GENERAL INFORMATION
| Item | Specification | |
|---|---|---|
| 75D23L | ||
| Voltage V | 12 | |
| Capacity (5-hour rate) Ah | 52 | |
| Electrolytic fluid specific gravity [fully charged state at 20°C (68°F)] | 1.220 - 1.290 | |
| Battery current sensor resistance (ohms) | Current sensor resistance value | Between terminal No. 1 - 3: 3 - 10 k |
| Between terminal No. 1 - 4: less than 0.5 k | ||
| Between terminal No. 3 - 4: 3 - 10 k | ||
| Temperature sensor resistance value | 4.5 - 7.2 k [when 0°C (32 °F)] | |
| 1.6 - 2.5 k [when 25°C (77 °F)] | ||
| 0.96 - 1.40 k [when 40°C (104 °F)] | ||
GENERAL SPECIFICATIONS
| WARNING | Battery posts, terminals and related accessories contain lead and lead compounds. WASH HANDS AFTER HANDLING. |
The battery contains a visual test indicator which gives a blue signal when an adequate charge level exists, and a white signal when charging is required.
Scheme 1
Make sure the ignition switch is in "LOCK" (OFF) position and all battery fed accessories are OFF.
- Disconnect the negative cable from battery before disconnecting the positive cable. WARNING: Care should be taken in the event battery case is cracked or leaking to protect hands from the electrolyte. A suitable pair of rubber gloves (not the household type) should be worn when removing battery by hand.
- Remove the battery from the vehicle.
- Inspect the battery carrier for damage caused by loss of acid from battery. If acid damage is present, it is necessary to clean area with a solution of clean warm water and baking soda. Scrub area with a stiff bristle brush. Wipe clean with a cloth moistened with ammonia or baking soda in water.
- Clean the battery, especially the top, with the same solutions as described in step 3 .
- Inspect the battery case and cover for cracks. If cracks are present, battery must be replaced.
- Clean the battery post with a suitable battery post cleaning tool.
- Clean the inside surfaces of the terminal clamps with a suitable battery terminal cleaning tool. Replace damaged or frayed cables and broken terminal clamps.
- Install the battery in the vehicle.
- Connect the positive and negative cables to the battery in the order of mention.
- Tighten the clamp nut securely.
| WARNING | When batteries are being charged, an explosive gas forms beneath the cover of each cell. Do not smoke near batteries on charge or which have recently been charged. Do not break live circuits at the terminals of the batteries on charge. A spark will occur where the live circuit is broken. Keep all open flames away from the battery. |
Battery electrolyte temperature may temporarily be allowed to rise to 55°C (131°F). Increase of electrolyte temperature above 55°C (131°F) is harmful to the battery, causing deformation of battery cell, decrease in life of battery, etc.
