INSTALLATION
Installation is in the reverse order of removal.
- Use a genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
- While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out by passenger compartment air pressure when a door is closed.
- The molding must be installed securely so that it is in position and leaves no gap.
- Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (preferably 24 hours). Curing time varies with temperature and humidity.
| WARNING | Keep heat and open flames away as primers and adhesive are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid contact with the skin and eyes. Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled. If affected by vapor inhalation, immediately move to an area with fresh air. Driving the vehicle before the urethane adhesive has completely cured may affect the performance of the windshield in case of an accident. |
| CAUTION | Do not use an adhesive which is past its usable term. Shelf life of this product is limited to six months after the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the box. Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator. Do not leave primers or adhesive cartridge unattended with their caps open or off. The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely cured. Curing time varies depending on temperature and humidities. The curing time will increase under lower temperatures and lower humidities. |
Scheme 90
Repairing Water Leaks for Windshield
Leaks can be repaired without removing and reinstalling glass.
If water is leaking between the urethane adhesive material and body or glass, determine the extent of leakage.
This can be done by applying water to the windshield area while pushing glass outward.
To stop the leak, apply primer (if necessary) and then urethane adhesive to the leak point.
Scheme 91
REMOVAL
- Remove the rear spoiler. Refer to " «REMOVAL AND INSTALLATION»(ref-320194-S13274492132009071300000) ".
- Disconnect the rear window defogger electrical connectors.
- Remove the rear glass stays.
- Remove the hinge nuts and the rear glass assembly.
- Remove the striker and handle.
- Remove the rear glass hinges.
Installation is in the reverse order of removal.
Scheme 92
Scheme 93
- Remove the front door speaker. Refer to " «REMOVAL AND INSTALLATION»(ref-320222-S01792434842009071300000) ".
- Remove the hole cover over rear glass bolt.
- Temporarily reconnect the power window switch.
- Operate the power window main switch to raise/lower the door window until the glass bolts can be seen.
- Remove the inside seal.
- Remove the glass bolts.
- While holding the front door glass, raise it at the rear end and pull the glass out of the sash toward the outside of the door.
Installation is in the reverse order of removal.
Glass bolts : 6.1 N.m (0.62 kg-m, 54 in-lb)
- Remove the front door speaker. Refer to " «REMOVAL AND INSTALLATION»(ref-320222-S01792434842009071300000) ".
- Remove the hole cover over rear glass bolt.
- Temporarily reconnect the power window switch.
- Operate the power window main switch to raise/lower the door window until the glass bolts can be seen.
- Remove the inside seal.
- Remove the glass bolts.
- Raise the front door glass and hold it in place with suitable tool.
- Disconnect the harness connector from the regulator assembly.
- Remove the bolts and the regulator assembly.
- Install the regulator assembly.
- Connect the harness connector to the regulator assembly.
- Align the glass and install the glass bolts. Glass bolts : 6.1 N.m (0.62 kg-m, 54 in-lb)
- Reset the limit switch. Follow the "Setting of Limit Switch" procedure.
- Install front door speaker. Refer to " «REMOVAL AND INSTALLATION»(ref-320222-S01792434842009071300000) ".
Installation is in the reverse order of removal.
Glass bolts : 6.1 N.m (0.62 kg-m, 54 in-lb)
- Connect the harness connector to the regulator assembly and install the regulator and guide channel.
- Install the glass from outside to ensure that it is in both the front and rear glass channels. Tighten glass bolts to the specified torque. Glass bolts : 6.1 N.m (0.62 kg-m, 54 in-lb)
- Install the inside seal.
- Install the rear door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-320209-S15187751682009071300000) ".
Scheme 94
- Remove the luggage side finisher lower. Refer to " «REMOVAL AND INSTALLATION»(ref-320209-S27835682652009071300000) ".
- Remove the luggage side finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-320209-S17240996162009071300000) ".
- Remove the rear side window latch bolts.
- Remove the rear side window nuts.
Installation is in the reverse order of removal.
- Install the glass from outside to insure that it is even with the top and bottom of the opening.
Scheme 95
- Remove the rear lower finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-320209-S17240996162009071300000) ".
- Remove the rear pillar upper finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-320209-S17240996162009071300000) ".
- Disconnect the rear side window motor harness.
- Remove the rear side window motor bolts.
- Remove the rear side window nuts.
Installation is in the reverse order of removal.
- Install the glass from outside to insure that it is even with the top and bottom of the opening.
