Audio, Visual & Navigation System (Base Audio) (Coupe): Removal & Installation Nissan Altima L33

INSTALLATION

Installation is in the reverse order of removal.

Scheme 308

1. Remove the front pillar finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-592057-S34064100072014010800000) ".
2. Remove the tweeter speaker grille, using a suitable tool.
3. Remove the tweeter speaker screws (A).
4. Pull out the tweeter speaker (1), disconnect the tweeter speaker connector and remove tweeter speaker.

Installation is in the reverse order of removal.

Scheme 309

1. Remove the front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-592057-S30789231392014010800000) ".
2. Remove the front door speaker screws (A).
3. Disconnect the front door speaker connector and remove the front door speaker (1).

Installation is in the reverse order of removal.

Scheme 310

1. Remove the upper trunk finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-592057-S01492370492014010800000) ".
2. Remove the rear speaker screws (A), then disconnect the rear speaker connector (B) and remove the rear speaker (1).

Installation is in the reverse order of removal.

Scheme 311

1. Disconnect the battery negative terminal. Refer to " «REMOVAL AND INSTALLATION (BATTERY)»(ref-592011-S06046231102014010800000) ".
2. Remove the trunk floor carpet and spare tire cover. Refer to " «REMOVAL AND INSTALLATION»(ref-592057-S01492370492014010800000) ".
3. Remove the LH trunk floor spacer.
4. Remove the satellite radio tuner assembly nuts (B), and satellite radio tuner screw (C).
5. Disconnect the satellite radio tuner harness connectors.
6. Remove the satellite radio tuner and bracket assembly (1 and 2).
7. Remove the satellite radio tuner screws (A) and remove satellite radio tuner (1) from the bracket (2).

Installation is in the reverse order of removal.

Scheme 312

1. Disconnect the battery negative terminal. Refer to " «REMOVAL AND INSTALLATION (BATTERY)»(ref-592011-S06046231102014010800000) ".
2. Remove the trunk floor carpet and spare tire cover. Refer to " «REMOVAL AND INSTALLATION»(ref-592057-S01492370492014010800000) ".
3. Remove the LH trunk floor spacer.
4. Remove the Bluetooth control unit screws (A), then disconnect the Bluetooth control unit connectors and remove the Bluetooth control unit (1).
5. Remove the satellite radio tuner assembly nuts (C), and satellite radio tuner screw (D), disconnect the satellite radio tuner harness connectors and remove the satellite radio tuner and bracket assembly (2 and 3), then remove the satellite radio tuner screws (B) and remove satellite radio tuner (2) from the bracket (3).

Installation is in the reverse order of removal.

Scheme 313

1. Lower the headlining at the rear. Refer to " «REMOVAL AND INSTALLATION»(ref-592057-S20647581082014010800000) ".
2. Remove the satellite radio antenna nut (A).
3. Disconnect the satellite radio antenna connector (B) and remove the satellite radio antenna (1).

Installation is in the reverse order of removal.

Scheme 314

1. Remove the driver airbag module. Refer to " «REMOVAL AND INSTALLATION»(ref-592012-S01619704382014010800000) ".
2. Remove the steering wheel audio control switches screws (A), then remove the steering wheel audio control switches (1).

Installation is in the reverse order of removal.

Scheme 315

1. Remove the rear pillar finisher RH. Refer to " «REMOVAL AND INSTALLATION»(ref-592057-S34064100072014010800000) ".
2. Detach the antenna amp. harness clip (B).
3. Disconnect the antenna amp. connectors (A).
4. Remove the antenna amp. screw (C) and remove the antenna amp. (1).

Installation is in the reverse order of removal.

Scheme 316

Scheme 317

Scheme 318

Scheme 319

Scheme 320

1. Attach probe circuit tester (ohm setting) to antenna terminal on each side. When measuring continuity, wrap tin foil around the top of probe. Then, press the foil against the wire with your finger.
2. If an element is broken, no continuity will exist.
3. To locate a break, move probe along element. Tester indication will change abruptly when probe passes the broken point.

Installation is in the reverse order of removal.

Scheme 321

1. Remove the rear parcel shelf. Refer to " «REMOVAL AND INSTALLATION - REAR PARCEL SHELF FINISHER»(ref-592057-S35755441302014010800000) ".
2. Remove the Bluetooth antenna screw (A).
3. Fold down the rear seat back.
4. Disconnect the Bluetooth antenna connector and remove the Bluetooth antenna (1).

Installation is in the reverse order of removal.

Scheme 322

1. Disconnect the negative battery terminal. Refer to " «REMOVAL AND INSTALLATION (BATTERY)»(ref-592011-S06046231102014010800000) ".
2. Remove the Bluetooth control unit screws (A).
3. Detach the Bluetooth control unit connector harness clip (B).
4. Disconnect the Bluetooth antenna connector (C).
5. Disconnect the Bluetooth control unit connector (D) and remove the Bluetooth control unit (1).
6. To remove the Bluetooth control unit bracket, remove the rear parcel shelf. Refer to " «REMOVAL AND INSTALLATION - REAR PARCEL SHELF FINISHER»(ref-592057-S35755441302014010800000) ".
7. Remove the Bluetooth control unit bracket.

Installation is in the reverse order of removal.
