WIRING DIAGRAM - METER
*For references to PG-POWER, see GROUND DISTRIBUTION & POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS
Scheme 40
Scheme 41
Scheme 42
WIRING DIAGRAM - COMPAS
*For references to PG-POWER, see GROUND DISTRIBUTION & POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS
Scheme 43
WIRING DIAGRAM - WARN
*For references to PG-POWER, see GROUND DISTRIBUTION & POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS
Scheme 44
Scheme 45
Scheme 46
Scheme 47
Scheme 48
Scheme 49
Scheme 50
Scheme 51
Scheme 52
Scheme 53
Scheme 54
Scheme 55
Scheme 56
- CHECK OIL PRESSURE SENSOR SIGNAL Turn ignition switch ON. Check voltage between combination meter harness connector M24 terminal 20 (Y) and ground. OK or NG OK: GO TO 2 . NG: GO TO 3 .
- CHECK OIL PRESSURE SENSOR GROUND CIRCUIT Turn ignition switch OFF. Disconnect combination meter connector M24 and oil pressure sensor connector F4. Check continuity between combination meter harness connector M24 terminal 16 (B/P) and oil pressure sensor harness connector F4 terminal 3 (B/P). Continuity should exist. OK or NG OK: Replace the combination meter. Refer to «COMBINATION METER»(ref-233304-S14186178792006052500000) . NG: Repair harness or connector.
- CHECK OIL PRESSURE SENSOR REFERENCE VOLTAGE Turn ignition switch OFF. Disconnect oil pressure sensor connector F4. Turn ignition switch ON. Check voltage between combination meter harness connector M24 terminal 22 (GR/L) and ground. Voltage : Approx. 5 V OK or NG OK: GO TO 4 . NG: Replace the combination meter. Refer to «COMBINATION METER»(ref-233304-S14186178792006052500000) ".
- CHECK OIL PRESSURE SENSOR POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect combination meter connector M24. Check continuity between combination meter harness connector M24 terminal 22 (GR/L) and oil pressure sensor harness connector F4 terminal 1 (GR/L). Continuity should exist. Check continuity between combination meter harness connector M24 terminal 22 (GR/L) and ground. Continuity should not exist. OK or NG OK: GO TO 5 . NG: Repair harness or connector.
- CHECK OIL PRESSURE SENSOR SIGNAL CIRCUIT Check continuity between combination meter harness connector M24 terminal 20 (Y) and oil pressure sensor harness connector F4 terminal 2 (Y). Continuity should exist. Check continuity between combination meter harness connector M24 terminal 20 (Y) and ground. Continuity should not exist. OK or NG OK: GO TO 6 . NG: Repair harness or connector.
- CHECK OIL PRESSURE SENSOR GROUND CIRCUIT Check continuity between combination meter harness connector M24 terminal 16 (B/P) and ground. Continuity should not exist. OK or NG OK: Replace oil pressure sensor. NG: Repair harness or connector.
WIRING DIAGRAM - AT/IND
*For references to PG-POWER, see GROUND DISTRIBUTION & POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS
Scheme 57
WIRING DIAGRAM - CHIME
*For references to PG-POWER, see GROUND DISTRIBUTION & POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS
Scheme 58
Scheme 59
Scheme 60
Scheme 61
Scheme 62
WIRING DIAGRAM - SONAR
*For references to PG-POWER, see GROUND DISTRIBUTION & POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS
Scheme 63
Scheme 64
Scheme 65
WIRING DIAGRAM - R/VIEW
*For references to PG-POWER, see GROUND DISTRIBUTION & POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS
