GENERAL INFORMATION

The cooling system is designed to keep every part of the engine at appropriate temperature in whatever condition the engine may be operated. The cooling method is of the water-cooled, pressure forced circulation type in which the water pump pressurizes coolant and circulates it throughout the engine. If the coolant temperature exceeds the prescribed temperature, the thermostat opens to circulate the coolant through the radiator as well so that the heat absorbed by the coolant may be radiated into the air. The radiator is the corrugated fin, cross flow type. The water pump is of the centrifugal impeller type and is driven by the drive belt from the crankshaft.

SERVICE SPECIFICATIONS

SERVICE SPECIFICATIONS

COOLANT

COOLANT SPECIFICATIONS

SEALANT

SEALANT SPECIFICATION

INTRODUCTION

The system cools the engine so that it does not overheat and maintains the engine at an optimum temperature. The system components are the radiator, water pump, thermostat, condenser fan assembly. Possible faults include low coolant, contamination, belt loosening and component damage.

TROUBLESHOOTING STRATEGY

Use these steps to plan your diagnostic strategy. If you follow them carefully, you will be sure to find most of the engine cooling faults.

1. Gather information from the customer.
2. Verify that the condition described by the customer exists.
3. Find and repair the malfunction by following the SYMPTOM CHART.
4. Verify that the malfunction is eliminated.

SYMPTOM CHART

PROBLEM SYMPTOMS

Scheme 1

1. STEP 1. Check for coolant leaks. WARNING: When pressure testing the cooling system, slowly release cooling system pressure to avoid getting burned by hot coolant. CAUTION: Be sure to completely clean away any moisture from the places checked. When the tester is removed, be careful not to spill any coolant. When installing and removing the tester and when testing, be careful not to deform the filler neck of the radiator. Check that the coolant level is up to the filler neck. Install a radiator tester and apply 160 kPa (23 psi) pressure, and then check for leakage from the radiator hose or connections. Q: Is leakage present from the radiator hose or connections? YES: Repair or replace the appropriate part, then go to Step 2. NO: There is no action to be taken.
2. STEP 2. Retest the system. Q: It there still coolant leakage? YES: Return to Step 1 . NO: The procedure is complete.

Scheme 2

1. STEP 1. Remove the radiator cap and check for coolant contamination. Q: Is the coolant contaminated with rust and oil? YES: Replace it. Refer to «ENGINE COOLANT REPLACEMENT»(/mitsubishi/outlander-sport/i-2012-2015/remont/cooling-system-mechanical/#engine-cooling-system__engine-coolant-replacement) . NO: There is no action to be taken. Go to Step 2.
2. STEP 2. Check the radiator cap valve opening pressure. NOTE: Be sure that the cap is clean before testing. Rust or other foreign material on the cap seal will cause an improper reading. Use a cap adapter to attach the cap to the tester. Increase the pressure until the gauge indicator stops moving. Minimum limit: 83 kPa (12 psi) Standard value: 93 - 123 kPa (14 - 18 psi) Q: Does the reading remain at or above the minimum limit? YES: Go to Step 3. NO: Replace the radiator cap. Then go to Step 5 .
3. STEP 3. Check thermostat operation. Refer to «THERMOSTAT CHECK»(/mitsubishi/outlander-sport/i-2012-2015/remont/cooling-system-mechanical/#engine-cooling-system) . Q: Does the thermostat operate correctly? YES: Go to Step 4. NO: Replace the thermostat, then go to Step 5 .
4. STEP 4. Check the drive belt for slippage or damage. Refer to «(CHECK CONDITION)»(/mitsubishi/outlander-sport/i-2012-2015/remont/hoistjack/#general-information) . Q: Is the drive belt loose or damaged? YES: Adjust or replace the drive belt, then go to Step 5. NO: There is no action to be taken.
5. STEP 5. Retest the system. Check the engine coolant temperature. Q: Is the engine coolant temperature abnormally high? YES: Return to Step 2 . NO: The procedure is complete.

Scheme 3

CIRCUIT OPERATION

1. Based on the signal from the engine coolant temperature sensor and the signal from the vehicle speed sensor < M/T > or the secondary pulley speed sensor signal (vehicle speed signal) from the transaxle control module (TCM) < CVT >, and the A/C switch signal from the A/C-ECU, the engine control module (ECM) sends the radiator fan and condenser fan control signal to the ETACS-ECU via CAN bus line.
2. Based on the radiator fan and condenser fan control signal from the ECM, the ETACS-ECU turns ON/OFF the radiator fan relay, condenser fan relay, and the fan control relay to control the rotation of the radiator fan motor and condenser fan motor.

TECHNICAL DESCRIPTION

1. If the radiator fan and condenser fan do not operate, the radiator fan motor, the condenser fan motor, the radiator fan relay, the condenser fan relay, the fan control relay, the ETACS-ECU may be defective.
2. The CAN bus line, ETACS-ECU, CVT system, A/C system, or MFI system may also be defective.

TROUBLESHOOTING HINTS (THE MOST LIKELY CAUSES FOR THIS CASE:)

1. Malfunction of CAN bus system.
2. Damaged harness or connector.
3. Malfunction of the MFI system.
4. Malfunction of the CVT system.
5. Malfunction of the A/C system.
6. Malfunction of fusible link No. 28.
7. Malfunction of fusible link No. 29.
8. Malfunction of radiator fan relay.
9. Malfunction of condenser fan relay.
10. Malfunction of fan control relay.
11. Malfunction of radiator fan motor.
12. Malfunction of condenser fan motor.
13. Malfunction of engine compartment relay box.
14. Malfunction of ETACS-ECU.
15. Malfunction of ECM.

DIAGNOSTIC PROCEDURE

Scheme 4

Scheme 5

1. STEP 1. Using scan tool MB991958, check the CAN bus line diagnostics. Use scan tool to diagnose the CAN bus line (Refer to «EXPLANATION ABOUT THE SCAN TOOL CAN BUS DIAGNOSTICS»(/mitsubishi/outlander-sport/i-2012-2015/remont/communication-devices/#controller-area-network-can__explanation-about-the-scan-tool-mut-iii) . Q: Is the check result satisfactory? YES: Go to Step 2. NO: Repair the CAN bus lines (Refer to «CAN BUS DIAGNOSTIC TABLE»(/mitsubishi/outlander-sport/i-2012-2015/remont/communication-devices/#controller-area-network-can__can-bus-diagnostics-table) . Then go to Step 23 .
2. STEP 2. Using scan tool MB991958, check the MFI system actuator test. Use scan tool to check the MFI system actuator test (Refer to «HOW TO PERFORM ACTUATOR TEST»(/mitsubishi/outlander-sport/i-2012-2015/remont/engine-control-systems/#multiport-fuel-injection-mfi-20l) . Item 14: Cooling fan (Refer to «ACTUATOR TEST REFERENCE TABLE»(/mitsubishi/outlander-sport/i-2012-2015/remont/engine-control-systems/#multiport-fuel-injection-mfi-20l) ) Q: Is the check result normal? YES: Go to Step 22 . NO: Go to Step 3.
3. STEP 3. Using scan tool MB991958, read the MFI system DTC. Use scan tool to read the MFI system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/outlander-sport/i-2012-2015/remont/engine-control-systems/#multiport-fuel-injection-mfi-20l) . Q: Is any DTC set? YES: Repair the MFI system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/outlander-sport/i-2012-2015/remont/engine-control-systems/#multiport-fuel-injection-mfi-20l) . Then go to Step 23 . NO: Go to Step 5 < M/T >. NO: Go to Step 4 < CVT >.
4. STEP 4. Using scan tool MB991958, read the CVT system DTC < CVT >. Use scan tool to read the CVT system DTC (Refer to «DIAGNOSIS FUNCTION»(/mitsubishi/outlander-sport/i-2012-2015/remont/automatic-trans/#continuously-variable-transaxle-cvt-diagnosis-on-vehicle-service__diagnostic-function) . Q: Is any DTC set? YES: Repair the CVT system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/outlander-sport/i-2012-2015/remont/automatic-trans/#continuously-variable-transaxle-cvt-diagnosis-on-vehicle-service__diagnostic-trouble-code-chart) . Then go to Step 23 . NO: Go to Step 5.
5. STEP 5. Using scan tool MB991958, read the A/C system DTC. Use scan tool to read the A/C system DTC (Refer to «DIAGNOSIS FUNCTION»(/mitsubishi/outlander-sport/i-2012-2015/remont/ac-compressor/#heating-air-conditioning-ventilation) ) < vehicles with manual A/C > or (Refer to «DIAGNOSIS FUNCTION»(/mitsubishi/outlander-sport/i-2012-2015/remont/automatic-hvac-system/#automatic-air-conditioning) ) < vehicles with automatic A/C >. Q: Is any DTC set? YES: Repair the A/C system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/outlander-sport/i-2012-2015/remont/ac-compressor/#heating-air-conditioning-ventilation__diagnostic-trouble-code-chart) ) < vehicles with manual A/C > or (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/outlander-sport/i-2012-2015/remont/automatic-hvac-system/#automatic-air-conditioning__diagnostic-trouble-code-chart) ) < vehicles with automatic A/C >. Then go to Step 23 . NO: Go to Step 6.
6. STEP 6. Using scan tool MB991958, read the ETACS system DTC. Use scan tool to read the ETACS system DTC (Refer to «DIAGNOSIS FUNCTION»(/mitsubishi/outlander-sport/i-2012-2015/remont/communication-devices/#electronic-time-alarm-control-system-etacs) . Q: Is any DTC set? YES: Repair the ETACS system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/outlander-sport/i-2012-2015/remont/communication-devices/#electronic-time-alarm-control-system-etacs__diagnostic-trouble-code-chart) . Then go to Step 23 . NO: Go to Step 7.
7. STEP 7. Measure the terminal voltage at ETACS-ECU connector C-410. Disconnect the ETACS-ECU connector C-410 and measure at the harness connector side. Turn the ignition switch to the "ON" position. Measure the terminal voltage between ETACS-ECU connector C-410 terminal number 2 and body ground, and between ETACS-ECU connector C-410 terminal number 8 and body ground. OK : Battery positive voltage. Q: Is the check result normal? YES: Go to Step 13 . NO: Go to Step 8.
8. STEP 8. Check the condenser fan relay connector A-30X, radiator fan relay connector A-33X, fan control relay connector A-35X, and ETACS-ECU connector C-410, for loose, corroded or damaged terminals, or terminals pushed back in the connector. Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/outlander-sport/i-2012-2015/remont/body-electrical/#general-electrical) . Q: Are the connectors and terminals in good condition? YES: Go to Step 9. NO: Repair or replace the damaged connectors or replace the relay box. Then go to Step 23 .
9. STEP 9. Check the harness wire between fusible link number 28 and condenser fan relay connector A-30X terminal number 1, between fusible link number 28 and fan control relay connector A-35X terminal number 1, and between fusible link number 29 and radiator fan relay connector A-33X terminal number 3, for damage. Check harness wire for open/short circuit and damage. Q: Are the harness wires in good condition? YES: Go to Step 10. NO: Repair or replace the damaged harness wire or replace the relay box. Then go to Step 23 .
10. STEP 10. Check the harness wire between condenser fan relay connector A-30X terminal number 2 and ETACS-ECU connector C-410 terminal number 8, between radiator fan relay connector A-33X terminal number 1 and ETACS-ECU connector C-410 terminal number 2, and between fan control relay connector A-35X terminal number 3 and ETACS-ECU connector C-410 terminal number 8, for damage. Check harness wire for open/short circuit and damage. Q: Are the harness wires in good condition? YES: Go to Step 11. NO: Repair or replace the damaged harness wire. Then go to Step 23 .
11. STEP 11. Check the radiator fan relay, the condenser fan relay and the fan control relay. Refer to «RADIATOR FAN RELAY CHECK»(/mitsubishi/outlander-sport/i-2012-2015/remont/cooling-system-mechanical/#engine-cooling-system__radiator-fan-relay-check) . Q: Is the relay in good condition? YES: Go to Step 12. NO: Replace the damaged relay. Then go to Step 23 .
12. STEP 12. Check the fusible link number 28 and fusible link number 29. Q: Is the fusible link in good condition? YES: Go to Step 20 . NO: Replace the damaged fusible link. Then go to Step 23 .
13. STEP 13. Check the condenser fan relay connector A-30X, radiator fan relay connector A-33X, fan control relay connector A-35X, radiator fan motor connector A-50, and condenser fan motor connector A-54, for loose, corroded or damaged terminals, or terminals pushed back in the connector. Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/outlander-sport/i-2012-2015/remont/body-electrical/#general-electrical) . Q: Are the connectors and terminals in good condition? YES: Go to Step 14. NO: Repair or replace the damaged connectors or replace the relay box. Then go to Step 23 .
14. STEP 14. Check the harness wire between fusible link number 28 and condenser fan relay connector A-30X terminal number 4, and between fusible link number 29 and radiator fan relay connector A-33X terminal number 4, for damage. Check harness wire for open/short circuit and damage. Q: Are the harness wires in good condition? YES: Go to Step 15. NO: Repair or replace the damaged harness wire or replace the relay box. Then go to Step 23 .
15. STEP 15. Check the harness wire between condenser fan relay connector A-30X terminal number 3 and condenser fan motor connector A-54 terminal number 1, and between radiator fan relay connector A-33X terminal number 2 and radiator fan motor connector A-50 terminal number 1, for damage. Check harness wire for open/short circuit and damage. Q: Are the harness wires in good condition? YES: Go to Step 16. NO: Repair or replace the damaged harness wire. Then go to Step 23 .
16. STEP 16. Check the harness wire between radiator fan motor connector A-50 terminal number 2 and fan control relay connector A-35X terminal number 5, and between condenser fan motor connector A-54 terminal number 2 and body ground, for damage. Check harness wire for open/short circuit and damage. Q: Are the harness wires in good condition? YES: Go to Step 17. NO: Repair or replace the damaged harness wire. Then go to Step 23 .
17. STEP 17. Check the harness wire between fan control relay connector A-35X terminal number 2 and condenser fan motor connector A-54 terminal number 1, and between fan control relay connector A-35X terminal number 4 and body ground, for damage. Check harness wire for open/short circuit and damage. Q: Are the harness wires in good condition? YES: Go to Step 18. NO: Repair or replace the damaged harness wire. Then go to Step 23 .
18. STEP 18. Check the radiator fan relay, the condenser fan relay and the fan control relay. Refer to «RADIATOR FAN RELAY CHECK»(/mitsubishi/outlander-sport/i-2012-2015/remont/cooling-system-mechanical/#engine-cooling-system__radiator-fan-relay-check) . Q: Is the relay in good condition? YES: Go to Step 19. NO: Replace the damaged relay. Then go to Step 23 .
19. STEP 19. Check the radiator fan motor and the condenser fan motor. Refer to «COOLING FAN MOTOR CHECK»(/mitsubishi/outlander-sport/i-2012-2015/remont/cooling-system-mechanical/#engine-cooling-system) . Q: Is the fan motor in good condition? YES: Go to Step 20. NO: Replace the damaged fan motor (Refer to «REMOVAL AND INSTALLATION»(/mitsubishi/outlander-sport/i-2012-2015/remont/cooling-system-mechanical/#engine-cooling-system) . Then go to Step 23 .
20. STEP 20. Using scan tool MB991958, read the ETACS system DTC. Use scan tool to read the ETACS system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/outlander-sport/i-2012-2015/remont/communication-devices/#electronic-time-alarm-control-system-etacs) . Q: Is any DTC set? YES: Replace the ETACS-ECU (Refer to «REMOVAL AND INSTALLATION»(/mitsubishi/outlander-sport/i-2012-2015/remont/communication-devices/#electronic-time-alarm-control-system-etacs__removal-and-installation) . Then go to Step 23 . NO: Go to Step 21.
21. STEP 21. Using scan tool MB991958, check the MFI system actuator test. Use scan tool to check the MFI system actuator test (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/outlander-sport/i-2012-2015/remont/engine-control-systems/#multiport-fuel-injection-mfi-20l) . Item 14: Cooling fan (Refer to «ACTUATOR TEST REFERENCE TABLE»(/mitsubishi/outlander-sport/i-2012-2015/remont/engine-control-systems/#multiport-fuel-injection-mfi-20l) ) Q: Is the check result normal? YES: Go to Step 22. NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/outlander-sport/i-2012-2015/remont/engine-control-systems/#multiport-fuel-injection-mfi-20l) ]. Then go to Step 23 .
22. STEP 22. Check the symptom. Q: Does the radiator fan and condenser fan operate normal? YES: An intermittent malfunction is suspected (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/outlander-sport/i-2012-2015/remont/hoistjack/#general-information__how-to-cope-with-intermittent-malfunctions) . NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/outlander-sport/i-2012-2015/remont/engine-control-systems/#multiport-fuel-injection-mfi-20l) ]. Then go to Step 23.
23. STEP 23. Check the symptom. Q: Does the radiator fan and condenser fan operate normal? YES: The procedure is complete. NO: Return to Step 1 .

SPECIAL TOOLS

SPECIAL TOOLS CHART Tool Tool number and name Supersession Application MB991958 Scan tool (M.U.T.-III sub assembly) MB991824 Vehicle communication interface (V.C.I.) MB991827 M.U.T.-III USB cable MB991910 M.U.T.-III main harness A (Vehicles with CAN communication system) MB991911 M.U.T.-III main harness B (Vehicles without CAN communication system) MB991914 M.U.T.-III main harness C (for Chrysler models only) MB991825 M.U.T.-III adapter harness MB991826 M.U.T.-III trigger harness MB991824-KIT NOTE: MB991826 M.U.T.-III Trigger Harness is not necessary when pushing V.C.I. ENTER key. CAUTION: For vehicles with CAN communication, use M.U.T.-III main harness A to send simulated vehicle speed. If you connect M.U.T.-III main harness B or C instead, the CAN communication does not function correctly. Reading diagnostic trouble codes MB991223 MB991219 MB991220 MB991221 MB991222 Harness set Test harness LED harness LED harness adaptor Probe General service tools Checking the continuity and measuring the voltage at the harness connector MB992006 Extra fine probe General service tool Continuity check and voltage measurement at harness wire or connector for loose, corroded or damaged terminals, or terminals pushed back in the connector. MB991871 LLC changer General service tool Coolant refilling MB992042 Water temperature sensor wrench MB992042-01 Engine coolant temperature sensor removal and installation

Scheme 6

Scheme 7

Scheme 8

Scheme 9

ENGINE COOLANT LEAK CHECK

Scheme 10

1. Check that the engine coolant level is up to the filler neck. Install a radiator tester and apply 160 kPa (23 psi) pressure, and then check for engine coolant leakage from the radiator hose or connections.
2. If there is engine coolant leakage, repair or replace the appropriate part.

Scheme 11

1. Use a cap adapter to attach the radiator cap to the tester. NOTE: Be sure that the radiator cap is clean before testing. Rust or other foreign material on the radiator cap seal will cause an improper reading.
2. Increase the pressure until the indicator of the gauge stops moving. Minimum limit: 83 kPa (12 psi) Standard value: 93 - 123 kPa (14 - 18 psi)
3. Replace the radiator cap if the reading does not remain at or above the limit.

ENGINE COOLANT REPLACEMENT

Required Special Tool

1. MB991871: LLC changer

Scheme 12

Scheme 13

Scheme 14

Scheme 15

1. Remove the engine room under cover front A (Refer to «REMOVAL AND INSTALLATION»(/mitsubishi/outlander-sport/i-2012-2015/remont/exterior-body-panels/#under-cover) . WARNING: When removing the radiator cap, use care to avoid contact with hot engine coolant or steam. Place a shop towel over the radiator cap and turn the radiator cap counterclockwise a little to let the pressure escape through the vinyl tube. After relieving the steam pressure, remove the radiator cap by slowly turning it counterclockwise.
2. Drain the engine coolant from the radiator, heater core and engine after unplugging the radiator drain plug and removing the radiator cap.
3. Disconnect the water hose < M/T > or cooling water line hose < CVT >, and drain the engine coolant in the water jacket.
4. Drain the water in the water jacket by unplugging the drain plug of the cylinder block.
5. Remove the radiator condenser tank and drain the engine coolant.
6. Connect the water hose < M/T > or cooling water line hose < CVT >.
7. Replace the cylinder block drain plug gasket, and tighten the drain plug to the specified torque. Tightening torque: 39 ± 3 N.m (29 ± 2 ft-lb)
8. Securely tighten the radiator drain plug.
9. Reinstall the radiator condenser tank. CAUTION: Do not use alcohol or methanol anti-freeze or any engine coolants mixed with alcohol or methanol anti-freeze. The use of an improper anti-freeze can cause corrosion of the aluminum components.
10. Use special tool MB991871 to refill the engine coolant up to the top of the radiator port. Recommended antifreeze: DIA QUEEN SUPER LONG LIFE COOLANT PREMIUM or equivalent* *: similar high quality ethylene glycol based non-silicate, non-amine, non-nitrate and non-borate coolant with long life hybrid organic acid technology Quantity: 7.5 dm 3 (7.9 quarts) [includes 0.65 dm 3 (0.69 quarts) in the radiator condenser tank] NOTE: For how to use special tool MB991871, refer to the manufacturer's instructions.
11. Tighten the radiator cap securely.
12. Remove the radiator condenser tank cap, and add the engine coolant up to the "FULL" line.
13. Turn the A/C switch to OFF position to start the engine and warm up until the radiator fan operates. NOTE: This work is to open the thermostat fully.
14. Rev the engine several times and then stop it. Check that there are no engine coolant leaks.
15. Remove the radiator cap with the engine cool, and then refill the engine coolant up to the top of the radiator port.
16. Tighten the radiator cap securely. CAUTION: Do not overfill the radiator condenser tank.
17. Remove the radiator condenser tank cap, and add the engine coolant up to the "FULL" line.
18. Reinstall the engine room under cover front A (Refer to «REMOVAL AND INSTALLATION»(/mitsubishi/outlander-sport/i-2012-2015/remont/exterior-body-panels/#under-cover) .

ENGINE COOLANT CONCENTRATION TEST

Using a hydrometer, check if the engine coolant concentration is within the standard value range.

Standard value: 30 to 60% (service concentration range)

WATER PUMP COOLANT LEAK CHECK

Even when the water pump is normal, a residue of the engine coolant draining may be found on the drain hole, the vapor hole and the installation surface of the water pump. If a residue of the engine coolant draining is found, check the water pump leakage by following method.

1. Wipe off the residue of the engine coolant draining on the water pump. WARNING: Make sure that the engine coolant is cold when removing the radiator cap.
2. Remove the radiator cap. CAUTION: Do not pressures 100 kPa (15 psi) or more.
3. Install the radiator tester and pressures at 100 kPa (15 psi.)
4. Hold the pressurized state for 20 minutes, and check that the engine coolant leakage from the drain hole, the vapor hole or the installation surface of the water pump.
5. Remove the radiator tester, and install the radiator cap.
6. Warm up the engine, let it idle for 20 minutes and stop it.
7. After stopping the engine, and check that the engine coolant leakage from the drain hole, the vapor hole or the installation surface of the water pump.
8. If the engine coolant leakage is found in step 4 or 7 , replace the water pump (Refer to «REMOVAL AND INSTALLATION»(/mitsubishi/outlander-sport/i-2012-2015/remont/cooling-system-mechanical/#engine-cooling-system) .

COOLING FAN RELAY REPLACEMENT

Scheme 16

Scheme 17

1. Remove the relay by hand. If it cannot be removed by hand, pinch the part "A" (shown in illustration) with long-nose pliers and remove the relay.
2. Install the new relay by hand.

FAN CONTROL RELAY CHECK

FAN CONTROL RELAY CHECK

Scheme 18

RADIATOR FAN RELAY CHECK

RADIATOR FAN RELAY CHECK

Scheme 19

CONDENSER FAN RELAY CHECK

CONDENSER FAN RELAY CHECK

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. Disconnect the fan motor connector.
2. Check that the fan motor runs when a positive battery terminal is connected to the fan motor-side connector terminal number 1, and terminal number 2 is grounded. Also check to see that there is no abnormal sound emitted from the fan motor at this time.
3. If the fan motor is defective, replace it (Refer to «REMOVAL AND INSTALLATION»(/mitsubishi/outlander-sport/i-2012-2015/remont/cooling-system-mechanical/#engine-cooling-system) .
4. Connect the fan motor connector.

Scheme 24

Scheme 25

Scheme 26

1. Make mating marks on the radiator lower hose and the hose clip (as shown in illustration) to install them in the original position.
2. Break off the tip of hose clip claw and spread out the hose clip, then disconnect the radiator lower hose. NOTE: If there is a hose clip claw, the hose clip cannot spread to capacity because the claw contacts the hose clip.

>> A << THERMOSTAT INSTALLATION

Install the thermostat with care to avoid peeling or damage to the rubber ring. When installing the thermostat, face the jiggle valve of the thermostat upward.

Scheme 27

>> B << RADIATOR LOWER HOSE/HOSE CLIP CONNECTION

Scheme 28

1. Make mating mark on a new hose clip in the same position as the remove one.
2. Insert the radiator lower hose until the protrusion of the water inlet fitting.
3. Align the mating marks on the radiator lower hose and hose clip.
4. Remove the hose clip claw and shorten the hose clip, then install the radiator lower hose.

Scheme 29

Scheme 30

1. Immerse the thermostat in water, and heat the water while stirring. Check the thermostat valve opening temperature. Standard value: 87 ± 1.5°C (189 ± 3°F)
2. Check that the amount of valve lift is at the standard value when the water is at the full-opening temperature. NOTE: Measure the valve height when the thermostat is fully closed, and use this measurement to compare the valve height when the thermostat is fully open. Standard value: Full-opening temperature: 95°C (203°F) Amount of valve lift: 8.5 mm (0.33 inch) or more

Scheme 31

Scheme 32

Required Special Tool

1. MB992042: Water Temperature Sensor Wrench

<< A >> HOSE CLIP/RADIATOR UPPER HOSE DISCONNECTION

1. Make mating marks on the radiator upper hose and the hose clip (as shown in illustration) to install them in the original position.
2. Break off the tip of hose clip claw and spread out the hose clip, then disconnect the radiator upper hose. NOTE: If there is a hose clip claw, the hose clip cannot spread to capacity because the claw contacts the hose clip.

<< B >> ENGINE COOLANT TEMPERATURE SENSOR REMOVAL

Use special tool MB992042 to remove the engine coolant temperature sensor.

Scheme 33

>> A << O-RING INSTALLATION

Fit the O-ring in the water inlet pipe groove, wet the O-ring circumference or the pipe mounting area inner wall, and then insert the O-ring.

Scheme 34

Scheme 35

1. Apply the specified sealant to the thread of the engine coolant temperature sensor. Specified sealant: ThreeBond 1324N or equivalent NOTE: Install the engine coolant temperature sensor immediately after applying sealant. CAUTION: After the installation, until a sufficient period of time (one hour or more) elapses, do not apply the oil or water to the sealant application area or start the engine.
2. Use special tool MB992042 to tighten the engine coolant temperature sensor to the specified torque. Tightening torque: 30 ± 9 N.m (22 ± 7 ft-lb)

>> C << RADIATOR UPPER HOSE/HOSE CLIP CONNECTION

Scheme 36

1. Make mating mark on a new hose clip in the same position as the remove one.
2. Insert the radiator upper hose until the protrusion of the water outlet fitting.
3. Align the mating marks on the radiator upper hose and hose clip.
4. Remove the hose clip claw and shorten the hose clip, then install the radiator upper hose.

WATER PIPE AND HOSE CHECK

Check the water pipe and hose for cracks, damage and clogs. Replace them if necessary.

Scheme 37

<< A >> HOSE CLIP/RADIATOR UPPER HOSE/RADIATOR LOWER HOSE REMOVAL

1. Make mating marks on the radiator hose and the hose clip (as shown in illustration) to install them in the original position.
2. Break off the tip of hose clip claw and spread out the hose clip, then disconnect the radiator hose. NOTE: If there is a hose clip claw, the hose clip cannot spread to capacity because the claw contacts the hose clip.

<< B >> FAN, FAN MOTOR AND FAN SHROUD ASSEMBLY REMOVAL

Remove the fan, fan motor and fan shroud assembly from the radiator assembly according to the procedure below.

Scheme 38

1. Release the upper locks of the radiator assembly from the fan, fan motor, and fan shroud assembly.
2. Slightly raise the fan, fan motor, and fan shroud assembly.
3. Release the lower locks of the radiator assembly from the fan, fan motor, and fan shroud assembly, and then remove the fan, fan motor and fan shroud assembly.

>> A << RADIATOR UPPER HOSE/RADIATOR LOWER HOSE/HOSE CLIP CONNECTION

Scheme 39

1. Make mating mark on a new hose clip in the same position as the remove one.
2. Insert the radiator hose until the protrusion of the pipe.
3. Align the mating marks on the radiator hose and hose clip.
4. Remove the hose clip claw and shorten the hose clip, then install the radiator hose.
