAN DIAG SUPPORT MONITOR check sheet. NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
6. According to the Check Sheet Results, start inspection.

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

1. When there are no indications of "TRANSMISSION", "METER A/C AMP", "BCM", "AUTO DRIVE POS." or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "TRANSMISSION", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "TRANSMISSION", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", put marks onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items which are not in check sheet table are not related to diagnostic procedure on service manual. Therefore, it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
5. Mark the "NG" or "UNKWN" item of the check sheet table from the result of CAN DIAG SUPPORT MONITOR check sheet. NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
6. According to the Check Sheet Results, start inspection.

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

1. When there are no indications of "TRANSMISSION", "METER A/C AMP", "BCM", "AUTO DRIVE POS." or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "TRANSMISSION", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "TRANSMISSION", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", put marks onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items which are not in check sheet table are not related to diagnostic procedure on service manual. Therefore, it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
5. Check CAN communication line of the navigation system.
6. Mark the "NG" or "UNKWN" item of the check sheet table from the result of CAN DIAG SUPPORT MONITOR check sheet. NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
7. According to the Check Sheet Results, start inspection.

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

1. When there are no indications of "TRANSMISSION", "METER A/C AMP", "BCM", "AUTO DRIVE POS." or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "TRANSMISSION", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "TRANSMISSION", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", put marks onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items which are not in check sheet table are not related to diagnostic procedure on service manual. Therefore, it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
5. Mark the "NG" or "UNKWN" item of the check sheet table from the result of CAN DIAG SUPPORT MONITOR check sheet. NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
6. According to the Check Sheet Results, start inspection.

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

1. When there are no indications of "TRANSMISSION", "METER A/C AMP", "BCM", "AUTO DRIVE POS." or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "TRANSMISSION", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "TRANSMISSION", "METER A/C AMP", "BCM", "AUTO DRIVE POS.", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", put marks onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items which are not in check sheet table are not related to diagnostic procedure on service manual. Therefore, it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
5. Check CAN communication line of the navigation system.
6. Mark the "NG" or "UNKWN" item of the check sheet table from the result of CAN DIAG SUPPORT MONITOR check sheet. NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
7. According to the Check Sheet Results, start inspection.
