Coil Nissan Altima L31 facelift

Coil

Check the magnet coil for a loose connection or cracked insulation.

Scheme 212

Scheme 213

Scheme 214

Scheme 215

1. Install the magnet coil. CAUTION: Be sure to align the magnet coil pin with the hole in the compressor front head.
2. Install the magnet coil harness clip using a screwdriver.
3. Install the pulley assembly using Tool and a wrench, and then install the snap ring using snap ring pliers. Tool number : - (J-38873-A)
4. Install the clutch disc on the drive shaft, together with the original shim(s). Press the clutch disc down using the drive plate installer.
5. Install the center bolt using Tool. Tool number : (J-44614) Center bolt : 12 N.m (1.2 kg-m, 9 ft-lb) After tightening the center bolt to specification, check that the pulley rotates smoothly.
