ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT
- SAVING VEHICLE SPECIFICATION Perform "READ CONFIGURATION" with CONSULT-III to save or print current vehicle specification. GO TO 2
- REPLACE BCM Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-382181-S23530132732011011400000) ". GO TO 3
- WRITING VEHICLE SPECIFICATION Perform "WRITE CONFIGURATION - Config file" or "WRITE CONFIGURATION - Manual selection" with CONSULT-III to write vehicle specification. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-382181-S20926656752011011400000) ". GO TO 4
- INITIALIZE BCM (NATS) Perform BCM initialization. (NATS) Work End.
CONFIGURATION : SPECIAL REPAIR REQUIREMENT
- WRITING VEHICLE SPECIFICATION Perform "WRITE CONFIGURATION" with CONSULT-III. When writing saved data: GO TO 2 When writing manually: GO TO 3
- PERFORM "WRITE CONFIGURATION - CONFIG FILE" Perform "WRITE CONFIGURATION - Config file" with CONSULT-III. Work End.
- PERFORM "WRITE CONFIGURATION - MANUAL SELECTION" For "WRITE CONFIGURATION - Manual selection", using the following flow chart, identify the correct model and configuration list. Confirm and/or change setting value for each item according to the configuration list. Depending on CONSULT-III software version being used, some or all of the write configuration items shown in the following configuration lists may be displayed. If an item does not display on the CONSULT-III "WRITE CONFIGURATION - Manual selection" screen, then it is an auto setting item and it cannot be manually set or changed. MANUAL SETTING ITEM MANUAL SETTING ITEM Items Setting value KEYLESS ENTRY WITH<=>WITHOUT I-KEY WITH<=>WITHOUT DTRL WITH<=>WITHOUT AUTO DOOR UNLOCK TIMING WITH I-KEY<=>W/O I-KEY NOTE: Confirm vehicle model. Refer to " «MODEL VARIATION»(ref-382152-S16615300642011011400000) ". Work End.
OUTLINE
- BCM (Body Control Module) controls the various electrical components. It inputs the information required to the control from CAN communication and the signal received from each switch and sensor.
- BCM has combination switch reading function for reading the operation status of combination switches (light, turn signal, wiper and washer) in addition to a function for controlling the operation of various electrical components. It also has the signal transmission function as the passed point of signal and the power consumption control function that reduces the power consumption with the ignition switch OFF.
- BCM is equipped with the diagnosis function that performs the diagnosis with CONSULT-III and various settings.
BCM control function list
| System | Refer to |
|---|---|
| Combination switch reading system | " SYSTEM DIAGRAM " |
| Signal buffer system | " SYSTEM DIAGRAM " |
| Power consumption control system | " SYSTEM DIAGRAM " |
| Auto light system | " SYSTEM DIAGRAM " |
| Turn signal and hazard warning lamp system | " SYSTEM DIAGRAM " |
| Headlamp system | " SYSTEM DIAGRAM " |
| Front fog lamp system (if equipped) | " SYSTEM DIAGRAM " |
| Daytime running light system (if equipped) | " SYSTEM DIAGRAM " |
| Interior room lamp control system | " SYSTEM DIAGRAM " |
| Step lamp system | " SYSTEM DIAGRAM " |
| Interior room lamp battery saver system | " SYSTEM DIAGRAM " |
| Front wiper and washer system | " SYSTEM DIAGRAM " |
| Rear wiper and washer system | " SYSTEM DIAGRAM " |
| Warning chime system | " WARNING CHIME SYSTEM : SYSTEM DIAGRAM " |
| Door lock system | WITH INTELLIGENT KEY SYSTEM: " DOOR LOCK AND UNLOCK SWITCH : SYSTEM DIAGRAM " WITHOUT INTELLIGENT KEY SYSTEM: " DOOR LOCK AND UNLOCK SWITCH : SYSTEM DIAGRAM " |
| (NATS) Nissan anti-theft system | WITH INTELLIGENT KEY SYSTEM: " SYSTEM DIAGRAM " WITHOUT INTELLIGENT KEY SYSTEM: " SYSTEM DIAGRAM " |
| Vehicle security system | WITH INTELLIGENT KEY SYSTEM: " SYSTEM DIAGRAM " WITHOUT INTELLIGENT KEY SYSTEM: " SYSTEM DIAGRAM " |
| Rear window defogger system | " SYSTEM DIAGRAM " |
| Remote keyless entry system | " REMOTE KEYLESS ENTRY : SYSTEM DIAGRAM " |
| Intelligent Key system (if equipped) | " INTELLIGENT KEY : SYSTEM DIAGRAM " |
| Power window system | " SYSTEM DIAGRAM " |
| RAP (retained accessory power) system | " RETAINED PWR : CONSULT-III FUNCTION (BCM - RETAINED PWR) " |
| TPMS (tire pressure monitoring system) | TPMS |
BCM CONTROL FUNCTION LIST
Scheme 75
- BCM M18, M19, M20 (view with instrument panel removed)
Scheme 76
- BCM reads the status of the combination switch (light, turn signal, wiper and washer) and recognizes the status of each switch.
- BCM is a combination of 5 output terminals (OUTPUT 1 - 5) and 5 input terminals (INPUT 1 - 5). It reads a maximum of 20 switch status.
Scheme 77
Combination switch INPUT-OUTPUT system list
| System | OUTPUT 1 | OUTPUT 2 | OUTPUT 3 | OUTPUT 4 | OUTPUT 5 |
|---|---|---|---|---|---|
| INPUT 1 | FR WASHER | FR WIPER LOW | TURN LH | TURN RH | |
| INPUT 2 | FR WIPER HI | FR WIPER INT | PASSING | HEADLAMP 1 | |
| INPUT 3 | INT VOLUME 1 | RR WASHER | HEADLAMP 2 | HI BEAM | |
| INPUT 4 | RR WIPER INT | INT VOLUME 3 | AUTO LIGHT | TAIL LAMP | |
| INPUT 5 | INT VOLUME 2 | RR WIPER | FR FOG |
COMBINATION SWITCH INPUT-OUTPUT SYSTEM LIST
Note. Headlamp has a dual system switch.
COMBINATION SWITCH READING FUNCTION
Description
Scheme 78
Scheme 79
- BCM reads the status of the combination switch at 10 ms interval normally. NOTE: BCM reads the status of the combination switch at 20 ms interval when BCM is controlled at low power consumption control mode.
- BCM operates as follows and judges the status of the combination switch. INPUT 1 - 5 outputs the voltage waveforms of 5 systems simultaneously. It operates the transistor on OUTPUT side in the following order: OUTPUT 5 --> 4 --> 3 --> 2 --> 1. The voltage waveform of INPUT corresponding to the formed circuit changes according to the operation of the transistor on OUTPUT side if any (1 or more) switches are ON. It reads this change of the voltage as the status signal of the combination switch.
Operation Example
In the following operation example, the combination of the status signals of the combination switch is replaced as follows: INPUT 1 - 5 to "1 - 5" and OUTPUT 1 - 5 to "A - E".
Example 1: When a switch (TURN RH switch) is turned ON
Scheme 80
- The circuit between INPUT 1 and OUTPUT 5 is formed when the TURN RH switch is turned ON.
- BCM detects the combination switch status signal "1E" when the signal of OUTPUT 5 is input to INPUT 1.
- BCM judges that the TURN RH switch is ON when the signal "1E" is detected.
Example 2: When some switches (turn RH switch, front wiper LO switch) are turned ON
Scheme 81
- The circuits between INPUT 1 and OUTPUT 5 and between INPUT 1 and OUTPUT 3 are formed when the TURN RH switch and FR WIPER LOW switch are turned ON.
- BCM detects the combination switch status signal "1CE" when the signals of OUTPUT 3 and OUTPUT 5 are input to INPUT 1.
- BCM judges that the TURN RH switch and FR WIPER LOW switch are ON when the signal "1CE" is detected.
BCM has the signal transmission function that outputs/transmits each input/received signal to each unit.
Signal transmission function list
| Signal name | Input | Output | Description |
|---|---|---|---|
| Oil pressure switch signal | IPDM E/R (CAN) | Combination meter (CAN) | Transmits the received oil pressure switch signal via CAN communication. |
SIGNAL TRANSMISSION FUNCTION LIST
Scheme 82
- BCM incorporates a power consumption control function that reduces the power consumption according to the vehicle status.
- BCM switches the status (control mode) by itself with the power saving control function. It performs the sleep request to each unit [IPDM E/R, combination meter and Intelligent Key unit (with Intelligent Key)] that operates with the ignition switch OFF.
Normal mode (wake-up)
- CAN communication is normally performed with other units
- Each control with BCM is operating properly
CAN communication sleep mode (CAN sleep)
- CAN transmission is stopped
- Control with BCM only is operating
Low power consumption mode (BCM sleep)
- Low power consumption control is active
- CAN transmission is stopped
LOW POWER CONSUMPTION CONTROL WITH BCM
BCM reduces the power consumption with the following operation in the low power consumption mode.
- The reading interval of the each switches changes from 10 ms interval to 20 ms interval.
Sleep mode activation
- BCM receives the sleep-ready signal (ready) from IPDM E/R, combination meter and Intelligent Key unit (with Intelligent Key) via CAN communication.
- BCM transmits the sleep wake up signal (sleep) to each unit when all of the CAN sleep conditions are fulfilled.
- Each unit stops the transmission of CAN communication with the sleep wake up signal. BCM is in CAN communication sleep mode.
- BCM is in the low power consumption mode and perform the low power consumption control when all of the BCM sleep conditions are fulfilled with CAN sleep condition.
Sleep condition
| CAN sleep condition | BCM sleep condition |
|---|---|
| Receiving the sleep-ready signal (ready) from all units Ignition switch: OFF Vehicle security system alarm: No operation Warning lamp: No operation Warning chime: No operation Stop lamp switch: OFF Key switch status: No change for 2 seconds Hazard warning lamp: No operation Exterior lamp: OFF Door lock status: No change for 2 seconds CONSULT-III communication status: No communication Door switch status: No change for 2 seconds | The controls only BCM are completed. (Interior room lamp battery saver: Time out etc.) |
SLEEP CONDITION CHART
Wake-up operation
- BCM transmits sleep wake up signal (wake up) to each unit when any condition listed below is established, and then goes into normal mode from low power consumption mode.
- Each unit starts transmissions with CAN communication by receiving sleep wake up signals. Each unit transmits wake up signals to BCM with CAN communication to convey the start of CAN communication.
Wake-up condition
| BCM wake-up condition |
|---|
| Ignition switch: OFF --> ACC or ON Stop lamp switch: ON (Depress brake pedal) Any door switch: OFF --> ON Lighting switch: OFF --> 1ST or PASS Hazard switch: OFF --> ON Back door opener switch OFF --> ON Remote keyless entry receiver: Receiving Intelligent Key unit: Receiving (with Intelligent Key) |
WAKE-UP CONDITION CHART
Scheme 83
DATA MONITOR
| Monitor Item [Unit] | Description |
|---|---|
| IGN ON SW [On/Off] | Indicates condition of ignition switch ON position. |
| KEY ON SW [On/Off] | Indicates condition of key switch. |
| CDL LOCK SW [On/Off] | Indicates condition of lock signal from door lock and unlock switch. |
| CDL UNLOCK SW [On/Off] | Indicates condition of unlock signal from door lock and unlock switch. |
| DOOR SW-DR [On/Off] | Indicates condition of front door switch LH. |
| DOOR SW-AS [On/Off] | Indicates condition of front door switch RH. |
| DOOR SW-RR [On/Off] | Indicates condition of rear door switch RH. |
| DOOR SW-RL [On/Off] | Indicates condition of rear door switch LH. |
| BACK DOOR SW [On/Off] | Indicates condition of back door switch. |
| KEY CYL LK-SW [On/Off] | Indicates condition of lock signal from door key cylinder switch. |
| KEY CYL UN-SW [On/Off] | Indicates condition of unlock signal from door key cylinder switch. |
| I-KEY LOCK (2) [On/Off] | Indicates condition of lock signal from Intelligent Key. |
| I-KEY UNLOCK (2) [On/Off] | Indicates condition of unlock signal from Intelligent Key. |
| KEYLESS LOCK (2) [On/Off] | Indicates condition of lock signal from keyfob. |
| KEYLESS UNLOCK (2) [On/Off] | Indicates condition of unlock signal from keyfob. |
| () With Intelligent Key (2) Without Intelligent Key | |
| () | With Intelligent Key |
| (2) | Without Intelligent Key |
DATA MONITOR REFERENCE
WORK SUPPORT
| Support Item | Setting | Description |
|---|---|---|
| DOOR LOCK-UNLOCK SET | (1) ON OFF | Automatic door locks function ON. Automatic door locks function OFF. |
| ANTI-LOCK OUT SET | OFF (1) ON | Anti lock out function OFF. Anti lock out function ON. |
| AUTOMATIC DOOR LOCK SELECT | SHIFT OUT OF P (1) VH SPD | Doors lock automatically when shifted out of park (P). Doors lock automatically when vehicle speed reaches 24 km/h (15 mph). |
| AUTOMATIC DOOR UNLOCK SELECT | MODE6 MODE5 MODE4 MODE3 (3) MODE2 (2) MODE1 | Doors lock automatically when vehicle speed reaches 24 km/h (15 mph). Drivers door unlocks automatically when key is removed. Drivers door unlocks automatically when shifted into park (P). Drivers door unlocks automatically when ignition is switched from ON to OFF. Doors unlock automatically when key is removed. Doors unlock automatically when shifted into park (P). Doors unlock automatically when ignition is switched from ON to OFF. |
| AUTOMATIC LOCK/UNLOCK SELECT | ON OFF | Automatic lock/unlock function ON. Automatic lock/unlock function OFF. |
| (1) Initial setting all vehicles (2) Initial setting vehicles with Intelligent Key (3) Initial setting vehicles without Intelligent Key | ||
| (1) | Initial setting all vehicles |
| (2) | Initial setting vehicles with Intelligent Key |
| (3) | Initial setting vehicles without Intelligent Key |
WORK SUPPORT REFERENCE
| Monitor Item [Unit] | Description |
|---|---|
| IGN ON SW [ON/OFF] | Indicates condition of ignition switch in ON position |
| ACC ON SW [ON/OFF] | Indicates condition of ignition switch in ACC position |
| REAR DEF SW [ON/OFF] | Displays "Press (ON)/other (OFF)" status determined with the rear window defogger switch |
DATA MONITOR REFERENCE
| Monitor Item [Unit] | Description |
|---|---|
| DOOR SW-DR [ON/OFF] | Indicates condition of front door switch LH. |
| IGN ON SW [ON/OFF] | Indicates condition of ignition switch ON position. |
| KEY ON SW [ON/OFF] | Indicates condition of key switch. |
| LIGHT SW 1ST [ON/OFF] | Indicates condition of combination switch. |
| BUCKLE SW [ON/OFF] | Indicates condition of seat belt buckle switch. |
DATA MONITOR REFERENCE
| Monitor Item [Unit] | Description |
|---|---|
| IGN ON SW [ON/OFF] | Indicates condition of ignition switch ON position. |
| KEY ON SW [ON/OFF] | Indicates condition of key switch. |
| DOOR SW-DR [ON/OFF] | Indicates condition of front door switch LH. |
| DOOR SW-AS [ON/OFF] | Indicates condition of front door switch RH. |
| DOOR SW-RR [ON/OFF] | Indicates condition of rear door switch RH. |
| DOOR SW-RL [ON/OFF] | Indicates condition of rear door switch LH. |
| BACK DOOR SW [ON/OFF] | Indicates condition of back door switch. |
| KEY CYL LK-SW [ON/OFF] | Indicates condition of lock signal from door key cylinder switch. |
| KEY CYL UN-SW [ON/OFF] | Indicates condition of unlock signal from door key cylinder switch. |
| CDL LOCK SW [ON/OFF] | Indicates condition of lock signal from door lock and unlock switch. |
| CDL UNLOCK SW [ON/OFF] | Indicates condition of unlock signal from door lock and unlock switch. |
| I-KEY LOCK (1) [ON/OFF] | Indicates condition of lock signal from Intelligent Key. |
| I-KEY UNLOCK (1) [ON/OFF] | Indicates condition of unlock signal from Intelligent Key. |
| KEYLESS LOCK (2) [On/Off] | Indicates condition of lock signal from keyfob. |
| KEYLESS UNLOCK (2) [On/Off] | Indicates condition of unlock signal from keyfob. |
| (1) With Intelligent Key (2) Without Intelligent Key | |
| (1) | With Intelligent Key |
| (2) | Without Intelligent Key |
DATA MONITOR REFERENCE
| Work Item | Setting item | Setting | |
|---|---|---|---|
| SET I/L D-UNLCK INTCON | OFF | Interior room lamp timer function OFF. | |
| ON (1) | Interior room lamp timer function ON. | ||
| ROOM LAMP ON TIME SET | MODE 7 | 0 sec. | Sets the interior room lamp gradual brightening time. |
| MODE 6 | 5 sec. | ||
| MODE5 | 4 sec. | ||
| MODE 4 | 3 sec. | ||
| MODE 3 | 2 sec. | ||
| MODE 2 (1) | 1 sec. | ||
| MODE 1 | 0.5 sec. | ||
| ROOM LAMP OFF TIME SET | MODE 7 | 0 sec. | Sets the interior room lamp gradual dimming time. |
| MODE 6 | 5 sec. | ||
| MODE 5 | 4 sec. | ||
| MODE 4 | 3 sec. | ||
| MODE 3 | 2 sec. | ||
| MODE 2 (1) | 1 sec. | ||
| MODE 1 | 0.5 sec. | ||
| (1) Initial setting | |||
| (1) | Initial setting |
WORK ITEM REFERENCE
| Monitored Item Unit | Description |
|---|---|
| IGN ON SW [On/Off] | Indicates condition of ignition switch ON position. |
| KEY ON SW [On/Off] | Indicates condition of key switch. |
| ACC ON SW [On/Off] | Indicates condition of ignition switch ACC position. |
| KEYLESS LOCK [On/Off] | Indicates condition of lock signal from keyfob. |
| KEYLESS UNLOCK [On/Off] | Indicates condition of unlock signal from keyfob. |
| KEYLESS PANIC [On/Off] | Indicates condition of panic signal from keyfob. |
| DOOR SW-DR [On/Off] | Indicates condition of front door switch LH. |
| DOOR SW-AS [On/Off] | Indicates condition of front door switch RH. |
| DOOR SW-RR [On/Off] | Indicates condition of rear door switch RH. |
| DOOR SW-RL [On/Off] | Indicates condition of rear door switch LH. |
| BACK DOOR SW [On/Off] | Indicates condition of back door switch. |
| CDL LOCK SW [On/Off] | Indicates condition of lock signal from door lock and unlock switch. |
| CDL UNLOCK SW [On/Off] | Indicates condition of unlock signal from door lock and unlock switch. |
| KEY CYL LK SW [On/Off] | Indicates condition of lock signal from door key cylinder switch. |
DATA MONITOR REFERENCE
| Support Item | Setting | Description | |
|---|---|---|---|
| HORN CHIRP SET | OFF | Horn chirp function can be changed in this mode. | |
| ON (1) | |||
| HAZARD LAMP SET | MODE 4 (1) | Lock and Unlock | Hazard warning lamp function can be changed in this mode. |
| MODE 3 | Lock Only | ||
| MODE2 | Unlock Only | ||
| MODE 1 | OFF | ||
| MULTI ANSWER BACK SET | MODE2 | Lock | Hazard warning lamps flash twice and horn does not sound. |
| Unlock | Hazard warning lamps do not flash and horn does not sound. | ||
| MODE1 (1) | Lock | Hazard warning lamps flash twice and horn sounds once. | |
| Unlock | Hazard warning lamps flash once and horn does not sound. | ||
| AUTO LOCK SET | MODE3 | 1 min | Auto locking function can be changed in this mode. |
| MODE2 | OFF | ||
| MODE1 (1) | 5 min | ||
| PANIC ALRM SET | MODE3 | 1.5 sec | Panic alarm operation can be changed in this mode. |
| MODE2 | OFF | ||
| MODE1 (1) | 0.5 sec | ||
| PW DOWN SET | MODE3 | 5 sec | Keyfob power window down can be changed in this mode. |
| MODE2 | OFF | ||
| MODE1 (1) | 3 sec | ||
| REMO CONT ID REGIST | Keyfob ID code can be registered. | ||
| REMO CONT ID ERASUR | Keyfob ID code can be erased. | ||
| REMO CONT ID CONFIR | Keyfob ID code is registration is displayed. | ||
| (1) Initial setting | |||
| (1) | Initial setting |
WORK SUPPORT REFERENCE
| Monitor Item [Unit] | Description |
|---|---|
| IGN ON SW [ON/OFF] | Indicates condition of ignition switch ON position. |
| ACC ON SW [ON/OFF] | Indicates condition of ignition switch ACC position. |
| HI BEAM SW [ON/OFF] | Indicates condition of combination switch. |
| HEAD LAMP SW 1 [ON/OFF] | |
| HEAD LAMP SW 2 [ON/OFF] | |
| LIGHT SW 1ST [ON/OFF] | |
| AUTO LIGHT SW [ON/OFF] | |
| PASSING SW [ON/OFF] | |
| FR FOG SW [On/Off] | |
| DOOR SW-DR [ON/OFF] | Indicates condition of front door switch LH. |
| DOOR SW-AS [ON/OFF] | Indicates condition of front door switch RH. |
| DOOR SW-RR [ON/OFF] | Indicates condition of rear door switch RH. |
| DOOR SW-RL [ON/OFF] | Indicates condition of rear door switch LH. |
| BACK DOOR SW [ON/OFF] | Indicates condition of back door switch. |
| TURN SIGNAL R [On/Off] | Indicates condition of combination switch. |
| TURN SIGNAL L [On/Off] | |
| CARGO LAMP SW [ON/OFF] | Indicates condition of cargo lamp switch. |
| OPTICAL SENSOR [V] | Indicates voltage signal from optical sensor. |
DATA MONITOR REFERENCE
| Work Item | Setting item | Setting | |
|---|---|---|---|
| BATTERY SAVER SET | OFF | Exterior lamp battery saver function OFF. | |
| ON (1) ) | Exterior lamp battery saver function ON. | ||
| CUSTOM A/LIGHT SETTING | MODE4 | Less sensitive setting than normal setting (Turns ON later than normal operation). | |
| MODE3 | More sensitive setting than MODE 2 (Turns ON earlier than MODE 2). | ||
| MODE2 | More sensitive setting than normal setting (Turns ON earlier than normal operation). | ||
| MODE1 (1) | Normal. | ||
| ILL DELAY SET | MODE8 | 180 sec | Sets delay timer function operation time (All doors closed). |
| MODE7 | 150 sec | ||
| MODE6 | 120 sec | ||
| MODE5 | 90 sec | ||
| MODE4 | 60 sec | ||
| MODE3 | 30 sec | ||
| MODE2 | OFF | ||
| MODE1 (1) | 45 sec | ||
| (1) Initial setting | |||
| (1) | Initial setting |
WORK SUPPORT REFERENCE
| Monitor Item [Unit] | Description |
|---|---|
| IGN ON SW [ON/OFF] | Indicates condition of ignition switch ON position. |
| IGN SW CAN [ON/OFF] | Indicates ignition switch ON signal received from IPDM E/R on CAN communication line. |
| FR WIPER HI [ON/OFF] | Indicates condition of front wiper operation of combination switch. |
| FR WIPER LOW [ON/OFF] | |
| FR WIPER INT [ON/OFF] | |
| FR WASHER SW [On/Off] | |
| INT VOLUME [1 - 7] | |
| FR WIPER STOP [On/Off] | Indicates front wiper motor auto stop signal received from IPDM E/R on CAN communication line. |
| VEHICLE SPEED [km/h/mph] | Indicates vehicle speed signal received from combination meter on CAN communication line. |
| RR WIPER ON [ON/OFF] | Indicates condition of rear wiper operation of combination switch. |
| RR WIPER INT [ON/OFF] | |
| RR WASHER SW [ON/OFF] | |
| RR WIPER STOP [ON/OFF] | Indicates rear wiper motor auto stop input from rear wiper motor. |
| RR WIPER STP2 [ON/OFF] | Indicates rear wiper motor auto stop 2 input from rear wiper motor. |
DATA MONITOR REFERENCE
| Work Item | Setting Item | Description |
|---|---|---|
| WIPER SPEED SETTING | OFF | Front wiper intermittent time linked with wiper dial position. |
| ON (1) | Front wiper intermittent time linked with vehicle speed and wiper dial position. | |
| (1) Factory setting | ||
| (1) | Factory setting |
WORK SUPPORT REFERENCE
| Monitor Item [Unit] | Description |
|---|---|
| IGN ON SW [ON/OFF] | Indicates condition of ignition switch ON position. |
| HAZARD SW [ON/OFF] | Indicates condition of hazard switch. |
| TURN SIGNAL R [ON/OFF] | Indicates condition of turn signal function of combination switch. |
| TURN SIGNAL L [ON/OFF] | |
| BRAKE SW [ON/OFF] | Indicates condition of brake switch. |
DATA MONITOR REFERENCE
| Monitor Item [Unit] | Description |
|---|---|
| IGN ON SW [ON/OFF] | Indicates condition of ignition switch ON position. |
| FAN ON SIG [ON/OFF] | Indicates condition of fan switch. |
| AIR COND SW [ON/OFF] | Indicates condition of A/C switch. |
DATA MONITOR REFERENCE
| Monitor Item [Unit] | Condition |
|---|---|
| I-KEY LOCK [ON/OFF] | Indicates condition of lock signal from Intelligent Key |
| I-KEY UNLOCK [ON/OFF] | Indicates condition of unlock signal from Intelligent Key |
| I-KEY PW DWN [ON/OFF] | Indicates condition of power window down signal from Intelligent Key. |
| I-KEY PANIC [ON/OFF] | Indicates condition of panic signal from Intelligent Key |
| PUSH SW [ON/OFF] | Indicates condition of ignition knob switch |
DATA MONITOR REFERENCE
| Monitor Item [Unit] | Description |
|---|---|
| TURN SIGNAL R [OFF/ON] | Indicates condition of turn signal operation of combination switch. |
| TURN SIGNAL L [OFF/ON] | |
| HI BEAM SW [OFF/ON] | Indicates condition of hi beam operation of combination switch. |
| HEAD LAMP SW1 [OFF/ON] | Indicates condition of headlamp operation of combination switch. |
| HEAD LAMP SW2 [OFF/ON] | |
| LIGHT SW 1ST [On/Off] | Indicates condition of lighting operation of combination switch. |
| PASSING SW [On/Off] | Indicates condition of passing switch operation of combination switch. |
| AUTO LIGHT SW [On/Off] | Indicates condition of auto light operation of combination switch. |
| FR FOG SW [On/Off] | Indicates condition of front fog light operation of combination switch. |
| FR WIPER HI [On/Off] | Indicates condition of front wiper operation of combination switch. |
| FR WIPER LOW [On/Off] | |
| FR WIPER LOW [On/Off] | |
| FR WIPER INT [On/Off] | |
| FR WASHER SW [OFF/ON] | Indicates condition of front washer operation of combination switch. |
| INT VOLUME [1 - 7] | Indicates condition of intermittent wiper operation of combination switch. |
| RR WIPER ON [OFF/ON] | Indicates condition of rear wiper operation of combination switch. |
| RR WIPER INT [OFF/ON] | |
| RR WASHER SW [OFF/ON] | Indicates condition of rear washer operation of combination switch. |
DATA MONITOR REFERENCE
| Support Item | Setting | Description |
|---|---|---|
| RESET SETTING VALUE | Reset | Returns BCM to initial value in factory shipment. |
| Cancel | Cancels the reset function. |
WORK SUPPORT REFERENCE
CONFIGURATION
Refer to " CONFIGURATION : DESCRIPTION ".
CAN DIAG SUPPORT MNTR
Refer to " CAN DIAGNOSTIC SUPPORT MONITOR ".
| Monitor Item [Unit] | Description |
|---|---|
| IGN ON SW [ON/OFF] | Indicates condition of ignition switch in ON position. |
DATA MONITOR REFERENCE
| Monitor Item [Unit] | Description |
|---|---|
| IGN ON SW [ON/OFF] | Indicates condition of ignition switch ON position. |
| KEY ON SW [ON/OFF] | Indicates condition of key switch. |
| DOOR SW-DR [ON/OFF] | Indicates condition of front door switch LH. |
| DOOR SW-AS [ON/OFF] | Indicates condition of front door switch RH. |
| DOOR SW-RR [ON/OFF] | Indicates condition of rear door switch RH. |
| DOOR SW-RL [ON/OFF] | Indicates condition of rear door switch LH. |
| BACK DOOR SW [ON/OFF] | Indicates condition of back door switch. |
| KEY CYL LK-SW [ON/OFF] | Indicates condition of lock signal from door key cylinder switch. |
| KEY CYL UN-SW [ON/OFF] | Indicates condition of unlock signal from door key cylinder switch. |
| CDL LOCK SW [ON/OFF] | Indicates condition of lock signal from door lock and unlock switch. |
| CDL UNLOCK SW [ON/OFF] | Indicates condition of unlock signal from door lock and unlock switch. |
| I-KEY LOCK (1) [ON/OFF] | Indicates condition of lock signal from Intelligent Key. |
| I-KEY UNLOCK (1) [ON/OFF] | Indicates condition of unlock signal from Intelligent Key. |
| KEYLESS LOCK (2) [ON/OFF] | Indicates condition of lock signal from keyfob. |
| KEYLESS UNLOCK (2) [ON/OFF] | Indicates condition of unlock signal from keyfob. |
| (1) With Intelligent Key (2) Without Intelligent Key | |
| (1) | With Intelligent Key |
| (2) | Without Intelligent Key |
DATA MONITOR REFERENCE
| Work Item | Setting | Description | |
|---|---|---|---|
| ROOM LAMP TIMER SET | MODE 3 | 10 min | Sets the interior room lamp battery saver timer operating time. |
| MODE 2 | 60 min. | ||
| MODE 1 (1) | 15 min | ||
| (1) Initial setting | |||
| (1) | Initial setting |
WORK SUPPORT REFERENCE
| Monitor Item [Unit] | Description |
|---|---|
| IGN ON SW [ON/OFF] | Indicates condition of ignition switch in ON position |
| VEHICLE SPEED [ON/OFF] | Indicates vehicle speed signal received from combination meter on CAN communication line. |
DATA MONITOR REFERENCE
| Monitor Item [Unit] | Description |
|---|---|
| IGN ON SW [ON/OFF] | Indicates condition of ignition switch ON position. |
| ACC ON SW [ON/OFF] | Indicates condition of ignition switch ACC position. |
| I-KEY LOCK (1) [ON/OFF] | Indicates condition of lock signal from Intelligent Key. |
| I-KEY UNLOCK (1) [ON/OFF] | Indicates condition of unlock signal from Intelligent Key. |
| KEYLESS LOCK (2) [ON/OFF] | Indicates condition of lock signal from keyfob. |
| KEYLESS UNLOCK (2) [ON/OFF] | Indicates condition of unlock signal from keyfob. |
| DOOR SW-DR [On/Off] | Indicates condition of front door switch LH. |
| DOOR SW-AS [ON/OFF] | Indicates condition of front door switch RH. |
| DOOR SW-RR [ON/OFF] | Indicates condition of rear door switch RH. |
| DOOR SW-RL [ON/OFF] | Indicates condition of rear door switch LH. |
| BACK DOOR SW [ON/OFF] | Indicates condition of back door switch. |
| KEY CYL LK-SW [ON/OFF] | Indicates condition of lock signal from door key cylinder switch. |
| KEY CYL UN-SW [ON/OFF] | Indicates condition of unlock signal from door key cylinder switch. |
| CDL LOCK SW [ON/OFF] | Indicates condition of lock signal from door lock and unlock switch. |
| CDL UNLOCK SW [ON/OFF] | Indicates condition of unlock signal from door lock and unlock switch. |
| (1) With Intelligent Key (2) With remote keyless entry system | |
| (1) | With Intelligent Key |
| (2) | With remote keyless entry system |
DATA MONITOR REFERENCE
| Support Item | Setting | Description |
|---|---|---|
| SECURITY ALARM SET | Off | Security alarm OFF. |
| (1) ON | Security alarm ON. | |
| THEFT ALM TRG | Off/On | |
| CLEAR | The switch which triggered vehicle security alarm is recorded [On]. This mode is able to confirm and erase the record of vehicle security alarm. The trigger data can be erased by touching [CLEAR]. | |
| (1) Initial Setting | ||
| (1) | Initial Setting |
WORK SUPPORT REFERENCE
| Monitor Item [Unit] | Description |
|---|---|
| IGN ON SW [ON/OFF] | Indicates condition of ignition switch ON position. |
| DOOR SW-DR [ON/OFF] | Indicates condition of front door switch LH. |
| DOOR SW-AS [ON/OFF] | Indicates condition of front door switch RH. |
DATA MONITOR REFERENCE
| Support Item | Setting | Description | |
|---|---|---|---|
| RETAINED PWR SET | MODE3 | 2 min | Sets the retained accessory power operating time. |
| MODE2 | OFF | ||
| MODE1 (1) | 45 sec | ||
| (1) Initial Setting | |||
| (1) | Initial Setting |
WORK SUPPORT REFERENCE
| Monitor Item [Unit] | Description |
|---|---|
| OIL PRESS SW [ON/OFF] | Indicates condition of oil pressure switch signal received from IPDM E/R on CAN communication line. |
DATA MONITOR REFERENCE
| Monitor Item | Condition | Specification |
|---|---|---|
| VEHICLE SPEED | Drive vehicle. | Vehicle speed (km/h or mph) |
| AIR PRESS FR | * Drive vehicle for a few minutes. or * Ignition switch ON and activation tool is transmitting activation signals. | Tire pressure (kPa, kg/cm2 or psi). |
| AIR PRESS RR | ||
| AIR PRESS RL | ||
| ID REGST FL1 | Ignition switch ON. | Registration ID: Green No registration: Red. |
| ID REGST FR1 | ||
| ID REGST RR1 | ||
| ID REGST RL1 | ||
| WARNING LAMP | Ignition switch ON. | Low tire pressure warning lamp on: ON. Low tire pressure warning lamp off: OFF. |
| BUZZER | Ignition switch ON. | Buzzer in combination meter on: ON. Buzzer in combination meter off: OFF. |
DATA MONITOR REFERENCE
| Support Item | Description |
|---|---|
| ID REGIST | Refer to " ID REGISTRATION PROCEDURE ". |
| ID READ | The registered ID number is displayed. |
TEST ITEM LIST REFERENCE
SPECIAL REPAIR REQUIREMENT
- ADDITIONAL SERVICE WHEN REPLACING BCM Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-382181-S20926656752011011400000) ".
- ADDITIONAL SERVICE WHEN REPLACING BCM Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-382181-S20926656752011011400000) ".
COMBINATION SWITCH MATRIX
Combination switch consists of INPUT circuit and OUTPUT circuit.
Combination switch INPUT-OUTPUT system list
| System | OUTPUT 1 | OUTPUT 2 | OUTPUT 3 | OUTPUT 4 | OUTPUT 5 |
|---|---|---|---|---|---|
| INPUT 1 | FR WASHER | FR WIPER LOW | TURN LH | TURN RH | |
| INPUT 2 | FR WIPER HI | FR WIPER INT | PASSING | HEADLAMP 1 | |
| INPUT 3 | INT VOLUME 1 | RR WASHER | HEADLAMP 2 | HI BEAM | |
| INPUT 4 | RR WIPER INT | INT VOLUME 3 | AUTO LIGHT | TAIL LAMP | |
| INPUT 5 | INT VOLUME 2 | RR WIPER | FR FOG |
COMBINATION SWITCH INPUT-OUTPUT SYSTEM LIST
Note. Headlamp has a dual system switch.
PHYSICAL VALUES
CONNECTOR TERMINAL REFERENCE Terminal Wire color Signal name Signal input/output Measuring condition Reference value or waveform (Approx.) Ignition switch Operation or condition 1 BR/W Ignition keyhole illumination Output OFF Door is locked (SW OFF) Battery voltage Door is unlocked (SW ON) 0V 2 SB Combination switch input 5 Input ON Lighting, turn, wiper OFF Wiper dial position 4 3 G/Y Combination switch input 4 Input ON Lighting, turn, wiper OFF Wiper dial position 4 4 Y Combination switch input 3 Input ON Lighting, turn, wiper OFF Wiper dial position 4 5 G/B Combination switch input 2 Input ON Lighting, turn, wiper OFF Wiper dial position 4 6 V Combination switch input 1 9 GR/R Rear window defogger switch Input ON Rear window defogger switch ON 0V Rear window defogger switch OFF 5V 10 G Hazard lamp flash Input OFF ON (opening or closing) 0V OFF (other than above) Battery voltage 11 O Ignition switch (ACC or ON) Input ACC or ON Ignition switch ACC or ON Battery voltage 12 R/L Front door switch RH Input OFF ON (open) 0V OFF (closed) Battery voltage 13 GR Rear door switch RH Input OFF ON (open) 0V OFF (closed) Battery voltage 15 L/W Tire pressure warning check connector Input OFF - 5V 18 P Remote keyless entry receiver and optical sensor (ground) Output OFF - 0V 19 V/W Remote keyless entry receiver (power supply) Output OFF Ignition switch OFF 20 G/W Remote keyless entry receiver (signal) Input OFF Stand-by (keyfob buttons released) When remote keyless entry receiver receives signal from keyfob (keyfob buttons pressed) 21 G NATS antenna amp. Input OFF --> ON Ignition switch (OFF --> ON) Just after turning ignition switch ON: Pointer of tester should move for approx. 1 second, then return to battery voltage. 22 W/V BUS - - Ignition switch ON or power window timer operates 23 G/O Security indicator lamp Output OFF Goes OFF --> illuminates (Every 2.4 seconds) Battery voltage --> 0V 25 BR NATS antenna amp. Input OFF --> ON Ignition switch (OFF --> ON) Just after turning ignition switch ON: Pointer of tester should move for approx. 1 second, then return to battery voltage. 26 Y/L Rear wiper auto stop switch 2 Input ON Rise up position (rear wiper arm on stopper) 0V A Position (full clockwise stop position) 0V Forward sweep (counterclockwise direction) Fluctuating B Position (full counterclockwise stop position) Battery voltage Reverse sweep (clockwise direction) Fluctuating 27 W/R Compressor ON signal Input ON A/C switch OFF 5V A/C switch ON 0V 28 L/R Front blower monitor Input ON Front blower motor OFF Battery voltage Front blower motor ON 0V 29 W/B Hazard switch Input OFF ON 0V OFF 5V 32 R/G Combination switch output 5 Output ON Lighting, turn, wiper OFF Wiper dial position 4 33 R/Y Combination switch output 4 Output ON Lighting, turn, wiper OFF Wiper dial position 4 34 L Combination switch output 3 Output ON Lighting, turn, wiper OFF Wiper dial position 4 35 O/B Combination switch output 2 Output ON Lighting, turn, wiper OFF Wiper dial position 4 36 R/W Combination switch output 1 37 (1) B/R Key switch and ignition knob switch Input OFF Intelligent Key inserted Battery voltage Intelligent Key inserted 0V 37 (2) B/R Key switch and key lock solenoid Input OFF Key inserted Battery voltage Key inserted 0V 38 W/L Ignition switch (ON) Input ON - Battery voltage 39 L CAN-H - - - - 40 P CAN-L - - - - 42 GR Glass hatch ajar switch Input ON Glass hatch open 0 Glass hatch closed Battery 43 R/B Back door switch (without power back door) or back door latch (door ajar switch) (with power back door) Input OFF ON (open) 0V OFF (closed) Battery voltage 44 O Rear wiper auto stop switch 1 Input ON Rise up position (rear wiper arm on stopper) 0V A Position (full clockwise stop position) Battery voltage Forward sweep (counterclockwise direction) Fluctuating B Position (full counterclockwise stop position) 0V Reverse sweep (clockwise direction) Fluctuating 47 SB Front door switch LH Input OFF ON (open) 0V OFF (closed) Battery voltage 48 R/Y Rear door switch LH Input OFF ON (open) 0V OFF (closed) Battery voltage 49 R Cargo lamp Output OFF Any door open (ON) 0V All doors closed (OFF) Battery voltage 51 G/Y Trailer turn signal (right) Output ON Turn right ON 52 G/B Trailer turn signal (left) Output ON Turn left ON 54 Y Rear wiper output circuit 2 Input ON Rise up position (rear wiper arm on stopper) 0V A Position (full clockwise stop position) 0V Forward sweep (counterclockwise direction) 0V B Position (full counterclockwise stop position) Battery voltage Reverse sweep (clockwise direction) Battery voltage 55 SB Rear wiper output circuit 1 Output ON OFF 0 ON Battery voltage 56 R/G Battery saver output Output OFF 30 minutes after ignition switch is turned OFF 0V ON - Battery voltage 57 Y/R Battery power supply Input OFF - Battery voltage 58 W/R Optical sensor Input ON When optical sensor is illuminated 3.1V or more When optical sensor is not illuminated 0.6V or less 59 G Front door lock assembly LH actuator (unlock) Output OFF OFF (neutral) 0V ON (unlock) Battery voltage 60 G/B Turn signal (left) Output ON Turn left ON 61 G/Y Turn signal (right) Output ON Turn right ON 62 R/W Step lamp LH and RH Output OFF ON (any door open) 0V OFF (all doors closed) Battery voltage 63 L Interior room/map lamp Output OFF Any door switch ON (open) 0V OFF (closed) Battery voltage 65 V All door lock actuators (lock) Output OFF OFF (neutral) 0V ON (lock) Battery voltage 66 G/Y Front door lock actuator RH, rear door lock actuators LH/RH and back door lock actuator (unlock) Output OFF OFF (neutral) 0V ON (unlock) Battery voltage 67 B Ground Input ON - 0V 68 W/L Power window power supply (RAP) Output - Ignition switch ON Battery voltage Within 45 seconds after ignition switch OFF Battery voltage More than 45 seconds after ignition switch OFF 0V When front door LH or RH is open or power window timer operates 0V 69 W/R Power window power supply Output - - Battery voltage 70 W/B Battery power supply Input OFF - Battery voltage (1) With Intelligent Key system (2) With remote keyless entry system
Scheme 84
Scheme 85
Scheme 86
Scheme 87
Scheme 88
Scheme 89
Scheme 90
FAIL SAFE
Fail-safe index
BCM performs fail-safe control when any DTC listed below is detected.
| Display contents of CONSULT | Fail-safe | Cancellation |
|---|---|---|
| U1000: CAN COMM CIRCUIT | Inhibit engine cranking | When the BCM re-establishes communication with the other modules. |
FAIL-SAFE REFERENCE
PRECAUTION FOR SUPPLEMENTAL RESTRAINT SYSTEM (SRS) "AIR BAG" AND "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS AIRBAG article and SEAT BELTS article.
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SRS AIRBAG . Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
| WARNING | When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service. |
PRECAUTION NECESSARY FOR STEERING WHEEL ROTATION AFTER BATTERY DISCONNECT
Note. This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYSTEM). Remove and install all control units after disconnecting both battery cables with the ignition knob in the "LOCK" position. Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work. If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NATS, an electrically controlled steering lock mechanism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and steering wheel rotation will become impossible.
If steering wheel rotation is required when battery power is interrupted, follow the procedure below before starting the repair operation.
