Driver Information System: Other Nissan Maxima A34

Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.

Information necessary to service the system safely is included in SUPPLEMENTAL RESTRAINT SYSTEM (SRS) and SEAT BELTS .

UNIFIED METER CONTROL UNIT

1. Speedometer, odo/trip meter, tachometer, fuel gauge and water temperature gauge are controlled by the unified meter control unit, which is built into the combination meter. Unified meter control unit receives signals from unified meter and A/C amp.
2. Warning lamps and indicator lamps are controlled by signals drawn from the unified meter and A/C amp., BCM (body control module), and components connected directly to the combination meter.
3. Digital meter is adopted for odo/trip meter.* *The record of the odometer is kept even if the battery cable is disconnected. The record of the trip meter is erased when the battery cable is disconnected.
4. Odo/trip meter and A/T indicator segments can be checked in diagnosis mode.
5. Meters/gauges can be checked in diagnosis mode.

Illumination control

The unified meter control unit outputs the odo/trip meter and A/T indicator lighting when the ignition switch is turned ON. When the lighting switch is turned on, the illumination control switch can be used to adjust the brightness of the combination meter illumination and the odo/trip meter illumination. When the ignition switch is in the START position, the combination meter dial lighting and illumination control switch lighting are turned off. For additional combination meter illumination control information, refer to SYSTEM DESCRIPTION .

UNIFIED METER AND A/C AMP.

For unified meter and A/C amp. system description information, refer to SYSTEM DESCRIPTION .

Scheme 802

Scheme 803

1. The vehicle speed signal and the memory signals from the meter memory circuit are processed by the combination meter and the mileage is displayed.
2. Depressing the odo/trip meter switch toggles the mode in the following order.
3. The odo/trip meter display mode toggling and trip display resetting can be identified by the amount of time that elapses from pressing the odo/trip meter switch to releasing it.
4. When resetting with trip A displayed, only trip A display is reset. (Trip B operates the same way.)

POWER SUPPLY AND GROUND CIRCUIT

Power is supplied at all times

1. through 10A fuse [No.19, located in the fuse block (J/B)]
2. to combination meter terminal 24, and
3. to unified meter and A/C amp. terminal 21.

With the ignition switch in the ON or START position, power is supplied

1. through 10A fuse [No.14, located in the fuse block (J/B)]
2. to combination meter terminal 23, and
3. through 10A fuse [No.12, located in the fuse block (J/B)]
4. to unified meter and A/C amp. terminal 22.

With the ignition switch in the ON position, power is supplied

1. through 15A fuse [No.10, located in the fuse block (J/B)], and
2. through 15A fuse [No.11, located in the fuse block (J/B)]
3. to unified meter and A/C amp. terminal 46.

Ground is supplied

1. to combination meter terminals 10, 11 and 12, and
2. to unified meter and A/C amp. terminals 29 and 30
3. through body grounds M57, M61 and M79.

WATER TEMPERATURE GAUGE

The water temperature gauge indicates the engine coolant temperature.

ECM provides a water temperature signal to unified meter and A/C amp. via CAN communication lines. Unified meter and A/C amp. provides a water temperature signal to combination meter for water temperature gauge via communication line between unified meter and A/C amp. and combination meter.

TACHOMETER

The tachometer indicates engine speed in revolutions per minute (rpm).

ECM provides an engine speed signal to unified meter and A/C amp. via CAN communication lines. Unified meter and A/C amp. provides an engine speed signal to combination meter for tachometer via communication lines between unified meter and A/C amp. and combination meter.

FUEL GAUGE

The fuel gauge indicates the approximate fuel level in the fuel tank.

The fuel gauge is regulated by a variable ground signal supplied

1. from unified meter and A/C amp. terminal 36
2. through the fuel level sensor unit and fuel pump terminal 5
3. to unified meter and A/C amp. terminal 28 for the fuel gauge.

Unified meter and A/C amp. provides a fuel level signal to combination meter for fuel gauge via communication line between unified meter and A/C amp. and combination meter.

SPEEDOMETER

ABS actuator and electric unit (control unit) provides a vehicle speed signal to the unified meter and A/C amp. via CAN communication lines. After unified meter and A/C amp. receives the vehicle speed signal, it changes the signal to 8 pulse signal and provides the 8 pulse signal to the combination meter for the speedometer via communication line.

Scheme 804

Scheme 805

Scheme 806

CONSULT-II Function

Refer to CONSULT-II FUNCTION (METER A/C AMP) in "UNIFIED METER AND A/C AMP".

1. Depending on vehicle position or driving circumstance, the fuel in the tank shifts and the pointer may fluctuate.
2. If the vehicle is fueled with the ignition switch ON, the pointer will move slowly.

Scheme 807

Scheme 808

Scheme 809

1. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL Select "METER A/C AMP" on CONSULT-II. Using "FUEL METER" on the data monitor, compare the value of data monitor with fuel gauge pointer of combination meter. FUEL GAUGE POINTER REFERENCE VALUE CHART Fuel gauge pointer Reference value of data monitor (lit.) (Approx). Full 81 Three quarters 61 Half 41 One quarter 21 Empty 2 OK or NG OK: GO TO 2 . NG: Replace the combination meter. Refer to «COMBINATION METER»(ref-233659-S36449423402006052600000) .
2. CHECK FUEL LEVEL SENSOR Check components. Refer to «FUEL LEVEL SENSOR UNIT CHECK»(ref-233665-S27319765792006052600000) . OK or NG OK: GO TO 3 . NG: Replace the fuel level sensor unit, refer to «REMOVAL AND INSTALLATION»(ref-233664-S25417632902006052600000) .
3. CHECK FUEL LEVEL SENSOR CIRCUIT 1 Disconnect fuel level sensor unit and fuel pump connector B16 and unified meter and A/C amp. connector M50. Check continuity between fuel level sensor unit and fuel pump harness connector B16 terminal 2 (G) and unified meter and A/C amp. harness connector M50 terminal 28 (L). Continuity should exist. Check continuity between fuel level sensor unit and fuel pump harness connector B16 terminal 2 (G) and ground. Continuity should not exist. OK or NG OK: GO TO 4 . NG: Repair harness or connector.
4. CHECK FUEL LEVEL SENSOR CIRCUIT 2 Check continuity between fuel level sensor unit and fuel pump harness connector B16 terminal 5 (B) and unified meter and A/C amp. harness connector M50 terminal 36 (B/R). Continuity should exist. Check continuity between fuel level sensor unit and fuel pump harness connector B16 terminal 5 (B) and ground. Continuity should not exist. OK or NG OK: GO TO 5 . NG: Repair harness or connector.
5. CHECK INSTALLATION CONDITION Check fuel level sensor unit installation, and determine whether the float arm interferes or binds with any of the internal components in the fuel tank. OK or NG OK: Replace the unified meter and A/C amp. Refer to «REMOVAL AND INSTALLATION OF UNIFIED METER AND A/C AMP»(ref-233665-S26086829982006052600000) . NG: Install the fuel level sensor unit properly.

LOW-FUEL WARNING LAMP

Depending on vehicle position or driving circumstance, the fuel in the tank shifts and the warning lamp ON timing may change.

1. CHECK FUEL GAUGE Ensure the fuel level in the tank is high enough so the low-fuel warning lamp should not be on. Verify fuel gauge is operating properly. OK or NG OK: Replace the combination meter. Refer to «COMBINATION METER»(ref-233659-S36449423402006052600000) . NG: Go to «FUEL LEVEL SENSOR SIGNAL INSPECTION 1»(ref-233665-S41695859212006052600000) .

Scheme 810

Scheme 811

Scheme 812

Scheme 813

Scheme 814

Scheme 815

Scheme 816

Scheme 817

1. CHECK CONNECTOR Check combination meter, unified meter and A/C amp. and terminals (combination meter side, unified meter and A/C amp. side, and harness side) for looseness or bent terminals. OK or NG OK: GO TO 2 . NG: Repair terminal or connector.
2. CHECK METER/GAUGES VISUALLY Does the pointer on the meter/gauges fluctuate when starting the engine? Is the fluctuation acceptable? YES: GO TO 3 . NO: GO TO 6 .
3. CHECK CONTINUITY OF COMMUNICATION CIRCUIT (TX: COMBINATION METER) Turn ignition switch OFF. Disconnect combination meter and unified meter and A/C amp. connectors. Check continuity between combination meter harness connector M24 terminal 22 (BR/Y) and unified meter and A/C amp. harness connector M49 terminal 19 (BR/Y). Continuity should exist. Check continuity between combination meter harness connector M24 terminal 22 (BR/Y) and ground. Continuity should not exist. OK or NG OK: GO TO 4 . NG: Repair harness or connector.
4. CHECK VOLTAGE OF UNIFIED METER AND A/C AMP. Connect unified meter and A/C amp. connector. Turn ignition switch ON. Check voltage between combination meter harness connector M24 terminal 22 (BR/Y) and ground. Approx. 5 V OK or NG OK: GO TO 5 . NG: Replace the unified meter and A/C amp. Refer to «REMOVAL AND INSTALLATION OF UNIFIED METER AND A/C AMP.»(ref-233665-S26086829982006052600000) .
5. CHECK VOLTAGE SIGNAL OF COMBINATION METER Turn ignition switch OFF and connect combination meter connector. Turn ignition switch ON. Check voltage signal between combination meter harness connector M24 terminal 22 (BR/Y) and ground with simple oscilloscope of CONSULT-II. OK or NG OK: Replace the unified meter and A/C amp. Refer to «REMOVAL AND INSTALLATION OF UNIFIED METER AND A/C AMP.»(ref-233665-S26086829982006052600000) . NG: Replace the combination meter. Refer to «COMBINATION METER»(ref-233659-S36449423402006052600000) .
6. CHECK CONTINUITY OF COMMUNICATION CIRCUIT (RX: COMBINATION METER) Turn ignition switch OFF. Disconnect combination meter and unified meter and A/C amp. connectors. Check continuity between combination meter harness connector M24 terminal 21 (L/W) and unified meter and A/C amp. harness connector M49 terminal 9 (L/W). Continuity should exist. Check continuity between combination meter harness connector M24 terminal 21 (L/W) and ground. Continuity should not exist. OK or NG OK: GO TO 7 . NG: Repair harness or connector.
7. CHECK VOLTAGE OF COMBINATION METER Connect combination meter connector. Turn ignition switch ON. Check voltage between unified meter and A/C amp. harness connector M49 terminal 9 (L/W) and ground. Approx. 5 V OK or NG OK: GO TO 8 . NG: Replace the combination meter. Refer to «COMBINATION METER»(ref-233659-S36449423402006052600000) .
8. CHECK VOLTAGE SIGNAL OF UNIFIED METER AND A/C AMP. Turn ignition switch OFF and connect unified meter and A/C amp. connector. Turn ignition switch ON. Check voltage signal between combination meter harness connector M24 terminal 21 (L/W) and ground with simple oscilloscope of CONSULT-II. OK or NG OK: Replace the combination meter. Refer to «COMBINATION METER»(ref-233659-S36449423402006052600000) . NG: Replace the unified meter and A/C amp. Refer to «REMOVAL AND INSTALLATION OF UNIFIED METER AND A/C AMP.»(ref-233665-S26086829982006052600000) .

Fuel Gauge Pointer Fluctuates, Indicates Wrong Value, or Varies

1. CHECK FUEL GAUGE FLUCTUATION Test drive vehicle to see if gauge fluctuates only during driving or just before or just after stopping. Does the indication value vary only during driving or just before or just after stopping? YES: The pointer fluctuation may be caused by fuel level change in the fuel tank. Condition is normal. NO: Ask the customer about the situation when the symptom occurs in detail, and perform the trouble diagnosis.

Fuel Gauge Does Not Move to Full-position

1. QUESTION 1 Does it take a long time for the pointer to move to full-position? YES or NO YES: GO TO 2 . NO: GO TO 3 .
2. QUESTION 2 Was the vehicle fueled with the ignition switch ON? YES or NO YES: Be sure to fuel the vehicle with the ignition switch OFF. Otherwise, it will take a long time for the pointer to move to full-position because of the characteristic of the fuel gauge. NO: GO TO 3 .
3. QUESTION 3 Is the vehicle parked on an incline? YES or NO YES: Check the fuel level indication with vehicle on a level surface. NO: GO TO 4 .
4. QUESTION 4 During driving, does the fuel gauge pointer move gradually toward empty-position? YES or NO YES: Check the fuel level sensor unit. Refer to «FUEL LEVEL SENSOR UNIT CHECK»(ref-233665-S27319765792006052600000) . NO: Check fuel level sensor unit installation, and determine whether the float arm interferes or binds with any of the internal components in the fuel tank.

FUEL LEVEL SENSOR UNIT CHECK

For removal, refer to FUEL LEVEL SENSOR UNIT, FUEL FILTER AND FUEL PUMP ASSEMBLY .

Check Fuel Level Sensor Unit and Fuel Pump

Check resistance between fuel level sensor unit and fuel pump connector terminals 2 and 5.

Scheme 818

Scheme 819

Scheme 820

1. Remove the combination meter covers.
2. Remove 3 screws using power tool and remove the combination meter assembly.
3. Disconnect electrical connector and remove combination meter.

CONSULT-II Function (METER A/C AMP)

CONSULT-II can display each diagnostic item using the diagnostic test modes shown in the CONSULT-II METER A/C AMP DIAGNOSTIC TEST MODES table.

CONSULT-II METER A/C AMP DIAGNOSTIC TEST MODES

Display Item List

DISPLAY ITEM LIST

Note. Any monitored item that does not match the vehicle being diagnosed is deleted from the display automatically.

*1: Monitor keeps indicating "OFF" when brake warning lamp is on because of parking brake operation or low brake fluid level.

*2: CAN status indicates the condition of the CAN communication judged by each signal input.

1. Normal: If no problems were found in the past, CAN status indicates "0". If the system is presently operating properly, but had a malfunction in the past, the CAN status will indicate "39-1".
2. Malfunction: If there is a malfunction, CAN indicates "40".

After the system returns to its normal operating condition, every time the ignition switch is cycled (turned OFF from ON), a value will be removed from the counter (i.e. "39" "-->38" "-->37"... "1"). If a malfunction is detected again, CAN status indicates "40". (Although the system has returned to normal operating condition, "0" is not immediately indicated. To reset, select and press "ERASE" on the "SELF-DIAGNOSIS" screen.)

Scheme 821

1. Remove center stack assembly, refer to «CENTER STACK ASSEMBLY»(ref-233659-S23449832072006052600000) .
2. Remove unified meter and A/C amp. screws, and remove unified meter and A/C amp. from brackets. CAUTION: When carrying audio unit body, do not touch internal mechanism access from cassette tape slot. Be careful not to allow foreign material to enter from cassette tape slot. Use appropriate screws for each, as screws for audio unit are different from that for unified meter and A/C amp.

Power is supplied at all times

1. through 10A fuse [No. 19, located in the fuse block (J/B)]
2. to auto anti-dazzling inside mirror (compass) terminal 5.

With the ignition switch in ON or START

Power is supplied

1. through 10A fuse [No. 14, located in the fuse block (J/B)]
2. to auto anti-dazzling inside mirror (compass) terminal 6.

Ground is supplied at all times

1. to auto anti-dazzling inside mirror (compass) terminal 8
2. through body grounds M57, M61, and M79.

Zone Variation Change Procedure

The difference between magnetic North and geographical North can sometimes be great enough to cause false compass readings. This difference is known as variance. In order for the compass to operate properly (accurately) in a particular zone, the zone variation must be calibrated using the following procedure.

Scheme 822

Oil Pressure Warning Lamp Does Not Turn Off (Oil Pressure Is Normal)

Note. For oil pressure inspection, refer to OIL PRESSURE CHECK .

Scheme 823

Scheme 824

1. CHECK IPDM E/R OUTPUT SIGNAL Disconnect oil pressure switch connector. Turn ignition switch ON. Check voltage between oil pressure switch harness connector F106 terminal + (R/L) and ground. Battery voltage should exist. OK or NG OK: GO TO 2 . NG: GO TO 3 .
2. CHECK OIL PRESSURE SWITCH Turn ignition switch OFF. Check oil pressure switch. Refer to «OIL PRESSURE SWITCH»(ref-233665-S15779730192006052600000) . OK or NG OK: Replace the IPDM E/R, refer to «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-233661-S42132645482006052600000) . NG: Replace the oil pressure switch.
3. CHECK OIL PRESSURE SWITCH CIRCUIT Turn ignition switch OFF. Disconnect IPDM E/R connector E121. Check continuity between IPDM E/R harness connector E121 terminal 57 (P/L) and ground. Continuity should not exist. OK or NG OK: Replace the IPDM E/R, refer to «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-233661-S42132645482006052600000) . NG: Repair harness or connector.

OIL PRESSURE SWITCH

Check continuity between oil pressure switch and ground.

Scheme 825

OIL PRESSURE SWITCH SPECIFICATION

FUNCTION

Power is supplied at all times

1. through 50A fusible link (letter f , located in the fuse and fusible link box)
2. to BCM terminal 55, and
3. through 10A fuse [No. 21, located in the fuse block (J/B)]
4. to key switch and key lock solenoid terminal 3.

With ignition switch ON or in START position, power is supplied

1. through 10A fuse [No. 1, located in the fuse block (J/B)]
2. to BCM terminal 38.

Ground is supplied

1. to BCM terminal 52, and
2. to combination switch terminal 12
3. through body grounds M57, M61, and M79.

Note. When ignition key warning chime, light warning chime, and seat belt warning chime should be conducted at the same time, the priorities for each chime are the following.

1. Light warning chime
2. Ignition key warning chime
3. Seat belt warning chime

IGNITION KEY WARNING CHIME

With the key inserted in the ignition switch, the ignition switch in OFF position, and the driver's door open, the warning chime will sound.

Power is supplied

1. through key switch and key lock solenoid terminal 4
2. to BCM terminal 37.

Ground is supplied

1. to BCM terminal 62
2. through front door switch LH terminal 2.

Front door switch LH is case grounded.

BCM sends door open signal to unified meter and A/C amp. via CAN communication lines.

BCM detects key inserted into the ignition switch, and sends key warning signal to unified meter and A/C amp. via CAN communication lines. Unified meter and A/C amp. sends key warning signal to combination meter via communication line between unified meter and A/C amp. and combination meter.

When combination meter receives key warning signal, it sounds warning chime.

LIGHT WARNING CHIME

With the key removed from the ignition switch, the driver's door open, and the lighting switch (part of the combination switch) in 1st or 2nd position, the warning chime will sound. [This is the operation of the light warning chime, except when headlamp battery saver control operates (for 5 minutes after ignition switch is turned to OFF or ACC position) and headlamps do not illuminate.]

Signal is supplied

1. from combination switch (lighting switch) terminals 1, 2, 3, 4, 5, 6, 7, 8, 9 and 10
2. to BCM terminals 2, 3, 4, 5, 6, 32, 33, 34, 35 and 36. NOTE: BCM detected lighting switch in 1st or 2nd position. Refer to «COMBINATION SWITCH READING FUNCTION»(ref-233675-S29629016432006052600000) .

Ground is supplied

1. to BCM terminal 62
2. through front door switch LH terminal 2.

Front door switch LH is case grounded.

BCM sends door open signal to unified meter and A/C amp. via CAN communication lines.

BCM detects headlamps are illuminated, and sends light warning signal to unified meter and A/C amp. via CAN communication lines. Unified meter and A/C amp. sends light warning signal to combination meter via communication line between unified meter and A/C amp. and combination meter.

When combination meter receives light warning signal, it sounds warning chime.

SEAT BELT WARNING CHIME

When the ignition switch is turned ON with the seat belt unfastened [seat belt buckle switch LH unfastened], warning chime will sound for approximately 6 seconds.

Ground is supplied

1. to combination meter terminal 1
2. through seat belt buckle switch LH terminal 1.

Seat belt buckle switch LH terminal 2 is grounded through body grounds B7 and B19.

Combination meter sends seat belt buckle switch LH unfastened signal to unified meter and A/C amp. via communication line between unified meter and A/C amp. and combination meter.

BCM receives seat belt buckle switch LH unfastened signal from unified meter and A/C amp. via CAN communication line, and sends seat belt warning signal to unified meter and A/C amp. via CAN communication line.

Unified meter and A/C amp. sends seat belt warning signal to combination meter via communication line between unified meter and A/C amp. and combination meter.

When the combination meter receives the seat belt warning signal, it sounds the warning chime. The BCM controls the (6 second) duration of the seat belt warning chime.

CONSULT-II Function (BCM)

CONSULT-II can display each diagnostic item using the diagnostic test modes shown (Scheme 826).

Scheme 826

Data Monitor Item

CONSULT-II DATA MONITOR ITEM SPECIFICATIONS (SWITCHES)

CONSULT-II DISPLAY - CAN COMMUNICATION DESCRIPTION

Note. If "CAN communication [U1000]" is indicated, after printing the monitor item, go to "CAN System". Refer to CAN COMMUNICATION .

Scheme 827

Scheme 828

1. CHECK CHIME OPERATION Select "BUZZER" on CONSULT-II, and perform "LIGHT WARN ALM", "IGN KEY WARN ALM", OR "SEAT BELT WARN TEST" active test. Does chime sound? YES: Replace the BCM. Refer to «REMOVAL AND INSTALLATION OF BCM»(ref-233675-S19678858802006052600000) . NO: GO TO 2 .
2. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL Select "METER A/C AMP" on CONSULT-II. Observe "BUZZER" of data monitor while operating switches in order to meet the requirements to sound warning chime. When requirements are met to: BUZZER ON sound warning chime Except above: BUZZER OFF OK or NG OK: Replace the combination meter. Refer to «COMBINATION METER»(ref-233659-S36449423402006052600000) . NG: Replace the BCM. Refer to «REMOVAL AND INSTALLATION OF BCM»(ref-233675-S19678858802006052600000) .

Scheme 829

Scheme 830

Scheme 831

Scheme 832

1. CHECK BCM INPUT SIGNAL With CONSULT-II Select "BCM" on CONSULT-II. With "DATA MONITOR" of "BUZZER", confirm "DOOR SW-DR" changes with the status of front door LH. When front door LH is opened: DOOR SW-DR ON When front door LH is closed: DOOR SW-DR OFF Without CONSULT-II Check continuity between BCM harness connector M20 terminal 62 (SB) and ground. When front door LH is opened: Continuity should exist. When front door LH is closed: Continuity should not exist. OK or NG OK: Replace the BCM. Refer to «REMOVAL AND INSTALLATION OF BCM»(ref-233675-S19678858802006052600000) . NG: GO TO 2 .
2. CHECK FRONT DOOR SWITCH LH CIRCUIT Turn ignition switch OFF. Disconnect BCM connector and front door switch LH connector. Check continuity between BCM harness connector M20 terminal 62 (SB) and front door switch LH harness connector B8 terminal 2 (SB). Continuity should exist. Check continuity between BCM harness connector M20 terminal 62 (SB) and ground. Continuity should not exist. OK or NG OK: GO TO 3 . NG: Repair harness or connector.
3. CHECK FRONT DOOR SWITCH LH AND GROUND CIRCUIT Check continuity between front door switch LH terminal 2 and ground while switching the door switch from ON (open) to OFF (closed). When front door LH is opened: Continuity should exist. When front door LH is closed: Continuity should not exist. OK or NG OK: Replace the BCM. Refer to «REMOVAL AND INSTALLATION OF BCM»(ref-233675-S19678858802006052600000) . NG: Replace the front door switch LH.

Scheme 833

Scheme 834

Scheme 835

Scheme 836

Scheme 837

Scheme 838

Scheme 839

1. CHECK FUSE Check if the key switch fuse [fuse 21, located in the fuse block (J/B)] is blown. Refer to «WIRING DIAGRAM - CHIME»(ref-233665-S24278981532006052600000) . Is the fuse blown? YES: Replace the fuse. Be sure to repair the cause of malfunction before installing new fuse. NO: GO TO 2 .
2. CHECK WARNING CHIME OPERATION With key removed from the ignition and the front door LH open, turn the lighting switch to 1st or 2nd position. Does warning chime sound? YES: GO TO 3 . NO: Go to «ALL WARNING CHIMES DO NOT OPERATE»(ref-233665-S08874152122006052600000) or «KEY WARNING CHIME AND LIGHT WARNING CHIME DO NOT OPERATE (SEAT BELT WARNING CHIME DOES OPERATE)»(ref-233665-S29943119982006052600000) .
3. CHECK BCM INPUT SIGNAL With CONSULT-II Check key switch ("KEY ON SW") in "DATA MONITOR" mode with CONSULT-II. Select "BCM". With "DATA MONITOR" of "BUZZER", confirm "KEY ON SW" changes when the key is inserted/removed from the ignition key cylinder. When key is inserted in ignition key cylinder: KEY ON SW ON When key is removed from ignition key cylinder: KEY ON SW OFF Without CONSULT-II Check voltage between BCM harness connector M18 terminal 37 (B/R) and ground. OK or NG OK: Replace the BCM. Refer to «REMOVAL AND INSTALLATION OF BCM»(ref-233675-S19678858802006052600000) . NG: GO TO 4 .
4. CHECK KEY SWITCH Disconnect key switch and key lock solenoid connector. Check continuity between key switch and key lock solenoid terminals 3 and 4. OK or NG OK: GO TO 5 . NG: Replace the key switch and key lock solenoid.
5. CHECK KEY SWITCH CIRCUIT Disconnect BCM connector M18. Check continuity between BCM harness connector M18 terminal 37 (B/R) and key switch and key lock solenoid harness connector M27 terminal 4 (B/R). Continuity should exist. Check continuity between BCM harness connector M18 terminal 37 (B/R) and ground. Continuity should not exist. OK or NG OK: GO TO 6 . NG: Repair harness or connector.
6. CHECK KEY SWITCH POWER SUPPLY CIRCUIT Check voltage between key switch and key lock solenoid harness connector M27 terminal 3 (Y/B) and ground. Battery voltage should exist. OK or NG OK: Replace the BCM. Refer to «REMOVAL AND INSTALLATION OF BCM»(ref-233675-S19678858802006052600000) . NG: Check harness for open between key switch and key lock solenoid and fuse.

Scheme 840

1. CHECK WARNING CHIME OPERATION Check key warning chime and seat belt warning chime functions. Do key warning chime and seat belt warning chime sound? YES: GO TO 2 . NO: Go to «ALL WARNING CHIMES DO NOT OPERATE»(ref-233665-S08874152122006052600000) .
2. CHECK BCM INPUT SIGNAL Select "BCM". With "DATA MONITOR" of "BUZZER", confirm "LIGHT SW 1ST" status changes when the lighting switch is moved from ON (1st position) to OFF. Lighting switch ON (1st position): LIGHT SW 1ST ON Lighting switch OFF: LIGHT SW 1ST OFF OK or NG OK: Replace the BCM. Refer to «REMOVAL AND INSTALLATION OF BCM»(ref-233675-S19678858802006052600000) . NG: Check lighting switch. Refer to «COMBINATION SWITCH»(ref-233676-S17687485942006052600000) .

Scheme 841

Scheme 842

Scheme 843

Scheme 844

Scheme 845

Scheme 846

1. CHECK WARNING CHIME OPERATION With key removed from the ignition and the front door LH open, turn the lighting switch to 1st or 2nd position. Return lighting switch to OFF position, and insert key into ignition. Does warning chime sound for both steps? YES: GO TO 2 . NO: Go to «ALL WARNING CHIMES DO NOT OPERATE»(ref-233665-S08874152122006052600000) .
2. CHECK BCM INPUT SIGNAL With "SEAT BELT ALM" on the data monitor, confirm "SEAT BELT SW" when the seat belt buckle switch LH is operated. Select "METER A/C AMP". With "DATA MONITOR" of "METER A/C AMP", confirm "SEAT BELT W/L" status changes with the operation of the seat belt. When seat belt LH is fastened: SEAT BELT W/L OFF When seat belt LH is unfastened: SEAT BELT W/L ON OK or NG OK: Replace the BCM. Refer to «REMOVAL AND INSTALLATION OF BCM»(ref-233675-S19678858802006052600000) . NG: GO TO 3 .
3. CHECK COMBINATION METER INPUT SIGNAL Turn ignition switch ON. Check voltage between combination meter harness connector M24 terminal 1 (O) and ground. OK or NG OK: Replace the combination meter. Refer to «COMBINATION METER»(ref-233659-S36449423402006052600000) . NG: GO TO 4 .
4. CHECK SEAT BELT BUCKLE SWITCH Turn ignition switch OFF. Disconnect seat belt buckle switch LH connector. Check continuity between seat belt buckle switch LH harness connector P15 terminals 1 and 2. OK or NG OK: GO TO 5 . NG: Replace the seat belt buckle switch LH.
5. CHECK SEAT BELT BUCKLE SWITCH CIRCUIT Disconnect combination meter connector. Check continuity between combination meter harness connector M24 terminal 1 (O) and seat belt buckle switch LH harness connector P15 terminal 1 (O). Continuity should exist. Check continuity between combination meter harness connector M24 terminal 1 (O) and ground. Continuity should not exist. OK or NG OK: Check seat belt buckle switch ground circuit. NG: Repair harness or connector.
