When replacing transfer assembly or transfer control unit, check the 4WD shift indicator lamp as follows.

1. Turn ignition switch "ON".
2. Check 4WD shift indicator lamp is turned ON for approx. 1 second.

1. If OK, the position between transfer assembly and transfer control unit is correct.
2. If NG, the position is different between transfer assembly and transfer control unit. Adjust the position between transfer assembly and transfer control unit. Refer to «METHOD FOR POSITION ADJUSTMENT»(ref-233277-S18829732382006052500000) .

Service Notice

1. After overhaul refill the transfer with new transfer fluid.
2. Check the fluid level or replace the fluid only with the vehicle parked on level ground.
3. During removal or installation, keep inside of transfer clear of dust or dirt.
4. Disassembly should be done in a clean work area.
5. Before proceeding with disassembly, thoroughly clean the transfer. It is important to prevent the internal parts from becoming contaminated by dirt or other foreign matter.
6. Check for the correct installation status prior to removal or disassembly. If matchmarks are required, be certain they do not interfere with the function of the parts when applied.
7. All parts should be carefully cleaned with a general purpose, non-flammable solvent before inspection or reassembly.
8. Check appearance of the disassembled parts for damage, deformation, and unusual wear. Replace them with new ones if necessary.
9. Gaskets, seals and O-rings should replaced any time the transfer is disassembled.
10. In principle, tighten bolts or nuts gradually in several steps working diagonally from inside to outside. If tightening sequence is specified, use it.
11. Observe the specified torque when assembling.
12. Clean and flush the parts sufficiently and blow-dry them.
13. Be careful not to damage sliding surfaces and mating surfaces.
14. Use lint-free cloth or towels for wiping parts clean. Common shop rags can leave fibers that could interfere with the operation of the transfer.

Special Service Tools

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

Scheme 256

Scheme 257

Scheme 258

Scheme 259

FILLING

Refer to CHANGING TRANSFER FLUID .

WAIT DETECTION SWITCH

1. The wait detection switch operates when there is "circulating" torque produced in the propeller shaft (L --> H) or when there is a phase difference between 2-4 sleeve and clutch drum (H --> L). After the release of the "circulating" torque, the wait detection switch helps provide the 4WD lock gear (clutch drum) shifts. A difference may occur between the operation of the 4WD shift switch and actual drive mode. At this point, the wait detection switch senses an actual drive mode.
2. The wait detection switch operates as follows.

1. 4WD lock gear (clutch drum) locked: ON
2. 4WD lock gear (clutch drum) released: OFF

1. The wait detection switch senses an actual drive mode and the 4WD shift indicator lamp indicates the vehicle drive mode.

NEUTRAL-4LO SWITCH

The neutral-4LO switch detects that transfer gear is in neutral or 4LO (or shifting from neutral to 4LO) condition by L-H shift fork position.

ATP SWITCH

It detects that transfer gear is under neutral condition by L-H shift fork position.

Note. Transfer gear may be under neutral condition in 4H-4LO.

2-4 WD SHIFT SOLENOID VALVE

The 2-4 WD shift solenoid valve operates to apply oil pressure to the wet-multiplate clutch, depending on the drive mode. The driving force is transmitted to the front wheels through the clutch so the vehicle is set in the 4WD mode. Setting the vehicle in the 2WD mode requires no pressure buildup. In other words, pressure force applied to the wet-multiplate clutch becomes zero.

CLUTCH PRESSURE SOLENOID VALVE

The clutch pressure solenoid valve distributes each of torque (front and rear) with AUTO mode.

LINE PRESSURE SWITCH

1. With the transfer system design, control of the oil pressure provides the transmission of drive torque to the front wheels. The main pressure to control the oil pressure is referred to as the line pressure.
2. The line pressure switch determines whether or not adequate line pressure has built up under different operating conditions.
3. The line pressure switch turns ON when line pressure is produced.
4. The line pressure switch senses line pressure abnormalities and turns the 4WD warning lamp ON.

CLUTCH PRESSURE SWITCH

1. The clutch pressure switch determines whether or not adequate clutch pressure has built up under different operating conditions.
2. The clutch pressure switch turns ON when clutch pressure is produced.
3. The clutch pressure switch senses clutch pressure abnormalities and turns the 4WD warning lamp ON.

The transfer temperature sensor detects the transfer fluid temperature and sends a signal to the transfer control unit.

1. Transfer control unit controls transfer control device by input signals of each sensor and each switch.
2. Self-diagnosis can be done.

The transfer control device changes the state of transfer assembly between 2WD, AUTO, 4H --> 4LO with the 2WD, AUTO, 4H and 4LO signals of 4WD shift switch.

Note. To shift between 4H <==> 4LO, stop the vehicle, depress the brake pedal and shift the transmission selector to the "N" position. Depress and turn the 4WD shift switch. The shift switch will not shift to the desired mode if the transmission is not in "N" or the vehicle is moving. The 4LO indicator lamp will be lit when the 4LO is engaged. Actuator motor and actuator position switch are integrated.

4WD Shift Switch

Able to select from 2WD, AUTO, 4H or 4LO.

4WD Shift Indicator Lamp

1. Displays driving conditions selected by 4WD shift switch with 2WD, AUTO and 4H indicators while engine is running. (When 4WD warning lamp is turned on, all 4WD shift indicator lamps are turned off.)
2. Turns ON for approximately 1 second when ignition switch is turned ON, for purpose of lamp check.

4LO Indicator Lamp

1. Displays 4LO condition while engine is running. 4LO indicator lamp flashes if transfer gear does not shift completely under 2WD, AUTO, 4H <==> 4LO. (When 4WD warning lamp is turned on, 4LO indicator lamp is turned off.)
2. Turns ON for approximately 1 second when ignition switch is turned ON, for purpose of lamp check.

4WD WARNING LAMP

Turns ON or FLASH when there is a malfunction in 4WD system.

Also turns ON when ignition switch is turned ON, for purpose of lamp check. Turns OFF for approximately 1 second after the engine starts if system is normal.

4WD Warning Lamp Indication

4WD WARNING LAMP INDICATION CONDITION

ATP WARNING LAMP

Even if A/T selector lever is in "P" position, vehicle may move because A/T parking mechanism does not operate when transfer is under neutral condition. ATP warning lamp is turned on so as to indicate this condition to the driver.

Scheme 260

COMPONENTS FUNCTION

COMPONENTS FUNCTION

CHECK BEFORE ENGINE IS STARTED

1. CHECK 4WD SHIFT INDICATOR LAMP Park vehicle on flat surface. Turn ignition switch to "OFF" position. Move A/T selector lever to "P" position. Set 4WD shift switch to "2WD" position. Turn ignition switch to "ON" position. (Do not start engine.) Does 4WD shift indicator lamp turn ON for approximately 1 second? YES: GO TO 2 . NO: Go to «4WD SHIFT INDICATOR LAMP AND 4LO INDICATOR LAMP DO NOT TURN ON»(ref-233277-S14621682402006052500000) .
2. CHECK 4WD WARNING LAMP Turn ignition switch to "OFF" position. Move A/T selector lever to "P" position. Set 4WD shift switch to "2WD" position. Turn ignition switch to "ON" position. (Do not start engine.) Does 4WD warning lamp turn ON? YES: GO TO «CHECK AT IDLE»(ref-233277-S06519092582006052500000) . NO: GO TO «4WD WARNING LAMP DOES NOT TURN ON»(ref-233277-S17958344532006052500000) .

Scheme 261

1. CHECK 4WD SHIFT INDICATOR LAMP Park vehicle on flat surface and engage the parking brake. Turn ignition switch to "OFF" position. Move A/T selector lever to "P" position. Set 4WD shift switch to "2WD" position. Start engine. Does 4WD shift indicator lamp turn ON? YES: GO TO 3 . NO: GO TO 2 .
2. CHECK 4WD WARNING LAMP Check 4WD warning lamp state? Is 4WD warning lamp turned ON? YES: Perform the self-diagnosis. Refer to «SELF-DIAGNOSTIC PROCEDURE (WITH CONSULT-II)»(ref-233277-S12863214092006052500000) (with CONSULT-II) or «SELF- DIAGNOSTIC PROCEDURE (WITHOUT CONSULT-II)»(ref-233277-S03706814972006052500000) (without CONSULT-II). NO: Go to «4WD SHIFT INDICATOR LAMP OR 4LO INDICATOR LAMP DOES NOT CHANGE»(ref-233277-S03053146682006052500000) .
3. CHECK 4WD SHIFT INDICATOR AND 4LO INDICATOR OPERATION Brake pedal depressed. Move A/T selector lever to "N" position. Set 4WD shift switch to "2WD", "AUTO", "4H", "4LO", "4H", "AUTO" and "2WD" in order. (Stay at each switch position for at least 1 second.) Do 4WD shift indicator and 4LO indicator lamps change properly? Does buzzer sound? YES: GO TO 4 . NO: GO TO «4WD SHIFT INDICATOR LAMP OR 4LO INDICATOR LAMP DOES NOT CHANGE»(ref-233277-S03053146682006052500000) .
4. CHECK ATP WARNING LAMP Move the A/T selector lever to "P" position. Set 4WD shift switch from "4HI" to "4LO". While switching from "4HI" to "4LO", does 4WD shift indicator lamp turn OFF and ATP warning lamp turn ON? YES: GO TO «ATP WARNING LAMP TURNS ON»(ref-233277-S22367138172006052500000) . NO: GO TO 5 .
5. CHECK "WAIT" FUNCTION Set 4WD shift switch from "4LO" to "4H". Check 4LO indicator lamp state. NOTE: While "wait" function is operating, 4LO indicator lamp flashes. Does 4LO indicator lamp flicker? YES: GO TO «4LO INDICATOR LAMP REPEATS FLASHING»(ref-233277-S27395260262006052500000) . NO: «CRUISE TEST»(ref-233277-S41298292982006052500000) .

FUNCTION

CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.

ALL MODE AWD/4WD DIAGNOSTIC MODE DESCRIPTION

CONSULT-II SETTING PROCEDURE

Note. For details, refer to the separate CONSULT-II Operations Manual.

Scheme 262

Scheme 263

1. Turn ignition switch "OFF".
2. Connect CONSULT-II and CONSULT-II CONVERTER to data link connector on vehicle.
3. Turn ignition switch "ON".
4. Touch "START (NISSAN BASED VHCL)".
5. Touch "ALL MODE AWD/4WD". If "ALL MODE AWD/4WD" is not indicated, go to «CONSULT-II DATA LINK CONNECTOR (DLC) CIRCUIT»(ref-233237-S35323486542006052500000) .
6. Perform each diagnostic test mode according to each service procedure.

Scheme 264

1. Perform "CONSULT-II SETTING PROCEDURE". Refer to «CONSULT-II SETTING PROCEDURE»(ref-233277-S19578046012006052500000)
2. With engine at idle, touch "SELF-DIAG RESULTS". Display shows malfunction experienced since the last erasing operation. NOTE: The details for "TIME" are as follow: "0": Error currently detected with transfer control unit. Except for "0": Error detected in the past and memorized with transfer control unit. Detects frequency of driving after DTC occurs (frequency of turning ignition switch "ON/OFF").

Scheme 265

Scheme 266

Note. If "SHIFT ACT POSI SW [P1818]" or "SHIFT ACT CIR [P1819]" is displayed, first erase self-diagnostic results. ("SHIFT ACT POSI SW [P1818]" or "SHIFT ACT CIR [P1819]" may be displayed after installing transfer control unit or transfer assembly.) If "CL PRES SW [P1827]" or "LINE PRES SW [P1828]" is displayed only while driving in reverse, check the continuity of "R" position on A/T PNP switch. When there is nothing wrong with the electrical system, check the hydraulic system.

WORK SUPPORT

When there is no problem with transfer and 4WD system, following symptom in "AUTO" mode may be claimed by a customer.

1. Vibration when accelerating on a low mu road (snow-covered or icy road) It is possible to deal with these symptoms by changing "CLUTCH FORCE RELEASE LIMIT VALUE". However, be careful when changing the values because it may adversely affect driving performance.

Note. A slight shock is felt at a few hertz as if it were being pushed lightly from behind.

CONSULT-II REFERENCE VALUE IN DATA MONITOR MODE

Data are reference value.

CONSULT-II REFERENCE VALUE IN DATA MONITOR MODE

Data are reference value and are measured between each terminal and ground.

Scheme 267

Scheme 268

Scheme 269

Scheme 270

Scheme 271

Scheme 272

1. CHECK POWER SUPPLY Turn ignition switch "OFF". (Stay for at least 5 seconds.) Connect transfer control unit harness connector. Check voltage between transfer control unit harness connector terminals and ground. Turn ignition switch "ON". (Do not start engine.) Check voltage between transfer control unit harness connector terminals and ground. OK or NG OK: GO TO 2 . NG: Check the following. If any items are damaged, repair or replace damaged parts. 10A fuses No. 26 located in fuse and fusible link box and No. 59 located in the fuse and relay box. Refer to «POWER SUPPLY ROUTING CIRCUIT»(ref-233318-S42666366662006052500000) . 20A fuse No. 53 located in the IPDM E/R. Refer to «POWER SUPPLY ROUTING CIRCUIT»(ref-233318-S42666366662006052500000) . Harness for short or open between battery and transfer control unit harness connector terminals 47. Harness for short or open between battery and transfer control unit harness connector terminal 29. Harness for short or open between battery and transfer shut off relay harness connector E69 terminal 1 (G), and 3 (G). Harness for short or open between transfer shut off relay harness connector E69 terminal 2 (SB) and transfer control unit harness connector terminal 30. Harness for short or open between transfer shut off relay harness connector E69 terminal 5 (Y/R) and transfer control unit harness connector terminals 16 (Y/R) and 22 (Y/R). Battery and ignition switch. Refer to «POWER SUPPLY ROUTING CIRCUIT»(ref-233318-S42666366662006052500000) . Transfer shut off relay. Refer to «COMPONENT INSPECTION»(ref-233277-S37070158002006052500000) .
2. CHECK GROUND CIRCUIT Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer control unit harness connector. Check continuity between transfer control unit harness connector E142 terminals 3 (B), 6 (B), E143 terminal 45 (B) and ground. Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 3 . NG: Repair open circuit or short to ground or short to power in harness or connectors.
3. CHECK TRANSFER CONTROL UNIT Check transfer control unit input/output signal. Refer to «Transfer Control Unit Input/Output Signal Reference Values»(ref-233277-S01882369842006052500000) . OK or NG OK: GO TO 4 . NG: Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
4. CHECK DTC Perform the self-diagnosis, after driving a vehicle for a while. OK or NG OK: Inspection End. NG: Replace transfer control unit. Refer to «Removal and Installation»(ref-233277-S39974486172006052500000) .

Scheme 273

1. Turn ignition switch "OFF". (Stay for at least 5 seconds.)
2. Remove transfer shut off relay. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .
3. Apply 12V direct current between transfer shut off relay terminals 1 and 2.
4. Check continuity between relay terminals 3 and 5. TERMINALS CONTINUITY REFERENCE Condition Continuity 12 V direct current supply between terminals 1 and 2 Yes OFF No
5. If NG, replace the transfer shut off relay.

Data are reference value.

Scheme 274

Data are reference value and are measured between each terminal and ground.

Scheme 275

Scheme 276

Scheme 277

Scheme 278

Scheme 279

Scheme 280

Scheme 281

Scheme 282

1. CHECK 4LO POSITION SWITCH SIGNAL With CONSULT-II Start engine. Select "DATA MONITOR" mode for "ALL MODE AWD/4WD" with CONSULT-II. Read out the value of "N POSI SW TF". Without CONSULT-II Start engine. Check voltage between transfer control unit harness connector terminal and ground. OK or NG OK: GO TO 5 . NG: GO TO 2 .
2. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND NEUTRAL-4LO SWITCH Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer control unit harness connector and the neutral-4LO switch harness connector. Check continuity between transfer control unit harness connector E143 terminal 25 (V) and neutral-4LO switch harness connector F60 terminal 13 (V). Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 3 . NG: Repair or replace damaged parts.
3. CHECK GROUND CIRCUIT Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect neutral-4LO switch harness connector. Check continuity between neutral-4LO switch harness connector F60 terminal 12 (B) and ground. Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 4 . NG: Repair open circuit or short to ground or short to power in harness or connectors.
4. CHECK 4LO SWITCH Turn ignition switch "OFF". Disconnect neutral-4LO switch harness connector. Remove neutral-4LO switch. Push and release neutral-4LO switch and check continuity between neutral-4LO switch terminals 12 and 13. TERMINALS CONTINUITY REFERENCE Terminal Condition Continuity 12-13 Push neutral-4LO switch Yes Release neutral-4LO switch No OK or NG OK: GO TO 5 . NG: Replace neutral-4LO switch. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .
5. CHECK TRANSFER CONTROL UNIT Check transfer control unit input/output signal. Refer to «Transfer Control Unit Input/Output Signal Reference Values»(ref-233277-S01882369842006052500000) . OK or NG OK: GO TO 6 . NG: Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
6. CHECK DTC Perform the self-diagnosis, after driving a vehicle for a while. OK or NG OK: Inspection End. NG: Replace transfer control unit. Refer to «Removal and Installation»(ref-233277-S39974486172006052500000) .

Scheme 283

1. Turn ignition switch "OFF". (Stay for at least 5 seconds.)
2. Disconnect neutral-4LO switch harness connector.
3. Remove neutral-4LO switch. Refer to " «Location of Electrical Parts»(ref-233277-S03515471932006052500000) ".
4. Push and release neutral-4LO switch and check continuity between neutral-4LO switch terminals 12 and 13. TERMINALS CONTINUITY REFERENCE Terminal Condition Continuity 12-13 Push neutral-4LO switch Yes 12-13 Release neutral-4LO switch No
5. If NG, replace the neutral-4LO switch. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .

Data are reference value.

Scheme 284

Data are reference value and are measured between each terminal and ground.

Scheme 285

Scheme 286

Scheme 287

Scheme 288

Scheme 289

Scheme 290

Scheme 291

Scheme 292

Scheme 293

1. CHECK 4WD SHIFT SWITCH SIGNAL With CONSULT-II Turn ignition switch "ON". (Do not start engine.) Select "DATA MONITOR" mode for "ALL MODE AWD/4WD" with CONSULT-II. Read out ON/OFF switching action of the "2WD SWITCH", "AUTO SWITCH", "LOCK SWITCH", "4L SWITCH" with operating 4WD shift switch. Without CONSULT-II Turn ignition switch "ON". (Do not start engine.) Check voltage between transfer control unit harness connector terminals and ground. OK or NG OK: GO TO 5 . NG: GO TO 2 .
2. CHECK 4WD SHIFT SWITCH POWER SUPPLY CIRCUIT Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect 4WD shift switch harness connector. Check voltage between 4WD shift switch harness connector terminal 1 and ground. TERMINALS VOLTAGE REFERENCE Connector Terminal (Wire color) Voltage (Approx.) M141 1 (W/R) - Ground 0V Turn ignition switch "ON". (Do not start engine.) Check voltage between 4WD shift switch harness connector terminal 1 and ground. TERMINALS VOLTAGE REFERENCE Connector Terminal (Wire color) Voltage (Approx.) M141 1 (W/R) - Ground Battery voltage OK or NG OK: GO TO 3 . NG: Go to «POWER SUPPLY CIRCUIT FOR TRANSFER CONTROL UNIT»(ref-233277-S03113677542006052500000) .
3. CHECK HARNESS BETWEEN 4WD SHIFT SWITCH AND TRANSFER CONTROL UNIT Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer control unit harness connector and the 4WD shift switch harness connector. Check continuity between the following terminals. Transfer control unit harness connector E142 terminal 9 (G/W) and 4WD shift switch harness connector M141 terminal 2 (G/W). Transfer control unit harness connector E142 terminal 18 (O) and 4WD shift switch harness connector M141 terminal 5 (O). Transfer control unit harness connector E142 terminal 23 (R) and 4WD shift switch harness connector M141 terminal 6 (R). Transfer control unit harness connector E142 terminal 24 (LG/R) and 4WD shift switch harness connector M141 terminal 3 (LG/R). Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 4 . NG: Check the following. If any items are damaged, repair or replace damaged parts. Harness for short or open between battery and transfer shut off relay harness connector E69 terminal 3 (G). Power supply circuit for transfer control unit. Refer to «Power Supply Circuit For Transfer Control Unit»(ref-233277-S03113677542006052500000) .
4. CHECK 4WD SHIFT SWITCH Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect 4WD shift switch harness connector. Operate 4WD shift switch and check continuity between 4WD shift switch terminals. OK or NG OK: GO TO 5 . NG: Replace 4WD shift switch.
5. CHECK TRANSFER CONTROL UNIT Check transfer control unit input/output signal. Refer to «Transfer Control Unit Input/Output Signal Reference Values»(ref-233277-S01882369842006052500000) . OK or NG OK: GO TO 6 . NG: Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
6. CHECK DTC Perform the self-diagnosis, after driving a vehicle for a while. OK or NG OK: Inspection End. NG: Replace transfer control unit. Refer to «Removal and Installation»(ref-233277-S39974486172006052500000) .

Scheme 294

Scheme 295

1. Turn ignition switch "OFF". (Stay for at least 5 second.)
2. Disconnect 4WD shift switch harness connector.
3. Operate 4WD shift switch and check continuity between 4WD shift switch terminals.
4. If NG, replace the 4WD shift switch.

Data are reference value.

Scheme 296

Data are reference value and are measured between each terminal and ground.

Scheme 297

Scheme 298

Scheme 299

Scheme 300

Scheme 301

Scheme 302

Scheme 303

Scheme 304

1. CHECK WAIT DETECTION SWITCH SIGNAL With CONSULT-II Start engine. Select "DATA MONITOR" mode for "ALL MODE AWD/4WD" with CONSULT-II. Read out the value of "WAIT DETCT SW". Without CONSULT-II Start engine. Check voltage between transfer control unit harness connector terminal and ground. OK or NG OK: GO TO 5 . NG: GO TO 2 .
2. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND WAIT DETECTION SWITCH Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer control unit harness connector and the wait detection switch harness connector. Check continuity between transfer control unit harness connector E143 terminal 43 (G/Y) and wait detection switch harness connector F59 terminal 10 (G/Y). Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 3 . NG: Repair or replace damaged parts.
3. CHECK GROUND CIRCUIT Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect wait detection switch harness connector. Check continuity between wait detection switch harness connector F59 terminal 11 (B) and ground. Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 4 . NG: Repair open circuit or short to ground or short to power in harness or connectors.
4. CHECK WAIT DETECTION SWITCH Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect wait detection switch harness connector. Remove wait detection switch. Refer to " «Location of Electrical Parts»(ref-233277-S03515471932006052500000) ". Push and release wait detection switch and check continuity between wait detection switch terminals 10 and 11. TERMINALS CONTINUITY REFERENCE Terminal Condition Continuity 10 - 11 Push wait detection switch Yes 10 - 11 Release wait detection switch No OK or NG OK: GO TO 5 . NG: Replace wait detection switch. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .
5. CHECK TRANSFER CONTROL UNIT Check transfer control unit input/output signal. Refer to «Transfer Control Unit Input/Output Signal Reference Values»(ref-233277-S01882369842006052500000) . OK or NG OK: GO TO 6 . NG: Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
6. CHECK DTC Perform the self-diagnosis, after driving a vehicle for a while. OK or NG OK: Inspection End. NG: Replace transfer control unit. Refer to «Removal and Installation»(ref-233277-S39974486172006052500000) .

Scheme 305

1. Turn ignition switch "OFF". (Stay for at least 5 seconds.)
2. Disconnect wait detection switch harness connector.
3. Remove wait detection switch. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .
4. Push and release wait detection switch and check continuity between wait detection switch terminals 10 and 11. TERMINALS CONTINUITY REFERENCE Terminal Condition Continuity 10 - 11 Push wait detection switch Yes 10 - 11 Release wait detection switch No
5. If NG, replace the wait detection switch. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .

Data are reference value.

Scheme 306

Data are reference value and are measured between each terminal and ground.

Scheme 307

Scheme 308

Scheme 309

Scheme 310

Scheme 311

Scheme 312

Scheme 313

Scheme 314

Scheme 315

Scheme 316

Scheme 317

Scheme 318

Scheme 319

Scheme 320

Scheme 321

1. CHECK ACTUATOR MOTOR SIGNAL With CONSULT-II Start engine. Select "DATA MONITOR" mode for "ALL MODE AWD/4WD" with CONSULT-II. Read out the value of "SHIFT ACT1", "SHIFT AC MON1", "SHIFT ACT2" and "SHIFT AC MON2". Without CONSULT-II Start engine. Check voltage between transfer control unit harness connector terminal and ground. OK or NG OK: GO TO 7 . NG: GO TO 2 .
2. CHECK ACTUATOR MOTOR POWER SUPPLY CIRCUIT Turn ignition switch "OFF". (Stay for at least 5 seconds.) Remove transfer shift high relay and transfer shift low relay. Check voltage between transfer shift high relay harness connector E46 terminal 5 (R), transfer shift low relay harness connector E47 terminal 5 (R) and ground. TERMINALS VOLTAGE REFERENCE Connector Terminal (Wire color) Voltage (Approx.) E46 5 (R) - Ground Battery voltage E47 5 (R) - Ground Turn ignition switch "ON". (Do not start engine.) Check voltage between transfer shift high relay harness connector E46 terminal 5 (R), transfer shift low relay harness connector E47 terminal 5 (R) and ground. TERMINALS VOLTAGE REFERENCE Connector Terminal (Wire color) Voltage (Approx.) E46 5 (R) - Ground Battery voltage E47 5 (R) - Ground OK or NG OK: GO TO 3 . NG: Check the following. If any items are damaged, repair or replace damaged parts. 20A fuse [No. 57, located in the fuse block (J/B)]. Refer to «POWER SUPPLY ROUTING CIRCUIT»(ref-233318-S42666366662006052500000) . Harness for short or open between battery, transfer shift high relay harness connector terminal 5 and transfer shift low relay harness connector terminal 5.
3. CHECK ACTUATOR MOTOR GROUND CIRCUIT Turn ignition switch "OFF". (Stay for at least 5 seconds.) Remove transfer shift high relay and transfer shift low relay. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) . Check continuity between transfer shift high relay harness connector E46 terminals 1 (B/W), 4 (B), transfer shift low relay harness connector E47 terminal 1 (B/W), 4 (B) and ground. Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 4 . NG: Repair open circuit or short to ground or short to power in harness or connectors.
4. CHECK TRANSFER SHIFT RELAY Turn ignition switch "OFF". Remove transfer shift high relay and transfer shift low relay. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) . Apply 12V direct current between transfer shift relay terminals 1 and 2. Check continuity between relay terminals 3 and 4, 3 and 5. TERMINALS CONTINUITY REFERENCE Terminal Condition Continuity 3 - 4 12V direct current supply between terminals 1 and 2 No 3 - 4 OFF Yes 3 - 5 12V direct current supply between terminals 1 and 2 Yes 3 - 5 OFF No OK or NG OK: GO TO 5 . NG: Replace the transfer shut off relay. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .
5. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND TRANSFER SHIFT RELAY Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer control unit harness connector and the transfer control device (actuator motor) harness connector. Remove transfer shift high relay and transfer shift low relay. Check continuity between the following terminals. Transfer control unit harness connector E143 terminal 33 (R/L) and transfer control device (actuator motor) harness connector F58 terminal 21 (R/L). Transfer control unit harness connector E143 terminal 42 (P/G) and transfer control device (actuator motor) harness connector F58 terminal 24 (P/G). Transfer control unit harness connector E142 terminal 4 (Y/L) and transfer shift high relay harness connector E46 terminal 2 (Y/L). Transfer control unit harness connector E142 terminal 13 (G/B) and transfer shift low relay harness connector E47 terminal 2 (G/B). Transfer control unit harness connector E143 terminal 33 (R/L) and transfer shift high relay harness connector E46 terminal 3 (R/L). Transfer control unit harness connector E143 terminal 42 (P/G) and transfer shift low relay harness connector E47 terminal 3 (P/G). Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 6 . NG: Repair or replace damaged parts.
6. CHECK ACTUATOR MOTOR Remove transfer control device. Refer to «Removal and Installation»(ref-233277-S20748892922006052500000) . Check operation by applying battery voltage to transfer control device (actuator motor) terminals 21 and 24. CAUTION: Do not operate actuator motor for more than 1 second. Change the actuator motor position to "HIGH" when installing. Be careful not to overheat the harness. TERMINALS REFERENCE Terminal Actuator motor 21 (Battery voltage) - 24 (Ground) Clockwise rotation 24 (Battery voltage) - 21 (Ground) Counterclockwise rotation Check continuity between transfer control device (actuator motor) terminals 21 and 24. 21 - 24: Approx. 0.2 ohms OK or NG OK: GO TO 7 . NG: Replace transfer control device (actuator motor). Refer to «Removal and Installation»(ref-233277-S20748892922006052500000) .
7. CHECK TRANSFER CONTROL UNIT Check transfer control unit input/output signal. Refer to «Transfer Control Unit Input/Output Signal Reference Values»(ref-233277-S01882369842006052500000) . OK or NG OK: GO TO 8 . NG: Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
8. CHECK DTC Perform the self-diagnosis, after driving a vehicle for a while. OK or NG OK: Inspection End. NG: Replace transfer control unit. Refer to «Removal and Installation»(ref-233277-S39974486172006052500000) .

Scheme 322

1. Turn ignition switch "OFF". (Stay for at least 5 seconds.)
2. Remove transfer shift high relay and transfer shift low relay. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .
3. Apply 12 V direct current between transfer shift relay terminals 1 and 2.
4. Check continuity between relay terminals 3 and 4, 3 and 5. TERMINALS CONTINUITY REFERENCE Terminal Condition Continuity 3 - 4 12V direct current supply between terminals 1 and 2 No 3 - 4 OFF Yes 3 - 5 12V direct current supply between terminals 1 and 2 Yes 3 - 5 OFF No
5. If NG, replace transfer shift relay.

Scheme 323

Scheme 324

1. Remove transfer control device. Refer to «Removal and Installation»(ref-233277-S20748892922006052500000) .
2. Check operation by applying battery voltage to transfer control device (actuator motor) terminals 21 and 24. CAUTION: Do not operate actuator motor for more than 1 second. Change the actuator motor position to "HIGH" when installing. Be careful not to overheat the harness. TERMINALS REFERENCE Terminal Actuator motor 21 (Battery voltage) - 24 (Ground) Clockwise rotate 24 (Battery voltage) - 21 (Ground) Counterclockwise rotate
3. Check continuity between transfer control device (actuator motor) terminals 21 and 24. 21 - 24: Approx. 0.2 ohms
4. If NG, replace transfer control device (actuator motor). Refer to «Removal and Installation»(ref-233277-S20748892922006052500000) .

Data are reference value.

Scheme 325

Data are reference value and are measured between each terminal and ground.

Scheme 326

Scheme 327

Scheme 328

Scheme 329

Scheme 330

Scheme 331

Scheme 332

Scheme 333

1. CHECK ACTUATOR POSITION SWITCH SIGNAL With CONSULT-II Start engine. Select "DATA MONITOR" mode for "ALL MODE AWD/4WD" with CONSULT-II. Read out the value of "SHIFT POS SW1" and "SHIFT POS SW2". Without CONSULT-II Start engine. Check voltage between transfer control unit harness connector terminal and ground. OK or NG OK: GO TO 5 . NG: GO TO 2 .
2. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND ACTUATOR POSITION SWITCH Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer control unit harness connector and the transfer control device (actuator position switch) harness connector. Check continuity between the following terminals. Transfer control unit harness connector E143 terminal 27 (W/L) and transfer control device (actuator position switch) harness connector F58 terminal 23 (W/L). Transfer control unit harness connector E143 terminal 44 (LG/B) and transfer control device (actuator position switch) harness connector F58 terminal 20 (LG/B). Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 3 . NG: Repair or replace damaged parts.
3. CHECK GROUND CIRCUIT Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer control device (actuator position switch) harness connector. Check continuity between transfer control device (actuator position switch) harness connector F58 terminal 22 (B) and ground. Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 4 . NG: Repair open circuit or short to ground or short to power in harness or connectors.
4. CHECK ACTUATOR POSITION SWITCH Remove transfer control device. Refer to «Removal and Installation»(ref-233277-S20748892922006052500000) . Check operation by applying battery voltage to transfer control device (actuator motor) terminals 21 and 24. CAUTION: Do not operate actuator motor for more than 1 second. Change the actuator motor position to "HIGH" when installing. Be careful not to overheat the harness. TERMINALS CONTINUITY REFERENCE Terminal Continuity Continuity 24 (Battery voltage) - 21 (Ground) 20 - 22 Yes 24 (Battery voltage) - 21 (Ground) 22 - 23 No 21 (Battery voltage) - 24 (Ground) 22 - 23 Yes 21 (Battery voltage) - 24 (Ground) 20 - 22 No OK or NG YES: GO TO 5 . NO: Replace transfer control device (actuator motor). Refer to «Removal and Installation»(ref-233277-S20748892922006052500000) .
5. CHECK TRANSFER CONTROL UNIT Check transfer control unit input/output signal. Refer to «Transfer Control Unit Input/Output Signal Reference Values»(ref-233277-S01882369842006052500000) . OK or NG OK: GO TO 6 . NG: Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
6. CHECK DTC Perform the self-diagnosis, after driving a vehicle for a while. OK or NG OK: Inspection End. NG: Replace transfer control device. Refer to «Removal and Installation»(ref-233277-S20748892922006052500000) .

Scheme 334

1. Remove transfer control device. Refer to «Removal and Installation»(ref-233277-S20748892922006052500000) .
2. Check operation by applying battery voltage to transfer control device (actuator motor) terminals 21 and 24. CAUTION: Do not operate actuator motor for more than 1 second. Change the actuator motor position to "HIGH" when installing. Be careful not to overheat the harness. TERMINALS CONTINUITY REFERENCE Terminal Continuity Continuity 24 (Battery voltage) - 21 (Ground) 20 - 22 Yes 24 (Battery voltage) - 21 (Ground) 22 - 23 No 21 (Battery voltage) - 24 (Ground) 22 - 23 Yes 21 (Battery voltage) - 24 (Ground) 20 - 22 No
3. If NG, replace transfer control device (actuator motor). Refer to «Removal and Installation»(ref-233277-S20748892922006052500000) .

Data are reference value.

Scheme 335

Data are reference value and are measured between each terminal and ground.

Scheme 336

Scheme 337

Scheme 338

Scheme 339

Scheme 340

Scheme 341

Scheme 342

Scheme 343

1. CHECK POWER SUPPLY Turn ignition switch "OFF". (Stay for at least 5 seconds.) Connect transfer control unit harness connector. Check voltage between transfer control unit harness connector terminal and ground. TERMINALS VOLTAGE REFERENCE Connector Terminal (Wire color) Voltage (Approx.) E142 16 (Y/R) - Ground 0V E142 22 (Y/R) - Ground 0V E143 30 (SB) - Ground Battery voltage Turn ignition switch "ON". (Do not start engine.) Check voltage between transfer control unit harness connector terminals and ground. TERMINALS VOLTAGE REFERENCE Connector Terminal (Wire color) Voltage (Approx.) E142 16 (Y/R) - Ground Battery voltage E142 22 (Y/R) - Ground Battery voltage E143 30 (SB) - Ground 0V OK or NG OK: GO TO 2 . NG: Check the following. If any items are damaged, repair or replace damaged parts. 10A fuse No. 26 located in the fuse and fusible link box. Refer to «POWER SUPPLY ROUTING CIRCUIT»(ref-233318-S42666366662006052500000) . Harness for short or open between battery and transfer shut off relay harness connector E69 terminal 1 (G). Harness for short or open between transfer shut off relay harness connector E69 terminal 2 (SB) and transfer control unit harness connector E143 terminal 30 (SB). Harness for short or open between battery and transfer shut off relay harness connector E69 terminal 3 (G). Harness for short or open between transfer shut off relay harness connector E69 terminal 5 (Y/R) and transfer control unit harness connector E142 terminal 22 (Y/R). Transfer shut off relay. Refer to «COMPONENT INSPECTION»(ref-233277-S37070158002006052500000) .
2. CHECK GROUND CIRCUIT Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer control unit harness connector. Check continuity between transfer control unit harness connector E142 terminals 3 (B), 6 (B), E143 terminal 45 (B) and ground. Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 3 . NG: Repair open circuit or short to ground or short to power in harness or connectors.
3. CHECK ACTUATOR MOTOR POWER SUPPLY CIRCUIT Turn ignition switch "OFF". (Stay for at least 5 seconds.) Remove transfer shift high relay and transfer shift low relay. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) . Check voltage between transfer shift high relay harness connector E46 terminal 5 (R), transfer shift low relay harness connector E47 terminal 5 (R) and ground. TERMINALS VOLTAGE REFERENCE Connector Terminal (Wire color) Voltage (Approx.) E46 5 (R) - Ground Battery voltage E47 5 (R) - Ground Battery voltage Turn ignition switch "ON". (Do not start engine.) Check voltage between transfer shift high relay harness connector E46 terminal 5 (R), transfer shift low relay harness connector E47 terminal 5 (R) and ground. TERMINALS VOLTAGE REFERENCE Connector Terminal (Wire color) Voltage (Approx.) E46 5 (R) - Ground Battery voltage E47 5 (R) - Ground Battery voltage OK or NG OK: GO TO 4 . NG: Check the following. If any items are damaged, repair or replace damaged parts. 20A fuse No. 57 located in the fuse and relay box. Refer to «POWER SUPPLY ROUTING CIRCUIT»(ref-233318-S42666366662006052500000) . Harness for short or open between battery, transfer shift high relay harness connector E46 terminal 5 (R) and transfer shift low relay harness connector E47 terminal 5 (R).
4. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND TRANSFER SHIFT RELAY Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer control unit harness connector and transfer control device (actuator motor) harness connector. Remove transfer shift high relay and transfer shift low relay. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) . Check continuity between the following terminals. Transfer control unit harness connector E143 terminal 33 (R/L) and transfer shift high relay harness connector E46 terminal 3 (R/L). Transfer control unit harness connector E143 terminal 42 (P/G) and transfer shift low relay harness connector E47 terminal 3 (P/G). Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 5 . NG: Repair or replace damaged parts.
5. CHECK TRANSFER SHIFT RELAY GROUND CIRCUIT Turn ignition switch "OFF". (Stay for at least 5 seconds.) Remove transfer shift high relay and transfer shift low relay. Check continuity between transfer shift high relay harness connector E46 terminals 1 (B/W), 4 (B), transfer shift low relay harness connector E47 terminal 1 (B/W), 4 (B) and ground. Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 6 . NG: Repair open circuit or short to ground or short to power in harness or connectors.
6. CHECK TRANSFER CONTROL UNIT Check transfer control unit input/output signal. Refer to «Transfer Control Unit Input/Output Signal Reference Values»(ref-233277-S01882369842006052500000) . OK or NG OK-1: With CONSULT-II: GO TO 7 . OK-2: Without CONSULT-II: GO TO 8 . NG: Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
7. PERFORM SELF-DIAGNOSIS (WITH CONSULT-II) With CONSULT-II Turn ignition switch "ON". (Do not start engine.) Select "SELF-DIAG RESULTS" mode for "ALL MODE AWD/4WD" with CONSULT-II. Touch "ERASE". Turn ignition switch "OFF" and wait at least 10 seconds. Perform the self-diagnosis again. Is the "SHIFT ACT CIR [P1819]" displayed? YES: Replace transfer control unit. Refer to «Removal and Installation»(ref-233277-S39974486172006052500000) . NO: Inspection End.
8. PERFORM SELF-DIAGNOSIS (WITHOUT CONSULT-II) Without CONSULT-II Perform the self-diagnosis and then erase self-diagnostic results. Refer to «SELF-DIAGNOSTIC PROCEDURE (WITHOUT CONSULT-II)»(ref-233277-S03706814972006052500000) and «ERASE SELF-DIAGNOSIS»(ref-233277-S40200345402006052500000) . Perform the self-diagnosis again. Do the self-diagnostic results indicate transfer control device? YES: Replace transfer control unit. Refer to «Removal and Installation»(ref-233277-S39974486172006052500000) . NO: Inspection End.

Data are reference value.

Scheme 344

Data are reference value and are measured between each terminal and ground.

Scheme 345

Scheme 346

Scheme 347

Scheme 348

Scheme 349

Scheme 350

Scheme 351

Scheme 352

Scheme 353

Scheme 354

Scheme 355

1. CHECK CLUTCH PRESSURE SIGNAL With CONSULT-II Start engine. Select "DATA MONITOR" mode for "ALL MODE AWD/4WD" with CONSULT-II. Read out the value of "DUTY SOLENOID". Without CONSULT-II Start engine. Check voltage between transfer control unit harness connector terminal and ground. OK or NG OK: GO TO 7 . NG: GO TO 2 .
2. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND CLUTCH PRESSURE SOLENOID VALVE Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer control unit harness connector, transfer terminal cord assembly harness connector and transfer dropping resistor. Check continuity between transfer control unit harness connector E142 terminal 19 (L) and transfer terminal cord assembly harness connector F56 terminal 6 (L). Continuity should exist. Check continuity between transfer dropping resistor harness connector E135 terminal 2 (L) and transfer terminal cord assembly harness connector F56 terminal 6 (L). Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 3 . NG: Repair or replace damaged parts.
3. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND TRANSFER DROPPING RESISTOR Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer control unit harness connector and transfer dropping resistor harness connector. Check continuity between transfer control unit harness connector E142 terminal 10 (L/W) and transfer dropping resistor harness connector E135 terminal 1 (L/W). Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 4 . NG: Repair or replace damaged parts.
4. CHECK GROUND CIRCUIT Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer terminal cord assembly harness connector. Check continuity between transfer terminal cord assembly harness connector F56 terminal 19 (B) and ground. Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 5 . NG: Repair open circuit or short to ground or short to power in harness or connectors.
5. CHECK CLUTCH PRESSURE SOLENOID Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer terminal cord assembly harness connector. Check resistance between transfer terminal cord assembly harness connector F56 terminals 6 and 19. 6 - 19: Approx. 3.0 - 3.4 ohms OK or NG OK: GO TO 6 . NG: Replace clutch pressure solenoid. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .
6. CHECK TRANSFER DROPPING RESISTOR Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer dropping resistor harness connector. Check resistance between transfer dropping resistor terminals 1 and 2. 1 - 2: Approx. 11.2 - 12.8 ohms OK or NG OK: GO TO 7 . NG: Replace transfer dropping resistor.
7. CHECK TRANSFER CONTROL UNIT Check transfer control unit input/output signal. Refer to «Transfer Control Unit Input/Output Signal Reference Values»(ref-233277-S01882369842006052500000) . OK or NG OK: GO TO 8 . NG: Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
8. CHECK DTC Perform the self-diagnosis, after driving a vehicle for a while. OK or NG OK: Inspection End. NG: Replace transfer control unit. Refer to «Removal and Installation»(ref-233277-S39974486172006052500000) .

Scheme 356

1. Turn ignition switch "OFF". (Stay for at least 5 seconds.)
2. Disconnect transfer terminal cord assembly harness connector.
3. Check resistance between transfer terminal cord assembly terminals 6 and 19. 6 - 19: Approx. 3.0 - 3.4 ohms
4. If NG, replace clutch pressure solenoid. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .

Scheme 357

1. Turn ignition switch "OFF". (Stay for at least 5 seconds.)
2. Disconnect transfer dropping resistor harness connector.
3. Check resistance between transfer dropping resistor terminals 1 and 2. 1 - 2: Approx. 11.2 - 12.8 ohms
4. If NG, replace transfer dropping resistor. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .

Data are reference value.

Scheme 358

Data are reference value and are measured between each terminal and ground.

Scheme 359

Scheme 360

Scheme 361

Scheme 362

Scheme 363

Scheme 364

Scheme 365

Scheme 366

Scheme 367

1. CHECK 4WD SHIFT SWITCH SYSTEM Perform self-diagnosis. Refer to «Self-diagnostic Procedure»(ref-233277-S27103964002006052500000) . Is the "4WD MOD SW [P1814]" (with CONSULT-II) or "Flickering pattern: 16 (without CONSULT-II) detected? YES: Perform trouble diagnosis for 4WD shift switch. Refer to «4WD Shift Switch»(ref-233277-S08227293292006052500000) . NO: GO TO 2 .
2. CHECK 2-4WD SHIFT SOLENOID SIGNAL With CONSULT-II Start engine. Select "DATA MONITOR" mode for "ALL MODE AWD/4WD" with CONSULT-II. Read out the value of "2-4WD SOL" and "2-4WD SOL MON". Without CONSULT-II Start engine. Check voltage between transfer control unit harness connector terminal and ground. OK or NG OK: GO TO 7 . NG: GO TO 3 .
3. CHECK 4WD SHIFT SWITCH SIGNAL Turn ignition switch "ON". (Do not start engine.) Check voltage between transfer control unit harness connector terminals and ground. TERMINALS VOLTAGE REFERENCE Connector Terminal (Wire color) Condition Voltage (Approx.) M141 4 (G/R) - ground 4WD shift switch: AUTO, 4H or 4LO Battery voltage M141 4 (G/R) - ground 4WD shift switch: 2WD 0V OK or NG OK: GO TO 4 . NG: Check 4WD shift switch. Refer to «COMPONENT INSPECTION»(ref-233277-S02265320442006052500000) .
4. CHECK HARNESS BETWEEN 4WD SHIFT SWITCH AND TRANSFER TERMINAL CORD ASSEMBLY Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect 4WD shift switch harness connector and transfer terminal cord assembly harness connector. Check continuity between 4WD shift switch harness connector M141 terminal 4 (G/R) and transfer terminal cord assembly harness connector F56 terminal 5 (G/R). Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 5 . NG: Repair or replace damaged parts.
5. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND TRANSFER TERMINAL CORD ASSEMBLY Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer control unit harness connector and transfer terminal cord assembly harness connector. Check continuity between transfer control unit harness connector E142 terminal 1 (GR) and transfer terminal cord assembly harness connector F56 terminal 4 (GR). Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 6 . NG: Repair or replace damaged parts.
6. CHECK 2-4WD SOLENOID Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer terminal cord assembly harness connector. Check resistance between transfer terminal cord assembly terminals 4 and 5. 4 - 5: Approx. 22.8 - 25.2 ohms OK or NG OK: GO TO 7 . NG: Replace 2-4WD solenoid. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .
7. CHECK TRANSFER CONTROL UNIT Check transfer control unit input/output signal. Refer to «Transfer Control Unit Input/Output Signal Reference Values»(ref-233277-S01882369842006052500000) . OK or NG OK: GO TO 8 . NG: Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
8. CHECK DTC Perform the self-diagnosis, after driving a vehicle for a while. OK or NG OK: Inspection End. NG: Replace transfer control unit. Refer to «Removal and Installation»(ref-233277-S39974486172006052500000) .

Scheme 368

1. Turn ignition switch "OFF". (Stay for at least 5 seconds.)
2. Disconnect transfer terminal cord assembly harness connector.
3. Check resistance between transfer terminal cord assembly terminals 4 and 5. 4 - 5: Approx. 22.8 - 25.2 ohms
4. If NG, replace the 2-4WD solenoid. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .

Data are reference value.

Scheme 369

Data are reference value and are measured between each terminal and ground.

Scheme 370

Scheme 371

Scheme 372

Scheme 373

Scheme 374

Scheme 375

Scheme 376

Scheme 377

Scheme 378

Scheme 379

Scheme 380

Scheme 381

1. CHECK TRANSFER MOTOR RELAY SIGNAL With CONSULT-II Start engine. Select "DATA MONITOR" mode for "ALL MODE AWD/4WD" with CONSULT-II. Read out the value of "MOTOR RELAY" and "MOTOR RELAY MON". Without CONSULT-II Start engine. Check voltage between transfer control unit harness connector terminal and ground. OK or NG OK: GO TO 7 . NG: GO TO 2 .
2. CHECK TRANSFER MOTOR RELAY POWER SUPPLY CIRCUIT Turn ignition switch "OFF". (Stay for at least 5 seconds.) Connect transfer control unit harness connector. Disconnect transfer motor relay. Check voltage between transfer motor relay harness connector terminals and ground. TERMINALS VOLTAGE REFERENCE Connector Terminal (Wire color) Voltage (Approx.) E153 2 (Y/R) - Ground 0V E154 5 (G/R) - Ground Battery voltage Turn ignition switch "ON". (Do not start engine.) Check voltage between transfer motor relay harness connector terminals and ground. TERMINALS VOLTAGE REFERENCE Connector Terminal (Wire color) Voltage (Approx.) E153 2 (Y/R) - Ground Battery voltage E154 5 (G/R) - Ground Battery voltage OK or NG OK: GO TO 3 . NG: Check the following. If any items are damaged, repair or replace damaged parts. 20A fuse No. 58 located in the fuse and relay box. Refer to «POWER SUPPLY ROUTING CIRCUIT»(ref-233318-S42666366662006052500000) . 10A fuse No. 26 located in the fuse and fusible link box. Refer to «POWER SUPPLY ROUTING CIRCUIT»(ref-233318-S42666366662006052500000) Harness for short or open between battery and transfer motor relay harness connector E154 terminal 5 (G/R). Harness for short or open between transfer shut off relay harness connector E69 terminal 5 (Y/R) and transfer motor relay harness connector E153 terminal 2 (Y/R). Battery and ignition switch. Refer to «POWER SUPPLY ROUTING CIRCUIT»(ref-233318-S42666366662006052500000) .
3. CHECK TRANSFER MOTOR RELAY Turn ignition switch "OFF". Remove transfer motor relay. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) . Apply 12V direct current between transfer motor relay terminals 1 and 2. Check continuity between relay terminals 3 and 5. TERMINALS CONTINUITY REFERENCE Condition Continuity 12V direct current supply between terminals 1 and 2 Yes OFF No OK or NG OK: GO TO 4 . NG: Replace the transfer motor relay.
4. CHECK TRANSFER MOTOR CONTROL CIRCUIT Turn ignition switch "OFF". (Stay for at least 5 seconds.) Remove transfer motor relay. Refer to. «Location of Electrical Parts»(ref-233277-S03515471932006052500000) . Disconnect transfer control unit harness connector and transfer motor. Check continuity between the following terminals. Transfer control unit harness connector E142 terminal 14 (LG) and transfer motor relay harness connector E153 terminal 1 (LG). Transfer control unit harness connector E142 terminal 41 (R) and transfer motor relay harness connector E154 terminal 3 (R). Transfer control unit harness connector E142 terminal 41 (R) and transfer motor harness connector F57 terminal 14 (R). Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 5 . NG: Repair or replace damaged parts.
5. CHECK TRANSFER MOTOR GROUND CIRCUIT Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer motor harness connector. Check continuity between transfer motor harness connector F57 terminal 15 (B) and ground. Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 6 . NG: Repair open circuit or short to ground or short to power in harness or connectors.
6. CHECK TRANSFER MOTOR Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer motor harness connector. Apply 12 V direct current between transfer motor terminals 14 and 15. Does transfer motor operate? YES: GO TO 7 . NO: Replace transfer motor. Refer to «Removal and Installation»(ref-233277-S26081923502006052500000) .
7. CHECK TRANSFER CONTROL UNIT Check transfer control unit input/output signal. Refer to " «Transfer Control Unit Input/Output Signal Reference Values»(ref-233277-S01882369842006052500000) ". OK or NG OK: GO TO 8 . NG: Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
8. CHECK DTC Perform the self-diagnosis, after driving a vehicle for a while. OK or NG OK: Inspection End. NG: Replace transfer control unit. Refer to «Removal and Installation»(ref-233277-S39974486172006052500000) .

Scheme 382

1. Turn ignition switch "OFF". (Stay for at least 5 seconds.)
2. Remove transfer motor relay. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .
3. Apply 12V direct current between transfer motor relay terminals 1 and 2.
4. Check continuity between relay terminals 3 and 5. TERMINALS CONTINUITY REFERENCE Condition Continuity 12V direct current supply between terminals 1 and 2 Yes OFF No
5. If NG, replace transfer motor relay «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .

Scheme 383

1. Turn ignition switch "OFF". (Stay for at least 5 seconds.)
2. Remove transfer motor.
3. Apply 12V direct current between transfer motor terminals 14 and 15.
4. If transfer motor does not operate, replace transfer motor. Refer to «Removal and Installation»(ref-233277-S26081923502006052500000) .

Data are reference value.

CONSULT-II REFERENCE VALUE IN DATA MONITOR MODE

Data are reference value and are measured between each terminal and ground.

Scheme 384

Scheme 385

Scheme 386

Scheme 387

Scheme 388

Scheme 389

1. CHECK TRANSFER FLUID TEMPERATURE SENSOR SIGNAL With CONSULT-II Start engine. Select "DATA MONITOR" mode for "ALL MODE AWD/4WD" with CONSULT-II. Read out the value of "FLUID TEMP SE". TRANSFER FLUID TEMPERATURE REFERENCE Condition Display value (Approx.) Transfer fluid temperature approx. 20 - 80°C (68 - 176°F) 1.1 - 0.3 V Without CONSULT-II Start engine. Check voltage between transfer control unit harness connector terminals and ground. OK or NG OK: GO TO 4 . NG: GO TO 2 .
2. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND TRANSFER TERMINAL CORD ASSEMBLY Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer control unit harness connector and transfer terminal cord assembly harness connector. Check continuity between the following terminals. Transfer control unit harness connector E143 terminal 28 (B/G) and transfer terminal cord assembly harness connector F56 terminal 3 (B/G). Transfer control unit harness connector E143 terminal 31 (G) and transfer terminal cord assembly harness connector F56 terminal 2 (G). Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 3 . NG: Repair or replace damaged parts.
3. CHECK TRANSFER FLUID TEMPERATURE SENSOR Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer terminal cord assembly harness connector. Check resistance between transfer terminal cord assembly terminals 2 and 3. TEMPERATURE RESISTANCE REFERENCE Temperature °C (°F) Resistance (Approx.) 20 (68) 2.5 kohms 80 (176) 0.3 kohms OK or NG OK: GO TO 4 . NG: Replace transfer fluid temperature sensor. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .
4. CHECK TRANSFER CONTROL UNIT Check transfer control unit input/output signal. Refer to «Transfer Control Unit Input/Output Signal Reference Values»(ref-233277-S01882369842006052500000) . OK or NG OK: GO TO 5 . NG: Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
5. CHECK DTC Perform the self-diagnosis, after driving a vehicle for a while. OK or NG OK: Inspection End. NG: Replace transfer control unit. Refer to «Removal and Installation»(ref-233277-S39974486172006052500000) .

Scheme 390

1. Turn ignition switch "OFF". (Stay for at least 5 seconds.)
2. Disconnect transfer terminal cord assembly harness connector.
3. Check resistance between transfer terminal cord assembly terminals 2 and 3. TEMPERATURE RESISTANCE REFERENCE Temperature °C (°F) Resistance (Approx.) 20 (68) 2.5 kohms 80 (176) 0.3 kohms
4. If NG, replace the transfer fluid temperature sensor. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .

Data are reference value.

Scheme 391

Data are reference value and are measured between each terminal and ground.

Scheme 392

Scheme 393

Scheme 394

Scheme 395

Scheme 396

Scheme 397

Scheme 398

1. CHECK CLUTCH PRESSURE SWITCH SIGNAL With CONSULT-II Start engine. Select "DATA MONITOR" mode for "ALL MODE AWD/4WD" with CONSULT-II. Read out ON/OFF switching action of the "CL PRES SW" while operating 4WD shift switch. Without CONSULT-II Start engine. Check voltage between transfer control unit harness connector terminals and ground. OK or NG OK: GO TO 5 . NG: GO TO 2 .
2. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND CLUTCH PRESSURE SWITCH Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer control unit harness connector and the transfer terminal cord assembly harness connector. Check continuity between transfer control unit harness connector E143 terminal 34 (BR) and transfer terminal cord assembly harness connector F56 terminal 7 (BR) Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 3 . NG: Repair or replace damaged parts.
3. CHECK TRANSFER CONTROL UNIT Check transfer control unit input/output signal. Refer to «Transfer Control Unit Input/Output Signal Reference Values»(ref-233277-S01882369842006052500000) . OK or NG OK: GO TO 4 . NG: Check transfer control unit pin terminals for damage or loose connection with the harness connector. If any items are damaged, repair or replace damaged parts.
4. CHECK CLUTCH PRESSURE SWITCH Turn ignition switch "OFF". (Stay for at least 5 seconds.) Remove clutch pressure switch. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) . Push and release clutch pressure switch and check continuity between terminal 7 and ground. TERMINALS CONTINUITY REFERENCE Terminal Condition Continuity 7 - Ground Push clutch pressure switch Yes 7 - Ground Release clutch pressure switch No OK or NG OK: GO TO 5 . NG: Replace clutch pressure switch.
5. CHECK DTC Perform the self-diagnosis, after driving a vehicle for a while. OK or NG OK: GO TO 6 . NG: Replace transfer control unit. Refer to «Removal and Installation»(ref-233277-S39974486172006052500000) .
6. CRUISE TEST Perform cruise test. Refer to «CRUISE TEST»(ref-233277-S41298292982006052500000) . OK or NG OK: INSPECTION END. NG: Perform the applicable trouble diagnosis.

Scheme 399

1. Turn ignition switch "OFF". (Stay for at least 5 seconds.)
2. Remove clutch pressure switch. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .
3. Push and release clutch pressure switch and check continuity between terminal 7 and ground. TERMINALS CONTINUITY REFERENCE Terminal Condition Continuity 7 - Ground Push clutch pressure switch Yes 7 - Ground Release clutch pressure switch No
4. If NG, replace the clutch pressure switch. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .

Data are reference value.

Scheme 400

Data are reference value and are measured between each terminal and ground.

Scheme 401

Scheme 402

Scheme 403

Scheme 404

Scheme 405

Scheme 406

Scheme 407

1. CHECK LINE PRESSURE SWITCH SIGNAL With CONSULT-II Start engine. Select "DATA MONITOR" mode for "ALL MODE AWD/4WD" with CONSULT-II. Read out ON/OFF switching action of "LINE PRES SW" while operating 4WD shift switch. Without CONSULT-II Start engine. Check voltage between transfer control unit harness connector terminals and ground OK or NG OK: GO TO 5 . NG: GO TO 2 .
2. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND LINE PRESSURE SWITCH Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer control unit harness connector and the transfer terminal cord assembly harness connector. Check continuity between transfer control unit harness connector E143 terminal 35 (BR/W) and transfer terminal cord assembly harness connector F56 terminal 1 (BR/W). Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 3 . NG: Repair or replace damaged parts.
3. CHECK TRANSFER CONTROL UNIT Check transfer control unit input/output signal. Refer to «Transfer Control Unit Input/Output Signal Reference Values»(ref-233277-S01882369842006052500000) . OK or NG OK: GO TO 4 . NG: Check the following. If any items are damaged, repair or replace damaged parts. Transfer control unit pin terminals for damage or loose connection with harness connector. Transfer control unit. Refer to «Removal and Installation»(ref-233277-S39974486172006052500000) .
4. CHECK LINE PRESSURE SWITCH Turn ignition switch "OFF". (Stay for at least 5 seconds.) Remove line pressure switch. Refer to " «Location of Electrical Parts»(ref-233277-S03515471932006052500000) ". Push and release line pressure switch and check continuity between terminal 1 and ground. TERMINALS CONTINUITY REFERENCE Terminal Condition Continuity 1 - Ground Push line pressure switch Yes 1 - Ground Release line pressure switch No OK or NG OK: GO TO 5 . NG: Replace line pressure switch.
5. CHECK DTC Perform the self-diagnosis, after driving a vehicle for a while. OK or NG OK: GO TO 6 . NG: Replace transfer control unit. Refer to «Removal and Installation»(ref-233277-S39974486172006052500000) .
6. CRUISE TEST Perform cruise test. Refer to «CRUISE TEST»(ref-233277-S41298292982006052500000) . OK or NG OK: INSPECTION END. NG: Perform the applicable trouble diagnosis.

Scheme 408

1. Turn ignition switch "OFF". (Stay for at least 5 seconds.)
2. Remove line pressure switch. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .
3. Push and release line pressure switch and check continuity between terminal 1 and ground. TERMINALS CONTINUITY REFERENCE Terminal Condition Continuity 1 - Ground Push line pressure switch Yes 1 - Ground Release line pressure switch No

Data are reference value.

Scheme 409

Data are reference value and are measured between each terminal and ground.

Scheme 410

Scheme 411

Scheme 412

Scheme 413

Scheme 414

Scheme 415

Scheme 416

Scheme 417

1. CHECK ATP SWITCH SIGNAL With CONSULT-II Start engine. Select "DATA MONITOR" mode for "ALL MODE AWD/4WD" with CONSULT-II. Read out the value of "ATP SWITCH". Without CONSULT-II Start engine. Check voltage between transfer control unit harness connector terminal and ground. OK or NG OK: GO TO 5 . NG: GO TO 2 .
2. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND ATP SWITCH Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect transfer control unit harness connector and the ATP switch harness connector. Check continuity between transfer control unit harness connector E143 terminal 40 (L) and ATP switch harness connector F55 terminal 8 (L/Y). Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 3 . NG: Repair or replace damaged parts.
3. CHECK GROUND CIRCUIT Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect ATP switch harness connector. Check continuity between ATP switch harness connector F55 terminal 9 (B) and ground. Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 4 . NG: Repair open circuit or short to ground or short to power in harness or connectors.
4. CHECK ATP SWITCH Turn ignition switch "OFF". (Stay for at least 5 seconds.) Disconnect ATP switch harness connector. Remove ATP switch. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) . Push and release ATP switch and check continuity between ATP switch terminals 8 and 9. TERMINALS CONTINUITY REFERENCE Terminal Condition Continuity 8 - 9 Push ATP switch Yes 8 - 9 Release ATP switch No OK or NG OK: GO TO 5 . NG: Replace ATP switch.
5. CHECK TRANSFER CONTROL UNIT Check transfer control unit input/output signal. Refer to «Transfer Control Unit Input/Output Signal Reference Values»(ref-233277-S01882369842006052500000) . OK or NG OK: GO TO 6 . NG: Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
6. CHECK ATP WARNING LAMP Turn ignition switch "ON". (Do not start engine.) Move A/T selector lever to "P" position. Set 4WD shift switch from "4H" to "4LO" or "4LO" to "4H". Does ATP warning lamp turn ON while switching? YES: GO TO «ATP WARNING LAMP TURNS ON»(ref-233277-S22367138172006052500000) . NO: Inspection End.

Scheme 418

1. Turn ignition switch "OFF". (Stay for at least 5 seconds.)
2. Disconnect ATP switch harness connector.
3. Remove ATP switch. Refer to «Location of Electrical Parts»(ref-233277-S03515471932006052500000) .
4. Push and release ATP switch and check continuity between ATP switch terminals 8 and 9. TERMINALS CONTINUITY REFERENCE Terminal Condition Continuity 8 - 9 Push ATP switch Yes 8 - 9 Release ATP switch No
5. If NG, replace the ATP switch.

4LO Indicator Lamp Repeats Flashing

SYMPTOM

4LO lamp keeps flashing.

CLEARANCE BETWEEN INNER GEAR AND OUTER GEAR

INNER GEAR AND OUTER GEAR CLEARANCE SPECIFICATIONS

CLUTCH

CLUTCH SPECIFICATIONS

PINION GEAR AND PLAY

PINION GEAR END PLAY SPECIFICATIONS

CLEARANCE BETWEEN SHIFT FORK AND SLEEVE

SHIFT FORK AND SLEEVE CLEARANCE SPECIFICATIONS

Sub-oil Pump

SUB-OIL PUMP SPECIFICATIONS

Main Oil Pump

MAIN OIL PUMP SPECIFICATIONS

Control Valve

CONTROL VALVE SPECIFICATIONS

Control Valve Spring

CONTROL VALVE SPRING SPECIFICATIONS

Return Spring

RETURN SPRING SPECIFICATIONS

RETURN SPRING SPECIFICATIONS
