Automatic Transmission: Overhaul Nissan Juke I facelift

ASSEMBLY

Note the following, and assemble in the reverse order of disassembly.

1. Follow the procedure below and place the selector knob onto the CVT shift selector.

Scheme 111

1. Install the lock pin (2) onto the selector lever knob (3).
2. Install the knob cover (1) onto the selector lever knob.
3. Press the selector lever knob onto the selector lever until it clicks. CAUTION: When pressing the selector lever knob onto the selector lever, never press the selector lever knob button. Never strike the selector lever knob to press it into place.

Disassembly

1. Remove transaxle assembly. Refer to " «AWD: REMOVAL AND INSTALLATION»(ref-621391-S08876999982014061000000) ".
2. Remove torque converter from transaxle assembly. CAUTION: Never damage bush on the inside of torque converter sleeve when removing torque converter.
3. Remove converter housing oil seal using a flat-bladed screwdriver. CAUTION: Be careful not to scratch converter housing.

Note the following, and install in the reverse order of removal.

1. Drive converter housing oil seal (1) evenly using a drift (A) (commercial service tool) so that converter housing oil seal protrudes by the dimension (B) respectively.

Note. Converter housing oil seal pulling direction is used as the reference.

Scheme 112

Scheme 113

1. After completing installation, check for CVT fluid leakage and CVT fluid level. Refer to " «INSPECTION»(ref-621391-S09008084222014061000000) ".
2. Attach the pawl (A) of the torque converter to the drive sprocket hole (B) on the transaxle assembly side. CAUTION: Rotate the torque converter for installing torque converter. Never damage the bushing inside the torque converter sleeve when installing the converter housing oil seal.

Scheme 114

1. After inserting a torque converter to the CVT, check dimension (A) with in the reference value limit. Dimension (A): Refer to " «TORQUE CONVERTER»(ref-621391-S13000872662014061000000) ".
