DETAILED FLOW
- CUSTOMER INFORMATION Talk to the customer to obtain detailed information about the symptom. GO TO 2
- PRELIMINARY CHECK Perform preliminary check. Refer to " «PRELIMINARY CHECK»(ref-320229-S04965419972009071300000) ". GO TO 3
- SYMPTOM Check for symptoms. Refer to " «SYMPTOM TABLE»(ref-320229-S06919997972009071300000) ". GO TO 4
- MALFUNCTIONING PARTS Repair or replace the applicable parts. GO TO 5
- SYSTEM CHECK Operate the pedal adjusting switch to ensure that the pedals move completely forward and backward. Does the system operate normally? YES: Inspection End. NO: Refer to " «INTERMITTENT INCIDENT»(ref-320178-S26015053282009071300000) ".
Preliminary Check
- FOREIGN OBJECTS Check the following: objects on or behind the pedals that could cause binding Are there any foreign objects that could be causing interference with the pedals? YES: Remove objects. NO: GO TO 2
- WIRING CONNECTIONS Disconnect pedal adjusting motor. Check terminals for damage or loose connections. Reconnect harness connector. Are any connectors damaged or loose? YES: Repair or replace damaged parts. NO: GO TO 3
- POWER AND GROUND Check power supply and ground circuits for pedal adjusting switch. Refer to " «PEDAL ADJUSTING SWITCH POWER SUPPLY AND GROUND CIRCUIT INSPECTION»(ref-320229-S34259638052009071300000) ". Is the inspection result normal? YES: Refer to " «SYMPTOM TABLE»(ref-320229-S06919997972009071300000) ". NO: Repair or replace as necessary.
Automatic Drive Positioner Interlocking Adjustable Pedal
Automatic drive positioner interlocking adjustable pedal. Refer to " AUTOMATIC DRIVE POSITIONER SYSTEM : SYSTEM DESCRIPTION ".
Scheme 12
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the " SRS AIRBAG " and " SEAT BELTS " articles.
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SRS AIRBAG . Do not use electrical test equipment on any circuit related to the SRS unless instructed to in the article. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
Precaution for Work
- When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
- When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
- Protect the removed parts with a shop cloth and keep them.
- Replace a deformed or damaged clip.
- If a part is specified as a non-reusable part, always replace it with new one.
- Be sure to tighten bolts and nuts securely to the specified torque.
- After re-installation is completed, be sure to check that each part works normally.
- Follow the steps below to clean components. Water soluble foul: Dip a soft cloth into lukewarm water, and wring the water out of the cloth to wipe the fouled area. Then rub with a soft and dry cloth. Oily foul: Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%), and wipe the fouled area. Then dip a cloth into fresh water, and wring the water out of the cloth to wipe the detergent off. Then rub with a soft and dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol, or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
