ECM Re-communicating Function

The following procedure can automatically perform re-communication of ECM and BCM, but only when the ECM has been replaced with a new one (*1).

*1: New one means a virgin ECM which has never been energized on-board.

(In this step, initialization procedure by CONSULT-II is not necessary.)

Note. When registering new Key IDs or replacing the ECM other than brand new, refer to CONSULT-II Operation Manual NATS-IVIS/NVIS. If multiple keys are attached to the key holder, separate them before work. Distinguish keys with unregistered key ID from those with registered ID.

  1. Install ECM.
  2. Using a registered key (*2), turn ignition switch to ON. *2: To perform this step, use the key that has been used before performing ECM replacement.
  3. Maintain ignition switch in ON position for at least 5 seconds.
  4. Turn ignition switch to OFF.
  5. Start engine. If engine can be started, procedure is completed. If engine cannot be started, refer to CONSULT-II Operation Manual NATS-IVIS/NVIS and initialize control unit.

Scheme 270

Scheme 270: Wiring Diagram - NATS
TerminalWire ColorItemConditionVoltage (V) (Approx.)
21PNATS antenna amp.Ignition switch (OFF --> ON)Just after turning ignition switch ON: Pointer of tester should move.
23G/ORSecurity indicator lampGoes OFF --> illuminates (Every 2.4 seconds)Battery voltage --> 0
25Y/BNATS antenna amp.Ignition switch (OFF --> ON)Just after turning ignition switch ON: Pointer of tester should move.
38RIgnition switch (ON or START)Ignition switch (ON or START position)Battery voltage
39LCAN-H
40PCAN-L
57WBattery power supplyBattery voltage
67BGround0
70W/BBattery power supplyBattery voltage

TERMINALS AND REFERENCE VALUE FOR BCM
