Precautions for Battery Service

Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any interference between the window edge and the vehicle when the door is opened/closed. During normal operation, the window slightly raises and lowers automatically to prevent any window to vehicle interference. The automatic window function will not work with the battery disconnected.

Special Service Tools

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

SPECIAL SERVICE TOOLS DESCRIPTION Tool number (Kent-Moore No.) Tool name Description KV10115801 (J38956) Oil filter wrench Removing and installing oil filter a: 64.3 mm (2.531 in)

Commercial Service Tools

COMMERCIAL SERVICE TOOLS DESCRIPTION (Kent-Moore No.) Tool name Description Power tool Loosening bolts and nuts Spark plug wrench Removing and installing spark plug

Scheme 12

General maintenance includes those items which should be checked during the normal day-to-day operation of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform checks and inspections themselves or have their NISSAN dealers do them.

OUTSIDE THE VEHICLE

The maintenance items listed here should be performed from time to time, unless otherwise specified.

EXPLANATION OF GENERAL MAINTENANCE - OUTSIDE VEHICLE

INSIDE THE VEHICLE

The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle, etc.

EXPLANATION OF GENERAL MAINTENANCE - INSIDE VEHICLE

UNDER THE HOOD AND VEHICLE

The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).

EXPLANATION OF GENERAL MAINTENANCE - UNDER HOOD AND VEHICLE

Two different maintenance schedules are provided, and should be used, depending upon the conditions in which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic maintenance at the same mileage/time intervals .

INTRODUCTION OF PERIODIC MAINTENANCE

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. [ ]: At the mileage intervals only

EMISSION CONTROL SYSTEM MAINTENANCE

EMISSION CONTROL SYSTEM MAINTENANCE

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary.

CHASSIS AND BODY MAINTENANCE

CHASSIS AND BODY MAINTENANCE

EMISSION CONTROL SYSTEM MAINTENANCE

CHASSIS AND BODY MAINTENANCE

Engine Oil Recommendation

NISSAN recommends the use of an energy conserving oil in order to improve fuel economy.

Select only engine oils that meet the American Petroleum Institute (API) certification and International Lubricant Standardization and Approval Committee (ILSAC) certification and SAE viscosity standard. These oils have the API certification mark on the front of the container. Oils which do not have the specified quality label should not be used as they could cause engine damage.

Anti-Freeze Coolant Mixture Ratio Chart. Scheme 13

ANTI-FREEZE COOLANT MIXTURE RATIO

The engine cooling system is filled at the factory with a high-quality, year-round, anti-freeze coolant solution. The anti-freeze solution contains rust and corrosion inhibitors. Therefore, additional cooling system additives are not necessary.

Checking Drive Belts. Scheme 14

1. Make sure that the indicator (C) (notch on fixed side) of drive belt auto-tensioner is within the possible use range (A). NOTE: Check the drive belt auto-tensioner indication when the engine is cold.
2. When new drive belt is installed, the indicator (C) (notch on fixed side) should be within the range (B) in the figure.
3. Visually check entire drive belt for wear, damage or cracks.
4. If the indicator (C) (notch on fixed side) is out of the possible use range or belts is damaged, replace drive belt.

Changing Engine Coolant

Scheme 15

1. Remove undercover with power tool.
2. Open radiator drain plug at the bottom of radiator, and then remove radiator cap. see scheme 4: Identifying Radiator Drain Plug When drain all of engine coolant in the system, open water drain plugs on engine cylinder block. Refer to " «DISASSEMBLY»(ref-271540-S30975576112007111400000) ".
3. Remove reservoir tank as necessary, and drain engine coolant and clean reservoir tank before installing.
4. Check drained engine coolant for contaminants such as rust, corrosion or discoloration. If contaminated, flush the engine cooling system. Refer to " «FLUSHING COOLING SYSTEM»(ref-271552-S16142340082007111400000) ".

Scheme 16

Scheme 17

Scheme 18

1. Install reservoir tank, and radiator drain plug. CAUTION: Be sure to clean drain plug and install with new O-ring. Radiator drain plug:: 1.2 N.m (0.12 kg-m, 11 in-lb) If water drain plugs on cylinder block are removed, close and tighten them. Refer to " «ASSEMBLY»(ref-271540-S36659995252007111400000) ".
2. Make sure that each hose clamp has been firmly tightened.
3. Remove air relief plug (1) on heater hose (2). (Scheme 15): Identifying Air Relief Plug On Heater Hose
4. Fill radiator and reservoir tank to specified level. Pour engine coolant through engine coolant filler neck slowly of less than 2 l (2-1/8 US qt, 1-3/4 lmp qt) a minute to allow air in system to escape. Use Genuine NISSAN Long Life Antifreeze/Coolant or equivalent mixed with water (distilled or demineralized). Refer to " «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-271552-S31952220342007111400000) ". (Scheme 16): Identifying Engine Coolant In Reservoir Tank Engine coolant capacity (with reservoir tank at "MAX" level): Approx. 9.0 l (9-1/2 US qt, 7-7/8 lmp qt) Reservoir tank capacity (at "MAX" level): 0.8 l (7/8 US qt, 3/4 lmp qt) When engine coolant overflows air relief hole on heater hose, install air relief plug with new O-ring. Air relief plug:: 1.2 N.m (0.12 kg-m, 11 in-lb) (Scheme 17): Identifying Engine Coolant Level
5. Install radiator cap.
6. Warm up until opening thermostat. Standard for warming-up time is approximately 10 minutes at 3,000 RPM. Make sure thermostat condition by touching radiator hose (lower) to see flow of warm water. CAUTION: Watch water temperature gauge so as not to overheat engine.
7. Stop engine and cool down to less than approximately 50°C (122°F). Cool down using fan to reduce the time. If necessary, refill radiator up to filler neck with engine coolant.
8. Refill reservoir tank to "MAX" level line with engine coolant.
9. Repeat steps 4 through 7 two or more times with radiator cap installed until engine coolant level no longer drops.
10. Check cooling system for leaks with engine running.
11. Warm up engine, and check for sound of engine coolant flow while running engine from idle up to 3,000 RPM with heater temperature controller set at several position between "COOL" and "WARM". Sound may be noticeable at heater unit.
12. Repeat step 11 three times.
13. If sound is heard, bleed air from cooling system by repeating step 4 through 7 until engine coolant level no longer drops. Clean excess engine coolant from engine.

Scheme 19

1. Install reservoir tank, and radiator drain plug. CAUTION: Be sure to clean drain plug and install with new O-ring. Radiator drain plug:: 1.2 N.m (0.12 kg-m, 11 in-lb) If water drain plugs on cylinder block are removed, close and tighten them. Refer to " «ASSEMBLY»(ref-271540-S36659995252007111400000) ".
2. Remove air relief plug (1) on heater hose (2). (Scheme 18): Identifying Air Relief Plug On Heater Hose
3. Fill radiator with water until water spills from the air relief hole, then close air relief plug. Fill radiator and reservoir tank with water and reinstall radiator cap. Air relief plug:: 1.2 N.m (0.12 kg-m, 11 in-lb)
4. Run engine and warm it up to normal operating temperature.
5. Rev engine two or three times under no-load.
6. Stop engine and wait until it cools down.
7. Drain water from the system. Refer to " «DRAINING ENGINE COOLANT»(ref-271552-S02576094302007111400000) ".
8. Repeat steps 1 through 7 until clear water begins to drain from radiator.

Checking Fuel Lines

Inspect fuel lines, fuel filler cap and fuel tank for improper attachment, leaks, cracks, damage, loose connections, chafing or deterioration.

If necessary, repair or replace damaged parts.

Identifying Air Cleaner Filter. Scheme 20

VISCOUS PAPER TYPE

The viscous paper type filter does not need cleaning between replacement intervals. Refer to " PERIODIC MAINTENANCE ".

Changing Engine Oil

Scheme 21

1. Warm up engine, put vehicle horizontally and check for oil leakage from engine components. Refer to " «ENGINE OIL LEAKAGE»(ref-271548-S37274770002007111400000) ".
2. Stop engine and wait for 10 minutes.
3. Loosen oil filler cap and then remove drain plug.
4. Drain engine oil.
5. Install drain plug with new washer. Refer to " «OIL PAN AND OIL STRAINER»(ref-271540-S04360635532007111400000) ". CAUTION: Be sure to clean drain plug and install with new washer. Oil pan drain plug:: 34.3 N.m (3.5 kg-m, 25 ft-lb)
6. Refill with new engine oil. Engine oil specification and viscosity: Refer to " «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-271552-S31952220342007111400000) ". Engine oil capacity (Approximate): ENGINE OIL CAPACITY SPECIFICATION Unit: (US qt, lmp qt) Drain and refill With oil filter change 4.9 (5-1/8, 4-1/4) Without oil filter change 4.6 (4-7/8, 4) Dry engine (Overhaul) 5.5 (5-3/4, 4-7/8) CAUTION: When filling engine oil, do not pull out oil level gauge. The refill capacity depends on the engine oil temperature and drain time. Use these specifications for reference only. Always use oil level gauge to determine the proper amount of engine oil in the engine.
7. Warm up engine and check area around drain plug and oil filter for oil leakage.
8. Stop engine and wait for 10 minutes.
9. Check the engine oil level. A: Make sure that the oil level is between "L" and "H" see scheme 11: Identifying Oil Level On Oil Level Gauge

Checking EVAP Vapor Lines

1. Visually inspect EVAP vapor lines for improper attachment and for cracks, damage, loose connections, chafing and deterioration.
2. Inspect fuel tank filler cap vacuum relief valve for clogging, sticking, etc. Refer to " «EVAPORATIVE EMISSION SYSTEM»(ref-271545-S39429824742007111400000) ".

Checking Exhaust System

Check exhaust pipes, muffler and mounting for improper attachment, leaks, cracks, damage, chafing or deterioration.

Scheme 22

1. If anything is found, repair or replace damaged parts. see scheme 18: Checking Exhaust Pipes, Muffler And Mounting For Leaks

Checking M/T Oil

Check for oil leakage.

Scheme 23

1. Drain oil from drain plug and refill with new gear oil.
2. Check oil level. Oil grade and viscosity: Refer to " «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-271552-S31952220342007111400000) ". Oil capacity: Approx. 2.9 l (3-1/8 US qt, 2-1/2 lmp qt) Filler plug and drain plug:: 34.5 N.m (3.5 kg-m, 25 ft-lb) CAUTION: Do not reuse gasket. see scheme 20: Checking Fluid Level

Scheme 24

Scheme 25

Scheme 26

Scheme 27

1. Warm up engine.
2. Check for A/T fluid leakage.
3. Loosen the level gauge bolt.
4. Before driving, A/T fluid level can be checked at A/T fluid temperatures of 30 to 50°C (86 to 122°F) using "COLD" range on A/T fluid level gauge as follows. Park vehicle on level surface and set parking brake. Start engine and move selector lever through each gear position. Leave selector lever in "P" position. Check A/T fluid level with engine idling. Remove A/T fluid level gauge and wipe clean with lint-free paper. (Scheme 23): Identifying A/T Fluid Level CAUTION: When wiping away the A/T fluid level gauge, always use lint-free paper, not a cloth one. Re-insert A/T fluid level gauge into A/T fluid charging pipe as far as it will go. CAUTION: To check A/T fluid level, insert the A/T fluid level gauge until the cap contacts the end of the A/T fluid charging pipe, with the A/T fluid level gauge reversed from the normal attachment conditions. Remove A/T fluid level gauge and note reading. If reading is at low side of range, add ATF to the A/T fluid charging pipe. CAUTION: Do not overfill.
5. Drive vehicle for approximately 5 minutes in urban areas.
6. Make the A/T fluid temperature approximately 65°C (149°F). NOTE: A/T fluid level will be greatly affected by temperature as shown in figure. Therefore, be certain to perform operation while checking data with CONSULT-II. (Scheme 24): A/T Fluid Temperature Graph Connect CONSULT-II to data link connector. Select "MAIN SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. Read out the value of "ATF TEMP 1".
7. Re-check A/T fluid level at A/T fluid temperatures of approximately 65°C (149°F) using "HOT" range on A/T fluid level gauge. CAUTION: When wiping away the A/T fluid level gauge, always use lint-free paper, not a cloth one. To check A/T fluid level, insert the A/T fluid level gauge until the cap contacts the end of the A/T fluid charging pipe, with the gauge reversed from the normal attachment conditions as shown.
8. Check A/T fluid condition. If ATF is very dark or smells burned, check operation of A/T. Flush cooling system after repair of A/T. If ATF contains frictional material (clutches, bands, etc.), replace radiator and flush cooler line using cleaning solvent and compressed air after repair of A/T. Refer to " «RADIATOR»(ref-271541-S15617060582007111400000) " and " «A/T FLUID COOLER CLEANING»(ref-271551-S41675137112007111400000) ". (Scheme 25): Identifying A/T Fluid Level Gauge And A/T Fluid Charging Pipe
9. Install the removed A/T fluid level gauge in the A/T fluid charging pipe.
10. Tighten the level gauge bolt. Level gauge bolt:: 5.1 N.m (0.52 kg-m, 45 in-lb) (Scheme 26): Identifying Level Gauge Bolt And A/T Fluid Charging Pipe

Checking Differential Gear Oil

Check for oil leakage.

Scheme 28

Scheme 29

1. Drain oil from drain plug and refill with new gear oil.
2. Check oil level. (Scheme 28): Checking Differential Gear Oil Level Oil grade and Viscosity: Refer to " «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-271552-S31952220342007111400000) ". Capacity: R200, R200V 1.4l (3 US pt, 2 - 1/2 lmp pt) Drain plug:: 34.5 N.m (3.5 kg-m, 25 ft-lb) Filler plug:: 34.5 N.m (3.5 kg-m, 25 ft-lb) CAUTION: Gaskets are not reusable. Never reuse them.

Tire Rotation

Note. Tire cannot be rotated in vehicle, as front tire are different size from rear tire and the direction of wheel rotation is fixed in each tire.

Scheme 30

1. If fluid level is extremely low, check brake system for leaks. see scheme 31: Identifying Brake Fluid Level

Scheme 31

1. Check brake fluid lines and parking brake cables for improper attachment, leaks, chafing, abrasions, deterioration, etc. (Scheme 30): Checking Brake Fluid Lines And Parking Brake Cables For Leaks

Scheme 32

1. Drain brake fluid from each bleed valve.
2. Refill until new brake fluid comes out from each bleed valve. Use same procedure as in bleeding hydraulic system to refill brake fluid. Refer to " «BRAKE FLUID»(ref-271559-S25314574312007111400000) ". Refill with recommended Genuine Brake Fluid or equivalent DOT 3 (US FMVSS No. 116). Refer to " «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-271552-S31952220342007111400000) ". Never reuse drained brake fluid. Be careful not to splash brake fluid on painted areas. (Scheme 31): Draining Brake Fluid From Bleed Valve

ROTOR

Check condition, wear, and damage.

ROTOR SPECIFICATION

Scheme 33

1. Check for leakage. (Scheme 32): Checking Caliper For Fluid Leakage

Scheme 34

1. Check for wear or damage. (Scheme 33): Identifying Pad

BRAKE PAD SPECIFICATION

Scheme 35

1. Check gear housing and boots for looseness, damage and grease leakage.
2. Check connection with steering column for looseness. (Scheme 34): Locating Gear Housing And Boots For Checking

STEERING LINKAGE

Check ball joint, dust cover and other component parts for looseness, wear, damage and grease leakage.

Axle and Suspension Parts

Check front and rear axle and suspension parts for excessive play, cracks, wear or other damage.

Scheme 36

Scheme 37

1. Shake each wheel to check for excessive play.
2. Check wheel bearings for smooth operation.
3. Check axle and suspension nuts and bolts for looseness.
4. Check strut (shock absorber) for oil leakage or other damage.
5. Check suspension ball joint for grease leakage and ball joint dust cover for cracks or other damage. see scheme 39: Checking Axle And Suspension Parts For Excessive Play (Scheme 36): Checking Suspension Ball Joint For Grease Leakage

Locating Locks, Hinges And Hood Latch (Roadster). Scheme 38

Identifying Seat Belt, Buckles, Retractors, Anchors And Adjusters With Torque Specifications. Scheme 39

For details, refer to Refer to SEAT BELTS .

1. Check anchors for loose mounting
2. Check belts for damage
3. Check retractor for smooth operation
4. Check function of buckles and tongues when buckled and released

BELT DEFLECTION AND TENSION

BELT DEFLECTION AND TENSION SPECIFICATIONS

SPARK PLUG (IRIDIUM-TIPPED TYPE)

SPARK PLUG SPECIFICATIONS (IRIDIUM-TIPPED TYPE)

WHEEL BALANCE

WHEEL BALANCE SPECIFICATIONS
