Power Window Control System (Except Hybrid): Other Nissan Altima L32

DETAILED FLOW

1. INTERVIEW FOR MALFUNCTION Interview the symptom to the customer. : GO TO 2.
2. SYMPTOM CHECK Check the symptom from the customer's information. : GO TO 3.
3. BASIC INSPECTION Check the operation of each part. Check that any symptom occurs other than the interviewed symptom. : GO TO 4.
4. SELF-DIAGNOSIS WITH CONSULT-III Perform the self-diagnosis with CONSULT-III. Check that any DTC is detected. Is any DTC detected? YES: GO TO 5. NO: GO TO 6 .
5. TROUBLE DIAGNOSIS BY DTC Perform the trouble diagnosis for the detected DTC. Specify the malfunctioning part. : GO TO 9 .
6. FAIL-SAFE ACTIVATION CHECK Check that the symptom is applied to the fail-safe activation. Does the fail-safe activate? YES: GO TO 7. NO: GO TO 8 .
7. SYSTEM DIAGNOSIS Perform the system diagnosis for the system that the fail-safe activates. Specify the malfunctioning part. : GO TO 9 .
8. SYMPTOM DIAGNOSIS Perform the symptom diagnosis. Specify the malfunctioning part. : GO TO 9.
9. MALFUNCTION PART REPAIR Repair or replace the malfunctioning part. : GO TO 10.
10. REPAIR CHECK (SELF-DIAGNOSIS WITH CONSULT-III) Perform the self-diagnosis with CONSULT-III. Check that any DTC is not detected. Erase DTC if DTC is detected before the repair. Check that DTC is not detected again. Is any DTC detected? YES: GO TO 5 . NO: GO TO 11.
11. REPAIR CHECK (OPERATION CHECK) Check the operation of each part. Does it operate normally? YES: Inspection End. NO: GO TO 3 .

MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH

INPUT/OUTPUT SIGNAL CHART

POWER WINDOW LOCK

Ground circuit inside main power window and door lock/unlock switch shuts off when power window lock switch is ON. This inhibits power window switch operation except with the main power window and door lock/unlock switch.

FRONT POWER WINDOW LH ANTI-PINCH SYSTEM

COMPONENT FUNCTION CHART

Data monitor

DATA MONITOR

POWER WINDOW MAIN SWITCH: Component Function Check

Main Power Window And Door Lock/unlock Switch

1. CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH FUNCTION Does power window motor operate with main power window and door lock/unlock switch operation? Is the inspection result normal? YES: Main power window and door lock/unlock switch power supply and ground circuit are OK. NO: Refer to " «POWER WINDOW MAIN SWITCH: DIAGNOSIS PROCEDURE»(ref-272640-S12369079842007112300000) ".

POWER WINDOW MAIN SWITCH: Special Repair Requirement

1. PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: SPECIAL REPAIR REQUIREMENT»(ref-272640-S12274346592007112300000) " Is the inspection result normal? YES: GO TO 2. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-272588-S25405727752007112300000) ".
2. CHECK ANTI-PINCH OPERATION Check anti-pinch operation. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: SPECIAL REPAIR REQUIREMENT»(ref-272640-S12274346592007112300000) " Is the inspection result normal? YES: Inspection end. NO: Refer to " «DRIVER SIDE: COMPONENT FUNCTION CHECK»(ref-272640-S25309102422007112300000) "

FRONT POWER WINDOW SWITCH: Component Function Check

Power Window And Door Lock/unlock Switch RH

1. CHECK POWER WINDOW MOTOR FUNCTION Does front power window motor operate with power window and door lock/unlock switch RH operation? Is the inspection result normal? YES: Power window and door lock/unlock switch RH power supply and ground circuit are OK. NO: Refer to " «FRONT POWER WINDOW SWITCH: DIAGNOSIS PROCEDURE»(ref-272640-S09797290532007112300000) ".

REAR POWER WINDOW SWITCH: Component Function Check

Rear Power Window Switch

1. CHECK REAR POWER WINDOW MOTOR FUNCTION Does rear power window motor operate with rear power window switch operation? Is the inspection result normal? YES: Rear power window switch power supply and ground circuit are OK. NO: Refer to " «REAR POWER WINDOW SWITCH: DIAGNOSIS PROCEDURE»(ref-272640-S29599702962007112300000) ".

DRIVER SIDE: Component Function Check

1. CHECK FRONT POWER WINDOW MOTOR LH CIRCUIT Does front power window motor LH operate with the main power window and door lock/unlock switch? Is the inspection result normal? YES: Front power window motor LH is OK. NO: Refer to " «DRIVER SIDE: DIAGNOSIS PROCEDURE»(ref-272640-S00728621342007112300000) ".

DRIVER SIDE: Special Repair Requirement

1. PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: SPECIAL REPAIR REQUIREMENT»(ref-272640-S12274346592007112300000) ". Is the inspection result normal? YES: GO TO 2. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-272588-S25405727752007112300000) ".
2. CHECK ANTI-PINCH OPERATION Check anti-pinch operation. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: SPECIAL REPAIR REQUIREMENT»(ref-272640-S12274346592007112300000) ". Is the inspection result normal? YES: Inspection end. NO: Refer to " «DRIVER SIDE: COMPONENT FUNCTION CHECK»(ref-272640-S25309102422007112300000) ".

PASSENGER SIDE: Component Function Check

1. CHECK FRONT POWER WINDOW MOTOR RH CIRCUIT Does front power window motor RH operate with main power window and door lock/unlock switch or power window and door lock/unlock switch? Is the inspection result normal? YES: Front power window motor RH is OK. NO: Refer to " «PASSENGER SIDE: DIAGNOSIS PROCEDURE»(ref-272640-S41492122652007112300000) ".

REAR LH: Component Function Check

1. CHECK REAR POWER WINDOW MOTOR LH CIRCUIT Does rear power window motor LH operate with main power window and door lock/unlock switch or rear power window switch LH? Is the inspection result normal? YES: Rear power window motor LH is OK. NO: Refer to " «REAR LH: DIAGNOSIS PROCEDURE»(ref-272640-S30201427712007112300000) "

REAR RH: Component Function Check

1. CHECK POWER WINDOW MOTOR CIRCUIT Does rear power window motor RH operate with operating power window main switch or rear power window switch RH? Is the inspection result normal? YES: Power window motor is OK. NO: Refer to " «REAR RH: DIAGNOSIS PROCEDURE»(ref-272640-S04396700492007112300000) ".

1. CHECK ENCODER OPERATION Does front door glass LH perform AUTO open/close operation normally with main power window and door lock/unlock switch? Is the inspection result normal? YES: Encoder operation is OK. NO: Refer to " «DRIVER SIDE: DIAGNOSIS PROCEDURE»(ref-272640-S33074756432007112300000) "

1. PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «BASIC INSPECTION: SPECIAL REPAIR REQUIREMENT»(ref-272640-S09801545022007112300000) " Is the inspection result normal? YES: Inspection end. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-272588-S25405727752007112300000) ".

Component Function Check

1. CHECK FRONT DOOR SWITCH INPUT SIGNAL Check ("DOOR SW-DR" and "DOOR SW-AS") in "DATA MONITOR" mode with CONSULT-III. Refer to " «RETAINED PWR: CONSULT-III FUNCTION (BCM-RETAINED PWR)»(ref-272640-S02840572952007112300000) ". MONITOR ITEM CONDITION CHART Monitor item Condition DOOR SW-DR OPEN : ON CLOSE : OFF DOOR SW-AS OPEN : ON CLOSE : OFF Is the inspection result normal? YES: Front door switch circuit is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-272640-S31464774632007112300000) ".

1. CHECK POWER WINDOW LOCK SIGNAL Exchanges for a normal main power window and door lock/unlock switch, and operation is checked. Does power window lock operate? YES: Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-272640-S01756352802007112300000) ". After that, " «BASIC INSPECTION: SPECIAL REPAIR REQUIREMENT»(ref-272640-S09801545022007112300000) " NO: Check condition of harness and connector.

Special Repair Requirement

1. PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «BASIC INSPECTION: SPECIAL REPAIR REQUIREMENT»(ref-272640-S09801545022007112300000) ". Is the inspection result normal? YES: Inspection end. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-272588-S25405727752007112300000) ".

TERMINAL LAYOUT

Refer to " TERMINAL LAYOUT ".

PHYSICAL VALUES

Refer to " PHYSICAL VALUES ".

Identifying Main Power Window And Door Lock/Unlock Switch Connector Terminal Layout. Scheme 7

MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH

VOLTAGE TERMINAL REFERENCE CHART Terminal No. (Wire color) Description Condition Voltage [V] (Approx.) + - Signal name Input/Output 1 (G/B) Ground Rear power window motor LH UP signal Output When rear LH switch in power window main switch is operated UP. Battery voltage 2 (W/B) Ground Encoder ground - - 0 3 (G/O) Ground Rear power window motor LH DOWN signal Output When rear LH switch in power window main switch is operated DOWN. Battery voltage 5 (G/R) Ground Rear power window motor RH DOWN signal Output When rear RH switch in power window main switch is operated DOWN. Battery voltage 6 (GR/R) Ground Door key cylinder switch UNLOCK signal Input Key position (Neutral --> Unlocked) 5 --> 0 7 (G/W) Ground Rear power window motor RH UP signal Output When rear RH switch in power window main switch is operated UP. Battery voltage 8 (R/B) 11 Front power window motor RH UP signal Output When front RH switch in power window main switch is operated UP. Battery voltage 9 (G/W) 2 Encoder pulse signal 2 Input When power window motor operates. 10 (L/W) Ground RAP signal Input IGN SW ON Battery voltage Within 45 second after ignition switch is turned to OFF. Battery voltage When driver side or passenger side door is opened during retained power operation. 0 11 (R/W) 8 Front power window motor RH DOWN signal Output When front RH switch in power window main switch is operated DOWN. Battery voltage 12 (L/B) 16 Front power window motor LH DOWN signal Output When front LH switch in power window main switch is operated DOWN. Battery voltage 13 (G/Y) 2 Encoder pulse signal 1 Input When power window motor operates. 15 (G/R) Ground Encoder power supply Output When ignition switch ON or power window timer operates. 10 16 (L/R) 12 Front power window motor LH UP signal Output When front LH switch in power window main switch is operated UP. Battery voltage 17 (B) Ground Ground - - 0 19 (R/Y) Battery power supply Input - Battery voltage

Scheme 8

Power Window System/With Left Only Power Window Anti-Pinch System Connectors (2 Of 7). Scheme 9

Power Window System/With Left Only Power Window Anti-Pinch System Connectors (3 Of 7). Scheme 10

Power Window System/With Left Only Power Window Anti-Pinch System Connectors (4 Of 7). Scheme 11

Power Window System/With Left Only Power Window Anti-Pinch System Connectors (5 Of 7). Scheme 12

Power Window System/With Left Only Power Window Anti-Pinch System Connectors (6 Of 7). Scheme 13

Power Window System/With Left Only Power Window Anti-Pinch System Connectors (7 Of 7). Scheme 14

FAIL-SAFE CONTROL

Switches to fail-safe control when malfunction is detected in encoder signal that detects up/down speed and direction of door glass. Switches to fail-safe control when error beyond regulation value is detected between the fully closed position and the actual position of the glass.

FAIL SAFE CHART

It changes to condition before initialization and the following functions do not operate when switched to fail-safe control.

1. Auto-up operation
2. Anti-pinch function
3. Retained power function

Perform initial operation to recover when switched to fail-safe mode. However, it switches back to fail-safe control when malfunction is found in power window switch or in motor.

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.

Information necessary to service the system safely is included in SRS AIRBAG and SEAT BELTS of this article.

1. INTERVIEW FOR MALFUNCTION Interview the symptom to the customer. : GO TO 2.
2. SYMPTOM CHECK Check the symptom from the customer's information. : GO TO 3.
3. BASIC INSPECTION Check the operation of each part. Check that any symptom occurs other than the interviewed symptom. : GO TO 4.
4. SELF-DIAGNOSIS WITH CONSULT-III Perform the self-diagnosis with CONSULT-III. Check that any DTC is detected. Is any DTC detected? YES: GO TO 5. NO: GO TO 6 .
5. TROUBLE DIAGNOSIS BY DTC Perform the trouble diagnosis for the detected DTC. Specify the malfunctioning part. : GO TO 9 .
6. FAIL-SAFE ACTIVATION CHECK Check that the symptom is applied to the fail-safe activation. Does the fail-safe activate? YES: GO TO 7. NO: GO TO 8 .
7. SYSTEM DIAGNOSIS Perform the system diagnosis for the system that the fail-safe activates. Specify the malfunctioning part. : GO TO 9 .
8. SYMPTOM DIAGNOSIS Perform the symptom diagnosis. Specify the malfunctioning part. : GO TO 9.
9. MALFUNCTION PART REPAIR Repair or replace the malfunctioning part. : GO TO 10.
10. REPAIR CHECK (SELF-DIAGNOSIS WITH CONSULT-III) Perform the self-diagnosis with CONSULT-III. Check that any DTC is not detected. Erase DTC if DTC is detected before the repair. Check that DTC is not detected again. Is any DTC detected? YES: GO TO 5 . NO: GO TO 11.
11. REPAIR CHECK (OPERATION CHECK) Check the operation of each part. Does it operate normally? YES: Inspection End. NO: GO TO 3 .

INITIALIZATION PROCEDURE

1. Disconnect battery minus terminal or power window main switch connector. Reconnect it after a minute or more.
2. Turn ignition switch ON.
3. Operate power window switch to fully open the window. (This operation is unnecessary if the window is already fully open)
4. Continue pulling the power window switch UP (AUTO-UP operation). Even after glass stops at fully closed position, keep pulling the switch for 3 seconds or more.
5. Inspect anti-pinch function.

CHECK ANTI-PINCH FUNCTION

1. Fully open the door window.
2. Place a piece of wood near fully closed position.
3. Close door glass completely with AUTO-UP.

1. Check that glass lowers for approximately 150 mm or 2 seconds without pinching piece of wood and stops.
2. Check that glass does not rise when operating the power window main switch while lowering.

1. Disconnect battery minus terminal or power window main switch connector. Reconnect it after a minute or more.
2. Turn ignition switch ON.
3. Operate power window switch to fully open the window. (This operation is unnecessary if the window is already fully open)
4. Continue pulling the power window switch UP (AUTO-UP operation). Even after glass stops at fully closed position, keep pulling the switch for 3 seconds or more.
5. Inspect anti-pinch function.

1. Fully open the door window.
2. Place a piece of wood near fully closed position.
3. Close door glass completely with AUTO-UP.

1. Check that glass lowers for approximately 150 mm or 2 seconds without pinching piece of wood and stops.
2. Check that glass does not rise when operating the power window main switch while lowering.

Front Window Anti-Pinch - System Diagram. Scheme 15

POWER WINDOW MAIN SWITCH

INPUT/OUTPUT SIGNAL CHART

POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH

INPUT/OUTPUT SIGNAL CHART

Ground circuit inside power window main switch shuts off when power window lock switch is ON. This inhibits power window switch operation except with the power window switch.

FRONT WINDOW ANTI-PINCH SYSTEM

COMPONENT FUNCTION CHART

DATA MONITOR

Main Power Window And Door Lock/unlock Switch

1. CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH FUNCTION Does power window motor operate with main power window and door lock/unlock switch operation? Is the inspection result normal? YES: Main power window and door lock/unlock switch power supply and ground circuit are OK. NO: Refer to " «POWER WINDOW MAIN SWITCH: DIAGNOSIS PROCEDURE»(ref-272640-S12369079842007112300000) ".

1. PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: SPECIAL REPAIR REQUIREMENT»(ref-272640-S12274346592007112300000) " Is the inspection result normal? YES: GO TO 2. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-272588-S25405727752007112300000) ".
2. CHECK ANTI-PINCH OPERATION Check anti-pinch operation. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: SPECIAL REPAIR REQUIREMENT»(ref-272640-S12274346592007112300000) " Is the inspection result normal? YES: Inspection end. NO: Refer to " «DRIVER SIDE: COMPONENT FUNCTION CHECK»(ref-272640-S25309102422007112300000) "

Power Window And Door Lock/unlock Switch RH

1. CHECK FRONT POWER WINDOW MOTOR RH FUNCTION Does front power window motor RH operate with power window and door lock/unlock switch RH operation? Is the inspection result normal? YES: Power window and door lock/unlock switch RH power supply and ground circuit are OK. NO: Refer to " «FRONT POWER WINDOW SWITCH: DIAGNOSIS PROCEDURE»(ref-272640-S09797290532007112300000) ".

FRONT POWER WINDOW SWITCH: Special Repair Requirement

1. PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: SPECIAL REPAIR REQUIREMENT»(ref-272640-S12274346592007112300000) ". Is the inspection result normal? YES: GO TO 2. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-272588-S25405727752007112300000) ".
2. CHECK ANTI-PINCH OPERATION Check anti-pinch operation. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: SPECIAL REPAIR REQUIREMENT»(ref-272640-S12274346592007112300000) ". Is the inspection result normal? YES: Inspection end. NO: Refer to " «PASSENGER SIDE: COMPONENT FUNCTION CHECK»(ref-272640-S41699072372007112300000) ".

Rear Power Window Switch

1. CHECK REAR POWER WINDOW MOTOR FUNCTION Does rear power window motor operate with rear power window switch operation? Is the inspection result normal? YES: Rear power window switch power supply and ground circuit are OK. NO: Refer to " «REAR POWER WINDOW SWITCH: DIAGNOSIS PROCEDURE»(ref-272640-S29599702962007112300000) ".

1. CHECK POWER WINDOW MOTOR CIRCUIT Does front power window motor LH operate with operating main power window and door lock/unlock switch? Is the inspection result normal? YES: Front power window motor LH is OK. NO: Refer to " «DRIVER SIDE: DIAGNOSIS PROCEDURE»(ref-272640-S00728621342007112300000) ".

1. PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: SPECIAL REPAIR REQUIREMENT»(ref-272640-S12274346592007112300000) ". Is the inspection result normal? YES: GO TO 2. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-272588-S25405727752007112300000) ".
2. CHECK ANTI-PINCH OPERATION Check anti-pinch operation. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: SPECIAL REPAIR REQUIREMENT»(ref-272640-S12274346592007112300000) ". Is the inspection result normal? YES: Inspection end. NO: Refer to " «DRIVER SIDE: COMPONENT FUNCTION CHECK»(ref-272640-S25309102422007112300000) ".

1. CHECK POWER WINDOW MOTOR CIRCUIT Does power window motor operate with operating main power window and door lock/unlock switch or power window and door lock/unlock switch RH? Is the inspection result normal? YES: Front power window motor RH is OK. NO: Refer to " «PASSENGER SIDE: DIAGNOSIS PROCEDURE»(ref-272640-S41492122652007112300000) ".

PASSENGER SIDE: Special Repair Requirement

1. PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: SPECIAL REPAIR REQUIREMENT»(ref-272640-S12274346592007112300000) ". Is the inspection result normal? YES: GO TO 2. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-272588-S25405727752007112300000) ".
2. CHECK ANTI-PINCH OPERATION Check anti-pinch operation. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: SPECIAL REPAIR REQUIREMENT»(ref-272640-S12274346592007112300000) ". Is the inspection result normal? YES: Inspection end. NO: Refer to " «PASSENGER SIDE: COMPONENT FUNCTION CHECK»(ref-272640-S41699072372007112300000) ".

1. CHECK REAR POWER WINDOW MOTOR LH CIRCUIT Does rear power window motor LH operate with main power window and door lock/unlock switch or rear power window switch LH? Is the inspection result normal? YES: Rear power window motor LH is OK. NO: Refer to " «REAR LH: DIAGNOSIS PROCEDURE»(ref-272640-S30201427712007112300000) "

1. CHECK REAR POWER WINDOW MOTOR RH CIRCUIT Does rear power window motor RH operate with operating main power window and door lock/unlock switch or rear power window switch RH? Is the inspection result normal? YES: Rear power window motor RH is OK. NO: Refer to " «REAR RH: DIAGNOSIS PROCEDURE»(ref-272640-S04396700492007112300000) ".

1. CHECK ENCODER OPERATION Does front door glass LH perform AUTO open/close operation normally when operating main power window and door lock/unlock switch? Is the inspection result normal? YES: Encoder operation is OK. NO: Refer to " «DRIVER SIDE: DIAGNOSIS PROCEDURE»(ref-272640-S33074756432007112300000) "

1. CHECK ENCODER OPERATION Does front door glass RH perform AUTO open/close operation normally when operating power window and door lock/unlock switch RH? Is the inspection result normal? YES: Encoder operation is OK. NO: Refer to " «PASSENGER SIDE: DIAGNOSIS PROCEDURE»(ref-272640-S04746524662007112300000) ".

1. CHECK FRONT DOOR SWITCH INPUT SIGNAL Check ("DOOR SW-DR" and "DOOR SW-AS") in "DATA MONITOR" mode with CONSULT-III. Refer to " «RETAINED PWR: CONSULT-III FUNCTION (BCM-RETAINED PWR)»(ref-272640-S02840572952007112300000) ". MONITOR ITEM CONDITION CHART Monitor item Condition DOOR SW-DR OPEN : ON CLOSE : OFF DOOR SW-AS OPEN : ON CLOSE : OFF Is the inspection result normal? YES: Front door switch circuit is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-272640-S31464774632007112300000) ".

1. CHECK DOOR KEY CYLINDER SWITCH INPUT SIGNAL Check ("KEY CYL LK-SW", "KEY CYL UN-SW") in "DATA MONITOR" mode for "POWER DOOR LOCK SYSTEM" with CONSULT-III. Refer to " «COMMON ITEM: CONSULT-III FUNCTION»(ref-272618-S17616528692007112300000) ". MONITOR ITEM CONDITION CHART Monitor item Condition KEY CYL LK-SW Lock : ON Neutral / Unlock : OFF KEY CYL UN-SW Unlock : ON Neutral / Lock : OFF Is the inspection result normal? YES: Key cylinder switch is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-272640-S25320992572007112300000) ".

1. PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: SPECIAL REPAIR REQUIREMENT»(ref-272640-S04448137012007112300000) " Is the inspection result normal? YES: Inspection end. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-272588-S25405727752007112300000) ".

1. CHECK POWER WINDOW SWITCH OUTPUT SIGNAL Check ("CDL LOCK SW ", "CDL UNLOCK SW") in "DATA MONITOR" mode for "POWER DOOR LOCK SYSTEM" with CONSULT-III. Refer to " «COMMON ITEM: CONSULT-III FUNCTION»(ref-272618-S17616528692007112300000) ". MONITOR ITEM CONDITION CHART Monitor item Condition CDL LOCK SW LOCK : ON UNLOCK : OFF CDL UNLOCK SW LOCK : OFF UNLOCK : ON Is the inspection result normal? YES: Power window serial link is OK. NO: Refer to " «POWER WINDOW MAIN SWITCH: DIAGNOSIS PROCEDURE»(ref-272640-S37424037782007112300000) ".

1. CHECK POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH OUTPUT SIGNAL Check ("CDL LOCK SW ", "CDL UNLOCK SW") in "DATA MONITOR" mode for "POWER DOOR LOCK SYSTEM" with CONSULT-III. Refer to " «COMMON ITEM: CONSULT-III FUNCTION»(ref-272618-S17616528692007112300000) ". MONITOR ITEM CONDITION CHART Monitor item Condition CDL LOCK SW LOCK : ON UNLOCK : OFF CDL UNLOCK SW LOCK : OFF UNLOCK : ON Is the inspection result normal? YES: Power window serial link is OK. NO: Refer to " «FRONT POWER WINDOW SWITCH: DIAGNOSIS PROCEDURE»(ref-272640-S09123845952007112300000) ".

1. CHECK POWER WINDOW LOCK SIGNAL Exchanges for a normal main power window and door lock/unlock switch, and operation is checked. Does power window lock operate? YES: Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-272640-S01756352802007112300000) ". After that, " «SPECIAL REPAIR REQUIREMENT»(ref-272640-S27984706762007112300000) " NO: Check condition of harness and connector.

1. PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: SPECIAL REPAIR REQUIREMENT»(ref-272640-S12274346592007112300000) ". Is the inspection result normal? YES: Inspection end. NO: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-272588-S25405727752007112300000) ".

CONSULT-III MONITOR ITEM

MONITOR ITEM CONDITION CHART

Refer to " TERMINAL LAYOUT ".

Refer to " PHYSICAL VALUES ".

TERMINAL DESCRIPTION CHART Terminal No. Description Condition Voltage [V] (Approx.) + - Signal name Input/Output 1 (G/B) Ground Rear power window motor LH UP signal Output When rear LH switch in power window main switch is operated UP. Battery voltage 2 (W/B) Ground Encoder ground - - 0 3 (G/O) Ground Rear power window motor LH DOWN signal Output When rear LH switch in power window main switch is operated DOWN. Battery voltage 4 (L/B) Ground Door key cylinder switch LH LOCK signal Input Key position (Neutral --> Locked) 5 --> 0 5 (G/R) Ground Rear power window motor RH DOWN signal Output When rear RH switch in power window main switch is operated DOWN. Battery voltage 6 (L/R) Ground Door key cylinder switch LH UNLOCK signal Input Key position (Neutral --> Unlocked) 5 --> 0 7 (G/W) Ground Rear power window motor RH UP signal Output When rear RH switch in power window main switch is operated UP. Battery voltage 8 (L/R) 11 Front door power window motor LH UP signal Output When front LH switch in power window main switch is operated UP. Battery voltage 9 (G/W) 2 Encoder pulse signal 2 Input When power window motor operates. 10 (L/W) Ground RAP signal Input IGN SW ON Battery voltage Within 45 second after ignition switch is turned to OFF. Battery voltage When front LH or RH door is opened during retained power operation. 0 11 (L/B) 8 Front door power window motor LH DOWN signal Output When front LH switch in power window main switch is operated DOWN. Battery voltage 13 (G/Y) 2 Encoder pulse signal 1 Input When power window motor operates. 14 (Y/G) Ground Power window serial link Input/Output IGN SW ON or power window timer operating. 15 (G/R) Ground Encoder power supply Output When ignition switch ON or power window timer operates. 10 17 (B) Ground Ground - - 0 19 (R/Y) Battery power supply Input - Battery voltage

Scheme 16

Wiring Diagram - Power Window System/With Left And Right Front Window Anti-Punch System. Scheme 17

Power Window System/With Left And Right Front Window Anti-Punch System Connectors (4 Of 6). Scheme 18

Power Window System/With Left And Right Front Window Anti-Punch System Connectors (5 Of 6). Scheme 19

Power Window System/With Left And Right Front Window Anti-Punch System Connectors (3 Of 6). Scheme 20

Power Window System/With Left And Right Front Window Anti-Punch System Connectors (6 Of 6). Scheme 21

Switches to fail-safe control when malfunction is detected in encoder signal that detects up/down speed and direction of door glass. Switches to fail-safe control when error beyond regulation value is detected between the fully closed position and the actual position of the glass.

FAIL SAFE CHART

It changes to condition before initialization and the following functions do not operate when switched to fail-safe control.

1. Auto-up operation
2. Anti-pinch function
3. Retained power function

Perform initial operation to recover when switched to fail-safe mode. However, it switches back to fail-safe control when malfunction is found in power window switch or in motor.

Identifying Front Power Window Switch Connector Terminal Layout. Scheme 22

POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH

TERMINAL DESCRIPTION CHART Terminal No. Description Condition Voltage [V] (Approx.) + - Signal name Input/Output 3 (W/B) Ground Encoder ground - - 0 4 (G/R) Ground Encoder power supply Output When ignition switch ON or power window timer operates 10 8 (L/R) 9 Power window motor UP signal Output When power window motor is UP at operated. Battery voltage 9 (L/B) 8 Power window motor DOWN signal Output When power window motor is DOWN at operated. Battery voltage 10 (R/Y) Ground Battery power supply Input - Battery voltage 11 (B) Ground Ground - - 0 12 (G/Y) 3 Encoder pulse signal 1 Input When power window motor operates. 15 (G/W) 3 Encoder pulse signal 2 Input When power window motor operates. 16 (Y/G) Ground Power window serial link Input/Output IGN SW ON or power window timer operating

Switches to fail-safe control when malfunction is detected in encoder signal that detects up/down speed and direction of door glass. Switches to fail-safe control when error beyond regulation value is detected between the fully closed position and the actual position of the glass.

FAIL SAFE CHART

It changes to condition before initialization and the following functions do not operate when switched to fail-safe control.

1. Auto-up operation
2. Anti-pinch function
3. Retained power function

Perform initial operation to recover when switched to fail-safe mode. However, it switches back to fail-safe control when malfunction is found in power window switch or in motor.
