Scheme 3
Component Description
| Component | Function |
|---|---|
| Pedal adjusting switch | Provide move forward/backward signals to pedal adjusting motor |
| Pedal adjusting motor | Move pedal assembly forward and backward |
COMPONENT DESCRIPTION
Scheme 4
Scheme 5
- CHECK PEDAL ADJUSTING SWITCH POWER SUPPLY Turn ignition switch OFF. Disconnect pedal adjusting switch. Check voltage between pedal adjusting switch connector M83 terminal 1 and ground. 1 - Ground : Battery voltage . Is inspection result normal? YES: GO TO 2 NO: Repair or replace harness.
- CHECK PEDAL ADJUSTING SWITCH GROUND CIRCUIT Check continuity between pedal adjusting switch connector M83 terminal 4 and ground. 4 - Ground : Continuity should exist . Is inspection result normal? YES: Pedal adjusting switch power supply and ground circuit is OK. NO: Repair or replace harness.
Scheme 6
Scheme 7
Scheme 8
- CHECK PEDAL ADJUSTING SWITCH Turn ignition switch OFF. Disconnect pedal adjusting switch. Check continuity between pedal adjusting switch terminals as follows. CONTINUITY SPECIFICATION Terminals Condition Continuity 3 1 Pedal adjusting switch forward. Continuity should exist. Pedal adjusting switch neutral. Continuity should not exist. 4 Pedal adjusting switch backward. Continuity should exist. Pedal adjusting switch neutral. Continuity should not exist. 2 1 Pedal adjusting switch backward. Continuity should exist. Pedal adjusting switch neutral. Continuity should not exist. 4 Pedal adjusting switch forward. Continuity should exist. Pedal adjusting switch neutral. Continuity should not exist. Is inspection result normal? YES: GO TO 2 NO: Replace pedal adjusting switch. Refer to " «EXPLODED VIEW»(ref-320213-S40115825932009071300000) ".
- CHECK PEDAL ADJUSTING MOTOR HARNESS Disconnect pedal adjusting motor. Check continuity between pedal adjusting switch connector M83 (A) terminals 2, 3 and pedal adjusting motor connector E167 (B) terminals 1, 2. 2 - 2 : Continuity should exist . 3 - 1 : Continuity should exist . Check continuity between pedal adjusting switch connector M83 (A) terminals 2, 3 and ground. 2 - Ground : Continuity should not exist . 3 - Ground : Continuity should not exist . Is inspection result normal? YES: GO TO 3 NO: Repair or replace harness.
- CHECK PEDAL ADJUSTING MOTOR POWER SUPPLY Connect pedal adjusting switch. Check voltage between pedal adjusting motor connector E167 and ground. VOLTAGE SPECIFICATION Connector Terminals Condition Voltage (V) (Approx.) (+) (-) E167 1 Ground Pedal adjusting switch forward Battery voltage Other than above 0 2 Pedal adjusting switch backward Battery voltage Other than above 0 Is inspection result normal? YES: Replace pedal adjusting motor. Refer to " «REMOVAL AND INSTALLATION»(ref-320229-S23854092042009071300000) ". NO: Repair or replace harness.
