Starting System: Overview Nissan 370Z I

Starter 4 illustrations ~274 words

Scheme 1

Scheme 1: OVERALL SEQUENCE

M/T: System Description

  1. When the clutch interlock switch is turned ON, power is supplied to starter relay and starter control relay. And BCM and IPDM E/R (CPU) detect clutch interlock switch condition by the inputted signal.
  2. When starter operating condition is satisfied, IPDM E/R turns starter control relay ON by starter control relay control signal.
  3. When engine cranking condition is satisfied, BCM turns starter relay ON by starter relay control signal.
  4. Then battery power is supplied to starter motor ("S" terminal) through starter control relay and starter relay. And IPDM E/R (CPU) detect starter relay condition by the inputted signal.

Scheme 2

Scheme 2: M/T: Component Parts Location

M/T: Component Description

Component partDescription
Clutch interlock switchThe switch turns ON and electric power is supplied to the starter relay and starter control relay inside IPDM E/R when the clutch pedal is depressed.
BCMBCM controls the starter relay inside IPDM E/R.
IPDM E/RCPU inside IPDM E/R controls the starter control relay.
Starter motorThe starter motor plunger closes and the motor is supplied with battery power, which in turn cranks the engine, when the "S" terminal is supplied with electric power.

COMPONENT DESCRIPTION

Scheme 3

Scheme 3: A/T: System Diagram

A/T: System Description

  1. When selector lever is P or N, power is supplied to starter relay and starter control relay by TCM. And BCM and IPDM E/R (CPU) detect selector lever P/N condition by the inputted signal.
  2. When starter operating condition is satisfied, IPDM E/R turns starter control relay ON by starter control relay control signal.
  3. When engine cranking condition is satisfied, BCM turns starter relay ON by starter relay control signal.
  4. Then battery power is supplied to starter motor ("S" terminal) through starter control relay and starter relay. And IPDM E/R (CPU) detect starter relay condition by the inputted signal.

Scheme 4

Scheme 4: A/T: Component Parts Location

A/T: Component Description

Component partDescription
TCMTCM supplies power to the starter relay and starter control relay inside IPDM E/R when the selector lever is shifted to the P or N position.
BCMBCM controls the starter relay inside IPDM E/R.
IPDM E/RCPU inside IPDM E/R controls the starter control relay.
Starter motorThe starter motor plunger closes and the motor is supplied with battery power, which in turn cranks the engine, when the "S" terminal is supplied with electric power.

COMPONENT DESCRIPTION

Description

The "B" terminal is constantly supplied with battery power.

The starter motor magnetic switch is supplied with power when the ignition switch is turned to the START position while the selector lever is in the P or N position for A/T models or the clutch pedal is depressed for M/T models.
