Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are buckled or unbuckled. Information necessary to service the system safely is included in the SRS AIRBAG and SEAT BELTS of this Service Information.
| WARNING | Always observe the following items for preventing accidental activation. To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision that would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see " SRS AIRBAG ". Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
| WARNING | Always observe the following items for preventing accidental activation. When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the ignition ON or engine running, never use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service. |
Scheme 11
Scheme 11: Precautions for Removing Battery Terminal
- When removing the 12V battery terminal, turn OFF the ignition switch and wait at least 30 seconds. NOTE: ECU may be active for several tens of seconds after the ignition switch is turned OFF. If the battery terminal is removed before ECU stops, then a DTC detection error or ECU data corruption may occur.
- For vehicles with the 2-batteries, be sure to connect the main battery and the sub battery before turning ON the ignition switch. NOTE: If the ignition switch is turned ON with any one of the terminals of main battery and sub battery disconnected, then DTC may be detected.
- After installing the 12V battery, always check "Self Diagnosis Result" of all ECUs and erase DTC. NOTE: The removal of 12V battery may cause a DTC detection error.
Scheme 12
Scheme 12: INTERIOR LIGHTING SYSTEM: Component Parts Location
| Part | Description |
|---|
| BCM | Controls the interior lighting system. |
| IPDM E/R | Controls the integrated relay according to the request signal from BCM (via CAN communication). |
| Remote keyless entry receiver | Receives the lock/unlock signal form Keyfob. |
| Combination switch (Lighting & turn signal switch) | Refer to " COMBINATION SWITCH READING SYSTEM: SYSTEM DESCRIPTION ". |
| Door lock and unlock switch Door request switch | Inputs the lock/unlock signal to BCM. |
| Door switch | Inputs the door switch signal to BCM. |
| Back door switch | Inputs the back door switch signal to BCM. |
| Unlock sensor | Detects door lock condition of driver side door. |
| Optical sensor | Refer to " COMPONENT DESCRIPTION ". |
Scheme 13
Scheme 13: INTERIOR ROOM LAMP CONTROL SYSTEM: System Diagram
OUTLINE
- Interior room lamps* are controlled by interior room lamp timer control function of BCM. *: Map lamp (when map lamp switch is in DOOR position).
- Luggage room lamp is controlled by luggage room lamp control function of BCM.
- Push-button ignition switch illumination is controlled by the push-button ignition switch illumination control function of BCM. (With Intelligent Key)
INTERIOR ROOM LAMP TIMER CONTROL
Interior Room Lamp Timer Basic Operation
Scheme 14
Scheme 14: INTERIOR ROOM LAMP TIMER CONTROL
- The interior room lamp turns ON and OFF (gradual brightening and dimming) by the interior room lamp timer.
- BCM judges the vehicle condition with the following items. It activates the interior room lamp timer. Ignition switch status *1 Door switch signal (except back door) Door lock/unlock signal (Remote keyless entry receiver, each door request switch *1 , door lock and unlock switch, key cylinder switch) Key switch signal *2 *1 : With Intelligent Key *2 : Without Intelligent Key
Note. Each function of interior room lamp timer can be set by CONSULT. Refer to " INT LAMP: CONSULT FUNCTION (BCM - INT LAMP) ".
Interior Room Lamp ON Operation
- BCM always turns the interior room lamp ON when any door opens except back door.
- BCM activates the interior room lamp timer in any of the following conditions to turn the interior room lamp ON for a period of time. Status of all doors except back door changes from open to close Ignition switch is turned ON --> OFF Door unlock signal is detected when all doors close except back door with ignition switch OFF
Note. The timer restarts if new condition is input during the timer operating time.
Interior Room Lamp OFF Operation
BCM stops the timer in any of the following conditions to turn the interior room lamp OFF.
- The timer operating time is expired
- Ignition switch is turned OFF --> ACC/ON
- Door lock signal is detected with all doors close except back door.
LUGGAGE ROOM LAMP CONTROL
BCM turns luggage room lamp ON when the following condition is detected.
BCM turns luggage room lamp OFF when the following condition is detected.
PUSH-BUTTON IGNITION SWITCH ILLUMINATION CONTROL (WITH INTELLIGENT KEY)
Push-button Ignition Switch Illumination Basic Operation
BCM provides the power supply to turn the push-button ignition switch illumination ON.
Push-button Ignition Switch Illumination ON Operation
BCM turns the push-button ignition switch illumination ON in the following conditions.
- Ignition switch ON
- Any of the following conditions with ignition switch OFF/ACC Engine start permission is entered Driver side door is LOCK --> UNLOCK Driver side door is open
Push-button Ignition Switch Illumination OFF Operation
BCM turns the push-button ignition switch illumination OFF in any of the following conditions.
- The push-button ignition switch illumination ON conditions do not satisfy.
- Any of the following conditions with ignition switch OFF. The push-button ignition switch illumination ON conditions do not change (15 seconds after the ignition switch OFF) Driver side door is UNLOCK --> LOCK
Scheme 15
Scheme 15: INTERIOR ROOM LAMP BATTERY SAVER SYSTEM: System Diagram
- Interior room lamp battery saver is controlled by BCM.
- BCM turns applicable lamps OFF depending on the vehicle condition. This function prevents the battery from over-discharging if the driver neglects turning OFF the lamps.
- Map lamp
- Luggage room lamp
INTERIOR ROOM LAMP BATTERY SAVER FUNCTION
- When the ignition switch is turned to other position than ON, BCM operates the timer for a period of time to cut the interior room lamp power supply.
- BCM restarts the timer when any of the following signals changes while operating the timer. Ignition switch status *1 Key switch status *2 Door switch signal (ALL) Door lock/unlock signal (remote keyless entry receiver, each door request switch*1, door lock and unlock switch, key cylinder switch)
- BCM provides the interior room lamp power supply continuously when the ignition switch position is ON. *1 : With Intelligent Key *2 : Without Intelligent Key
Note. Each function of interior room lamp battery saver can be set by CONSULT. Refer to " BATTERY SAVER: CONSULT FUNCTION (BCM - BATTERY SAVER) ".
Scheme 16
Scheme 16: ILLUMINATION CONTROL SYSTEM: System Diagram
Each illumination lamp is controlled by each function of BCM and IPDM E/R.
- Combination switch reading function
- Headlamp control function
Control by combination meter
- Meter illumination control function (Refer to " «SPEEDOMETER: SYSTEM DESCRIPTION»(ref-621397-S22721794212014061000000) ".)
ILLUMINATION CONTROL
- BCM detects the combination switch condition by the combination switch reading function.
- BCM transmits position light request signal to IPDM E/R and combination meter according to tail lamp ON condition.
- Lighting switch 1ST
- Lighting switch 2ND
- Lighting switch AUTO, and the auto light function ON judgment (With auto light system)
- IPDM E/R turns the integrated tail lamp relay ON according to position light request signal. It provides the power supply to each illumination lamp.
- Combination meter enters in the nighttime mode according to position light request signal. Under the nighttime mode the combination meter controls the illuminance by controlling the each illumination lamp (ground side).
FREEZE FRAME DATA (FFD)
The BCM records the following vehicle condition at the time a particular DTC is detected, and displays on CONSULT.
| CONSULT screen item | Indication/Unit | Description |
|---|
| Vehicle Speed | Km/h | Vehicle speed of the moment a particular DTC is detected |
| ODO/Trip Meter | Km | Total mileage (Odometer value) of the moment a particular DTC is detected |
| Vehicle Condition | SLEEP>LOCK | Power position status of the moment a particular DTC is detected | While turning BCM status from low power consumption mode to normal mode (Power position is "LOCK" (1) .) |
| SLEEP>OFF | While turning BCM status from low power consumption mode to normal mode (Power position is "OFF".) |
| LOCK>ACC | While turning power position from "LOCK" (1) (1) to "ACC" |
| ACC>ON | While turning power position from "ACC" to "IGN" |
| RUN>ACC | While turning power position from "RUN" to "ACC" (Vehicle is stopping and selector lever is except P position.) |
| CRANK>RUN | While turning power position from "CRANKING" to "RUN" (From cranking up the engine to run it) |
| RUN>URGENT | While turning power position from "RUN" to "ACC" (Emergency stop operation) |
| ACC>OFF | While turning power position from "ACC" to "OFF" |
| OFF>LOCK | While turning power position from "OFF" to "LOCK" (1) |
| OFF>ACC | While turning power position from "OFF" to "ACC" |
| ON>CRANK | While turning power position from "IGN" to "CRANKING" |
| OFF>SLEEP | While turning BCM status from normal mode (Power position is "OFF".) to low power consumption mode |
| LOCK>SLEEP | While turning BCM status from normal mode (Power position is "LOCK" (1) .) to low power consumption mode |
| LOCK | Power position is "LOCK" (1) |
| OFF | Power position is "OFF" (Ignition switch OFF) |
| ACC | Power position is "ACC" (Ignition switch ACC) |
| ON | Power position is "IGN" (Ignition switch ON with engine stopped) |
| ENGINE RUN | Power position is "RUN" (Ignition switch ON with engine running) |
| CRANKING | Power position is "CRANKING" (At engine cranking) |
| IGN Counter | 0 - 39 | The number of times that ignition switch is turned ON after DTC is detected The number is 0 when a malfunction is detected now. The number increases like 1 --> 2 --> 3...38 --> 39 after returning to the normal condition whenever ignition switch OFF --> ON. The number is fixed to 39 until the self-diagnosis results are erased if it is over 39. |
| NOTE: (1) Power position shifts to "LOCK" from "OFF", when ignition switch is in the OFF position, selector lever is in the P position (A/T models and CVT models), and any of the following conditions are met. Closing door Opening door Door is locked using door request switch Door is locked using Intelligent Key The power position shifts to "ACC" when the push-button ignition switch (push switch) is pushed at "LOCK". |
| NOTE |
|---|
| (1) Power position shifts to "LOCK" from "OFF", when ignition switch is in the OFF position, selector lever is in the P position (A/T models and CVT models), and any of the following conditions are met. Closing door Opening door Door is locked using door request switch Door is locked using Intelligent Key The power position shifts to "ACC" when the push-button ignition switch (push switch) is pushed at "LOCK". |
| (1) | Power position shifts to "LOCK" from "OFF", when ignition switch is in the OFF position, selector lever is in the P position (A/T models and CVT models), and any of the following conditions are met. |
Scheme 17
| Service item | Setting item | Setting |
|---|
| ROOM LAMP TIMER SET | MODE 2 | 7.5 sec. | Sets the interior room lamp ON time. (Timer operating time) |
| MODE 3 (1) | 15 sec. |
| MODE 4 | 30 sec. |
| SET I/L D-UNLCK INTCON | On (1) | With the interior room lamp timer function |
| Off | Without the interior room lamp timer function |
| ROOM LAMP ON TIME SET | MODE 1 | 0.5 sec. | Sets the interior room lamp gradual brightening time. |
| MODE 2 (1) | 1 sec. |
| MODE 3 | 2 sec. |
| MODE 4 | 3 sec. |
| MODE 5 | 0 sec. |
| ROOM LAMP OFF TIME SET | MODE 1 | 0.5 sec. | Sets the interior room lamp gradual dimming time. |
| MODE 2 (1) | 1 sec. |
| MODE 3 | 2 sec. |
| MODE 4 | 3 sec. |
| MODE 5 | 0 sec. |
| R LAMP TIMER LOGIC SET | MODE 1 (1) | Interior room lamp timer activates with synchronizing all doors. |
| MODE 2 | Interior room lamp timer activates with synchronizing the driver door only. |
| (1) Factory setting |
DATA MONITOR
Note. The following table includes information (items) inapplicable to this vehicle. For information (items) applicable to this vehicle, refer to CONSULT display items.
| Monitor item [Unit] | Description |
|---|
| REQ SW-DR [On/Off] | Indicated [On/Off] condition of door request switch (driver side) |
| REQ SW-AS [On/Off] | Indicated [On/Off] condition of door request switch (passenger side) |
| REQ SW-RR [On/Off] | NOTE: This item is displayed, but cannot be monitored |
| REQ SW-RL [On/Off] | NOTE: This item is displayed, but cannot be monitored |
| PUSH SW [On/Off] | Indicates [On/Off] condition of push-button ignition switch |
| UNLK SEN-DR [On/Off] | Indicates [On/Off] condition of driver door UNLOCK status |
| DOOR SW-DR [On/Off] | Indicated [On/Off] condition of front door switch (driver side) |
| DOOR SW-AS [On/Off] | Indicated [On/Off] condition of front door switch (passenger side) |
| DOOR SW-RR [On/Off] | Indicated [On/Off] condition of rear door switch RH |
| DOOR SW-RL [On/Off] | Indicated [On/Off] condition of rear door switch LH |
| DOOR SW-BK [On/Off] | Indicated [On/Off] condition of back door switch |
| CDL LOCK SW [On/Off] | Indicated [On/Off] condition of lock signal from door lock unlock switch |
| CDL UNLOCK SW [On/Off] | Indicated [On/Off] condition of unlock signal from door lock unlock switch |
| TRNK/HAT MNTR [On/Off] | NOTE: This item is displayed, but cannot be monitored |
| KEY CYL LK-SW [On/Off] | Indicated [On/Off] condition of lock signal from door key cylinder |
| KEY CYL UN-SW [On/Off] | Indicated [On/Off] condition of unlock signal from door key cylinder |
| RKE-LOCK [On/Off] | Indicates [On/Off] condition of LOCK signal from Intelligent Key |
| RKE-UNLOCK [On/Off] | Indicates [On/Off] condition of UNLOCK signal from Intelligent Key |
| NOTE |
|---|
| This item is displayed, but cannot be monitored |
| NOTE |
|---|
| This item is displayed, but cannot be monitored |
| NOTE |
|---|
| This item is displayed, but cannot be monitored |
WORK SUPPORT
| Service item | Setting item | Setting |
|---|
| ROOM LAMP TIMER SET | MODE 1 | 30 min. | Sets the interior room lamp battery saver timer operating time. NOTE: The factor setting is 10 minutes. The setting cannot be returned to the factory setting, when the setting is changed once. |
| MODE 2 | 60 min. |
| MODE 3 | 15 min. |
| BATTERY SAVER SET | On (1) | With the exterior lamp battery saver function |
| Off | Without the exterior lamp battery saver function |
| (1) Factory setting |
| NOTE |
|---|
| The factor setting is 10 minutes. The setting cannot be returned to the factory setting, when the setting is changed once. |
Note. The following table includes information (items) inapplicable to this vehicle. For information (items) applicable to this vehicle, refer to CONSULT display items.
| Monitor item [Unit] | Description |
|---|
| REQ SW-DR [On/Off] | Indicated [On/Off] condition of door request switch (driver side) |
| REQ SW-AS [On/Off] | Indicated [On/Off] condition of door request switch (passenger side) |
| REQ SW-RR [On/Off] | NOTE: This item is displayed, but cannot be monitored |
| REQ SW-RL [On/Off] | NOTE: This item is displayed, but cannot be monitored |
| PUSH SW [On/Off] | Indicates [On/Off] condition of push-button ignition switch |
| UNLK SEN-DR [On/Off] | Indicates [On/Off] condition of driver door UNLOCK status |
| DOOR SW-DR [On/Off] | Indicated [On/Off] condition of front door switch (driver side) |
| DOOR SW-AS [On/Off] | Indicated [On/Off] condition of front door switch (passenger side) |
| DOOR SW-RR [On/Off] | Indicated [On/Off] condition of rear door switch RH |
| DOOR SW-RL [On/Off] | Indicated [On/Off] condition of rear door switch LH |
| DOOR SW-BK [On/Off] | Indicated [On/Off] condition of back door switch |
| CDL LOCK SW [On/Off] | Indicated [On/Off] condition of lock signal from door lock unlock switch |
| CDL UNLOCK SW [On/Off] | Indicated [On/Off] condition of unlock signal from door lock unlock switch |
| TRNK/HAT MNTR [On/Off] | NOTE: This item is displayed, but cannot be monitored |
| KEY CYL LK-SW [On/Off] | Indicated [On/Off] condition of lock signal from door key cylinder |
| KEY CYL UN-SW [On/Off] | Indicated [On/Off] condition of unlock signal from door key cylinder |
| RKE-LOCK [On/Off] | Indicates [On/Off] condition of LOCK signal from Intelligent Key |
| RKE-UNLOCK [On/Off] | Indicates [On/Off] condition of UNLOCK signal from Intelligent Key |
| NOTE |
|---|
| This item is displayed, but cannot be monitored |
| NOTE |
|---|
| This item is displayed, but cannot be monitored |
| NOTE |
|---|
| This item is displayed, but cannot be monitored |
Note. The following table includes information (items) inapplicable to this vehicle. For information (items) applicable to this vehicle, refer to CONSULT display items.
| Monitor item [Unit] | Description |
|---|
| IGN ON SW [On/Off] | Indicated [On/Off] condition of ignition switch in ON position |
| KEY ON SW [On/Off] | Indicated [On/Off] condition of key switch |
| DOOR SW-DR [On/Off] | Indicated [On/Off] condition of front door switch (driver side) |
| DOOR SW-AS [On/Off] | Indicated [On/Off] condition of front door switch (passenger side) |
| DOOR SW-RR [On/Off] | Indicated [On/Off] condition of rear door switch RH |
| DOOR SW-RL [On/Off] | Indicated [On/Off] condition of rear door switch LH |
| BACK DOOR SW [On/Off] | Indicated [On/Off] condition of back door switch |
| LOCK STATUS [On/Off] | The switch status input from door lock status switch (driver side) |
| CDL LOCK SW [On/Off] | Indicates [On/Off] condition of door lock and unlock switch |
| CDL UNLOCK SW [On/Off] | Indicates [On/Off] condition of door lock and unlock switch |
| KEYLESS LOCK [On/Off] | Indicates [On/Off] condition of lock signal from keyfob |
| KEYLESS UNLOCK [On/Off] | Indicates [On/Off] condition of unlock signal from keyfob |
| TRNK/HAT MNTR [On/Off] | NOTE: This item is displayed, but cannot be tested |
| KEY CYL LK-SW [On/Off] | Indicated [On/Off] condition of lock signal from door key cylinder |
| KEY CYL UN-SW [On/Off] | Indicated [On/Off] condition of unlock signal from door key cylinder |
| ACC ON SW [On/Off] | Indicates [On/Off] condition of ignition switch in ACC position |
| NOTE |
|---|
| This item is displayed, but cannot be tested |
| Service item | Setting item | Setting |
|---|
| ROOM LAMP TIMER SET | MODE 1 | 30 min. | Sets the interior room lamp battery saver timer operating time. NOTE: The factor setting is 10 minutes. The setting cannot be returned to the factory setting, when the setting is changed once. |
| MODE 2 | 60 min. |
| MODE 3 | 15 min. |
| *:Factory setting |
| NOTE |
|---|
| The factor setting is 10 minutes. The setting cannot be returned to the factory setting, when the setting is changed once. |
Note. The following table includes information (items) inapplicable to this vehicle. For information (items) applicable to this vehicle, refer to CONSULT display items.
| Monitor item [Unit] | Description |
|---|
| IGN ON SW [On/Off] | Indicated [On/Off] condition of ignition switch in ON position |
| KEY ON SW [On/Off] | Indicated [On/Off] condition of key switch |
| DOOR SW-DR [On/Off] | Indicated [On/Off] condition of front door switch (driver side) |
| DOOR SW-AS [On/Off] | Indicated [On/Off] condition of front door switch (passenger side) |
| DOOR SW-RR [On/Off] | Indicated [On/Off] condition of rear door switch RH |
| DOOR SW-RL [On/Off] | Indicated [On/Off] condition of rear door switch LH |
| BACK DOOR SW [On/Off] | Indicated [On/Off] condition of back door switch |
| LOCK STATUS [On/Off] | The switch status input from door lock status switch (driver side) |
| CDL LOCK SW [On/Off] | Indicates [On/Off] condition of door lock and unlock switch |
| CDL UNLOCK SW [On/Off] | Indicates [On/Off] condition of door lock and unlock switch |
| KEYLESS LOCK [On/Off] | Indicates [On/Off] condition of lock signal from keyfob |
| KEYLESS UNLOCK [On/Off] | Indicates [On/Off] condition of unlock signal from keyfob |
| TRNK/HAT MNTR [On/Off] | NOTE: This item is displayed, but cannot be tested |
| KEY CYL LK-SW [On/Off] | Indicated [On/Off] condition of lock signal from door key cylinder |
| KEY CYL UN-SW [On/Off] | Indicated [On/Off] condition of unlock signal from door key cylinder |
| ACC ON SW [On/Off] | Indicates [On/Off] condition of ignition switch in ACC position |
| NOTE |
|---|
| This item is displayed, but cannot be tested |
WITH INTELLIGENT KEY: List of ECU Reference
| ECU | Reference |
|---|
| BCM | " REFERENCE VALUE " |
| " FAIL-SAFE " |
| " DTC INSPECTION PRIORITY CHART " |
| " DTC INDEX " |
WITHOUT INTELLIGENT KEY: List of ECU Reference
| ECU | Reference |
|---|
| BCM | " REFERENCE VALUE " |
| " FAIL-SAFE " |
| " DTC INSPECTION PRIORITY CHART " |
| " DTC INDEX " |
Scheme 18
Scheme 18: Wiring Diagram
Scheme 19
Scheme 20
Scheme 20: Connector End Views
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
Scheme 26
Scheme 26: Wiring Diagram
Scheme 27
Scheme 28
Scheme 29
Scheme 29: Connector End Views
Scheme 30
Scheme 31
Scheme 32
Scheme 33
Scheme 34
Scheme 35
Scheme 35: OVERALL SEQUENCE
DETAILED FLOW
- GET INFORMATION FOR SYMPTOM Get detailed information from the customer about the symptom (the condition and the environment when the incident/malfunction occurs). Check operation condition of the function that is malfunctioning. : GO TO 2.
- CHECK DTC Check DTC. Perform the following procedure if DTC is detected. Record DTC and freeze frame data (Print them out using CONSULT.) Erase DTC. Study the relationship between the cause detected by DTC and the symptom described by the customer. Check related service bulletins for information. Are any symptoms described and any DTC detected? Symptom is described, DTC is detected: GO TO 3. Symptom is described, DTC is not detected: GO TO 4 . Symptom is not described, DTC is detected: GO TO 5 .
- CONFIRM THE SYMPTOM Try to confirm the symptom described by the customer. Also study the normal operation and fail-safe related to the symptom. Verify relation between the symptom and the condition when the symptom is detected. : GO TO 5 .
- CONFIRM THE SYMPTOM Try to confirm the symptom described by the customer. Verify relation between the symptom and the condition when the symptom is detected. : GO TO 6 .
- PERFORM DTC CONFIRMATION PROCEDURE Perform DTC CONFIRMATION PROCEDURE for the detected DTC, and then check that DTC is detected again. At this time, always connect CONSULT to the vehicle, and check self diagnostic results in real time. If two or more DTCs are detected, refer to «DTC INSPECTION PRIORITY CHART»(ref-621407-S27046810572014061000000) , and determine trouble diagnosis order. NOTE: Freeze frame data is useful if the DTC is not detected. Perform Component Function Check if DTC CONFIRMATION PROCEDURE is not included on Service Information. This simplified check procedure is an effective alternative though DTC cannot be detected during this check. If the result of Component Function Check is NG, it is the same as the detection of DTC by DTC CONFIRMATION PROCEDURE. Is DTC detected? YES: GO TO 7 . NO: Check according to " «INTERMITTENT INCIDENT»(ref-621370-S29645329712014061000000) ".
- DETECT MALFUNCTIONING SYSTEM BY SYMPTOM DIAGNOSIS Detect malfunctioning system according to SYMPTOM DIAGNOSIS based on the confirmed symptom in step 4 , and determine the trouble diagnosis order based on possible causes and symptom. Is the symptom described? YES: GO TO 7. NO: Monitor input data from related sensors or check voltage of related module terminals using CONSULT.
- DETECT MALFUNCTIONING PART BY DIAGNOSIS PROCEDURE Inspect according to Diagnosis Procedure of the system. Is malfunctioning part detected? YES: GO TO 8. NO: Check according to " «INTERMITTENT INCIDENT»(ref-621370-S29645329712014061000000) ".
- REPAIR OR REPLACE THE MALFUNCTIONING PART Repair or replace the malfunctioning part. Reconnect parts or connectors disconnected during Diagnosis Procedure again after repair and replacement. Check DTC. If DTC is detected, erase it. : GO TO 9.
- FINAL CHECK When DTC is detected in step 2 , perform DTC CONFIRMATION PROCEDURE again, and then check that the malfunction is repaired securely. When symptom is described by the customer, refer to confirmed symptom in step 3 or 4 , and check that the symptom is not detected. Is DTC detected and does symptom remain? YES-1: DTC is detected: GO TO 7 . YES-2: Symptom remains: GO TO 4 . NO: Before returning the vehicle to the customer, always erase DTC.
Component Function Check
- CHECK INTERIOR ROOM LAMP POWER SUPPLY FUNCTION CONSULT ACTIVE TEST Turn ignition switch ON. Turn each interior room lamp ON. Map lamp Luggage room lamp Select "BATTERY SAVER" of BCM (BATTERY SAVER) active test item. With operating the test items, check that each interior room lamp turns ON/OFF. Off: Interior room lamp OFF On: Interior room lamp ON Does each interior room lamp turn ON/OFF? YES: Interior room lamp power supply circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-621431-S20066672832014061000000) ".
| CAUTION | Before performing the diagnosis, check that the following are normal. Interior room lamp power supply Map lamp bulb |
- CHECK INTERIOR ROOM LAMP CONTROL FUNCTION CONSULT ACTIVE TEST Switch the map lamp switch to DOOR. Turn ignition switch ON. Select "INT LAMP" of BCM (INT LAMP) active test item. With operating the test items, check that each interior room lamp turns ON/OFF (gradual brightening/dimming). On: Interior room lamp gradual brightening Off: Interior room lamp gradual dimming Does the interior room lamp turns ON/OFF (gradual brightening/dimming)? YES: Interior room lamp control circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-621431-S21465572562014061000000) ".
- CHECK PUSH-BUTTON IGNITION SWITCH ILLUMINATION OPERATION CONSULT ACTIVE TEST Turn the ignition switch ON. Select "ENGINE SW ILLUMI" of BCM (INTELLIGENT KEY) active test item. With operating the test items, check that the push-button ignition switch illumination turns ON/OFF. On: Push-button ignition switch illumination ON Off: Push-button ignition switch illumination OFF Does the push-button ignition switch illumination turn ON/OFF? YES: Push-button ignition switch illumination circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-621431-S23063510422014061000000) ".
