Fuses & Circuit Breakers 5 illustrations

ENGINE COMPARTMENT

For fuse location and values, refer to illustrations below.

Scheme 3

Scheme 3: ENGINE COMPARTMENT

Scheme 4

Scheme 4

Scheme 5

Scheme 5
NO.POWER SUPPLY CIRCUITFUSE TYPERATED CAPACITY (A)HOUSING COLORLOAD CIRCUIT
1Fusible link No.36Fuse15ABlueFog light and fog light relay
2Fusible link No.36Fuse7.5ABrownEngine control module
3Fusible link No.36Fuse20AYellowInput shaft speed sensor, output shaft speed sensor and transmission control module
4Fusible link No.36Fuse10ARedHorn and horn relay
5Fusible link No.36Fuse7.5ABrownGenerator
6Fusible link No.36Fuse
7Fusible link No.36Fuse10ARedA/C compressor assembly and A/C compressor clutch relay
8Fusible link No.36Fuse15ABlueEngine control module
9Fusible link No.36Fuse20AYellowTheft-alarm horn and theft-alarm horn relay
10Fusible link No.36Fuse
11Fusible link No.36Fuse
12Fusible link No.36Fuse
13Fusible link No.36Fuse10ARedDaytime running light and daytime running light relay
14Headlight relay (High)Fuse10ARedHeadlight (High: LH)
15Headlight relay (High)Fuse10ARedHeadlight (High: RH)
16Headlight relay (Low)Fuse20AYellowHeadlight assembly (LH)
17Headlight relay (Low)Fuse20AYellowHeadlight assembly (RH)
18Headlight relay (Low)Fuse10ARedHeadlight assembly (LH) and headlight automatic leveling-ECU
19Headlight relay (Low)Fuse10ARedHeadlight assembly (RH)
20MFI relayFuse20AYellowCenter exhaust pipe heated oxygen sensor and evaporative emission ventilation solenoid
21MFI relayFuse10ARedIgnition coil No.1 to 4
22MFI relayFuse20AYellowEngine control module, engine oil control valve, evaporative emission purge solenoid, exhaust gas recirculation valve, injector No.1 to 4, left bank heated oxygen sensor, mass airflow sensor, radiator sensor, right bank heated oxygen sensor, throttle valve control servo relay and variable intake air control solenoid valve
23MFI relayFuse15ABlueFuel pump module
24Fusible link No.36Fusible link30APinkStarter
25Fusible link No.36Fusible link
26Fusible link No.36Fusible link40AGreenABS-ECU and ASC-ECU
27Fusible link No.36Fusible link30APinkABS-ECU and ASC-ECU
28Fusible link No.36Fusible link30APinkCondenser fan motor, condenser fan relay and fan control relay
29Fusible link No.36Fusible link40AGreenRadiator fan motor and radiator fan relay
30Fusible link No.36Fuse30AGreenFuse No.7 to 9 in passenger compartment
31Fusible link No.36Fuse30AGreenAudio amplifier
32MFI relayFuse
33*BatteryFusible link120AGenerator
34*BatteryFusible link80AFuse Nos.2, 4, 5, 10, 11, 12, 14, 15, 17, 18, 20 and No.23 to 25 in passenger compartment
35*BatteryFusible link80A
36*BatteryFusible link120AFuse No.1 to 32 in engine compartment, headlight relay (High), headlight relay (Low) and MFI relay
37*Fusible link No.33/ GeneratorFusible link80AFuse Nos.1, 3, 6, 13, 16, 19, 21 and 22 in passenger compartment and blower relay

IDENTIFYING FUSES & FUSIBLE LINKS (ENGINE COMPARTMENT)

*: Fusible link connected directly to battery positive terminal.

Some fuses may not be installed on your vehicle, depending on the vehicle model or specifications.

PASSENGER COMPARTMENT

For fuse location and values, refer to illustrations below.

Scheme 6

Scheme 6: PASSENGER COMPARTMENT

Scheme 7

Scheme 7
NO.POWER SUPPLY CIRCUITFUSE TYPERATED CAPACITY (A)HOUSING COLORLOAD CIRCUIT
1Fusible link No.37Fusible link30APinkBlower motor
2Fusible link No.34Fuse15ABlueETACS-ECU, high-mounted stoplight, rear combination light, shift switch assembly and spare connector (for switch box)
3Fusible link No.37Fuse10ARed
4ETACS-ECU (ACC relay 3)Fuse30AGreenETACS-ECU, washer motor and windshield wiper motor
5Fusible link No.34Fuse10RedData link connector
6Fusible link No.37Fuse20AYellowETACS-ECU, front door lock actuator, liftgate lock actuator and rear door lock actuator
7Fusible link No.30Fuse15ABlueAudio visual navigation unit, CAN box unit, center panel unit, hands free module, radio and CD player or CD changer, rear display unit, satellite radio tuner and spare connector (for rear display)
8IFusible link No.30Fuse7.5ABrownA/C-ECU, column switch, combination meter, ETACS-ECU, key reminder switch, KOS-ECU, power window relay and wireless control module
9Fusible link No.30Fuse15ABlueCenter panel unit, combination meter and key reminder switch
10Fusible link No.34Fuse15ABlueETACS-ECU
11ETACS-ECU (ACC relay 3)Fuse15ABrownETACS-ECU and rear wiper motor
12ETACS-ECU (IG1 relay)Fuse7.5ABrownAWD-ECU, A/C control panel, A/C-ECU, A/T control relay, ABS-ECU, AC inverter, center panel unit, column switch, combination meter, headlight automatic leveling-ECU, KOS-ECU, rear window defogger relay, shift switch assembly, SRS-ECU, steering wheel sensor, sunroof motor assembly and wireless control module
13ETACS-ECU (ACC relay 2)Fuse15ABlue
14Fusible link No.34Fuse10ARedIgnition switch circuit
15Fusible link No.34Fuse20AYellowSunroof motor assembly
16ETACS-ECU (ACC relay 2)Fuse10ARedCAN box unit, door mirror assembly, radio and CD player or CD changer, rear display unit and spare connector (for rear display)
17Fusible link No.34Fuse10ARedAWD-ECU and occupant classification-ECU
18ETACS-ECU (IG1 relay)Fuse7.5ABrownAudio visual navigation unit, backup light switch, spare connector (for switch box), SRS-ECU and transmission control module
19Fusible link No.37Fuse15ABlueAccessory socket and ETACS-ECU
20Fusible link No.34Fusible link30APinkFront power window motor (RH), power window main switch and rear power window motor
21Fusible link No.37Fusible link30APinkRear window defogger relay
22Rear window defogger relayFuse7.5ABrownDoor mirror assembly
23Fusible link No.34Fuse15ABlueAC inverter
24Fusible link No.34Fuse25ATransparentFoot light and power seat assembly
25Fusible link No.34Fuse30AGreenHeated seat

IDENTIFYING FUSES (PASSENGER COMPARTMENT)

Some fuses may not be installed on your vehicle, depending on the vehicle model or specifications.
