GENERAL INFORMATION

The wireless control module (WCM) is a system that integrates the keyless entry function with which remote operation (opening/closing of all doors, opening of liftgate and warning function to warn a person who intends to damage the vehicle*) can be performed by operating the lock/unlock button or panic button on the ignition key (transmitter). Also, WCM incorporates the immobilizer function, which prohibits the starting of engine using an unauthorized key, and the tire pressure monitoring system (TPMS), which issues a warning to a driver by illuminating or flashing the warning light if an abnormality to the tire pressure or system is detected. WCM has the following features

  1. The ignition key has an indicator light that enables the driver to check if the signal is transmitted correctly or if the battery in the key is discharged.
  2. Each vehicle is provided with two ignition keys, and up to eight ignition keys can be registered.
  3. The antenna for the immobilizer has been installed in the steering lock (key reminder switch) due to the change of WCM installation position.
  4. Settings of the keyless entry function can be adjusted using a customization function. NOTE: *: Horn sounds, and headlights and taillights flash.

Scheme 1

Scheme 1: CONSTRUCTION DIAGRAM

OPERATION

  1. When the ignition key is inserted to the ignition switch and the ignition switch is turned to the ON position, WCM transmits an ID code (key ID) registered in the WCM to the ignition key via the steering lock (key reminder switch) by radio.
  2. When the ignition key receives the transmission signal from WCM, the transponder (small transmitter) integrated in the ignition key transmits an ID code peculiar to each key (key ID) to WCM via the steering lock (key reminder switch) by radio.
  3. WCM compares the ID code (key ID) sent from the ignition key with the already-registered ID code (key ID), and only when they match, the starting of engine is permitted.
  4. More than one trillion of ID code (key ID) combinations can be registered, and this feature prevents code copying, resulting in higher security of the system.

Note. The transponder integrated in the ignition key uses the power supplied from WCM. Therefore, it can be used even when the battery in ignition key (for transmitter) is discharged. Two ignition keys (transmitter and transponder) are provided, and up to eight keys can be registered to one vehicle as needed. When WCM is replaced or when the key is lost or added, the ID codes for all the keys (key ID) must be registered using M.U.T.-III.

TECHNICAL DESCRIPTION (COMMENT)

If no data [ETACS transmits engine random number data to WCM via the CAN bus lines] is received from the engine control module via the CAN bus lines when the ignition switch is turned to ON position, it is judged as abnormal.

WCM determines that the abnormality is present when no VIN is recorded in it.

  1. B1A08: WCM determines that the abnormality is present when the rolling code received from the transmitter 1 (the first transmitter registered in WCM) greatly differs from the rolling code stored in WCM.
  2. B1A09: WCM determines that the abnormality is present when the rolling code received from the transmitter 2 (the second transmitter registered in WCM) greatly differs from the rolling code stored in WCM.
  3. B1A0A: WCM determines that the abnormality is present when the rolling code received from the transmitter 3 (the third transmitter registered in WCM) greatly differs from the rolling code stored in WCM.
  4. B1A0B: WCM determines that the abnormality is present when the rolling code received from the transmitter 4 (the fourth transmitter registered in WCM) greatly differs from the rolling code stored in WCM.
  5. B1A0C: WCM determines that the abnormality is present when the rolling code received from the transmitter 5 (the fifth transmitter registered in WCM) greatly differs from the rolling code stored in WCM.
  6. B1A0D: WCM determines that the abnormality is present when the rolling code received from the transmitter 6 (the sixth transmitter registered in WCM) greatly differs from the rolling code stored in WCM.
  7. B1A0E: WCM determines that the abnormality is present when the rolling code received from the transmitter 7 (the seventh transmitter registered in WCM) greatly differs from the rolling code stored in WCM.
  8. B1A0F: WCM determines that the abnormality is present when the rolling code received from the transmitter 8 (the eighth transmitter registered in WCM) greatly differs from the rolling code stored in WCM.
  1. B1A10: WCM determines that the abnormality is present when it receives low battery voltage signal from the transmitter 1 (the first transmitter registered in WCM) five consecutive times.
  2. B1A11: WCM determines that the abnormality is present when it receives low battery voltage signal from the transmitter 2 (the second transmitter registered in WCM) five consecutive times.
  3. B1A12: WCM determines that the abnormality is present when it receives low battery voltage signal from the transmitter 3 (the third transmitter registered in WCM) five consecutive times.
  4. B1A13: WCM determines that the abnormality is present when it receives low battery voltage signal from the transmitter 4 (the fourth transmitter registered in WCM) five consecutive times.
  5. B1A14: WCM determines that the abnormality is present when it receives low battery voltage signal from the transmitter 5 (the fifth transmitter registered in WCM) five consecutive times.
  6. B1A15: WCM determines that the abnormality is present when it receives low battery voltage signal from the transmitter 6 (the sixth transmitter registered in WCM) five consecutive times.
  7. B1A16: WCM determines that the abnormality is present when it receives low battery voltage signal from the transmitter 7 (the seventh transmitter registered in WCM) five consecutive times.
  8. B1A17: WCM determines that the abnormality is present when it receives low battery voltage signal from the transmitter 8 (the eighth transmitter registered in WCM) five consecutive times.

WCM determines that the abnormality is present, if the ignition key's key ID is not registered in WCM when the ignition switch is turned ON.

WCM determines that the abnormality is present, if the key ID for the ignition key does not match the one registered in WCM when the ignition switch is turned ON.

WCM determines that the abnormality is present, if the key certification result and the engine control module starting condition do not match after the engine start permission communication is completed.

WCM determines that the abnormality is present, if it cannot receive the key ID for the ignition key when the ignition switch is turned ON.

WCM determines that the abnormality is present, if it has detected discrepancy in the ignition switch level shown below ten consecutive times when WCM has received the CAN message (ignition switch position information) from ETACS-ECU with the ignition switch turned to the ON or START position.

WCM determines that the abnormality is present when the vehicle information registered in it does not match the vehicle information data.

WCM determines that the abnormality is present when VIN registered in it and the one that has been transmitted on the CAN bus do not match.

WCM determines that the abnormality is present, if it has detected discrepancy in the ignition switch level shown below ten consecutive times when WCM has received the CAN message (ignition switch position information) from ETACS-ECU with the ignition switch turned to the ON or START position.

When the ignition switch is turned ON, WCM transmits signal to the antenna. When the antenna is found faulty, WCM determines that the abnormality is present.

If the number of keyless ID registered transmitter is zero, the WCM determines that there is a problem.

WCM determines that the abnormality is present, if the data abnormality is found when the ignition switch is turned ON and then EEPROM is written.

If WCM cannot perform the data transmission in normal conditions due to a malfunction of the CAN-B bus circuit, WCM determines that there is a problem.

CIRCUIT OPERATION

WCM receives the vehicle information stored in the ETACS-ECU via CAN bus lines.

If the scan tool cannot communicate with the WCM, the CAN bus lines may be defective. If the WCM does not work, the WCM or the power supply circuit may be defective.

If only some ignition keys cannot be registered, the ignition key itself may be faulty. If no ignition key can be registered, the key assembly may have already been registered for another vehicle, or the WCM may be faulty.

If the fuel injection does not work, WCM and the MFI system may have a problem. This symptom is not considered abnormal when the engine is started by an ignition key that has not been registered.

If the WCM does not work at all or if the WCM cannot communicate with the scan tool, the WCM power supply or the ground circuit may be defective.

The lock/unlock signals from the transmitter are received by WCM, and then sent to ETACS-ECU from WCM. When ETACS-ECU receives signals from the key reminder switch and all the door switches, ETACS-ECU actuates the keyless entry system.

If the hazard warning light and the dome light works normally, ETACS-ECU may be faulty. Also, the answerback function may have been disabled using the customization function.

If the timer lock function does not work normally, the keyless entry transmitter input signal circuit or ETACS-ECU may be faulty.
