Timing Chain: Removal & Installation Nissan Altima U13

Mechanical 4 illustrations ~470 words

Removal

  1. Release fuel pressure. See «FUEL PRESSURE RELEASE»(ref-49198-S32789705022001011500000). Drain coolant from radiator and cylinder block. Drain engine oil. Disconnect all necessary coolant hoses, electrical connectors, vacuum hoses, fuel lines and control cables.
  2. Remove front exhaust tube. Remove air injection valve pipe. Remove intake air duct. Remove radiator fan and shroud. Remove injectors and fuel rail as an assembly. Remove distributor cap and spark plugs.
  3. Set cylinder No. 1 at TDC of compression stroke, ensuring marks on crankshaft pulley and front cover align, and distributor rotor points to spark plug wire No. 1 on cap. Remove cylinder head cover. Remove distributor. NOTE: It is not necessary to install a stopper to prevent inner or outer timing chains from disengaging sprockets.
  4. Prevent camshafts from turning, and remove camshaft sprocket bolts. Remove camshaft sprocket. (Scheme 10) Mark and remove camshaft bearing caps in reverse order of installation. see scheme 13 Remove camshafts.
  5. Loosen cylinder head bolts in 2 or 3 steps, in reverse order of tightening sequence. (Scheme 9) Remove camshaft sprocket cover. Remove outer (upper) chain tensioner and guide. Remove outer timing chain. Remove idler sprocket bolt. Remove cylinder head.
  6. Remove oil pan and oil strainer. See «OIL PAN»(ref-49198-S33564362632001011500000). Remove accessory drive belts. Remove A/C compressor idler pulley (if equipped). Remove crankshaft pulley. Remove front cover. Remove chain tensioner, tensioner arm and chain guides. Remove inner (lower) timing chain and idler sprocket. Remove oil pump drive gear and crankshaft sprocket.

Installation

  1. Install crankshaft sprocket with sprocket teeth toward front of engine, and shoulder toward rear of engine. Install oil pump drive spacer. Ensure cylinder No. 1 is at TDC, with crankshaft sprocket keyway at 12 o'clock position. (Scheme 11)
  2. Install inner timing chain onto crankshaft sprocket and idler sprocket. Hold idler sprocket in position. Ensure mating marks on sprockets align with Silver chain links. Install chain guide and tensioner.
  3. Apply lithium grease to front cover oil seal. Apply a.08-.12" (2-3 mm) diameter bead of sealant to front cover. Install front cover. Install crankshaft pulley. Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-49198-S16349599862001011500000).
  4. Install oil strainer, oil pan, accessory drive components and belts. Install front engine mount. Install cylinder head and NEW gasket, and temporarily tighten cylinder head bolts loosely. Install outer timing chain, chain tensioner and chain guide. Ensure mating marks align. (Scheme 12) Hold outer timing chain in position.
  5. Apply sealant to camshaft sprocket cover sealing surfaces. Install camshaft sprocket cover. Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(ref-49198-S16349599862001011500000). Tighten cylinder head bolts to specification. Install camshafts and bearing caps. Tighten bearing cap bolts in sequence to specification. see scheme 13
  6. Install camshaft sprockets and chain guide. Apply sealant to cylinder head rubber plugs. see scheme 8 Install rubber plugs. Install cylinder head cover. To complete installation, reverse removal procedure.
