COMPONENT INSPECTION
- CHECK FRONT POWER WINDOW MOTOR LH Does motor operate by connecting the battery voltage directly to power window motor? MOTOR CONDITION CHART Terminal Motor condition (+) (-) 1 2 DOWN 2 1 UP Is the inspection result normal? YES: Front power window motor LH is OK. NO: Replace front power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-320233-S24391439612009071300000) ".
- CHECK FRONT POWER WINDOW MOTOR RH Does motor operate by connecting the battery voltage directly to front power window motor RH? MOTOR TERMINAL CONDITION CHART Terminal Motor condition (+) (-) 1 2 DOWN 2 1 UP Is the inspection result normal? YES: Front power window motor RH is OK. NO: Replace front power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-320233-S24391439612009071300000) ".
- CHECK REAR POWER WINDOW MOTOR LH Does motor operate by connecting the battery voltage directly to rear power window motor LH? CONTINUITY CHART Terminal Motor condition (+) (-) 2 1 DOWN 1 2 UP Is the inspection result normal? YES: Rear power window motor LH is OK. NO: Replace rear power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-320233-S06280241482009071300000) ".
- CHECK REAR POWER WINDOW MOTOR RH Does motor operate by connecting the battery voltage directly to rear power window motor RH? MOTOR TERMINAL CONDITION CHART Terminal Motor condition (+) (-) 2 1 DOWN 1 2 UP Is the inspection result normal? YES: Rear power window motor RH is OK. NO: Replace rear power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-320233-S06280241482009071300000) ".
Diagnosis Procedure
- CHECK REAR POWER VENT WINDOW SWITCH RH SIGNAL Turn ignition switch OFF. Disconnect rear power vent window motor RH. Turn ignition switch ON. Check voltage between rear power vent window motor LH connector B150 terminals 1, 2 and ground. VOLTAGE SPECIFICATION Connector Terminals Condition Voltage (V) (Approx.) (+) (-) B150 1 Ground Opening Battery voltage Closing 0 2 Opening 0 Closing Battery voltage Is the inspection result normal? YES: Replace rear power vent window motor RH. Refer to " «REMOVAL AND INSTALLATION (WITH REAR POWER VENT WINDOWS)»(ref-320233-S27644923002009071300000) ". NO: Repair or replace harness.
VALUES ON THE DIAGNOSIS TOOL
| Monitor Item | Condition | Value/Status |
|---|---|---|
| AIR COND SW | A/C switch OFF | OFF |
| A/C switch ON | ON | |
| AUT LIGHT SYS | Outside of the room is dark | OFF |
| Outside of the room is bright | ON | |
| AUTO LIGHT SW | Lighting switch OFF | OFF |
| Lighting switch AUTO | ON | |
| BACK DOOR SW | Back door closed | OFF |
| Back door opened | ON | |
| CDL LOCK SW | Door lock/unlock switch does not operate | OFF |
| Press door lock/unlock switch to the LOCK side | ON | |
| CDL UNLOCK SW | Door lock/unlock switch does not operate | OFF |
| Press door lock/unlock switch to the UNLOCK side | ON | |
| DOOR SW-AS | Front door RH closed | OFF |
| Front door RH opened | ON | |
| DOOR SW-DR | Front door LH closed | OFF |
| Front door LH opened | ON | |
| DOOR SW-RL | Rear door LH closed | OFF |
| Rear door LH opened | ON | |
| DOOR SW-RR | Rear door RH closed | OFF |
| Rear door RH opened | ON | |
| ENGINE RUN | Engine stopped | OFF |
| Engine running | ON | |
| FR FOG SW | Front fog lamp switch OFF | OFF |
| Front fog lamp switch ON | ON | |
| FR WASHER SW | Front washer switch OFF | OFF |
| Front washer switch ON | ON | |
| FR WIPER LOW | Front wiper switch OFF | OFF |
| Front wiper switch LO | ON | |
| FR WIPER HI | Front wiper switch OFF | OFF |
| Front wiper switch HI | ON | |
| FR WIPER INT | Front wiper switch OFF | OFF |
| Front wiper switch INT | ON | |
| FR WIPER STOP | Any position other than front wiper stop position | OFF |
| Front wiper stop position | ON | |
| HAZARD SW | When hazard switch is not pressed | OFF |
| When hazard switch is pressed | ON | |
| LIGHT SW 1ST | Lighting switch OFF | OFF |
| Lighting switch 1st | ON | |
| HEADLAMP SW1 | Headlamp switch OFF | OFF |
| Headlamp switch 1st | ON | |
| HEADLAMP SW2 | Headlamp switch OFF | OFF |
| Headlamp switch 1st | ON | |
| HI BEAM SW | High beam switch OFF | OFF |
| High beam switch HI | ON | |
| H/L WASH SW | NOTE: The item is indicated, but not monitored | OFF |
| IGN ON SW | Ignition switch OFF or ACC | OFF |
| Ignition switch ON | ON | |
| IGN SW CAN | Ignition switch OFF or ACC | OFF |
| Ignition switch ON | ON | |
| INT VOLUME | Wiper intermittent dial is in a dial position 1 - 7 | 1 - 7 |
| I-KEY LOCK (1) | LOCK button of Intelligent Key is not pressed | OFF |
| LOCK button of Intelligent Key is pressed | ON | |
| I-KEY UNLOCK (1) | UNLOCK button of Intelligent Key is not pressed | OFF |
| UNLOCK button of Intelligent Key is pressed | ON | |
| KEY ON SW | Mechanical key is removed from key cylinder | OFF |
| Mechanical key is inserted to key cylinder | ON | |
| KEYLESS LOCK (2) | LOCK button of key fob is not pressed | OFF |
| LOCK button of key fob is pressed | ON | |
| KEYLESS UNLOCK (2) | UNLOCK button of key fob is not pressed | OFF |
| UNLOCK button of key fob is pressed | ON | |
| OIL PRESS SW | Ignition switch OFF or ACC Engine running | OFF |
| Ignition switch ON | ON | |
| PASSING SW | Other than lighting switch PASS | OFF |
| Lighting switch PASS | ON | |
| PUSH SW1 | Return to ignition switch to LOCK position | OFF |
| Press ignition switch | ON | |
| REAR DEF SW | Rear window defogger switch OFF | OFF |
| Rear window defogger switch ON | ON | |
| RKE LOCK AND UNLOCK (2) | NOTE: The item is indicated, but not monitored | OFF |
| ON | ||
| RR WASHER SW | Rear washer switch OFF | OFF |
| Rear washer switch ON | ON | |
| RR WIPER INT | Rear wiper switch OFF | OFF |
| Rear wiper switch INT | ON | |
| RR WIPER ON | Rear wiper switch OFF | OFF |
| Rear wiper switch ON | ON | |
| RR WIPER STOP | Rear wiper stop position | OFF |
| Other than rear wiper stop position | ON | |
| TAIL LAMP SW | Lighting switch OFF | OFF |
| Lighting switch 1ST | ON | |
| TRNK OPNR SW | When back door opener switch is not pressed | OFF |
| When back door opener switch is pressed | ON | |
| TURN SIGNAL L | Turn signal switch OFF | OFF |
| Turn signal switch LH | ON | |
| TURN SIGNAL R | Turn signal switch OFF | OFF |
| Turn signal switch RH | ON | |
| VEHICLE SPEED | While driving | Equivalent to speedometer reading |
| (1) With Intelligent Key (2) With remote keyless entry system | ||
| NOTE |
|---|
| The item is indicated, but not monitored |
| NOTE |
|---|
| The item is indicated, but not monitored |
| (1) | With Intelligent Key |
| (2) | With remote keyless entry system |
MONITOR ITEM CONDITION CHART
Scheme 10
- CHECK BCM POWER SUPPLY AND GROUND CIRCUIT Check BCM power supply and ground circuit. Refer to " «DIAGNOSIS PROCEDURE»(ref-320221-S10966391262009071300000) ". Is the inspection result normal? YES: GO TO 2 NO: Repair or replace the malfunctioning parts.
- CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH POWER SUPPLY AND GROUND CIRCUIT Check power window switch main power supply and ground circuit. Refer to " «POWER WINDOW MAIN SWITCH : COMPONENT FUNCTION CHECK»(ref-320232-S21715065812009071300000) ". Is the inspection result normal? YES: GO TO 3 NO: Repair or replace the malfunctioning parts.
- CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH SERIAL CIRCUIT Check main power window and door lock/unlock switch serial circuit. Refer to " «POWER WINDOW MAIN SWITCH : COMPONENT FUNCTION CHECK»(ref-320232-S21715065812009071300000) ". Is the inspection result normal? YES: GO TO 4 NO: Repair or replace the malfunctioning parts.
- CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH Check main power window and door lock/unlock switch. Refer to " «POWER WINDOW MAIN SWITCH : COMPONENT FUNCTION CHECK»(ref-320232-S21715065812009071300000) ". Is the inspection result normal? YES: Inspection End. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-320178-S26015053282009071300000) ".
- CHECK FRONT POWER WINDOW MOTOR LH Check front power window motor LH. Refer to " «DRIVER SIDE : COMPONENT FUNCTION CHECK»(ref-320232-S36544077962009071300000) ". Is the inspection result normal? YES: Inspection End. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-320178-S26015053282009071300000) ".
- CHECK POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH Check power window and door lock/unlock switch RH. Refer to " «FRONT POWER WINDOW SWITCH : COMPONENT FUNCTION CHECK»(ref-320232-S23575066072009071300000) ". Is the inspection result normal? YES: GO TO 2 NO: Repair or replace the malfunctioning parts.
- CHECK POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH SERIAL LINK CIRCUIT Check power window and door lock/unlock switch RH serial link circuit. Refer to " «FRONT POWER WINDOW SWITCH : COMPONENT FUNCTION CHECK»(ref-320232-S31000899762009071300000) ". Is the inspection result normal? YES: GO TO 3 NO: Repair or replace the malfunctioning parts.
- CHECK FRONT POWER WINDOW MOTOR RH CIRCUIT Check front power window motor RH circuit. Refer to " «PASSENGER SIDE : COMPONENT FUNCTION CHECK»(ref-320232-S14534306992009071300000) ". Is the inspection result normal? YES: Inspection End. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-320178-S26015053282009071300000) ".
- CHECK REAR POWER WINDOW SWITCH LH Check rear power window switch LH. Refer to " «REAR POWER WINDOW SWITCH : COMPONENT FUNCTION CHECK»(ref-320232-S41693561502009071300000) ". Is the inspection result normal? YES: GO TO 2 NO: Repair or replace the malfunctioning parts.
- CHECK REAR POWER WINDOW MOTOR LH Check rear power window motor LH. Refer to " «REAR LH : COMPONENT FUNCTION CHECK»(ref-320232-S32189861202009071300000) ". Is the inspection result normal? YES: Inspection End. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-320178-S26015053282009071300000) ".
- CHECK REAR POWER WINDOW SWITCH RH Check rear power winodw switch RH. Refer to " «REAR POWER WINDOW SWITCH : COMPONENT FUNCTION CHECK»(ref-320232-S41693561502009071300000) ". Is the inspection result normal? YES: GO TO 2 NO: Repair or replace the malfunctioning parts.
- CHECK REAR POWER WINDOW MOTOR RH Check rear power window motor RH. Refer to " «REAR RH : COMPONENT FUNCTION CHECK»(ref-320232-S37385311682009071300000) ". Is the inspection result normal? YES: Inspection End. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-320178-S26015053282009071300000) ".
- CHECK DOOR WINDOW SLIDING PART A foreign material adheres to window glass or glass run rubber. Glass run rubber wear or deformation. Sash is tilted too much or not enough. Is the inspection result normal? YES: GO TO 2 NO: Repair or replace the malfunctioning parts.
- CHECK ENCODER CIRCUIT Check encoder circuit. Refer to " «DRIVER SIDE : COMPONENT FUNCTION CHECK»(ref-320232-S34176546432009071300000) ". Is the inspection result normal? YES: Inspection End. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-320178-S26015053282009071300000) ".
- CHECK DOOR WINDOW SLIDING PART A foreign material adheres to window glass or glass run rubber. Glass run rubber wear or deformation. Sash is tilted too much or not enough. Is the inspection result normal? YES: GO TO 2 NO: Repair or replace the malfunctioning parts.
- CHECK ENCODER CIRCUIT Check encoder circuit. Refer to " «PASSENGER SIDE : COMPONENT FUNCTION CHECK»(ref-320232-S21498843562009071300000) ". Is the inspection result normal? YES: Inspection End. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-320178-S26015053282009071300000) ".
- CHECK ENCODER Check encoder. Refer to " «DRIVER SIDE : COMPONENT FUNCTION CHECK»(ref-320232-S34176546432009071300000) ". Is the inspection result normal? YES: Inspection End. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-320178-S26015053282009071300000) ".
- CHECK ENCODER Check encoder. Refer to " «PASSENGER SIDE : COMPONENT FUNCTION CHECK»(ref-320232-S21498843562009071300000) ". Is the inspection result normal? YES: Inspection End. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-320178-S26015053282009071300000) ".
- CHECK FRONT DOOR SWITCH Check front door switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-320232-S04010582772009071300000) ". Is the inspection result normal? YES: Inspection End. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-320178-S26015053282009071300000) ".
- CHECK FRONT DOOR LOCK ASSEMBLY LH (KEY CYLINDER SWITCH) Check front door lock assembly LH (key cylinder switch). Refer to " «COMPONENT FUNCTION CHECK»(ref-320232-S17617895762009071300000) ". Is the inspection result normal? YES: Inspection End. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-320178-S26015053282009071300000) ".
- CHECK INTELLIGENT KEY OR KEYFOB FUNCTION Check Intelligent Key or keyfob function. Refer to " «INTELLIGENT KEY : CONSULT-III FUNCTION (BCM - INTELLIGENT KEY)»(ref-320221-S11651664122009071300000) " with Intelligent Key or " «MULTIREMOTE ENT : CONSULT-III FUNCTION (BCM - MULTIREMOTE ENT)»(ref-320221-S18192257852009071300000) " with remote keyless entry system. Is the inspection result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-320178-S26015053282009071300000) ". NO: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-320221-S13583495772009071300000) ".
- REPLACE MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-320232-S24079453482009071300000) ". Is the inspection result normal? YES: Inspection End. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-320178-S26015053282009071300000) ".
- CHECK BCM POWER SUPPLY AND GROUND CIRCUIT Check BCM power supply and ground circuit. Refer to " «DIAGNOSIS PROCEDURE»(ref-320221-S10966391262009071300000) ". Is the inspection result normal? YES: GO TO 2 NO: Repair or replace the malfunctioning parts.
- CHECK REAR POWER VENT WINDOW SWITCH Check rear power vent window switch. Refer to " «DIAGNOSIS PROCEDURE»(ref-320232-S21868561992009071300000) ". Is the inspection result normal? YES: GO TO 3 NO: Repair or replace the malfunctioning parts.
- CHECK REAR POWER VENT WINDOW MOTOR CIRCUIT Check rear power vent window motor circuit. Refer to " «DIAGNOSIS PROCEDURE»(ref-320232-S31585236692009071300000) " and " «DIAGNOSIS PROCEDURE»(ref-320232-S25593610002009071300000) ". Is the inspection result normal? YES: GO TO 4 NO: Repair or replace the malfunctioning parts.
- CHECK REAR POWER VENT WINDOW RELAY Check rear power vent window relay. Refer to " «DIAGNOSIS PROCEDURE»(ref-320232-S37393502622009071300000) " and " «DIAGNOSIS PROCEDURE»(ref-320232-S13437514852009071300000) ". Is the inspection result normal? YES: Inspection End. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-320178-S26015053282009071300000) ".
