Maintenance Information Nissan 300ZX Z31

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation. Scheme 2

SEVERE & NORMAL SERVICE DEFINITIONS

Service is recommended at mileage intervals based on vehicle operation. Service schedule is based on the following primary operating conditions

Normal Service

1. Driven More Than 10 Miles Daily
2. No Operating Conditions From Severe Service Schedule

Severe Service (Unique Operating Conditions)

1. Repeated Short Trips Less Than 5 Miles When Outside Temperatures Remain Below Freezing
2. Extensive Idling
3. Driving In Dusty Conditions
4. Driving On Rough, Muddy, Or Salt Spread Roads
5. Towing A Trailer

CAMSHAFT TIMING BELT

The condition of camshaft drive belts should always be checked on vehicles which have more than 50,000 miles. Although some manufacturers do not recommend belt replacement at a specified mileage, others require it at 60,000-100,000 miles. A camshaft drive belt failure may cause extensive damage to internal engine components on most engines, although some designs do not allow piston-to-valve contact. These designs are often called "Free Wheeling".

Many manufacturers changed their maintenance and warranty schedules in the mid-1980's to reflect timing belt inspection and/or replacement at 50,000-60,000 miles. Most service interval schedules in this manual reflect these changes.

Belts or components should be inspected and replaced if any of the following conditions exist

1. Cracks Or Tears In Belt Surface
2. Missing, Damaged, Cracked Or Rounded Teeth
3. Oil Contamination
4. Damaged Or Faulty Tensioners
5. Incorrect Tension Adjustment

Replace camshaft timing belt every 60,000 miles.

Scheme 3

TIRE INFLATION

Cold tire inflation pressures can be found on the tire information label located on the center console lid.

WHEEL TIGHTENING

Tighten wheel lug nuts to 72-87 ft. lbs. (98-118 N.m).

BATTERY SPECIFICATIONS

If battery is replaced, new battery should be of the same group number as shown on the original battery's label. All years and models use BCI group 24 batteries.

SPARE TIRE USAGE

Ensure correct lug nuts are used when the spare tire is fitted. DO NOT use lug nuts from alloy wheels on steel wheels.

RADIATOR CAP

When checking the coolant level, always allow the engine to cool before removing the radiator cap. If the radiator cap of a hot engine is removed, hot, high pressure coolant may be sprayed out and cause injury.

FUEL INJECTION LINES

On vehicles equipped with electronic fuel injection, the fuel filter and fuel lines are under high pressure even when the engine is off. Exercise care when servicing these items so as not to cause injury to yourself.

WARRANTY INFORMATION

NEW VEHICLE LIMITED WARRANTY (BASIC COVERAGE)

Covers all parts and components for any repairs or adjustments needed to correct defects in materials or workmanship for 36 months or 36,000 miles, whichever comes first, from date of delivery to the first retail buyer.

CORROSION COVERAGE

Covers any body sheet metal panel found to have developed perforation (rust-through) due to corrosion in normal use for 60 months from date of delivery, regardless of mileage.

RADIO, TAPE DECK, & AMPLIFIER COVERAGE

Covers repairs needed to correct defects in materials or workmanship for 12 months from date of delivery, regardless of mileage. Replacement units repaired or replaced are covered for 3 months or the remainder of the 12 month period, whichever is longer.

AIR CONDITIONING

Covers the sealed refrigerant portion of the air conditioning system for 12 months, regardless of mileage.

EMISSION DEFECTS WARRANTY

Warrants that the vehicle was designed, built and equipped to conform at the time of sale with all applicable U.S. emission standards. Covers any repairs needed to correct defects in materials or workmanship which would cause the vehicle not to meet these standards for 5 years or 50,000 miles from date of first use, whichever comes first.

EMISSION PERFORMANCE WARRANTY

Covers all repairs, adjustments, or replacements if vehicle fails to conform to applicable emission standards and such failure results or will result in the vehicle owner having to bear any penalty or other sanctions under local, state or federal law for 5 years or 50,000 miles, whichever comes first. Also covers remedy of non-conformity which causes vehicle to fail EPA approved emissions test during the first 24 months or 24,000 miles of this warranty. During the remainder of the warranty period, covers remedy of non-conformity resulting from failure of any of the following components

1. EFI Engine Control System
2. Air/Fuel Ratio Feedback And/Or Control System
3. Cold Start Enrichment System
4. Deceleration Controls
5. Altitude Compensation System
6. Catalytic Converter
7. Exhaust Pipe From Manifold To Catalyst
8. Spark Advance/Retard System
9. Vapor Storage Canister And Liquid Separator
10. Fuel Filler Neck Restrictor And Check Valve
11. Fuel Tank And Filler Cap
12. PCV System
13. EGR Control Valve
14. Exhaust Air Induction System
15. Hoses, Clamps, Fittings And Tubing Used In Above Systems
16. Vacuum, Temperature And Time Sensitive Valves And Switches Used In Above Systems
17. Electronic Controls Used In Above Systems

FUSES & CIRCUIT BREAKERS

The fuse box is located beneath the instrument panel behind a cover to the left of the driver's pedals.

Scheme 4

Fuse & Circuit Breaker Identification

1. 1 - 10 Amp Right Headlight, Headlight System (1988-89), Auxiliary Driving Switch (1988-89), Theft Warning Control Unit (1988-89)
2. 2 - 10 Amp Left Headlight, Headlight System (1988-89)
3. 3 - 15 Amp Right Headlight Motor
4. 4 - 15 Amp Left Headlight Motor
5. 5 - 15 Amp Clearance Light, Illumination Lights, Taillight, License Lights, Headlight System
6. 6 - 10 Amp Interior Lights, Spot Lights, Step & Key Hole Lights, Luggage Compartment Light, Clock, Radio, Antenna Timer, Digital Meter, Steering Lock Switch, Time Control Unit (1984), Oxygen Sensor Amp (1984-87), Chime (1988-89), Air Conditioner (Auto) (1988-89)
7. 7 - 15 Amp Auxiliary Driving Light
8. 8 - 10 Amp Hazard Warning Lights
9. 9 - 10 Amp Horn, Time Control Unit (1985-89)
10. 10 - 20 Amp Stoplight, Injector Cooling Fan Timer (1984-87 Non-Turbo), A/T Interlock System (1988-89)
11. 11 - 15 Amp Air Conditioner
12. 12 - 15 Amp Air Conditioner
13. 13 - 15 Amp Ignition Coil, EFI System (1984), ECCS System (1985-89)
14. 14 - 10 Amp Fuel Pump, EFI System (1984), ECCS System (1985-89)
15. 15 - 10 Amp Gauge, Time Control Unit, Hold Relay (1984-87), Oxygen Sensor Module (1984-87), Bulb Check Relay (1985-87 Non-Turbo)
16. 16 - 10 Amp Turn Signal, Back-Up Light, Cruise Control, Receiver Amplifier, Boost Sensor (Turbo), Power Steering Switch (Non-Turbo), Voice Warning Unit (1984-86), Injector Cooling Fan Timer (1984-87 Turbo), Vacuum Pump (Turbo)
17. 17 - 10 Amp Kickdown Solenoid, Seat Belt Tension Reducer, Overdrive Switch, A/T Control Unit, Shock Absorber Control System, A/T Interlock Control Unit (1988-89)
18. 18 - 10 Amp Door Lock System (1984-86), Theft Warning Control Unit (1987-89), Security Light (1988-89)
19. 19 - 10 Amp Theft Warning Control Unit (1984-86), Door Lock System (1987-89)
20. 20 - 10 Amp Radio, Radio Amplifier, Clock, Time Control Unit, Remote Control Mirror, Door Mirror Defogger, Theft Warning Control Unit
21. 21 - 10 Amp Rear Wiper & Washer, Digital Gauges, Headlight Washer
22. 22 - 15 Amp Wiper & Washer
23. 23 - 15 Amp Cigarette Lighter
24. 24 - 10 Amp Air Conditioner
25. 25 - 20 Amp Fan Motor (Turbo), Bulb Check Relay (1985-89 Turbo)
26. 26 - 20 Amp Rear Defogger
27. 27 - 20 Amp Rear Defogger
