WIRING DIAGRAM - CAN

*For references to PG-POWER, see GROUND DISTRIBUTION & POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS

Scheme 200

Scheme 201

Scheme 202

Scheme 203

Scheme 204

Scheme 205

1. When there are no indications of "BCM", "HVAC" or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "A/T", "BCM", "HVAC", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "A/T", "BCM", "HVAC", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Attach the printed sheet of "SELECT SYSTEM", "SELF-DIAG RESULTS" and "CAN DIAG SUPPORT MNTR" onto the check sheet. Refer to «CHECK SHEET»(ref-233315-S33520211622006052500000) .
5. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", puts a check mark onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. Refer to «CHECK SHEET»(ref-233315-S33520211622006052500000) . NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items, which are not in check sheet table, are not related to diagnostic procedure on service manual. So it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
6. According to the check sheet results (example), start inspection. Refer to «CHECK SHEET RESULTS (EXAMPLE)»(ref-233315-S14335381572006052500000) .

*For references to PG-POWER, see GROUND DISTRIBUTION & POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS

Scheme 206

Scheme 207

Scheme 208

Scheme 209

Scheme 210

Scheme 211

1. When there are no indications of "AUTO DRIVE POS.", "BCM", "HVAC" or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "A/T", "AUTO DRIVE POS.", "BCM", "HVAC", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "A/T", "AUTO DRIVE POS.", "BCM", "HVAC", "ABS"and "IPDM E/R" displayed on CONSULT-II.
4. Attach the printed sheet of "SELECT SYSTEM", "SELF-DIAG RESULTS" and "CAN DIAG SUPPORT MNTR" onto the check sheet. Refer to «CHECK SHEET»(ref-233315-S27553138012006052500000)
5. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", puts a check mark onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. Refer to «CHECK SHEET»(ref-233315-S27553138012006052500000) NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items, which are not in check sheet table, are not related to diagnostic procedure on service manual. So it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
6. According to the check sheet results (example), start inspection. Refer to «CHECK SHEET RESULTS (EXAMPLE)»(ref-233315-S21553617622006052500000)

*For references to PG-POWER, see GROUND DISTRIBUTION & POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS

Scheme 212

Scheme 213

Scheme 214

Scheme 215

Scheme 216

Scheme 217

1. When there are no indications of "AUTO DRIVE POS.", "BCM", "HVAC" or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "A/T", "AUTO DRIVE POS.", "BCM", "HVAC", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "A/T", "AUTO DRIVE POS.", "BCM", "HVAC", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Attach the printed sheet of "SELECT SYSTEM", "SELF-DIAG RESULTS" and "CAN DIAG SUPPORT MNTR" onto the check sheet. Refer to «CHECK SHEET»(ref-233315-S01137638622006052500000) .
5. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", puts a check mark onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. Refer to «CHECK SHEET»(ref-233315-S01137638622006052500000) . NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items, which are not in check sheet table, are not related to diagnostic procedure on service manual. So it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
6. Check CAN communication line of the navigation system. Refer to «CAN COMMUNICATION LINE CHECK»(ref-233316-S05935892422006052500000) .
7. Attach the CAN DIAG SUPPORT MONITOR check sheet onto the check sheet. Refer to «CHECK SHEET»(ref-233315-S01137638622006052500000) .
8. Mark the "NG" or "UNKWN" item of the check sheet table with "v" from the result of CAN DIAG SUPPORT MONITOR check sheet. Refer to «CHECK SHEET»(ref-233315-S01137638622006052500000) . NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MONITOR" for the diagnosed control unit, replace the control unit. Refer to «CAN COMMUNICATION LINE CHECK»(ref-233316-S05935892422006052500000) .
9. According to the check sheet results (example), start inspection. Refer to «CHECK SHEET RESULTS (EXAMPLE)»(ref-233315-S03948257192006052500000) .

*For references to PG-POWER, see GROUND DISTRIBUTION & POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS

Scheme 218

Scheme 219

Scheme 220

Scheme 221

Scheme 222

Scheme 223

Scheme 224

1. When there are no indications of "BCM", "HVAC", "ALL MODE AWD/4WD" or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "A/T", "BCM", "HVAC", "ALL MODE AWD/4WD", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "A/T", "BCM", "HVAC", "ALL MODE AWD/4WD", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Attach the printed sheet of "SELECT SYSTEM", "SELF-DIAG RESULTS" and "CAN DIAG SUPPORT MNTR" onto the check sheet. Refer to «CHECK SHEET»(ref-233315-S20477630692006052500000) .
5. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", puts a check mark onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. Refer to «CHECK SHEET»(ref-233315-S20477630692006052500000) . CAUTION: "ALL MODE AWD/4WD" puts a check mark on the check sheet when "Present" is "UNKWN" and "Past" is "0". NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items, which are not in check sheet table, are not related to diagnostic procedure on service manual. So it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
6. According to the check sheet results (example), start inspection. Refer to «CHECK SHEET RESULTS (EXAMPLE)»(ref-233315-S42121048592006052500000) .

*For references to PG-POWER, see GROUND DISTRIBUTION & POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS

Scheme 225

Scheme 226

Scheme 227

Scheme 228

Scheme 229

Scheme 230

Scheme 231

1. When there are no indications of "AUTO DRIVE POS.", "BCM", "HVAC", "ALL MODE AWD/4WD" or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "A/T", "AUTO DRIVE POS.", "BCM", "HVAC", "ALL MODE AWD/4WD", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "A/T", "AUTO DRIVE POS.", "BCM", "HVAC", "ALL MODE AWD/4WD", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Attach the printed sheet of "SELECT SYSTEM", "SELF-DIAG RESULTS" and "CAN DIAG SUPPORT MNTR" onto the check sheet. Refer to «CHECK SHEET»(ref-233315-S38529712102006052500000) .
5. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", puts a check mark onto the items with "NO indication", "NG", or "UNKWN" in the check sheet table. Refer to «CHECK SHEET»(ref-233315-S38529712102006052500000) . CAUTION: "ALL MODE AWD/4WD" puts a check mark on the check sheet when "Present" is "UNKWN" and "Past" is "0". NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items, which are not in check sheet table, are not related to diagnostic procedure on service manual. So it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
6. According to the check sheet results (example), start inspection. Refer to «CHECK SHEET RESULTS (EXAMPLE)»(ref-233315-S15408007562006052500000) .

*For references to PG-POWER, see GROUND DISTRIBUTION & POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS

Scheme 232

Scheme 233

Scheme 234

Scheme 235

Scheme 236

Scheme 237

Scheme 238

1. When there are no indications of "AUTO DRIVE POS.", "BCM", "HVAC", "ALL MODE AWD/4WD" or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "A/T", "AUTO DRIVE POS.", "BCM", "HVAC", "ALL MODE AWD/4WD", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "A/T", "AUTO DRIVE POS.", "BCM", "HVAC", "ALL MODE AWD/4WD", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Attach the printed sheet of "SELECT SYSTEM", "SELF-DIAG RESULTS" and "CAN DIAG SUPPORT MNTR" onto the check sheet. Refer to «CHECK SHEET»(ref-233315-S26590426272006052500000) .
5. Based on the indications of "SELECT SYSTEM" and the results of "CAN DIAG SUPPORT MNTR", puts a check mark onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. Refer to «CHECK SHEET»(ref-233315-S26590426272006052500000) . CAUTION: "ALL MODE AWD/4WD" puts a check mark on the check sheet when "Present" is "UNKWN" and "Past" is "0". NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit. The "CAN DIAG SUPPORT MNTR" items, which are not in check sheet table, are not related to diagnostic procedure on service manual. So it is not necessary to check the status of the "CAN DIAG SUPPORT MNTR" items not in check sheet table.
6. Check CAN communication line of the navigation system. Refer to «CAN COMMUNICATION LINE CHECK»(ref-233316-S05935892422006052500000) .
7. Attach the CAN DIAG SUPPORT MONITOR check sheet onto the check sheet. Refer to «CHECK SHEET»(ref-233315-S26590426272006052500000) .
8. Mark the "NG" or "UNKWN" item of the check sheet table with "v" from the result of CAN DIAG SUPPORT MONITOR check sheet. Refer to «CHECK SHEET»(ref-233315-S26590426272006052500000) . NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MONITOR" for the diagnosed control unit, replace the control unit. Refer to «CAN COMMUNICATION LINE CHECK»(ref-233316-S05935892422006052500000) .
9. According to the check sheet results (example), start inspection. Refer to «CHECK SHEET RESULTS (EXAMPLE)»(ref-233315-S06007136022006052500000) .
