Roof: Adjustments Nissan Frontier D40

GAP ADJUSTMENT

If a gap or minor height difference between glass lid assembly and roof panel is found, adjust in the following manner

1. Open sunshade assembly and tilt glass lid assembly up.
2. Loosen glass lid securing screws (2 each on left and right sides), then tilt glass lid down.
3. Manually adjust glass lid from outside of vehicle so it is within specification "A-A" as shown.
4. After adjustment, tilt glass lid assembly up and tighten screws.
5. Tilt glass lid assembly up and down several times to check that it moves properly.

HEIGHT DIFFERENCE ADJUSTMENT

If an excessive height difference between glass lid assembly and roof panel is found, adjust in the following manner

1. Remove headlining. Refer to " «HEADLINING»(ref-272366-S31763418142007111800000) ".
2. Loosen sunroof frame assembly nuts and sunroof bracket bolts.
3. Add shims until gap is within specification "A-A" as shown. NOTE: Temporarily snug nuts and bolts to prevent movement between each adjustment.
4. Tilt glass lid assembly up and down several times to check that it moves and seals properly.
5. Tighten sunroof frame assembly nuts and sunroof bracket bolts. NOTE: First tighten left front then right rear sunroof frame assembly nuts to prevent uneven torque while tightening remaining sunroof bracket bolts.
6. Install headlining. Refer to " «HEADLINING»(ref-272366-S31763418142007111800000) ".

Scheme 1

1. After any adjustment, check sunroof operation and glass lid alignment.
2. Handle glass lid with care so not to cause damage.
3. For easier installation, mark each point before removal.
