Engine Mechanical - 3.5L: Specifications Nissan Altima L31

PARTS REQUIRING ANGULAR TIGHTENING

1. Use an angle wrench for the final tightening of the following engine parts: Cylinder head bolts Main bearing cap bolts Connecting rod cap nuts Crankshaft pulley bolt (No angle wrench is required as the bolt flange is provided with notches for angular tightening)
2. Do not use a torque value for final tightening.
3. The torque value for these parts are for a preliminary step.
4. Ensure thread and seat surfaces are clean and coated with engine oil.

Scheme 241

1. After removing the mounting bolts and nuts, disconnect the component using a seal cutter. CAUTION: Be careful not to damage the mating surfaces.
2. In areas where the cutter is difficult to use, use a plastic hammer to lightly tap the areas where the sealant is applied to disconnect the component. CAUTION: If a tool such as a flat-bladed screwdriver is used, be careful not to damage the mating surfaces.

Scheme 242

1. Using a scraper, remove the old sealant adhering to the gasket application surface and the mating surface. Remove the sealant completely from the groove of the gasket application surface, mounting bolts, and bolt holes.
2. Completely clean the gasket application surface and the mating surface to remove all of the adhering moisture, grease, and foreign materials.
3. Attach the sealant tube to the tube presser. Use Genuine RTV Silicone Sealant, or equivalent. Refer to «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-177331-S04337218152005052600000) .
4. Apply the sealant without breaks to the specified location with the specified dimensions. If there is a groove for the sealant application, apply the sealant to the groove. As for the bolt holes, normally apply the sealant inside the holes. If specified, it should be applied outside the holes. Make sure to read the text in this manual. Within five minutes of sealant application, install the mating component. If the sealant protrudes, wipe it off immediately. Do not retighten after the installation. Wait 30 minutes or more after installation before filling the engine with oil and coolant. CAUTION: Follow all specific instructions in this article .

General Specifications

General Specifications Cylinder arrangement V-6 Displacement cm 3 (cu in) 3,498 (213.45) Bore and stroke mm (in) 95.5 x 81.4 (3.76 x 3.205) Valve arrangement DOHC Firing order 1-2-3-4-5-6 Number of piston rings Compression 2 Oil 1 Number of main bearings 4 Compression ratio 10.0 Compression pressure kPa (kg/cm 2 , psi)/300 rpm Standard 1,275 (13.0, 185) Minimum 981 (10.0, 142) Differential limit between cylinders 98 (1.0, 14) Cylinder number Valve timing (IVTC - OFF) Unit: degree a b c d e f 240 238 -6 64 8 52

Scheme 243

Scheme 244

Scheme 245

Scheme 246

Scheme 247

Scheme 248

Scheme 249

Scheme 250

Scheme 251

Scheme 252

Scheme 253

Scheme 254

Scheme 255

Scheme 256

Scheme 257

Scheme 258

Scheme 259

Scheme 260

Scheme 261

Scheme 262

Scheme 263

Scheme 264

Scheme 265

Scheme 266

Scheme 267

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

Scheme 268

Scheme 269

Scheme 270

Scheme 271

Scheme 272

Scheme 273

Scheme 274

Scheme 275

Scheme 276

Scheme 277

Scheme 278

Scheme 279

Scheme 280

Scheme 281
