Interior Lighting System: Removal & Installation Nissan Juke I facelift

Interior/illumination Lights 8 illustrations ~284 words

REMOVAL

CAUTIONDisconnect the battery negative terminal or remove power circuit fuse when performing the operation for preventing electric leakage.

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3
  1. Disengage lens fixing pawls using a remover tool (A), and then remove lens (1). CAUTION: Use a remover tool wrapped in tape. Insert a remover tool into the gap between bulb housing and lens.
  2. Disengage bulb housing (1) fixing pawl using a remover tool (A) according to numerical order 1-->2 indicated by the arrows as shown in the figure below. CAUTION: Use a remover tool wrapped in tape.
  3. Disconnect map lamp harness connector, and then remove bulb housing.

INSTALLATION

Install in the reverse order of removal.

Replacement

CAUTIONDisconnect the battery negative terminal or remove power circuit fuse when performing the operation for preventing electric leakage. Never touch the glass surface of the bulb with bare hands or allow oil or grease to get on it for preventing damage to the bulb. The surface of the bulb is very hot just after the lamp is turned OFF. Never touch the glass surface of the bulb with bare hands for preventing burns. Leaving the bulb removed from housing for a long period of time can deteriorate performance of the lens and reflector (due to dirt or clouding). Always prepare a new bulb and have it on hand when replacing the bulb.

Scheme 4

Scheme 4: MAP LAMP BULB
Scheme 4: MAP LAMP BULB
  1. Disengage lens fixing pawls using a remover tool (A), and then remove lens (1). CAUTION: Use a remover tool wrapped in tape. Insert a remover tool into the gap between bulb housing and lens.
  2. Remove bulb.

Scheme 5

Scheme 5: Exploded View
Scheme 5: Exploded View
CAUTIONDisconnect the battery negative terminal or remove power circuit fuse when performing the operation for preventing electric leakage. Never touch the glass surface of the bulb with bare hands or allow oil or grease to get on it for preventing damage to the bulb. The surface of the bulb is very hot just after the lamp is turned OFF. Never touch the glass surface of the bulb with bare hands for preventing burns. Leaving the bulb removed from housing for a long period of time can deteriorate performance of the lens and reflector (due to dirt or clouding). Always prepare a new bulb and have it on hand when replacing the bulb.

Scheme 6

Scheme 6: GLOVE BOX LAMP BULB
Scheme 6: GLOVE BOX LAMP BULB
  1. Remove glove box assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-621414-S19239322442014061000000) ".
  2. Rotate the bulb & socket assembly counterclockwise and unlock it, and then remove bulb & socket assembly.

Scheme 7

Scheme 7: Exploded View
Scheme 7: Exploded View
CAUTIONDisconnect the battery negative terminal or remove power circuit fuse when performing the operation for preventing electric leakage. When removing, always use a remover tool that is made of plastic to prevent damage to the parts.

Scheme 8

Scheme 8
Scheme 8
  1. Disengage luggage room lamp fixing pawl using a remover tool (A) according to numerical order 1-->2 indicated by the arrows as shown in the figure below. CAUTION: Insert a remover tool into the gap between luggage room lamp and luggage side lower finisher RH.
  2. Disconnect luggage room lamp harness connector, and then remove luggage room lamp.

Install in the reverse order of removal.

CAUTIONDisconnect the battery negative terminal or remove power circuit fuse when performing the operation for preventing electric leakage. Never touch the glass surface of the bulb with bare hands or allow oil or grease to get on it for preventing damage to the bulb. The surface of the bulb is very hot just after the lamp is turned OFF. Never touch the glass surface of the bulb with bare hands for preventing burns. Leaving the bulb removed from housing for a long period of time can deteriorate performance of the lens and reflector (due to dirt or clouding). Always prepare a new bulb and have it on hand when replacing the bulb.

Scheme 9

Scheme 9: LUGGAGE ROOM LAMP BULB
Scheme 9: LUGGAGE ROOM LAMP BULB
  1. Remove luggage room lamp. Refer to " «REMOVAL AND INSTALLATION»(ref-621431-S19967161912014061000000) ".
  2. Disengage shade fixing pawls using a remover tool (A) according to the direction indicated by the arrow as shown in the figure below. CAUTION: Use remover tool wrapped in tape.
  3. Remove shade, and then remove bulb.
