DETAILED FLOW
- GET INFORMATION FOR SYMPTOM Get detailed information from the customer about the symptom (the condition and the environment when the incident/malfunction occurred). : GO TO 2
- CONFIRM THE SYMPTOM Try to confirm the symptom described by the customer. Verify relation between the symptom and the condition when the symptom is detected. : GO TO 3
- DETECT MALFUNCTIONING PART BY DIAGNOSTIC PROCEDURE Inspect according to Diagnostic Procedure of the system. Is malfunctioning part detected? YES: GO TO 4 NO: GO TO 2
- REPAIR OR REPLACE THE MALFUNCTIONING PART Repair or replace the malfunctioning part. Reconnect parts or connectors disconnected during Diagnostic Procedure. : GO TO 5
- FINAL CHECK Refer to confirmed symptom in step 2 , and make sure that the symptom is not detected. Has the symptom been repaired? YES: Inspection End. NO: GO TO 2
Scheme 323
AUDIO SYSTEM
The audio system consists of the following components
- Audio unit
- Window antenna
- Steering wheel audio control switches
- Door speakers
- Front tweeters
- Rear speakers
When the audio system is on, radio signals are received by the window antenna. The audio unit then sends audio signals to the door speakers, front tweeters and rear speakers.
Refer to Owner's Manual for audio system operating instructions.
SATELLITE RADIO SYSTEM
The satellite radio system consists of the following components
- Satellite antenna
- Satellite radio tuner
When the satellite radio system is on, radio signals are supplied to the satellite radio tuner from the satellite antenna. The satellite radio tuner then sends audio signals to the audio unit.
Refer to Owner's Manual for satellite radio system operating instructions.
Scheme 324
PHYSICAL VALUES
Terminal (Wire color) Description Condition Reference value (Approx.) + - Signal name Input/Output Ignition switch Operation 2 (W) 3 (B) Audio sound signal front LH Output ON Receive audio signal 4 (O/B) 5 (W/R) Audio sound signal rear LH Output ON Receive audio signal 6 (1) (W/G) Ground Remote control A Input ON Press SOURCE switch 0 V Press SEEK UP switch 0.75 V Press VOL UP switch 2.0 V Except for above 5.0 V 7 (V/Y) Ground ACC signal Input ON Ignition switch ACC or ON Battery voltage 9 (R/L) 8 (R/Y) ILL signal Input ON Headlamps ON Battery voltage 11 (G/W) 12 (BR) Audio sound signal front RH Output ON Receive audio signal 13 (L) 14 (B/W) Audio sound signal rear RH Output ON Receive audio signal 15 (1) (L/B) - Remote control ground Input - - - 16 (1) (GR/L) Ground Remote control B Input ON Press SEEK DOWN switch 0.75 V Press VOL DOWN switch 2.0 V Except for above 5.0 V 19 (Y/R) Ground Battery power Input - - Battery voltage 32 (Y/L) 31 (G/B) Audio left channel sound signal from satellite radio tuner Input ON Receive audio signal 34 (BR/W) 33 (Y/G) Audio right channel sound signal from satellite radio tuner Input ON Receive audio signal 38 (R) Ground Satellite radio tuner request to audio unit Input ON Turn audio unit ON 5.0 V 39 (R/W) Ground Audio RX Input Operate audio volume 40 (B) Ground Audio TX Output Operate audio volume 75 (B) Ground Antenna amp power supply Output ON Turn audio unit ON Battery voltage 76 (B) Ground Main antenna Input ON Turn audio unit ON - (1) With steering wheel audio control switches
Scheme 325
Scheme 326
Terminal (Wire color) Description Condition Voltage (approx.) + - Signal name Input/Output Ignition switch Operation 22 (Y/L) 21 (W/L) Audio signal LH Output ON Receive audio signal. 24 (BR/L) 23 (Y/G) Audio signal RH Output ON Receive audio signal. 28 (B) Ground REQ1 (SAT-AUDIO) Output ON Set to the satellite radio mode 29 (W) Ground Communication signal (SAT-AUDIO) Output ON Set to the satellite radio mode 30 (R) Ground Communication signal (AUDIO-SAT) Input ON Set to the satellite radio mode 32 (SB) Ground Battery power supply Input OFF - Battery voltage 36 (P) ACC power supply ACC
Scheme 327
Scheme 328
Scheme 329
Scheme 330
Scheme 331
Scheme 332
Scheme 333
| Symptoms | Check items | Probable malfunction location |
|---|---|---|
| The disk cannot be removed. | Audio unit | Malfunction in audio unit. Refer to " DIAGNOSIS DESCRIPTION ". |
| No sound comes out or the level of the sound is low. | No sound from all speakers. | Speaker circuit shorted to ground. Refer to " WIRING DIAGRAM ". Audio unit power supply and ground circuits malfunction. Refer to " AUDIO UNIT: DIAGNOSIS PROCEDURE ". |
| Only a certain speaker (door speaker LH, door speaker RH, front tweeter LH, front tweeter RH, rear speaker LH, rear speaker RH) does not output sound. | Poor connector connection of speaker. Sound signal circuit malfunction between audio unit and speaker. Refer to: " DIAGNOSIS PROCEDURE " (door speaker). " DIAGNOSIS PROCEDURE " (front tweeter). " DIAGNOSIS PROCEDURE " (rear speaker). Malfunction in speaker. Refer to: " REMOVAL AND INSTALLATION " (door speaker). " REMOVAL AND INSTALLATION " (front tweeter). " REMOVAL AND INSTALLATION " (rear speaker). Malfunction in audio unit. Refer to " DIAGNOSIS DESCRIPTION ". | |
| Noise is mixed with audio. | Noise comes out from all speakers. | Malfunction in audio unit. Refer to " DIAGNOSIS DESCRIPTION ". |
| Noise comes out only from a certain speaker (door speaker LH, door speaker RH, front tweeter LH, front tweeter RH, rear speaker LH, rear speaker RH). | Poor connector connection of speaker. Sound signal circuit malfunction between audio unit and speaker. Refer to: " DIAGNOSIS PROCEDURE " (door speaker). " DIAGNOSIS PROCEDURE " (front tweeter). " DIAGNOSIS PROCEDURE " (rear speaker). Malfunction in speaker. Poor Installation of speaker (e.g. backlash and looseness). Refer to: " REMOVAL AND INSTALLATION " (door speaker). " REMOVAL AND INSTALLATION " (front tweeter). " REMOVAL AND INSTALLATION " (rear speaker). Malfunction in audio unit. Refer to " DIAGNOSIS DESCRIPTION ". | |
| Noise is mixed with radio only (when the vehicle hits a bump or while driving over bad roads) | Poor connector connection of antenna or antenna feeder. Refer to " LOCATION OF ANTENNA ". | |
| No radio reception or poor reception. | Other audio sounds are normal. Any radio station cannot be received or poor reception is caused even after moving to a service area with good reception (e.g. a place with clear view and no obstacles generating external noises). | Antenna amp. ON signal circuit malfunction. Refer to " REFERENCE VALUE ". Poor connector connection of antenna or antenna feeder. Refer to " LOCATION OF ANTENNA ". |
| No satellite radio reception. | Satellite radio antenna malfunction. | Poor continuity in antenna feeder. Poor connector connection of antenna or antenna feeder. Loose satellite radio antenna mounting nut. Refer to " LOCATION OF ANTENNA ". |
| Buzz/rattle sound from speaker | The majority of buzz/rattle sounds are not indicative of an issue with the speaker, usually something nearby the speaker is causing the buzz/rattle. | Refer to SQUEAK AND RATTLE TROUBLE DIAGNOSES in the appropriate interior trim information. |
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are buckled or unbuckled. Information necessary to service the system safely is included in the SRS AIRBAG (COUPE) and SEAT BELTS (COUPE) article of this Service Information.
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SRS AIRBAG . Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
| WARNING | When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service. |
AV COMMUNICATION SYSTEM
- Do not apply voltage of 7.0 V or higher to the measurement terminals.
- Use the tester with its open terminal voltage being 7.0 V or less.
- Be sure to turn ignition switch OFF and disconnect the battery cable from the negative terminal before checking the circuit.
Scheme 334
Scheme 335
- Solder the repaired parts, and wrap with tape. [Frays of twisted line must be within 110 mm (4.33 in).]
- Do not perform bypass wire connections for the repair parts. (The spliced wire will become separated and the characteristics of twisted line will be lost.)
Precaution for Work
- When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
- When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
- Protect the removed parts with a shop cloth and prevent them from being dropped.
- Replace a deformed or damaged clip.
- If a part is specified as a non-reusable part, always replace it with new one.
- Be sure to tighten bolts and nuts securely to the specified torque.
- After installation is complete, be sure to check that each part works properly.
- Follow the steps below to clean components. Water soluble dirt: Dip a soft cloth into lukewarm water, and wring the water out of the cloth to wipe the dirty area. Then rub with a soft and dry cloth. Oily dirt: Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%), and wipe the dirty area. Then dip a cloth into fresh water, and wring the water out of the cloth to wipe the detergent off. Then rub with a soft and dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol, or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
Special Service Tools
The actual shapes of the tools may differ from those illustrated here.
Tool number (TechMate No.) Tool name Description - (J-46534) Trim tool set Removing trim components
Scheme 336
Commercial Service Tools
Tool name Description Power tools Removing nuts, screws and bolts
Scheme 337
- Disconnect the negative battery terminal. Refer to " «REMOVAL AND INSTALLATION (BATTERY)»(ref-592011-S06046231102014010800000) ".
- Remove the cluster lid C. Refer to " «REMOVAL AND INSTALLATION»(ref-592049-S03959165542014010800000) ".
- Remove the cluster lid C screws (A), then remove the audio unit (1).
- Remove the audio unit bracket screws (B), then remove the front air control unit screws and remove the audio unit brackets.
REPAIR EQUIPMENT
- Conductive silver composition (DuPont No. 4817 or equivalent)
- Ruler 30 cm (11.8 in) long
- Drawing pen
- Heat gun
- Alcohol
- Cloth
Scheme 338
Scheme 339
Scheme 340
- Wipe broken heat wire and its surrounding area clean with a cloth dampened in alcohol.
- Apply a small amount of conductive silver composition to tip of drawing pen. Shake silver composition container before use.
- Place ruler on glass along broken line. Deposit conductive silver composition on break with drawing pen. Slightly overlap existing heat wire on both sides [preferably 5 mm (0.20 in)] of the break.
- After repair has been completed, check repaired wire for continuity. This check should be conducted 10 minutes after silver composition is deposited. Do not touch repaired area while test is being conducted.
- Apply a constant stream of hot air directly to the repaired area for approximately 20 minutes with a heat gun. A minimum distance of 3 cm (1.2 in) should be kept between repaired area and hot air outlet. If a heat gun is not available, let the repaired area dry for 24 hours.
Scheme 341
Scheme 342
Scheme 343
- Remove the front room/map lamp assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-592062-S37612441602014010800000) ".
- Detach the microphone connector (A).
- Remove the front room/map lamp covers (1), then remove the map lamp assembly cover (2).
- Release the microphone tabs (A), then remove the microphone (1).
