Maintenance Information: Overview Mitsubishi Montero II

Fuse & Circuit Breaker Identification

1. 1 - 20 Amp (Yellow) Hazard Light, Dome Light, Clock
2. 2 - 10 Amp (Red) Taillights
3. 3 - 10 Amp (Red) Turn Signal Lights
4. 4 - 10 Amp (Red) Back-Up Lights, Gauges
5. 5 - 15 Amp (Light Blue) Defogger
6. 6 - 20 Amp (Yellow) Heater
7. 7 - 15 Amp (Light Blue) Stoplights
8. 8 - 15 Amp (Light Blue) Horn, Wiper, Washer
9. 9 - 10 Amp (Red) Rear Wiper, Rear Washer
10. 10 - 15 Amp (Light Blue) Cigarette Lighter, Radio

Scheme 1

1. 1 - 20 Amp Not Used
2. 2 - Not Used
3. 2 - 10 Amp (1994-96) ELC-4 A/T Control Module, Cruise Control Unit
4. 3 - 10 Amp Blower Motor Relay, Headlight Washer Relay, Defogger Relay, Car Telephone (1992-93)
5. 4 - 10 Amp Radio Clock, Accessory Socket Relay, Cruise Control Unit (1994-96), Data Link Connector (1994-96)
6. 5 - 15 Amp Remote Controlled Mirror, Cigarette Lighter Accessory Socket Relay (1992-93)
7. 6 - 15 Amp Door Lock Relay, Door Lock Control Unit (1994-96)
