Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp SRS (Airbag)
  2. 2 - 15 Amp Air Conditioner
  3. 3 - 15 Amp Air Conditioner
  4. 4 - 7.5 Amp A/T TP/SW
  5. 5 - 7.5 Amp Tail Light, Turn Signal Switch
  6. 6 - 15 Amp Horn
  7. 7 - 10 Amp Power Mirror, Mirror Heaters
  8. 8 - 10 Amp
  9. 9 - 10 Amp
  10. 10 - 15 Amp Tail Light, ABS, ASCD
  11. 11 - 10 Amp Turn Signal
  12. 12 - 7.5 Amp Power Window, Door Locks, Sunroof, Time Control Unit
  13. 13 - 10 Amp Meter, ABS, ASCD, Back-up Lights, Air Bag, Warning Chime
  14. 14 - 7.5 Amp Corner, Turn
  15. 15 - 10 Amp ABS
  16. 16 - 7.5 Amp
  17. 17 - 10 Amp A/C, Fuel Pump, Canister, EGR, Cooling Fan, ASCD
  18. 18 - 7.5 Amp Illumination
  19. 19 - 7.5 Amp Wiper & Washer
  20. 20 - 20 Amp Wiper Washer Timer
  21. 21 - 10 Amp Horn, Audio, Power Antenna
  22. 22 - 15 Amp Audio
  23. 23 - 10 Amp
  24. 24 - 10 Amp
  25. 25 - 15 Amp
  26. 26 - 7.5 Amp Step/L, Room
  27. 27 - 10 Amp
  28. 28 - 7.5 Amp 29 - 7.5 Amp Heated Seats
  29. 30 - 20 Amp A/C
  30. 31 - 10 Amp
  31. 32 - 15 Amp Fuel Pump
  32. 33 - 10 Amp Theft Warning System
  33. 34 - 10 Amp Fuel, R02H
  34. 35 - 15 Amp
  35. 36 - 7.5 Amp
  36. 37 - 10 Amp TLID, MULTI
  37. 38 - 7.5 Amp Rear Defogger
  38. 39 - 7.5 Amp Rear Defogger
  39. 40 - 20 Amp Door Lock, Horn, Multi, SRS, Power Antenna, Timer

Scheme 1

Scheme 1: UNDERHOOD FUSE & FUSIBLE LINK IDENTIFICATION

Fuse Identification

  1. 1 - 15 Amp Light Switch
  2. 2 - 7.5 Amp Horn, Headlamp
  3. 3 - 10 Amp Horn, ASCD, Theft
  4. 4 - 15 Amp Front Fog
  5. 5 - Not Used
  6. 6 - 7.5 Amp A/C FICD
  7. 7 - 7.5 Amp Charge
  8. 8 - 10 Amp Main, POS, MAFS
  9. 9 - 7.5 Amp Main, POS, MAFS
  10. 10 - 7.5 Amp Steplight
  11. 11 - 15 Amp Headlight, DTRL
  12. 12 - 15 Amp Headlight, DTRL, Corner, Fog
WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.
  1. A - 120 Amp Main
  2. B - 75 Amp Fuse Box
  3. C - 30 Amp ABS
  4. D - 30 Amp Ignition Switch
  5. E - 30 Amp ABS
  6. F - 30 Amp Power Seat (Circuit Breaker), Power Window, Door Lock
  7. G - 30 Amp Radiator Fan System, Air Conditioner
  8. H - 30 Amp Radiator Fan System, Air Conditioner
  9. J - 65 Amp Relay Box
