Starters: Other Mitsubishi Mirage V

Starter 3 illustrations ~684 words

STARTER RELAY

Note. Testing procedures for the anti-theft starter relay, for models equipped with anti-theft systems, are contained in appropriate ANTI-THEFT SYSTEMS article in ACCESSORIES & EQUIPMENT.

Scheme 26

Scheme 26: Diamante
Scheme 26: Diamante
  1. Remove starter relay. See «STARTER RELAY LOCATIONS»(ref-5348-S03404174662000081400000) table. With no power supplied to any terminal, continuity should exist between relay terminals No. 1 and 2. (Scheme 26)and «WIRING DIAGRAMS»(ref-5348-S16272827632000081400000).
  2. Connect a jumper wire from positive battery terminal to relay terminal No. 2 and another jumper wire from negative battery terminal to relay terminal No. 1. Continuity should exist between relay terminals No. 3 and 4. Replace relay as necessary.

Eclipse (With A/T)

  1. Remove starter relay. See «STARTER RELAY LOCATIONS»(ref-5348-S03404174662000081400000) table. With no power supplied to any terminal, continuity should exist between relay terminals No. 1 and 3. (Scheme 27)and «WIRING DIAGRAMS»(ref-5348-S16272827632000081400000).
  2. Connect a jumper wire from positive battery terminal to relay terminal No. 3 and another jumper wire from negative battery terminal to relay terminal No. 1. Continuity should exist between relay terminals No. 2 and 5. Replace relay as necessary.

Scheme 27

Scheme 27: Eclipse (With M/T) & Mirage (With M/T)
Scheme 27: Eclipse (With M/T) & Mirage (With M/T)
  1. Remove starter relay. See «STARTER RELAY LOCATIONS»(ref-5348-S03404174662000081400000) table. With no power supplied to any terminal, continuity should exist between relay terminals No. 1 and 3, and between relay terminals No. 2 and 4. (Scheme 27)and «WIRING DIAGRAMS»(ref-5348-S16272827632000081400000).
  2. Connect a jumper wire from positive battery terminal to relay terminal No. 3 and another jumper wire from negative battery terminal to relay terminal No. 1. Continuity should not exist between relay terminals No. 2 and 4. Replace relay as necessary. NOTE: Terminals No. 1 and 3 in (Scheme 27) may be reversed. See «WIRING DIAGRAMS»(ref-5348-S16272827632000081400000).

Galant (With M/T)

  1. Remove starter relay. See «STARTER RELAY LOCATIONS»(ref-5348-S03404174662000081400000) table. With no power supplied to any terminal, continuity should exist between relay terminals No. 1 and 3. (Scheme 27)and «WIRING DIAGRAMS»(ref-5348-S16272827632000081400000).
  2. Connect a jumper wire from positive battery terminal to relay terminal No. 3 and another jumper wire from negative battery terminal to relay terminal No. 1. Continuity should exist between relay terminals No. 2 and 4. Replace relay as necessary.

Montero Sport (With A/T)

  1. Remove starter relay. See «STARTER RELAY LOCATIONS»(ref-5348-S03404174662000081400000) table. With no power supplied to any terminal, continuity should exist between relay terminals No. 1 and 3. (Scheme 27)and «WIRING DIAGRAMS»(ref-5348-S16272827632000081400000).
  2. Connect a jumper wire from positive battery terminal to relay terminal No. 3 and another jumper wire from negative battery terminal to relay terminal No. 1. Continuity should exist between relay terminals No. 2 and 5. Replace relay as necessary.

Montero Sport (With M/T)

  1. Remove starter relay. See «STARTER RELAY LOCATIONS»(ref-5348-S03404174662000081400000) table. With no power supplied to any terminal, continuity should exist between relay terminals No. 1 and 3. (Scheme 27)and «WIRING DIAGRAMS»(ref-5348-S16272827632000081400000).
  2. Connect a jumper wire from positive battery terminal to relay terminal No. 1 and another jumper wire from negative battery terminal to relay terminal No. 3. Continuity should exist between relay terminals No. 2 and 4. Replace relay as necessary.

3000GT

  1. Remove starter relay. See «STARTER RELAY LOCATIONS»(ref-5348-S03404174662000081400000) table. With no power supplied to any terminal, continuity should exist between relay terminals No. 1 and 3, and between relay terminals No. 2 and 4. (Scheme 27)and «WIRING DIAGRAMS»(ref-5348-S16272827632000081400000).
  2. Connect a jumper wire from positive battery terminal to relay terminal No. 1 and another jumper wire from negative battery terminal to relay terminal No. 3. Continuity should not exist between relay terminals No. 2 and 4. Replace relay as necessary.
ApplicationLocation
DiamanteAt Left Front Fender, Under Fuse/Relay Block
EclipseBehind Center Of Dash, On Far Right
Galant M/T & Mirage M/TIn Left Underhood Fuse/Relay Block
Montero SportIn Left Underhood Fuse/Relay Block
3000GTIn Right Underhood Fuse/Relay Block

STARTER RELAY LOCATIONS

PINION GAP MEASUREMENT

  1. Disconnect field coil wire from terminal "M" at starter solenoid. see scheme 7, see scheme 8, see scheme 9 or see scheme 10. Connect jumper wire between positive battery terminal of 12-volt battery and terminal "S" of starter solenoid.
  2. Connect a second jumper wire from negative battery terminal and touch terminal "M" of starter solenoid. Using a feeler gauge, measure clearance between pinion and stopper. (Scheme 28)
  3. Clearance should be within specification. See «STARTER SPECIFICATIONS»(ref-5348-S00218797422000081400000) table. Adjust clearance by adding or removing gaskets between solenoid and front housing.

Scheme 28

Scheme 28
Scheme 28

STARTER MOTOR

Note. It may be necessary to disconnect transmission oil cooler lines, air cleaner, engine undercover and/or front actuator assembly for starter removal.
