Audio, Visual, Navigation System (Audio with Navigation): Diagnosis Nissan Juke I facelift

END ON-BOARD DIAGNOSIS

Turn OFF ignition switch.

ON BOARD DIAGNOSIS ITEM

The on board diagnosis has 3 modes: the self-diagnosis mode that performs the trouble diagnosis, the speaker adaptation data deleting mode and the hands free phone system initialization mode.

SELF-DIAGNOSIS RESULTS

Self-diagnosis mode reads out the self-diagnosis results and indicates DTC on the audio screen.

Note. Error count is read out simultaneously when reading out the DTC name. The errors are read out continuously when some errors occur at the same time. The DTC displays are combined and displayed. For example, DTC 01100 is displayed when DTC 01000 and DTC 00100 are indicated at the same time.

SELF-DIAGNOSIS RESULTS

The Details of Error Count

The error count guides "0" when the error occurs. The next time it counts up "1" if it is normal with the ignition switch ON. It continues the count up unless the initialization of hands free phone system is performed.

Scheme 76

Scheme 77

NAVI CONTROL UNIT: Diagnosis Procedure

1. CHECK FUSE Check for blown fuses. Power source Fuse No. Battery 34 Ignition switch ACC or ON 19 Is inspection result OK? YES: GO TO 2. NO: Be sure to eliminate cause of malfunction before installing new fuse.
2. CHECK POWER SUPPLY CIRCUIT Check voltage between NAVI control unit harness connector and ground. Signal name NAVI control unit Probe Condition Reference value Terminal Connector (+) (-) Ignition switch Battery power supply M107 19 20 OFF Battery voltage ACC power supply 7 ACC Is inspection result OK? YES: GO TO 3. NO: Check harness between NAVI control unit and fuse.
3. CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect NAVI control unit connector. Check continuity between NAVI control unit harness connector and ground. Signal name Connector Terminal Ignition switch position Continuity Ground M107 20 OFF Existed Is inspection result OK? YES: INSPECTION END NO: Repair harness or connector.

TEL ADAPTER UNIT: Diagnosis Procedure

1. CHECK FUSE Check for blown fuses. Power source Fuse No. Battery 34 Ignition switch ACC or ON 19 Is the inspection result normal? YES: GO TO 2. NO: Be sure to eliminate cause of malfunction before installing new fuse.
2. CHECK POWER SUPPLY CIRCUIT Check voltage between TEL adapter unit harness connector and ground. Signal name TEL adapter unit Probe Condition Standard Reference value Terminal Connector (+) (-) Ignition switch Battery power supply M127 1 4 OFF 9.0 - 16.0 V Battery voltage ACC power supply 2 ACC 7.0 - 16.0 V Is the inspection result normal? YES: GO TO 3. NO: Check harness between TEL adapter unit and fuse.
3. CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect TEL adapter unit connector. Check continuity between TEL adapter unit harness connector and ground. Signal name Connector Terminal Ignition switch position Continuity Ground M127 4 OFF Existed Is the inspection result normal? YES: INSPECTION END NO: Repair harness or connector.

Diagnosis Procedure

1. CHECK CONTINUITY CONTROL SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect TEL adapter unit connector. Check continuity between TEL adapter unit harness connector and ground. TEL adapter unit Ground Standard Continuity Connector Terminals M127 23 3.1 V or less Existed 24 27 Is the inspection result normal? YES: Replace TEL adapter unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621429-S04339187832014061000000) ". NO: Repair harness or connector.

1. CHECK CONTINUITY CAMERA POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect NAVI control unit connector and rear view camera connector. Check continuity between NAVI control unit harness connector and rear view camera harness connector. NAVI control unit Rear view camera Continuity Connector Terminal Connector Terminal M118 43 D111 1 Existed Check continuity between NAVI control unit harness connector and ground. NAVI control unit Ground Continuity Connector Terminal M118 43 Not existed Is inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
2. CHECK VOLTAGE CAMERA POWER SUPPLY Connect NAVI control unit connector and rear view camera connector. Turn ignition switch ON. Shift the selector lever to "R" position. Check voltage between NAVI control unit harness connector and ground. Probe Condition Reference value (Approx.) (+) (-) NAVI control unit Connector Terminal Connector Terminal M118 43 M107 20 Shift position is in "R". 6.0 V Is inspection result normal? YES: GO TO 3. NO: Replace NAVI control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621429-S28127536322014061000000) ".
3. CHECK CONTINUITY CAMERA IMAGE SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect NAVI control unit connector and rear view camera connector. Check continuity between NAVI control unit harness connector and rear view camera harness connector. NAVI control unit Rear view camera Continuity Connector Terminal Connector Terminal M118 41 D111 3 Existed Check continuity between NAVI control unit harness connector and ground. NAVI control unit Ground Continuity Connector Terminal M118 41 Not existed Is inspection result normal? YES: GO TO 4. NO: Repair harness or connector.
4. CHECK CAMERA IMAGE SIGNAL Connect NAVI control unit connector and rear view camera connector. Turn ignition switch ON. Shift the selector lever to "R" position. Check signal between NAVI control unit harness connector and ground. Probe Condition Reference value (+) (+) NAVI control unit Connector Terminal Connector Terminal M118 41 M107 20 At rear view camera image is displayed. Is inspection result normal? YES: Replace NAVI control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621429-S28127536322014061000000) ". NO: Replace rear view camera. Refer to " «REMOVAL AND INSTALLATION»(ref-621429-S14690235982014061000000) ".

1. CHECK CONTINUITY WOOFER AMP. ON SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect NAVI control unit connector and woofer connector. Check continuity between NAVI control unit harness connector and woofer harness connector. NAVI control unit Woofer Continuity Connector Terminal Connector Terminal M107 1 B74 4 Existed Check continuity between woofer harness connector and ground. Woofer Ground Continuity Connector Terminal B74 4 Not existed Is inspection result OK? YES: GO TO 2. NO: Repair harness or connector.
2. CHECK VOLTAGE WOOFER AMP. ON SIGNAL Connect NAVI control unit connector Turn ignition switch ON. Check voltage between NAVI control unit harness connector and ground. Probe Reference value (Approx.) (+) (-) NAVI control unit Connector Terminal Connector Terminal M107 1 M107 20 12.0 V Is inspection result OK? YES: Replace woofer. Refer to " «REMOVAL AND INSTALLATION»(ref-621429-S21198995992014061000000) ". NO: Replace NAVI control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621429-S28127536322014061000000) ".

1. CHECK STEERING SWITCH SIGNAL A CIRCUIT Disconnect NAVI control unit connector and spiral cable connector. Check continuity between NAVI control unit harness connector and spiral cable harness connector. NAVI control unit Spiral cable Continuity Connector Terminal Connector Terminal M107 6 M33 24 Existed Check continuity between NAVI control unit harness connector and ground. NAVI control unit Ground Continuity Connector Terminal M107 6 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
2. CHECK SPIRAL CABLE Check spiral cable. Is the inspection result normal? YES: GO TO 3. NO: Replace spiral cable. Refer to " «EXPLODED VIEW»(ref-621416-S08409483432014061000000) ".
3. CHECK NAVI CONTROL UNIT VOLTAGE Connect NAVI control unit connector and spiral cable connector. Turn ignition switch ON. Check voltage between NAVI control unit harness connector. Probe Reference value (Approx.) (+) (-) NAVI control unit Connector Terminal Connector Terminal M107 6 M107 15 5.0 V Is the inspection result normal? YES: GO TO 4. NO: Replace NAVI control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621429-S28127536322014061000000) ".
4. CHECK STEERING SWITCH Turn ignition switch OFF. Check steering switch. Refer to " «COMPONENT INSPECTION»(ref-621429-S35027291952014061000000) ". Is the inspection result normal? YES: INSPECTION END NO: Replace steering switch. Refer to " «EXPLODED VIEW»(ref-621429-S02433848552014061000000) ".

Component Inspection

Measure the resistance between the steering switch connector.

Scheme 78

RESISTANCE SPECIFICATIONS

1. CHECK STEERING SWITCH SIGNAL B CIRCUIT Disconnect NAVI control unit connector and spiral cable connector. Check continuity between NAVI control unit harness connector and spiral cable harness connector. NAVI control unit Spiral cable Continuity Connector Terminal Connector Terminal M107 16 M33 31 Existed Check continuity between NAVI control unit harness connector and ground. NAVI control unit Ground Continuity Connector Terminal M107 16 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
2. CHECK SPIRAL CABLE Check spiral cable. Is the inspection result normal? YES: GO TO 3. NO: Replace spiral cable. Refer to " «EXPLODED VIEW»(ref-621416-S08409483432014061000000) ".
3. CHECK NAVI CONTROL UNIT VOLTAGE Connect NAVI control unit connector and spiral cable connector. Turn ignition switch ON. Check voltage between NAVI control unit harness connector. Probe Reference value (Approx.) (+) (-) NAVI control unit Connector Terminal Connector Terminal M107 16 M107 15 5.0 V Is the inspection result normal? YES: GO TO 4. NO: Replace NAVI control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621429-S28127536322014061000000) ".
4. CHECK STEERING SWITCH Turn ignition switch OFF. Check steering switch. Refer to " «COMPONENT INSPECTION»(ref-621429-S14247312442014061000000) ". Is the inspection result normal? YES: INSPECTION END NO: Replace steering switch. Refer to " «EXPLODED VIEW»(ref-621429-S02433848552014061000000) ".

Measure the resistance between the steering switch connector.

Scheme 79

RESISTANCE SPECIFICATIONS

1. CHECK STEERING SWITCH SIGNAL GROUND CIRCUIT Disconnect NAVI control unit connector and spiral cable connector. Check continuity between NAVI control unit harness connector and spiral cable harness connector. NAVI control unit Spiral cable Continuity Connector Terminal Connector Terminal M107 15 M33 33 Existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
2. CHECK SPIRAL CABLE Check spiral cable. Is the inspection result normal? YES: GO TO 3. NO: Replace spiral cable. Refer to " «EXPLODED VIEW»(ref-621416-S08409483432014061000000) ".
3. CHECK GROUND CIRCUIT Connect NAVI control unit connector. Check continuity between NAVI control unit harness connector and ground. NAVI control unit Ground Continuity Connector Terminal M107 15 Existed Is the inspection result normal? YES: GO TO 4. NO: Replace NAVI control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-621429-S28127536322014061000000) ".
4. CHECK STEERING SWITCH Turn ignition switch OFF. Check steering switch. Refer to " «COMPONENT INSPECTION»(ref-621429-S34950159672014061000000) ". Is the inspection result normal? YES: INSPECTION END NO: Replace steering switch. Refer to " «EXPLODED VIEW»(ref-621429-S02433848552014061000000) ".

Measure the resistance between the steering switch connector.

Scheme 80

RESISTANCE SPECIFICATIONS
