STARTER SPECIFICATIONS
| Application | In. (mm) |
|---|
| Commutator Maximum Runout |
| Mirage | .002 (.05) |
| All Others | .004 (.10) |
| Commutator Minimum Diameter |
| Diamante | 1.23 (31.2) |
| Eclipse |
| Direct Drive Type | (1) |
| Gear Reduction Type | 1.12 (28.4) |
| Galant, Montero & Montero Sport | 1.13 (28.8) |
| Mirage |
| Direct Drive Type | 1.22 (31.4) |
| Gear Reduction Type | 1.12 (28.4) |
| 3000GT | 1.12 (28.4) |
| Commutator Undercut Depth |
| Mirage | .008 (.20) |
| All Others | .020 (.51) |
| Pinion Gap | .020-.079 (.51-2.01) |
| (1) Information is not available from manufacturer at time of publication. |
| (1) | Information is not available from manufacturer at time of publication. |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Starter-To-Block Bolts |
| Diamante | 23 (31) |
| Eclipse |
| 2.0L Non-Turbo | 40 (54) |
| 2.0L Turbo & 2.4L | 22 (30) |
| Galant | 22 (30) |
| Mirage | 36 (49) |
| Montero & Montero Sport | 19-24 (26-33) |
| 3000GT | 23 (31) |
Starting System Wiring Diagram (Diamante). Scheme 1
Scheme 1: Starting System Wiring Diagram (Diamante)
Starting System Wiring Diagram (Eclipse - 2.0L A/T With Anti-Theft). Scheme 2
Scheme 2: Starting System Wiring Diagram (Eclipse - 2.0L A/T With Anti-Theft)
Starting System Wiring Diagram (Eclipse - 2.0L Turbo A/T & 2.4L A/T With Anti-Theft). Scheme 3
Scheme 3: Starting System Wiring Diagram (Eclipse - 2.0L Turbo A/T & 2.4L A/T With Anti-Theft)
Starting System Wiring Diagram (Eclipse - M/T With Anti-Theft). Scheme 4
Scheme 4: Starting System Wiring Diagram (Eclipse - M/T With Anti-Theft)
Starting System Wiring Diagram (Eclipse - 2.0L Without Anti-Theft). Scheme 5
Scheme 5: Starting System Wiring Diagram (Eclipse - 2.0L Without Anti-Theft)
Starting System Wiring Diagram (Eclipse - 2.0L Turbo & 2.4L Without Anti-Theft). Scheme 6
Scheme 6: Starting System Wiring Diagram (Eclipse - 2.0L Turbo & 2.4L Without Anti-Theft)
Starting System Wiring Diagram (Galant - A/T). Scheme 7
Scheme 7: Starting System Wiring Diagram (Galant - A/T)
Starting System Wiring Diagram (Galant - M/T). Scheme 8
Scheme 8: Starting System Wiring Diagram (Galant - M/T)
Starting System Wiring Diagram (Mirage). Scheme 9
Scheme 9: Starting System Wiring Diagram (Mirage)
Starting System Wiring Diagram (Montero). Scheme 10
Scheme 10: Starting System Wiring Diagram (Montero)
Starting System Wiring Diagram (Montero Sport - A/T). Scheme 11
Scheme 11: Starting System Wiring Diagram (Montero Sport - A/T)
Starting System Wiring Diagram (Montero Sport - M/T). Scheme 12
Scheme 12: Starting System Wiring Diagram (Montero Sport - M/T)
Starting System Wiring Diagram (3000GT - A/T With Anti-Theft). Scheme 13
Scheme 13: Starting System Wiring Diagram (3000GT - A/T With Anti-Theft)
Starting System Wiring Diagram (3000GT - M/T With Anti-Theft). Scheme 14
Scheme 14: Starting System Wiring Diagram (3000GT - M/T With Anti-Theft)
Starting System Wiring Diagram (3000GT - Without Anti-Theft). Scheme 15
Scheme 15: Starting System Wiring Diagram (3000GT - Without Anti-Theft)
