Transfer: Maintenance Nissan Armada I

Transfer Case 8 illustrations ~204 words

DRAINING

Refer to CHANGING TRANSFER FLUID .

FLUID LEAKAGE AND FLUID LEVEL

Refer to CHECKING TRANSFER FLUID .

Scheme 240

Scheme 240: Cross-section View

Scheme 241

Scheme 241: POWER TRANSFER DIAGRAM

Scheme 242

Scheme 242: POWER TRANSFER FLOW

Scheme 243

Scheme 243: CONTROL SYSTEM

Scheme 244

Scheme 244: ALL-MODE 4WD Transfer Basic Control

Scheme 245

Scheme 245: Hydraulic Control Circuits
  1. The transfer motor drives the sub-oil pump to provide proper lubrication and oil pressure control when the vehicle is at standstill, during low-speed operations or is being driven in reverse.
  2. The main oil pump is operated by the driving force of the mainshaft. In other words, sufficient oil pressure buildup does not occur when the vehicle is at standstill or during low-speed operations. While the vehicle is being driven in reverse, the main oil pump rotates in the reverse direction. Therefore the main oil pump does not discharge oil pressure. During any of the above vehicle operations, the transfer motor drives the sub-oil pump to compensate for insufficient oil pressure.
  3. The transfer motor operates as follows.
  1. The motor relay turns OFF in the 2WD mode.
  2. The motor relay operates as described in the table below in modes other than the 2WD mode.

Table 1

Scheme 246

Scheme 246

Table 2

Scheme 247

Scheme 247
  1. 4WD shift switch, PNP switch, Neutral-4LO switch, vehicle speed sensor and throttle position sensor are used in conjunction with the transfer motor.
