Audio, Visual, Navigation System (Audio Without Navigation): Diagnosis Nissan Juke I facelift

ON BOARD DIAGNOSIS ITEM

Self-diagnosis mode can check the following items.

1. Display all icons and segments
2. Audio unit hardware/software/CD mechanism/EEPROM versions
3. Satellite radio version
4. Audio CD changer version
5. iPod® hardware/software versions

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

1. Turn ignition switch to the ON position.
2. Turn the audio unit off.
3. While pressing the "1" button, turn the volume control dial clockwise or counterclockwise 30 clicks or more. When the self-diagnosis mode is started, a short beep will be heard.
4. Initially, all display segments will be illuminated.
5. Press the "DISP TEXT" switch to enter version diagnostics. "Soft" (audio software version) is displayed.
6. Press the "DISP TEXT" switch again to display the "Hard" (audio hardware version).
7. Press the "DISP TEXT" switch again to display the "CD Mech" (CD mechanism version).
8. Press the "DISP TEXT" switch again to display the "EEP" (audio unit EEPROM version).
9. Press the "DISP TEXT" switch again to display the "SDARS" (satellite radio version).
10. Press the "DISP TEXT" switch again to display the "CHG" (audio CD changer version). If audio CD changer is not connected, "FFFFFF" is displayed.
11. Press the "DISP TEXT" switch again to display the "iPodS" (iPod® software version). "FFFFFF" is displayed when communication signals between the audio unit and iPod adapter include a malfunction.
12. Press the "DISP TEXT" switch again to display the "iPodH" (iPod® hardware version). "FFFFFF" is displayed when communication signals between the audio unit and iPod adapter include a malfunction.

Finishing Self-diagnosis Mode

Self-diagnosis Mode is canceled when turning ignition switch OFF.

The on board diagnosis has 3 modes: the self-diagnosis mode that performs the trouble diagnosis, the speaker adaptation data deleting mode and the hands free phone system initialization mode.

SELF-DIAGNOSIS RESULTS

Self-diagnosis mode reads out the self-diagnosis results and indicates DTC on the audio screen.

Note. Error count is read out simultaneously when reading out the DTC name. The errors are read out continuously when some errors occur at the same time. The DTC displays are combined and displayed. For example, DTC 01100 is displayed when DTC 01000 and DTC 00100 are indicated at the same time.

SELF-DIAGNOSIS RESULTS

The Details of Error Count

The error count guides "0" when the error occurs. The next time it counts up "1" if it is normal with the ignition switch ON. It continues the count up unless the initialization of hands free phone system is performed.

Scheme 37

Scheme 38

AUDIO UNIT: Diagnosis Procedure

1. CHECK FUSE Check that the following fuses of the audio unit are not blown. Power source Fuse No. Battery 34 Ignition switch ACC or ON Models without Intelligent Key 18 Models with Intelligent Key 19 Is inspection result OK? YES: GO TO 2. NO: If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse.
2. CHECK AUDIO UNIT POWER SUPPLY CIRCUIT Check voltage between the audio unit and ground. Signal name Audio unit Probe Condition Standard Reference value Terminal Connector (+) (-) Ignition switch Battery power supply M91 19 Ground OFF 10.8 - 15.6 V Battery voltage ACC power supply 7 ACC 10.8 - 15.6 V Is inspection result OK? YES: INSPECTION END NO: Check harness between audio unit and fuse.

SATELLITE RADIO TUNER: Diagnosis Procedure

1. CHECK FUSES Check that the following fuses of the satellite radio tuner are not blown. Power source Fuse No. Battery 34 Ignition switch ACC or ON Models without Intelligent Key 18 Models with Intelligent Key 19 Is inspection result OK? YES: GO TO 2. NO: If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse.
2. CHECK POWER SUPPLY CIRCUIT Check voltage between the satellite radio tuner and ground. Signal name Satellite radio tuner Probe Condition Standard Reference value Terminal Connector (+) (-) Ignition switch Battery power supply B69 12 15 OFF 10.8 - 15.6 V Battery voltage ACC power supply 16 ACC 7.0 - 16.0 V Is inspection result OK? YES: GO TO 3. NO: Check harness between satellite radio tuner and fuse.
3. CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect satellite radio tuner connector. Check continuity between satellite radio tuner harness connector and ground. Signal name Connector Terminal No. Ignition switch position Continuity Ground B69 15 OFF Existed Is the inspection result normal? YES: INSPECTION END NO: Repair harness or connector.

TEL ADAPTER UNIT: Diagnosis Procedure

1. CHECK FUSE Check for blown fuses. Power source Fuse No. Battery 34 Ignition switch ACC or ON Models without Intelligent Key 18 Models with Intelligent Key 19 Is the inspection result normal? YES: GO TO 2. NO: Be sure to eliminate cause of malfunction before installing new fuse.
2. CHECK POWER SUPPLY CIRCUIT Check voltage between TEL adapter unit harness connector and ground. Signal name TEL adapter unit Probe Condition Standard Reference value Terminal Connector (+) (-) Ignition switch Battery power supply M127 1 4 OFF 9.0 - 16.0 V Battery voltage ACC power supply 2 ACC 7.0 - 16.0 V Is the inspection result normal? YES: GO TO 3. NO: Check harness between TEL adapter unit and fuse.
3. CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect TEL adapter unit connector. Check continuity between TEL adapter unit harness connector and ground. Signal name Connector Terminal Ignition switch position Continuity Ground M127 4 OFF Existed Is the inspection result normal? YES: INSPECTION END NO: Repair harness or connector.

iPod ADAPTER: Diagnosis Procedure

1. CHECK FUSE Check for blown fuses. Power source Fuse No. Battery 34 Ignition switch ACC or ON Models without Intelligent Key 18 Models with Intelligent Key 19 Is the inspection result normal? YES: GO TO 2. NO: Be sure to eliminate the cause of malfunction before installing new fuse.
2. CHECK POWER SUPPLY CIRCUIT Check voltage between iPod adapter harness connector and ground. Signal name iPod adapter Probe Condition Standard Reference value Terminal Connector (+) (-) Ignition switch Battery power supply M102 5 Ground OFF 9.0 - 16.0 V Battery voltage ACC power supply 3 ACC 7.8 - 14.9 V Is the inspection result normal? YES: INSPECTION END NO: Check harness between iPod adapter and fuse.

Diagnosis Procedure

1. CHECK CONTINUITY BETWEEN TEL ADAPTER UNIT AND MICROPHONE CIRCUIT Turn ignition switch OFF. Disconnect TEL adapter unit connector and microphone connector. Check continuity between TEL adapter unit harness connector and microphone harness connector. TEL adapter unit Microphone Continuity Connector Terminal Connector Terminal M127 7 R2 1 Existed 8 2 29 4 Check continuity between TEL adapter unit harness connector and ground. TEL adapter unit Ground Continuity Connector Terminal M127 7 Not existed 29 Is inspection result OK? YES: GO TO 2. NO: Repair harness or connector.
2. CHECK VOLTAGE MICROPHONE VCC Connect TEL adapter unit connector. Turn ignition switch ON. Check voltage between TEL adapter unit harness connector and ground. Probe Standard Reference value (Approx.) (+) (-) TEL adapter unit Connector Terminal Connector Terminal M127 29 M127 8 4.7 - 5.3 V 5.0 V Is inspection result OK? YES: GO TO 3. NO: Replace TEL adapter unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S33459026422014061000000) ".
3. CHECK MICROPHONE SIGNAL Turn ignition switch OFF. Connect microphone connector. Turn ignition switch ON. Check signal between TEL adapter unit harness connector. Probe Condition Standard Reference value (+) (-) TEL adapter unit Connector Terminal Connector Terminal M127 7 M127 8 Give a voice. Wave form synchronized with voice is input. Is inspection result OK? YES: Replace TEL adapter unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S33459026422014061000000) ". NO: Replace microphone. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S02888776902014061000000) ".

1. CHECK CONTINUITY CONTROL SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect TEL adapter unit connector. Check continuity between TEL adapter unit harness connector and ground. TEL adapter unit Ground Standard Continuity Connector Terminals M127 20 3.1 V or less Existed 21 Is the inspection result normal? YES: Replace TEL adapter unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S33459026422014061000000) ". NO: Repair harness or connector.

1. CHECK CONTINUITY TELEPHONE ON SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect TEL adapter unit connector and audio unit connector. Check continuity between TEL adapter unit harness connector and audio unit harness connector. TEL adapter unit Audio unit Continuity Connector Terminal Connector Terminal M127 11 M94 54 Existed Check continuity between TEL adapter unit harness connector and ground. TEL adapter unit Ground Continuity Connector Terminal M127 11 Not existed Is inspection result OK? YES: GO TO 2. NO: Repair harness or connector.
2. CHECK TELEPHONE ON SIGNAL Connect audio unit connector and TEL adapter unit connector. Turn ignition switch ON. Check voltage between audio unit harness connector and ground. Probe Condition Standard Reference value (Approx.) (+) (-) Audio unit Ground Connector Terminal M94 54 While using hands-free phone system. 1.32 V or less 0 V While not using hands-free phone system. 1.33 V or more 5.0 V Is inspection result OK? YES: INSPECTION END NO: Replace audio unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S21956037782014061000000) ".

1. CHECK STEERING SWITCH SIGNAL A (STEERING SWITCH TO TEL ADAPTER UNIT) CIRCUIT Turn ignition switch OFF. Disconnect TEL adapter unit connector and spiral cable connector. Check continuity between TEL adapter unit harness connector and spiral cable harness connector. TEL adapter unit Spiral cable Continuity Connector Terminal Connector Terminal M127 12 M33 24 Existed Check continuity between TEL adapter unit harness connector and ground. TEL adapter unit Ground Continuity Connector Terminal M127 12 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
2. CHECK SPIRAL CABLE Check spiral cable. Is the inspection result normal? YES: GO TO 3. NO: Replace spiral cable. Refer to " «EXPLODED VIEW»(ref-621416-S08409483432014061000000) ".
3. CHECK TEL ADAPTER UNIT VOLTAGE Connect TEL adapter unit connector and spiral cable connector. Turn ignition switch ON. Check voltage between TEL adapter unit harness connector. Probe Standard Reference value (Approx.) (+) (-) TEL adapter unit Connector Terminal Connector Terminal M127 12 M127 14 0 - 5.2 V 5.0 V Is the inspection result normal? YES: GO TO 4. NO: Replace TEL adapter unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S33459026422014061000000) ".
4. CHECK STEERING SWITCH Turn ignition switch OFF. Check steering switch. Refer to " «COMPONENT INSPECTION»(ref-621428-S37694916112014061000000) ". Is the inspection result normal? YES: INSPECTION END NO: Replace steering switch. Refer to " «EXPLODED VIEW»(ref-621428-S03837607832014061000000) ".

Component Inspection

Measure the resistance between the steering switch connector.

Scheme 39

RESISTANCE SPECIFICATIONS

1. CHECK STEERING SWITCH SIGNAL B (STEERING SWITCH TO TEL ADAPTER UNIT) CIRCUIT Turn ignition switch OFF. Disconnect TEL adapter unit connector and spiral cable connector. Check continuity between TEL adapter unit harness connector and spiral cable harness connector. TEL adapter unit Spiral cable Continuity Connector Terminal Connector Terminal M127 13 M33 31 Existed Check continuity between TEL adapter unit harness connector and ground. TEL adapter unit Ground Continuity Connector Terminal M127 13 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
2. CHECK SPIRAL CABLE Check spiral cable. Is the inspection result normal? YES: GO TO 3. NO: Replace spiral cable. Refer to " «EXPLODED VIEW»(ref-621416-S08409483432014061000000) ".
3. CHECK TEL ADAPTER UNIT VOLTAGE Connect TEL adapter unit connector and spiral cable connector. Turn ignition switch ON. Check voltage between TEL adapter unit harness connector. Probe Standard Reference value (Approx.) (+) (-) TEL adapter unit Connector Terminal Connector Terminal M127 13 M127 14 0 - 5.2 V 5.0 V Is the inspection result normal? YES: GO TO 4. NO: Replace TEL adapter unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S33459026422014061000000) ".
4. CHECK STEERING SWITCH Turn ignition switch OFF. Check steering switch. Refer to " «COMPONENT INSPECTION»(ref-621428-S28497570422014061000000) ". Is the inspection result normal? YES: INSPECTION END NO: Replace steering switch. Refer to " «EXPLODED VIEW»(ref-621428-S03837607832014061000000) ".

Measure the resistance between the steering switch connector.

Scheme 40

RESISTANCE SPECIFICATIONS

1. CHECK STEERING SWITCH SIGNAL GROUND CIRCUIT (STEERING SWITCH TO TEL ADAPTER UNIT) Turn ignition switch OFF. Disconnect TEL adapter unit connector and spiral cable connector. Check continuity between TEL adapter unit harness connector and spiral cable harness connector. TEL adapter unit Spiral cable Continuity Connector Terminal Connector Terminal M127 14 M33 33 Existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
2. CHECK SPIRAL CABLE Check spiral cable. Is the inspection result normal? YES: GO TO 3. NO: Replace spiral cable. Refer to " «EXPLODED VIEW»(ref-621416-S08409483432014061000000) ".
3. CHECK GROUND CIRCUIT Connect TEL adapter unit connector. Check continuity between TEL adapter unit harness connector and ground. TEL adapter unit Ground Continuity Connector Terminal M127 14 Existed Is the inspection result normal? YES: GO TO 4. NO: Replace TEL adapter unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S33459026422014061000000) ".
4. CHECK STEERING SWITCH Check steering switch. Refer to " «COMPONENT INSPECTION»(ref-621428-S26692715992014061000000) ". Is the inspection result normal? YES: INSPECTION END NO: Replace steering switch. Refer to " «EXPLODED VIEW»(ref-621428-S03837607832014061000000) ".

Measure the resistance between the steering switch connector.

Scheme 41

RESISTANCE SPECIFICATIONS

1. CHECK STEERING SWITCH SIGNAL A CIRCUIT (TEL ADAPTER UNIT TO AUDIO UNIT) Turn ignition switch OFF. Disconnect audio unit connector and TEL adapter unit connector. Check continuity between audio unit harness connector and TEL adapter unit harness connector. Audio unit TEL adapter unit Continuity Connector Terminal Connector Terminal M91 6 M127 17 Existed Check continuity between audio unit harness connector and ground. Audio unit Ground Continuity Connector Terminal M91 6 Not existed Is inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
2. CHECK AUDIO UNIT VOLTAGE Connect audio unit connector and TEL adapter unit connector. Turn ignition switch ON. Check voltage between audio unit harness connector terminals. Probe Standard Reference value (Approx.) (+) (-) Audio unit Connector Terminal Connector Terminal M91 6 M91 15 0 - 3.3 V 3.3 V Is inspection result normal? YES: Replace TEL adapter unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S33459026422014061000000) ". NO: Replace audio unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S21956037782014061000000) ".

1. CHECK STEERING SWITCH SIGNAL B CIRCUIT (TEL ADAPTER UNIT TO AUDIO UNIT) Turn ignition switch OFF. Disconnect audio unit connector and TEL adapter unit connector. Check continuity between audio unit harness connector and TEL adapter unit harness connector. Audio unit TEL adapter unit Continuity Connector Terminal Connector Terminal M91 16 M127 18 Existed Check continuity between audio unit harness connector and ground. Audio unit Ground Continuity Connector Terminal M91 16 Not existed Is inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
2. CHECK AUDIO UNIT VOLTAGE Connect audio unit connector and TEL adapter unit connector. Turn ignition switch ON. Check voltage between audio unit harness connector terminals. Probe Standard Reference value (Approx.) (+) (-) Audio unit Connector Terminal Connector Terminal M91 16 M91 15 0 - 3.3 V 3.3 V Is inspection result normal? YES: Replace TEL adapter unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S33459026422014061000000) ". NO: Replace audio unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S21956037782014061000000) ".

1. CHECK STEERING SWITCH SIGNAL GROUND CIRCUIT (TEL ADAPTER UNIT TO AUDIO UNIT) Turn ignition switch OFF. Disconnect audio unit connector and TEL adapter unit connector. Check continuity between audio unit harness connector and TEL adapter unit harness connector. Audio unit TEL adapter unit Continuity Connector Terminal Connector Terminal M91 15 M127 19 Existed Is inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
2. CHECK GROUND CIRCUIT Connect audio unit connector. Check continuity between audio unit harness connector and ground. Audio unit Ground Continuity Connector Terminal M91 15 Existed Is inspection result normal? YES: Replace TEL adapter unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S33459026422014061000000) ". NO: Replace audio unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S21956037782014061000000) ".

1. CHECK CONTINUITY COMMUNICATION SIGNAL (AUDIO-SAT) CIRCUIT Turn ignition switch OFF. Disconnect satellite radio tuner connector and audio unit connector. Check continuity between satellite radio tuner harness connector and audio unit harness connector. Satellite radio tuner Audio unit Continuity Connector Terminal Connector Terminal B69 9 M93 39 Existed 10 40 Existed Check continuity between satellite radio tuner harness connector and ground. Satellite radio tuner Ground Continuity Connector Terminal B69 9 Not existed 10 Is inspection result OK? YES: GO TO 2. NO: Repair harness or connector.
2. CHECK AUDIO UNIT Connect audio unit connector. Turn ignition switch ON. Check voltage between audio unit harness connector and ground. Probe Reference value (Approx.) (+) (-) Audio unit Ground Connector Terminal M93 39 4.0 V Is inspection result OK? YES: GO TO 3. NO: Replace audio unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S21956037782014061000000) ".
3. CHECK SATELLITE RADIO TUNER Turn ignition switch OFF. Disconnect audio unit connector, and connect satellite radio tuner connector. Turn ignition switch ON. Check voltage between satellite radio tuner harness connector and ground. Probe Reference value (Approx.) (+) (-) Satellite radio tuner Ground Connector Terminal B69 10 7.5 V Is inspection result OK? YES: GO TO 4. NO: Replace satellite radio tuner. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S03647680482014061000000) ".
4. CHECK COMMUNICATION SIGNAL (SAT TO AUDIO) Turn ignition switch OFF. Connect audio unit connector. Turn ignition switch ON. Check signal between satellite radio tuner harness connector and ground. Probe Condition Standard Reference value (+) (+) Satellite radio tuner Connector Terminal Connector Terminal B69 9 B69 15 When satellite radio mode is selected. Waveform of 0.5 - 7.0 V is input. Is inspection result OK? YES: GO TO 5. NO: Replace satellite radio tuner. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S03647680482014061000000) ".
5. CHECK COMMUNICATION SIGNAL (AUDIO TO SAT) Check signal between audio unit harness connector and ground. Probe Condition Standard Reference value (+) (+) Audio unit Ground Connector Terminal M93 40 When satellite radio mode is selected. Waveform of 1.5 - 6.0 V is input. Is inspection result OK? YES: INSPECTION END NO: Replace audio unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S21956037782014061000000) ".

1. CHECK CONTINUITY REQUEST SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect satellite radio tuner connector and audio unit connector. Check continuity between satellite radio tuner harness connector and audio unit harness connector. Satellite radio tuner Audio unit Continuity Connector Terminal Connector Terminal B69 8 M93 38 Existed Check continuity between satellite radio tuner harness connector and ground. Satellite radio tuner Ground Continuity Connector Terminal B69 8 Not existed Is inspection result OK? YES: GO TO 2. NO: Repair harness or connector.
2. CHECK AUDIO UNIT Connect audio unit connector. Turn ignition switch ON. Check voltage between audio unit harness connector and ground. Probe Reference value (Approx.) (+) (-) Audio unit Ground Connector Terminal M93 38 4.0 V Is inspection result OK? YES: GO TO 3. NO: Replace audio unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S21956037782014061000000) ".
3. CHECK CONTINUITY REQUEST SIGNAL Turn ignition switch OFF. Connect satellite radio tuner connector. Turn ignition switch ON. Check signal between satellite radio tuner harness connector and ground. Probe Condition Standard Reference value (+) (+) Satellite radio tuner Connector Terminal Connector Terminal B69 8 B69 15 When satellite radio mode is selected. Waveform of 0.5 - 7.0 V is input. Is inspection result OK? YES: INSPECTION END NO: Replace satellite radio tuner. Refer to " «REMOVAL AND INSTALLATION»(ref-621428-S03647680482014061000000) ".

Trouble Diagnosis Chart by Symptom

Connect another iPod® and check if the symptom is reproduced or not. If the symptom is reproduced, diagnose the vehicle. If no malfunction is detected, replace the iPod harness.

Note. It is unable to read a connection between iPod® and iPod harness. Charging of iPod® with no 5 V charging circuit is not supported. (e.g. iPod 1G mechanical scroll wheel, iPod Classic 2G touch-sensitive wheel, and iPod Classic 3G 4 touch button)

TROUBLE DIAGNOSIS CHART BY SYMPTOM
