Rear Final Drive: Specifications Nissan Frontier D40

Side Bearing Preload Torque

1. A selection of side bearing adjusting washers is required for successful completion of this procedure.

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

1. Apply differential gear oil to the side bearings, and install the differential case assembly with the side bearing outer races into the gear carrier. CAUTION: Do not reuse side bearing outer race when replacing side bearing inner race (replace as a set). see scheme 43: Identifying Correct Bearing Races
2. Insert the left and right original side bearing adjusting washers in place between side bearings and gear carrier using Tool. Tool number: KV38100600 (J-25267) see scheme 44: Inserting Left And Right Original Side Bearing Adjusting Washers
3. Align the matching mark on the side bearing cap with the matching mark on the gear carrier.
4. Install the side bearing caps and tighten the side bearing cap bolts to the specified torque. Refer to " «COMPONENTS»(ref-272368-S36163325402007111800000) ".
5. Turn the differential assembly several times to seat the side bearings. see scheme 45: Aligning Matching Mark On Gear Carrier
6. To determine side bearing preload torque, measure the pulling force of the differential assembly at the drive gear bolt using Tool. Tool number: - (J-8129) Specification: 34.2-39.2 N (3.5-4.0 kg, 7.7-8.8 lb) of pulling force at the drive gear bolt NOTE: If pulling force of the differential assembly at the drive gear bolt is within specification, side bearing preload torque will also be within specification. Refer to " «TOTAL PRELOAD TORQUE»(ref-272368-S22403184942007111800000) ". see scheme 46: Measuring Torque Drive Gear Bolts
7. If the pulling force is outside the specification, use a thicker or thinner side bearing adjusting washer to adjust. Refer to " «SIDE BEARING ADJUSTING WASHER»(ref-272368-S42179806442007111800000) ". If the pulling force is less than the specification: Use a thicker side bearing adjusting washer. If the pulling force is greater than the specification: Use a thinner side bearing adjusting washer. CAUTION: Select a side bearing adjusting washer for right and left individually. see scheme 47: Adjusting Washer Position
8. Record the total amount of washer thickness required for the correct side bearing preload torque.

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

1. Make sure all parts are clean and that the bearings are well lubricated.
2. Assemble the drive pinion bearings onto the Tool. Tool number: - (J-34309) see scheme 48: Assembling Pinion Gear Bearings Drive pinion front bearing; make sure the J-34309-3 drive pinion front bearing seat is secured tightly against the J-34309-2 gauge anvil. Then turn the J-34309-5 drive pinion front bearing pilot to secure the drive pinion bearing in its proper position. Drive pinion rear bearing; the J-34309-8 drive pinion rear bearing pilot is used to center the drive pinion rear bearing only. The J-34309-4 drive pinion rear bearing locking seat is used to lock the drive pinion rear bearing to the assembly. Installation of J-34309-9 and J-34309-16; place a suitable 2.5 mm (0.098 in) thick plain washer between J-34309-9 and J-34309-16. Both surfaces of J-34309-9 and J-34309-16 must be parallel with a clearance of 2.5 mm (0.098 in). see scheme 49: Identifying Drive Pinion Rear Bearing
3. Install the drive pinion rear bearing inner race into the gear carrier. Then insert the drive pinion height adjusting washer selector tool, J-34309-1, gauge screw assembly. see scheme 50: Identifying Drive Pinion Rear Bearing Inner Race Into Axle Housing
4. Assemble the drive pinion front bearing inner race and the J-34309-2 gauge anvil. Assemble them together with the J-34309-1 gauge screw in the gear carrier. Make sure that the drive pinion height gauge plate, J-34309-16, will turn a full 360°. Tighten the two sections together by hand. see scheme 51: Assembling Drive Pinion Front Bearing Inner Race
5. Turn the assembly several times to seat the drive pinion bearings. see scheme 52: Identifying Pinion Front Bearing Inner Race
6. Measure the turning torque at the end of the J-34309-2 gauge anvil using Tool. Tool number: ST3127S000 (J-25765-A) Turning torque: 1.0-1.3 N.m (0.11-0.13 kg-m, 9-11 in-lb) see scheme 53: Measuring Turning Torque
7. Place the J-34309-11 drive pinion height adapter onto the gauge plate and tighten it by hand. CAUTION: Make sure all machined surfaces are clean. see scheme 54: Identifying Pinion Height Adopter
8. Position the side bearing discs, Tool, and arbor firmly into the side bearing bores. Install the side bearing caps and tighten the side bearing cap bolts to the specified torque. Refer to " «COMPONENTS»(ref-272368-S36163325402007111800000) ". Tool number: - (J-25269-4) see scheme 55: Identifying Side Bearing Discs
9. Select the correct standard drive pinion height adjusting washer thickness. Select by using a standard gauge of 3 mm (0.12 in) and your J-34309-101 feeler gauge. Measure the distance between the J-34309-11 drive pinion height adapter, including the standard gauge and the arbor. see scheme 56: Measuring Distance Between J-34309-10 Pinion Height Adapter Including Standard Gauge And Arbor
10. Write down the exact measurement (the value of feeler gauge). see scheme 57: Identifying Pinion Height Adjusting Washer Thickness
11. Correct the drive pinion height adjusting washer size by referring to the drive pinion "head number". There are two numbers painted on the drive pinion. The first one refers to the drive pinion and drive gear as a matched set. This number should be the same as the number on the drive gear. The second number is the drive pinion "head number". It refers to the ideal drive pinion height from standard for quietest operation. Use the following chart to determine the correct drive pinion height adjusting washer. DRIVE PINION HEIGHT ADJUSTING WASHER THICKNESS Head number Add or remove from the standard drive pinion height adjusting washer thickness measurement - 6 Add 0.06 mm (0.0024 in) - 5 Add 0.05 mm (0.0020 in) - 4 Add 0.04 mm (0.0016 in) - 3 Add 0.03 mm (0.0012 in) - 2 Add 0.02 mm (0.0008 in) - 1 Add 0.01 mm (0.0004 in) 0 Use the selected washer thickness +1 Subtract 0.01 mm (0.0004 in) +2 Subtract 0.02 mm (0.0008 in) +3 Subtract 0.03 mm (0.0012 in) +4 Subtract 0.04 mm (0.0016 in) +5 Subtract 0.05 mm (0.0020 in) +6 Subtract 0.06 mm (0.0024 in) (Scheme 91): Correcting Pinion Height Washer Size
12. Select the correct drive pinion height adjusting washer. Refer to " «DRIVE PINION HEIGHT ADJUSTING WASHER»(ref-272368-S19348901102007111800000) ".
13. Remove the Tool from the gear carrier and disassemble to retrieve the drive pinion bearings. Tool number: - (J-34309) (Scheme 92): Identifying Pinion Head Number

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

1. Install the new drive pinion front and rear bearing outer races using Tools. Tool number A: ST30611000 (J-25742-1) B: ST30621000 (J-25742-5) C: ST30613000 (J-25742-3) CAUTION: First tap the drive pinion bearing outer race until it becomes flush with the gear carrier. Do not reuse drive pinion front and rear bearing outer race. (Scheme 93): Identifying Front And Rear Bearing Outer Races
2. Select a drive pinion height adjusting washer. Refer to " «DRIVE PINION HEIGHT»(ref-272368-S24482360682007111800000) ".
3. Install the selected drive pinion height adjusting washer to the drive pinion. Press the new drive pinion rear bearing inner race to it using Tool. Tool number: ST30901000 (J-26010-01) CAUTION: Install the drive pinion height adjusting washer in the proper direction as shown. Do not reuse drive pinion rear bearing inner race. (Scheme 94): Identifying Drive Pinion Height Adjusting Washer
4. Assemble the new collapsible spacer to the drive pinion. CAUTION: Do not reuse collapsible spacer.
5. Apply differential gear oil to the drive pinion rear bearing, and install the drive pinion assembly to the gear carrier.
6. Apply differential gear oil to the drive pinion front bearing, and install the new drive pinion front bearing inner race to the drive pinion assembly. CAUTION: Do not reuse drive pinion front bearing inner race. (Scheme 95): Assembling Collapsible Spacer To Drive Pinion
7. Press the drive pinion front bearing inner race to the drive pinion as far as drive pinion lock nut can be tightened using suitable spacer. (Scheme 96): Identifying Drive Pinion Assembly In Differential Carrier
8. Apply multi-purpose grease to the lips and differential gear oil to the circumference of the new front oil seal. Then drive the new front oil seal in evenly until it becomes flush with the gear carrier using Tool. Tool number: KV38100500 (J-25273) CAUTION: Do not reuse front oil seal. Do not incline the new front oil seal when installing. Apply multi-purpose grease to the lips and differential gear oil to the circumference of the new front oil seal. (Scheme 97): Identifying Front Oil Seal
9. Install the companion flange to the drive pinion while aligning the matching marks.
10. Apply anti-corrosive oil to the threads of the drive pinion and the seating surface of the new drive pinion lock nut. Then adjust the drive pinion lock nut tightening torque using Tool A, and check the drive pinion bearing preload torque using Tool B. Tool number A: KV38108300 ( - ) B: ST3127S000 (J-25765-A) Drive pinion bearing preload torque: 1.1-1.4 N.m (0.12-0.14 kg-m, 10-12 in-lb) CAUTION: Do not reuse drive pinion lock nut. Apply anti-corrosive oil to the threads of the drive pinion and the seating surface of the new drive pinion lock nut. Adjust the drive pinion lock nut tightening torque to the lower limit first. Do not exceed the drive pinion lock nut specified torque. Refer to " «COMPONENTS»(ref-272368-S36163325402007111800000) ". If the drive pinion bearing preload torque exceeds the specified value, replace collapsible spacer and tighten it again to adjust. Do not loosen drive pinion lock nut to adjust the drive pinion bearing preload torque. After adjustment, rotate drive pinion back and forth 2 to 3 times to check for unusual noise, rotation malfunction, and other malfunctions. (Scheme 98): Checking Drive Pinion Bearing Preload Torque
11. Check companion flange runout. Refer to " «COMPANION FLANGE RUNOUT»(ref-272368-S20306603422007111800000) ".
12. Install differential case assembly. Refer to " «DIFFERENTIAL ASSEMBLY»(ref-272368-S12655894032007111800000) ".

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

1. Install side gear thrust washers with the same thickness as the ones installed prior to disassembly, or reinstall the old ones on the side gears. (Scheme 99): Assembling Side Gear Thrust Washers
2. Install the side gears and side gear thrust washers into the differential case. CAUTION: Make sure that the circular clip is installed to side gears.
3. Install the pinion mate thrust washers to the two pinion mate gears. Then install the pinion mate gears with the pinion mate thrust washers by aligning them in diagonally opposite positions and rotating them into the differential case. (Scheme 100): Identifying Pinion Mate Thrust Washers Into Differential Case
4. Align the lock pin hole on the differential case with the lock pin hole on the pinion mate shaft, and install the pinion mate shaft.
5. Measure the side gear end play. If necessary, select the appropriate side gear thrust washers. Refer to " «SIDE GEAR BACK CLEARANCE»(ref-272368-S42811984652007111800000) ". (Scheme 101): Aligning Lock Pin Holes On Differential Case With Shaft
6. Drive a new lock pin into the pinion mate shaft until it is flush with the differential case using suitable tool. CAUTION: Do not reuse lock pin. (Scheme 102): Driving Lock Pin Into Pinion Mate Shaft
7. Align the matching mark of the differential case with the mark of the drive gear, then place the drive gear onto the differential case. (Scheme 103): Aligning Matching Mark Of Differential Case
8. Apply thread locking sealant into the threaded holes of the drive gear and install the bolts. Use Genuine Medium Strength Thread Locking Sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-272334-S29650495302007111800000) ". CAUTION: Make sure the drive gear back and threaded holes are clean. (Scheme 104): Applying Thread Locking Sealant Into Thread Hole Of Drive Gear
9. Tighten the drive gear bolts to the specified torque. Refer to " «COMPONENTS»(ref-272368-S36163325402007111800000) ". After tightening the drive gear bolts to the specified torque, tighten an additional 31° to 36° using Tool. Tool number: KV10112100-A (BT-8653-A) CAUTION: Always use Tool. Avoid tightening based on visual check alone. Tighten drive gear bolts in a crisscross pattern. (Scheme 105): Tightening Drive Gear Bolts
10. Press the new side bearing inner races to the differential case using Tools. Tool number A: ST33230000 (J-25805-01) B: ST33061000 (J-8107-2) CAUTION: Do not reuse side bearing inner race. (Scheme 106): Pressing Side Bearing Inner Races Into Differential Case
11. Install the differential case assembly with the side bearing outer races into gear carrier.
12. Measure the side bearing preload torque. If necessary, select the appropriate side bearing adjusting washers. Refer to " «SIDE BEARING PRELOAD TORQUE»(ref-272368-S20552745352007111800000) ". (Scheme 107): Identifying Correct Bearing Races
13. Insert the selected left and right side bearing adjusting washers in place between the side bearings and gear carrier using Tool. Tool number: KV38100600 (J-25267) (Scheme 108): Inserting Left And Right Original Side Bearing Adjusting Washers
14. Install the side bearing caps with the matching marks aligned and tighten the side bearing cap bolts to the specified torque. Refer to " «COMPONENTS»(ref-272368-S36163325402007111800000) ". (Scheme 109): Aligning Matching Mark On Bearing Cap With Matching Mark On Gear Carrier
15. Check and adjust the drive gear runout, tooth contact, drive gear to drive pinion backlash, and total preload torque. Refer to " «DRIVE GEAR RUNOUT»(ref-272368-S31567255082007111800000) ", " «TOOTH CONTACT»(ref-272368-S10155100232007111800000) ", " «BACKLASH»(ref-272368-S04673504012007111800000) " and " «TOTAL PRELOAD TORQUE»(ref-272368-S22403184942007111800000) ". Recheck above items.
16. Apply sealant to the mating surface of the carrier cover. Use Genuine Silicone RTV or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-272334-S29650495302007111800000) ". CAUTION: Remove any old sealant adhering to the mating surfaces. Also remove any moisture, oil, or foreign material adhering to the application and mating surfaces.
17. Install the carrier cover to the gear carrier. Tighten the bolts to the specified torque. Refer to " «COMPONENTS»(ref-272368-S36163325402007111800000) ". (Scheme 110): Applying Sealant To Mating Surface Of Rear Cover

PRELOAD TORQUE

PRELOAD TORQUE SPECIFICATION

Total Preload Torque

1. Rotate the drive pinion back and forth 2 to 3 times to check for unusual noise and rotation malfunction.
2. Rotate the drive pinion at least 20 times to check for smooth operation of the bearings.
3. Measure total preload torque using Tool. Tool number: ST3127S000 (J-25765-A) Total preload torque Gear ratio 3.538 Type: 2.49-4.57 N.m (0.26-0.46 kg-m, 22-40 in-lb) Gear ratio 3.692 Type: 2.38-4.46 N.m (0.25-0.45 kg-m, 21-39 in-lb) NOTE: Total preload torque = Drive pinion bearing preload torque + Side bearing preload torque (Scheme 123): Checking Total Preload Torque If the measured value is out of the specification, check and adjust each part. Adjust the drive pinion bearing preload torque first, then adjust the side bearing preload torque. If the total preload torque is greater than specification On drive pinion bearings: Replace collapsible spacer. On side bearings: Loosen side bearing adjuster. If the total preload torque is less than specification On drive pinion bearings: Tighten drive pinion lock nut. On side bearings: Tighten side bearing adjuster.

General Specifications

GENERAL SPECIFICATIONS

PRELOAD TORQUE SPECIFICATION

Specifications with CONSULT-II

DIFFERENTIAL LOCK CONTROL UNIT INSPECTION CHART

Scheme 124

Data are reference value and are measured between each terminal and ground.

DIFFERENTIAL LOCK CONTROL UNIT TERMINAL DATA REFERENCE VALUE

1. Rotate the drive pinion back and forth 2 to 3 times to check for unusual noise and rotation malfunction.
2. Rotate the drive pinion at least 20 times to check for smooth operation of the bearings.
3. Measure total preload torque using Tool. Tool number: ST3127S000 (J-25765-A) Total preload torque: 2.38-4.46 N.m (0.25-0.45 kg-m, 21-39 in-lb) NOTE: Total preload torque = Drive pinion bearing preload torque + Side bearing preload torque If the measured value is out of the specification, check and adjust each part. Adjust the drive pinion bearing preload torque first, then adjust the side bearing preload torque. If the total preload torque is greater than specification On drive pinion bearings: Replace collapsible spacer. On side bearings: Loosen side bearing adjuster. If the total preload torque is less than specification On drive pinion bearings: Tighten drive pinion lock nut. On side bearings: Tighten side bearing adjuster. see scheme 210: Checking Total Preload Torque

GENERAL SPECIFICATIONS

PRELOAD TORQUE SPECIFICATION
