Starting System: Removal & Installation Nissan 370Z I

INSTALLATION

Install in the reverse order of removal.

Scheme 10

Scheme 11

1. Disconnect the battery cable from the negative terminal.
2. Remove engine undercover using power tools.
3. Remove "B" terminal nut (1).
4. Disconnect "S" connector (A).
5. Remove starter motor mounting bolts (B) and harness bracket, using power tools.
6. Remove the bolt (A) and remove the harness bracket (1).
7. Remove A/T fluid cooler tube clip bolts and bracket. Refer to " «EXPLODED VIEW»(ref-402639-S41962262122011053100000) ".
8. Move A/T fluid cooler tube (1) downward.
9. Remove starter motor (2) forward from the vehicle.

Scheme 12

Install in the reverse order of removal.
